protech KF-7131 User Manual

Kiosk system powered by intel® bay trail platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
KF-7131 M1
KF-7131
Kiosk System Powered By
Intel
Bay Trail Platform
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KF-7131 and is the answer not in the manual?

Questions and answers

Related Manuals for protech KF-7131

Summary of Contents for protech KF-7131

  • Page 1 USER MANUAL KF-7131 Kiosk System Powered By Intel Bay Trail Platform ® KF-7131 M1...
  • Page 2 KF-7131 17” Projected Capacitive Touch Kiosk COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in January, 2017. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    1.2.5 Side View ................1-5 Quick Setup ................1-6 1.3.1 Connecting KF-7131 to the Network ........1-6 1.3.2 Turn On KF-7131 Kiosk ............1-7 System Specifications (Intel Bay Trail Platform) ....... 1-8 PB-6822 Mainboard Specification (Bay Trail Platform) ... 1-13 KR-7130 Daughter Board Specification ........
  • Page 5 VGA Port ................... 2-5 COM Port .................. 2-5 Cash Drawer Port ..............2-5 USB Ports .................. 2-6 RAID Port .................. 2-6 2.10 RAID Power Port ............... 2-6 2.11 Printer Power Port ..............2-6 2.12 Main Board Component Location & Jumper Settings ....2-7 2.13 Setting Jumpers ................
  • Page 6 2.14.18 Clear CMOS Data Selection ..........2-20 2.14.19 MSR/Card Reader Connector ......... 2-20 2.14.20 UPS Connector..............2-21 2.14.21 Fan Connector ..............2-21 2.14.22 RAID LED Connector (Optional) ........2-21 2.14.23 SATA & SATA Power Connector ........2-22 2.14.24 SATA RAID Function Selection (Optional) ....... 2-23 2.14.25 Power Button Connector ..........
  • Page 7 BIOS SETUP ..................4-1 Introduction ................4-2 Accessing Setup Utility .............. 4-3 Main Menu ................. 4-7 Advanced Menu ................ 4-8 4.4.1 ACPI Settings ............... 4-9 4.4.2 Hardware Monitor ............... 4-10 4.4.3 F81866 Watchdog .............. 4-11 4.4.4 CPU Configuration ............. 4-12 4.4.4.1 Socket 0 CPU Information ...........
  • Page 8 Security Menu ................. 4-36 Boot Menu ................4-38 4.7.1 Configuring Hard Drive BBS Priorities ....... 4-39 Save & Exit Menu ..............4-40 Appendix A System Diagrams ............ A-1 Front Base Bracket Assembly ..............A-2 Barcode Scanner Bracket Assembly ............A-3 Front Decoration Bracket Assembly ............A-4 Ticket Holder and Card Bracket Assembly ..........A-5 Front Panel Cover Parts Assembly-1 ............A-6 Front Panel Cover Parts Assembly-2 ............A-7...

  • Page 9: Introduction

    Introduction This chapter provides the information for the KF-7131 Kiosk. It describes how to set up the system quickly and outlines the system specifications. The following topics are included: • About This Manual • Kiosk System Diagram • Quick Setup •...

  • Page 10: About This Manual

    Chapter 1 Introduction About This Manual Thank you for purchasing our KF-7131 Kiosk System. The KF-7131 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The KF-7131 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 11: Kiosk System Diagrams

    Chapter 1 Introduction Kiosk System Diagrams Unit: mm 1.2.1 Front View KF-7131 SERIES USER MANUAL Page: 1-2...

  • Page 12: Rear View

    Chapter 1 Introduction 1.2.2 Rear View KF-7131 SERIES USER MANUAL Page: 1-3...

  • Page 13: Top View

    Chapter 1 Introduction 1.2.3 Top View 1.2.4 Quarter View KF-7131 SERIES USER MANUAL Page: 1-4...

  • Page 14: Side View

    Chapter 1 Introduction 1.2.5 Side View Unit: mm KF-7131 SERIES USER MANUAL Page: 1-5...

  • Page 15: Quick Setup

    See the figure shown below LAN Port AC Power Jack Figure 1-1. Connect KF-7131 to the Network and Power KF-7131 SERIES USER MANUAL Page: 1-6...

