Summary of Contents for Real Spirit Aqua-Ionizer Pro Deluxe 7.0
- Page 1 AID7000/B Read Carefully Retain Manual for Before Initial Use. Future Reference.
-
Page 2: Table Of Contents
Table of Contents: • Included with Your Water Ionizer/Parts & Supplies ... . . 01 • Water Ionizer Assembly Overview ......02 •... -
Page 3: Included With Your Water Ionizer/Parts & Supplies
Included with Your Water Ionizer/Parts & Supplies: 3-Bolt Faucet Inner Tread Dual-Tread Connector Faucet Joint Faucet Connector Faucet Diverter Carbon Mineral/Carbon Valve Water Filter (1) Water Filter (1) Standard RO or Low pH Water (City) Water Pre-Installed Flexible Metal Spout Inlet and Outlet Hose Silicone Caps NEED HELP CALL 1-888-601-5886... -
Page 4: Water Ionizer Assembly Overview
Important Note: As a result of minor technical or aesthetic changes some ionizer parts may appear slightly different in appearence or color than depicted on product packaging or in this manual. Should this occur, the part(s) remain usable and should be installed and used in accordance with this product manual. -
Page 5: Safety Instructions & Symbols
Safety Instructions & Symbols: Avoid the specified action as it may destroy the unit, WARNING cause serious injury or even death. Avoid the specified action as it may damage the unit CAUTION or cause serios injury. DO NOT Do NOT perform the specified action. The specified action is very important and must be IMPORTANT completed for the unit to function properly. - Page 6 CAUTION If you have a R/O (Reverse Osmosis)System WELL WATER or low pH PLEASE USE the included Mineral filter. This mineral filter will add back the benifical minerals the ionizer needs to function properly. 1-888-601-5886 DO NOT IMPORTANT Do Not install your water ionizer in any of the following locations... •...
- Page 7 CAUTION If You have a R/O System (REVERSE OSMOSIS) WELL WATER low pH PLEASE USE the included Mineral filter. This mineral filter will add back the beneficiial minerals the ionizer needs to function properly. Any questions call 1-888-601-5886 NEED HELP CALL 1-888-601-5886...
- Page 8 WARNING IMPORTANT • Do NOT share the electrical outlet used for your ionizer with other electrical appliances. • Use only alternating current 110V power supply. Exceeding the rated power range may damage the unit and/or cause a fire. • Do NOT attempt to plug in, unplug, or otherwise operate your water ionizer if your hands are wet.
- Page 9 WARNING IMPORTANT Health Issues: If any of the following apply to you, please consult your physician before drinking or continuing to drink ionized alkaline water: • You have kidney disease, renal failure, and/or have difficulty discharging/eliminating potassium in which case you should generally NOT ingest alkaline water.
- Page 10 IMPORTANT Storing Ionized Water: Under normal temperature conditions, alkaline water stored properly in a sealed, insulated container will retain its ionized properties for at least 24 hours and up to 48 hours when refrigerated. • Do NOT store ionized water in metal containers. It should only be stored in plastic, glass or ceramic containers.
- Page 11 CAUTION Fish & Aquariums: Unless you are an experienced aquarium owner or qualified aquatic life professional, Do NOT introduce ionized water to your aquarium without knowing the precise alkaline or acidic water settings applicable to your particular fish species. Fish may become ill or die if their water's pH balance is changed or changed too quickly.
- Page 12 CAUTION DO NOT Continuous Operation: Do NOT exceed the following maximum continuous operational time frames for your water ionizer: • Do NOT operate the unit in "Initial Drinking," "Daily Drinking" or "Cosmetic" mode for more than 60 minutes continuously. • Do NOT operate the unit in "Cleaning," "Cooking" or mode for more than 30 minutes continuously.
