protech prox SP-C085 Quick Reference Manual

SP-C085/
SP-C105
Quick
Reference
Guide

Jumper Setting

JP2
PWM / Analog
Selection
1
Pin Description
1-2 PWM
2-3 Analog
Ver. Q1
All Rights Reserved. Copyright 2019
JP2
3
32
1
31
1
8
J7
CN5
CN2

Specifications

LCD
Customer (2nd) Display
Display Resolution
Brightness
Life time of Backlight lamp
Touch Panel
Dimensions (Panel)
Weight
Viewing Angle
Wall Mount
Power Supply
I/O Ports
VGA
DVI-I
HDMI
USB
Environment
EMC & Safety
Operating Temp.
Storage Temp.
Humidity
10
J6
2
1
J5
JP1
6 4
3
1
CN1
CN4
SP-C085 / SP-C105
SP-C085: 8.4" SVGA LCD
SP-C105: 10.4" SVGA LCD
SP-C085: LVDS 800x600 dots SVGA
SP-C105: LVDS 1024x768 dots SVGA
2
Typ. 600 cd/m (SP-C085) / Typ. 450 cd/m
Min. 30,000 hours (SP-C085) /
Min. 50,000 hours (SP-C105)
P-CAP or Resistive Touch (USB Interface) or N/A
SP-C085: 225 x 177 x 49mm (W x H x D)
SP-C105:
260 x 217 x 48mm (W x H x D)
SP-C085: 1.4kg
SP-C105: 1.8kg
° ° °
Horizontal: -80 ~ 80 , Vertical: -80 ~ 70
VESA Mount 100x100 mm
DC 12V/3.3A/ 40W Power Adapter
(AC Input: 90 ~264 Vac, 47/63Hz)
1 x VGA port
1 x DVI-I port (support DVI-D signals only)
1 x HDMI port
1 x USB port (touch connection)
CE
-20°C ~ 60°C (-4°F ~ 140°F)
-30°C ~ 70°C (-22°F ~ 158°F)
5% ~ 95%
SP-C085 / SP-C105
1
J9
J11
J12
Panel 3.3V / 5V / 12V
Selection
6
1
Pin
1-6
2-5
3-4
2
(SP-C105)
°
JP1
4
3
Description
3.3V
5V
12V