  • Page 16: Turn On Kf-7131 Kiosk

    Chapter 1 Introduction 1.3.2 Turn On KF-7131 Kiosk 1. Unlock the top front door and open it. 2. Press the Power Button located on the back of the top front cover. See the picture below: Power Button KF-7131 SERIES USER MANUAL...

  • Page 17: System Specifications (Intel Bay Trail Platform)

    0 ° C ~ 60 ° C (32 ° F~140 ° F) Storage Temperature Humidity Operating 20~85RH (no condensation) Humidity Storage Humidity 20~85RH (no condensation) External I/O Port LAN Port 1 Model 1 x 10/100/1000 Mbps (PB-6822 LAN) KF-7131 SERIES USER MANUAL Page: 1-8...
  • Page 18 15 mils PDF 417 60 ~ 380 mm 10 mils QR code 45 ~ 170 mm 15 mils QR code 48 ~ 155 mm 10 mils Data Matrix 50 ~ 220 mm 15 mils Data Matrix 40 ~ 305 mm KF-7131 SERIES USER MANUAL Page: 1-9...
  • Page 19 Monochrome Black printing: Up to140 cards/hour Card Format CR-80 ISO7810(53.98mm x 85.60mm) Thickness:0.25mm ~ 1.0mm (10mil ~ 40mil) Card Input 100 cards (thickness: 0.76mm / Capacity 30mil) Card Output 50 cards (thickness: 0.76mm / Capacity 30mil) KF-7131 SERIES USER MANUAL Page: 1-10...
  • Page 20 2&5), Interleaved 2 of 5, EAN128, EAN8/13(add on 2&5), Codabar, PostNET, DUN14, MaxiCode, HIBC, Plessey, RPS128, PDF417, Datamatrix, QR code Resident Fonts 11 Resident Windows bit mapped font, and scalable font in 4 orientations. KF-7131 SERIES USER MANUAL Page: 1-11...
  • Page 21 PCX, BMP files Handling LED Display 2 x LED indicators and 1 x function key Interface USB interface Model APC Back-UPS 550 Specification 110V/ 500VA / 330W Dimension 8.8 x 18 x 30.2 mm KF-7131 SERIES USER MANUAL Page: 1-12...

  • Page 22: Pb-6822 Mainboard Specification (Bay Trail Platform)

    Total 7 x USB 2.0 ports (M/B) wafer USB 1 1x 5-pin wafer (M/B) wafer USB 2 1x 5-pin wafer (M/B) wafer USB 6 1x 5-pin wafer (M/B) wafer USB 7 1x 5-pin wafer KF-7131 SERIES USER MANUAL Page: 1-13...
  • Page 23 DC Power Input DC-IN 1x 4-pin DC-In Jack (DC24V) CPU FAN 1x 4-pin wafer Interface SATA SATA1 2x SATA III Port Interface (with 4-in power connector) SATA2 LED Indicator 1x connector 1x 2 pin-header (Power) KF-7131 SERIES USER MANUAL Page: 1-14...

  • Page 24: Kr-7130 Daughter Board Specification

    1x 5-pin wafer USB 2-3 1x 5-pin wafer USB 2-4 1x 5-pin wafer COM Port COM1 2x 5-pin wafer Speaker Dual Channel Speaker Total 2 x wafer L-SPK 1x 2-pin wafer R-SPK 1x 2-pin wafer KF-7131 SERIES USER MANUAL Page: 1-15...

  • Page 25: Os Specification

    OS Specification Description ® Supports 32 bits. Windows 7 Pro FES API Specification • Watch Dog Timer API • Digital I/O API • Hardware Monitor API • USB Power API • RS-232 Power API KF-7131 SERIES USER MANUAL Page: 1-16...

  • Page 26: Safety Precautions

    Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use KF-7131 when it has been left outdoors in a cold winter day. •...

  • Page 27: System Configuration

    The following topics are included: • LAN Port • Rear I/O Ports Diagram • Main Board Component Locations • Setting Jumpers • Setting Main Board Connectors and Jumpers • Setting Daughter Board Connectors and Jumpers KF-7131 SERIES USER MANUAL Page: 2-1...
  • Page 28 Chapter 2 System Configuration LAN Port LAN Port KF-7131 SERIES USER MANUAL Page: 2-2...
  • Page 29 Giga LAN connection is enabled. No LAN switch/hub is connected Power Button Open the top front door and press the Power button located on the back of the cover. Please see Turn On KF-7131 Kiosk for details. ACTION ASSIGNMENT Power Press...