-
Page 13: Technical Specifications
IMPORTANT Waste Disposal: In compliance with the "Waste Electrical and Electronic Equipment Directive"... • This marking indicates that this product should not be disposed with other household waste through- out the EU (European Union). • To prevent possible harm to the environment or human health from uncontrolled waste disposal and to conserve material resources, this product should be recycled responsibly. - Page 14 Technical Specifications: (continued) Max. Operating Temp ............60°C / 140°F Source Water Temp...........5° - 60°C / 41° - 140° F Operational Pressure ......14.5 - 43.5 psa / 0.1 - 0.3 Mpa Water Flow Rate .........4 liters per min (adjustable) pH Levels ........7 total: 4 alkaline, 1 neutral, 2 acidic Adjustable pH ....Yes: 3.5 to 11.0, depending on intake source ORP Range ............-860mV to +1000mV Measurements........8.25 (W) x 13 (H) x 4.3(D) inches...
-
Page 15: Installation Schematic & Instructions
Installation Schematic: (Optional Wall Mont) Water Ionizer Flexible Metal Spout Power Cord Acidic Water Outlet Hose Inlet Water Hose www.AquaIonizerPro.com/pages/install Video Install Guide ONLINE Installation Order: There are 7 simple steps to installing your water ionizer each of which is described in detail beginning on the next page. -
Page 16: Identify Required Connector/Attach Faucet Diverter Valve
www.AquaIonizerPro.com/pages/install Installation Step 1 - Identify Required Connectors/ Attach Faucet Diverter Valve: Home faucets typically fall into 1 of 3 categories, a.) threaded on the outside, b.) threaded on the inside, and c.) unthreaded, i.e., those without screw on/in connectors. a. - Page 17 www.AquaIonizerPro.com/pages/install b) Threaded Inside Faucet: Being sure to first insert the washer, screw the dual-thread faucet connector into the faucet. Then screw the faucet diverter Valve onto the Dual read Connector. Dual-Thread 24mm Faucet Connector Faucet Diverter Valve c) Unthreaded Faucet: If your faucet has neither inside nor outside threads, loosen the bolts on the 3-bolt faucet connector, slip it over the end of the faucet pressing upward firmly then tighten bolts securely locking it on to faucet.
-
Page 18: Install The Inner Carbon Filter
Installation Step 2 - Insert the Inner Carbon Filter: Though your water ionizer's Inner Carbon Filter is shipped with your water ionizer, it is NOT preinstalled in the unit. Simply remove the filter from the box, remove any packing materials, and install it in the following manner: A. - Page 19 D. Insert the newly flushed Inner Carbon Filter into the open filter chamber as shown in Fig. D. E. Reseat the Inner Filter Cover and twist it clockwise to close the filter in filter chamber. Inner Filter Cover Inner Carbon Water Filter Fig.
-
Page 20: Attach Metal Spout
Installation Step 4 Attach Metal Spout: Innner Cover REMOVE THE PLASTIC Screw the flexible Metal Spout clockwise into the outlet connector on top of the water ionizer. If you a leak unscrew until leak stops. If it persists call 1-888-601-5886 Installation Step 5 Connect the Inlet Water Hose to the Faucet Diverter Valve:... - Page 21 Installation Step 5a (special) Connect the inlet and acid water hoses to the faucet diverter Valve: There are two (2) post hose connectors for the hoses on the faucet diverter Valve. The 'top' barbed post connector is for outgoing water which when diverted with the control handle will flow into the water “in”...