  • Page 30: Dc-In Port

    Rear I/O Ports Diagram Rear I/O Ports Diagram DC IN LAN1 Audio COM2 Power Button COM1 COM3 Printer (Optional) DC-IN Port DC-IN: DC Power-In Port (rear I/O) PIN ASSIGNMENT PIN ASSIGNMENT +24V +24V DC IN KF-7131 SERIES USER MANUAL Page: 2-4...

  • Page 31: Vga Port

    DRW1: Signal from M/B GPIO (rear I/O) PIN ASSIGNMENT PIN ASSIGNMENT +12V/+24V (Max. current: 1A) Drawer Open Drawer Sense DRW1 DRW1 Open Write "700"h to I/O port "588"h Close Write "00"h to I/O port "588"h KF-7131 SERIES USER MANUAL Page: 2-5...

  • Page 32: Usb Ports

    2.10 RAID Power Port RAID PWR: Power supply for the stand-RAID storage device PIN ASSIGNMENT +24V GNDV RAID PWR 2.11 Printer Power Port PRINT PWR: DC24V power supply for the stand-printer PIN ASSIGNMENT +24V PRINT PWR GNDV KF-7131 SERIES USER MANUAL Page: 2-6...

  • Page 33: Main Board Component Location & Jumper Settings

    Make sure both the system and the external devices are turned OFF as sudden surge of power could ruin sensitive components. Make sure KF-7131 is properly grounded. CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while configuring the connectors and jumpers.

  • Page 34: Setting Jumpers

    2 to create one setting and shorting. You can also select to connect pins 2 and 3 to create another setting. The format of the jumper picture will be illustrated throughout this manual. The figure below shows different types of jumpers and jumper settings. KF-7131 SERIES USER MANUAL Page: 2-8...
  • Page 35 Chapter 2 System Configuration Jumper diagrams Jumper settings KF-7131 SERIES USER MANUAL Page: 2-9...

  • Page 36: Setting Main Board Connectors And Jumpers

    There is no pin connection for JP_COM2 or JP_COM3 by default. Refer to the Voltage/RI Adjustment Configuration section in chapter 3 for detailed BIOS setting (BIOS default: Disabled) The voltage level of COM4 is not adjustable on BIOS. KF-7131 SERIES USER MANUAL Page: 2-10...

  • Page 37: Com Connector

    JP20, JP21, JP22: COM3 / i-Button Function Connectors SELECTION JUMPER SETTING JUMPER ILLUSTRATION COM 3 (Default) JP20/JP21/JP22/ i-Button* JP20/JP21/JP22/ Note: COM3 & COM3-1 will not function when jumpers JP20, JP21 & JP22 are set as “i-Button.” KF-7131 SERIES USER MANUAL Page: 2-11...

  • Page 38: Cash Drawer Control Selection

    SELECTION JUMPER SETTING JUMPER ILLUSTRATION DRW1-2 Open JP37 (Default) JP37 2.14.6 Cash Drawer Power Selection JP29: Cash Drawer Power Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION +24V JP29 +12V JP29 Note: Default is no pin connection. KF-7131 SERIES USER MANUAL Page: 2-12...

  • Page 39: Usb Connector

    USB1, USB2 , USB6 , USB7: USB 2.0 Connectors ASSIGNMENT 5V (Maximum current: 0.5A) USB1/ USB2/ USB7 Note: USB1 would be used when jumpers JP14 & JP15 are set as 1-2 (short) connected. USB6 KF-7131 SERIES USER MANUAL Page: 2-13...

  • Page 40: Led Connector

    LED1_1: Power LED Indication Connector ASSIGNMENT LED1_1 PWR_LED LED1_2: Power & HDD LED Indication Connector ASSIGNMENT ASSIGNMENT PWR_LED HDD_LEDJ PWR_LEDJ HDD_LED LED1_2 LED1_4: Power & HDD LED Indication Connector ASSIGNMENT ASSIGNMENT PWR_LED HDD_LEDJ PWR_LEDJ HDD_LEDJ LED1_4 KF-7131 SERIES USER MANUAL Page: 2-14...

  • Page 41: Power Connector

    DC5V_PWR1: DC 5Voltage Provider Connector ASSIGNMENT DC5V_PWR1 2.14.10 Power for Thermal Printer Connector PRT_PWR1: Power for Thermal Printer Connector ASSIGNMENT VCC24SB VCC24SB PRT_PWR1 2.14.11 External Speaker Connector SPK1, SPK2: External Speaker Connector ASSIGNMENT SPK_GND SPK1/ SPK_OUT SPK2/ KF-7131 SERIES USER MANUAL Page: 2-15...

  • Page 42: Inverter Connector

    JINV3/ LVDS_BKLTEN 2.14.13 LED Backlight Power Control Selection JP12: LED Backlight Power Control Connector (for LED backlight panel without the built-in power driver) SELECTION JUMPER SETTING JUMPER ILLUSTRATION JP12 JP12 Note: Default is LED. KF-7131 SERIES USER MANUAL Page: 2-16...

  • Page 43: Panel Resolution Selection

    JP8: 1-3, 4-6 1024 x 768 JP9: 3-5, 4-6 (24 bit) 10.4” JP8: 2-4, 3-5 1024 x 768 JP9: 3-5, 4-6 (18 bit) 10.4” JP8: 3-5, 4-6 800 x 600 JP9: 3-5, 4-6 (18bit) KF-7131 SERIES USER MANUAL Page: 2-17...

  • Page 44: Lvds Connector

    LR (Low Right) UR (Up Right) LL (Low Left) UL (Up Left) Probe TOUCH1 TOUCH2: Touch Panel Connector ASSIGNMENT ASSIGNMENT LR (Low Right) UR (Up Right) LL (Low Left) UL (Up Left) Probe TOUCH2 KF-7131 SERIES USER MANUAL Page: 2-18...

  • Page 45: Touch Panel Signal Interface Selection

    1. Manufacturing default is USB1 Connector. 2. The COM2 & COM2-1 connector will not function when JP38 & JP39 are set as 1-2 connected. 3. USB1 connector when JP14 & JP15 are set as 1-2 connected. KF-7131 SERIES USER MANUAL Page: 2-19...

  • Page 46: Clear Cmos Data Selection

    CMOS” as shown above. After five to six seconds, set the jumper back to the Normal state and power on the computer. 2.14.19 MSR/Card Reader Connector PS/2_1, PS/2_2: MSR/Card Reader Connectors ASSIGNMENT KB_CLK (Output) PS/2_1 KB_CLK_C (Input) KB_DATA_C (Input) KB_DATA (Output) PS/2_2 KF-7131 SERIES USER MANUAL Page: 2-20...

  • Page 47: Ups Connector

    J5: UPS Data Connector ASSIGNMENT LPC_PSONJ LPC_PWRBTN PCIE_DBG_CLK PCIE_DBG_DATA 2.14.21 Fan Connector CPU_FAN1: CPU Fan Connector ASSIGNMENT VCC5 CPU_FANIN CPU_FAN1 CPU_FANOUT 2.14.22 RAID LED Connector (Optional) LED2: SATA RAID LED Connector ASSIGNMENT VCC3_3 LED1_E VCC3_3 LED2_E LED2 KF-7131 SERIES USER MANUAL Page: 2-21...

  • Page 48: Sata & Sata Power Connector

    ASSIGNMENT ASSIGNMENT SATA1/ SATA2/ Note: SATA1 only supports the optional RAID function on board. JPWR_4P1, JPWR_4P2: Serial ATA Power Connectors ASSIGNMENT JPWR_4P1/ VCC12 JPWR_4P2/ Note: JPWR_4P1 only supports the optional RAID function on board. KF-7131 SERIES USER MANUAL Page: 2-22...

  • Page 49: Sata Raid Function Selection (Optional)

    JP42, JP43, JP44: SATA RAID Function Pin-headers SELECTIO JUMPER JUMPER ILLUSTRATION SETTING JP42: 1-2 RAID1 JP43: Open (Default) JP44: 1-2 JP43 JP42 JP44 2.14.25 Power Button Connector SW1_1, SW1_2: Power Button Connector ASSIGNMENT LPC_PWRBTNJ SW1_1/ SW1_2/ KF-7131 SERIES USER MANUAL Page: 2-23...

  • Page 50: Printer Connector

    Chapter 2 System Configuration 2.14.26 Printer Connector LPT1: Printer Connector ASSIGNMENT ASSIGNMENT STBJ ALFJ LPT1 PDR0 ERRJ PDR1 PAR_INITJ PDR2 SLCTINJ PDR3 PDR4 PDR5 PDR6 PDR7 ACKJ BUSY SLCTJ KF-7131 SERIES USER MANUAL Page: 2-24...