-
Page 22: Check For Leaks
Installation Step 6 - Check for Leaks: After completing all prior installation steps and making sure all hoses are securely attached, you should perform each of the following filter related tasks when a) initially installing the unit, b) each time you replace the unit’s Inner Carbon Filter and c) any time the unit has not been used for 2 or more days... -
Page 23: R/O Systems And Well Water
Reverse Osmosis (R/O) or Well Water If your water source is from a tested, safe to drink well/ground water or has passed through a “Reverse Osmosis” system you may not have enough beneficial minerals in your water for the Water Ionizer to function at it’s full potential. -
Page 24: Plug In The Water Ionizer
Installation Step 8 - Plug In Your Water Ionizer: A.) Confirm that the power outlet is a 110 V/60Hz and grounded BEFORE plugging in your water ionizer. B. When you first plug the unit in, a water indicator, e.g., "Daily Drinking," will light. -
Page 25: Free Ph Kit
CAUTION • Do NOT Use Litmus Paper to Evaluate pH - Most commercially available litmus paper is much less accurate tool for measuring pH than the pH Reagent (testing liquid). Would You Like a Free pH Test Kit? Just call 1-888-601-5886 or visit www.AquaIonizerPro.com ORP TESTERS Caution using store bought ORP Testers. -
Page 26: Understanding The Lcd Display
Understanding Your LCD Display: In addition to the alerts and indicators described below, your LCD displays in 1 of 7 different colors, to indicate which of the unit’s 7 presets is currently selected. A. Total Inflow Monitor - Displays the total commutative water flow through the water ionizer. -
Page 27: Understanding Your Ph Presets
Understanding Your pH Preset Options: Your water ionizer has 7 pH presets: 4 Alkaline, 1 Purified and 2 Acidic. Each is shown below along with its control panel icon, factory set pH range and the general application(s) for which each setting should be used. Alkaline Water Presets: General Application: This setting is ideal for cooking since alkaline water dramatically improves the flavor... -
Page 28: Selecting Your Ph Preset & Dispensing Water
Selecting Your pH Preset & Dispensing Water: A. Once properly installed and plugged in with water flowing to the unit, your water ionizer will enter standby mode displaying the most recently selected preset, e.g., Daily Drinking. B. To change to a different preset, a) press the Alkalinity button to cycle through each of the 4 alkaline water settings. -
Page 29: Enhanced Cleaning Function
C. When automatic cleaning is triggered, it will take only about 20 seconds during which time the Washing Flasher will appear on the unit's LCD display. When auto-cleaning is completed, the Washing Flasher will disappear and the LCD will display only the Total Inflow data as the unit returns to standby mode. -
Page 30: Manual Cleaning & Descaling
Manual Cleaning & Descaling: Descaling removes these mineral deposits ("scales") which inhibit the electrolysis process, from the surface of the electroplates. If your local source water is particularly high in mineral deposits and/or if routine pH testing reveals an increasingly wide variance from the preset values over time, you should descale your water ionizer. - Page 31 D. Raise the Flexible Metal Spout as shown in Fig. 2 below, to ensure the spout opening is HIGHER than the top the water ionizer itself. Flexible Metal Spout Raised Above Top of the Water Ionizer E. Fill a pitcher, jar or other waterproof container with approximately 2 cups (17oz / 500ml) of HOT (NOT boiling) water and pour the entire...
-
Page 32: Problems & Solutions
Problems & Solutions: Problem: None of the LCD or Control Panel functions light up. Solution: Check that the power cord is plugged in and/or that the electrical socket is functioning properly. Make sure water is flowing though the Call for more help 1-888-601-5886 machine. - Page 33 Problem: Acidic water continues to drip from the Acid Water Outlet Hose for 10 to 20 seconds after dispensing alkaline water. Solution: This is a normal phenomenon. The excess acidic water is "divided" from the alkaline water as part of the ionization process and then dispelled through the outlet tube.
-
Page 34: Warranty Information
Limited Lifetime Warranty: Aqua Ionizer Pro® and its parent company, Real Spirit USA, o er a Limited Lifetime Warranty on all water ionizers to the original consumer purchaser under the following terms and conditions: Aqua Ionizer Pro®, Deluxe 5.0 & 7.0 models; a) For the rst 5 years from the date of original... - Page 35 Aqua Ionizer Pro® water ionizers and lters are covered by our Limited Lifetime Warranty* Aqua Ionizer Pro® or its parent company Real Spirit USA, Inc accepts no liability, nor o ers any warranty or remedy for damages of any kind in regard to water damage caused or reported to be caused by leaks from hoses, ttings or directly from any of our products.
- Page 36 Any Questions? 1-888-601-5886 We would love to hear from you! Aqua Ionizer Pro® is a division of Real Spirit USA, Inc. 320 South Rock Blvd Suite 210 • Reno NV 89502 • Ph 888.601.5886 www.AquaIonizerPro.com • help@realspiritusa.com...