  • Page 51: Mini-Pcie / Msata Connector

    WAKE# +3.3V +1.5V SLOT1 Reserved SMB_CLK Reserved PETn2 +1.5V SMB_DATA CLKREQ# PETp2 Reserved Reserved REFCLK1- Reserved REFCLK1+ +3.3V Reserved +3.3V Reserved Reserved Reserved Reserved Reserved Reserved Reserved PERST# +1.5V PERn2 +3.3SB PERp2 Reserved +3.3V KF-7131 SERIES USER MANUAL Page: 2-25...

  • Page 52: Daughter Board Component Locations

    Chapter 2 System Configuration 2.15 Daughter Board Component Locations Figure 2-2. Daughter Board Component Location 2.16 Setting Daughter Board Connectors and Jumpers 2.16.1 Power Supply Connector JVIN1: Power Supply Wafer ASSIGNMENT +24V +24V JVIN1 KF-7131 SERIES USER MANUAL Page: 2-26...

  • Page 53: Com Connector

    The pin assignments for SPK1 are as follows: ASSIGNMENT SPK1/ OUTPL OUTNL SPK2/ The pin assignments for SPK2 are as follows: ASSIGNMENT OUTNR OURPR 2.16.4 Micro USB Connector USB_IN1, USB_IN2 : Micro USB IN Connector ASSIGNMENT USB_IN1/ USB_IN2/ KF-7131 SERIES USER MANUAL Page: 2-27...

  • Page 54: Usb Connector

    USB1, USB2 , USB3 , USB4 , USB5 , USB6 , USB7 , USB8: USB 2.0 Wafers ASSIGNMENT USB1/ USB2/ USB3/ USB4/ USB5 USB6/ USB7/ USB8 2.16.6 Audio Connector AUDIO_IN1 : LINE_OUT Connector ASSIGNMENT AUDIO_GND L_IN AUDIO_IN1 R_IN KF-7131 SERIES USER MANUAL Page: 2-28...

  • Page 55: Software Utilities

    The following topics are included: • Installing Intel ® Chipset Software Installation Utility • Installing VGA Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility KF-7131 SERIES USER MANUAL Page: 3-1...

  • Page 56: Introduction

    Chapter 4 BIOS Setup Introduction Enclosed with the KF-7131 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that Purpose WIN7 DVD-ROM drive is D:) 32bit D:\Driver\Platform\ WIN7...

  • Page 57: Installing Intel Chipset Software Installation Utility

    7 series, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to KF-7131 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 58: Installing Vga Driver Utility

    Chapter 4 BIOS Setup Installing VGA Driver Utility The VGA interface embedded in KF-7131 can support a wide range of display types. You can have dual displays via LVDS interfaces and make the system work simultaneously. To install the VGA driver utility, follow the steps below: Connect the USB DVD-ROM device to KF-7131 and insert the driver disk.

  • Page 59: Installing Lan Driver Utility

    Enhanced with LAN function, KF-7131 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to KF-7131 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).

  • Page 60: Installing Sound Driver Utility

    POSReady 7 & Windows 7 series. To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to KF-7131 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).

  • Page 61: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Boot Menu • Security Menu • Save & Exit Menu • KF-7131 SERIES USER MANUAL Page: 4-1...

  • Page 62: Introduction

    Chapter 4 BIOS Setup Introduction The KF-7131 Kiosk System uses an AMI (American Megatrends Aptio BIOS that is stored in the Serial Peripheral Interface Incorporated) Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 63: Accessing Setup Utility

    All the menu settings are described in details in this chapter. Accessing Setup Utility After the system is powered on, BIOS will enter the Power-On Self-Test (POST) routines and the POST message will be displayed: KF-7131 SERIES USER MANUAL Page: 4-3...
  • Page 64 Chapter 4 BIOS Setup Figure 4-2. POST Screen with AMI Logo Press the <Del> key to access the Setup Utility program. KF-7131 SERIES USER MANUAL Page: 4-4...
  • Page 65 BIOS setup menu. BIOS Setup Description Menu Key <←> and <→> Select a different menu screen (move the cursor from the selected menu to the left or right). KF-7131 SERIES USER MANUAL Page: 4-5...
  • Page 66 The CMOS battery The battery may be losing power and users is bad or has been should replace the battery immediately. Also, recently replaced. this message is displayed once the new battery is replaced. KF-7131 SERIES USER MANUAL Page: 4-6...

  • Page 67: Main Menu

    TXE FW Version No changeable options Display the current TXE Version System Language English BIOS Setup language. System Date month, day, year Specify the current date. System Time hour, minute, second Specify the current time. KF-7131 SERIES USER MANUAL Page: 4-7...

  • Page 68: Advanced Menu

    OS Selection Voltage/RI Adjust Sub-Menu Voltage/RI Adjust settings. Configuration Configure Option ROM execution, boot CSM Configuration Sub-Menu options filters, etc. USB Configuration Sub-Menu USB Configuration Parameters. SIO Configuration Sub-Menu System Super I/O Chip Configuration. KF-7131 SERIES USER MANUAL Page: 4-8...

  • Page 69: Acpi Settings

    - S3 Only (Suspend to Suspend Disabled disables ACPI sleep RAM) feature. S3 allows the platform to enter the Suspend to RAM mode. Lock Legacy - Disabled Enable or disable the lock of Legacy Resources. - Enabled Resources. KF-7131 SERIES USER MANUAL Page: 4-9...

  • Page 70: Hardware Monitor

    Display the voltage level of the 5VSB options +VSB5 in supply. No changeable Display the voltage level of the VCC5 options + VCC5 in supply. No changeable Display the voltage level of the VCC12 options + VCC12 in supply. KF-7131 SERIES USER MANUAL Page: 4-10...

  • Page 71: F81866 Watchdog

    Enable WatchDog -Disable Select the time interval in seconds or Watchdog timer unit -60s minutes Count for Timer multiple options Set the desired value (seconds) for the (Seconds) ranging from 1 to 255 watchdog timer. KF-7131 SERIES USER MANUAL Page: 4-11...

  • Page 72: Cpu Configuration

    - Enabled boot processors with extended CPUID functions. Select Disabled for Win XP. When Enabled is selected, a VMM can Intel Virtualization - Disabled Technology - Enabled utilize additional hardware capabilities provided by Vanderpool Technology(VT). KF-7131 SERIES USER MANUAL Page: 4-12...

  • Page 73: Socket 0 Cpu Information

    Display L1 data cache size. L1 Code Cache No changeable options Display L1 code cache size. L2 Cache No changeable options Display L2 cache size. L3 Cache No changeable options Display L3 cache size. KF-7131 SERIES USER MANUAL Page: 4-13...

  • Page 74: Ide Configuration

    SATA Port 0(Note*1) - Disabled Enable or disable SATA port 0 device. - Enabled SATA Port 0 HotPlug - Disabled Enable or disable SATA port 0 device Hot - Enabled Plug KF-7131 SERIES USER MANUAL Page: 4-14...
  • Page 75 0. Shows [Empty] if no drive is installed. If the mother board supports RAID, it will show ASMT109x- Conf (0.1GB) SATA Port 1 [drive] Display the drive installed on this SATA port 1. Shows [Empty] if no drive is installed. KF-7131 SERIES USER MANUAL Page: 4-15...

  • Page 76: Os Selection

    Select CPU Configuration > OS Selection from the Advanced menu and press Enter to select the Windows operating system. Figure 4-12. OS Selection Screen BIOS Setting Options Description/Purpose OS Selection - Windows 8 Operating System Selection - Android - Windows 7 KF-7131 SERIES USER MANUAL Page: 4-16...

  • Page 77: Voltage/Ri Adjustment Configuration

    Select the voltage level of COM2 port. - RI -12V COM3 Select - Disabled Select the voltage level of COM3 port. - RI -12V COM4 Select - Disabled Select the voltage level of COM4 port. - RI -12V KF-7131 SERIES USER MANUAL Page: 4-17...

  • Page 78: Csm Configuration

    Always: do not allow disabling • GA20; this option is useful when any RT code is executed above 1MB. Option ROM - Force BIOS Set the display mode for Option ROM Messages - Keep Current messages. KF-7131 SERIES USER MANUAL Page: 4-18...
  • Page 79 - Legacy only - Legacy first - UEFI first Other PCI devices Select the launch method for other PCI - UEFI first devices, such as NIC, mass storage or - Legacy only video card. KF-7131 SERIES USER MANUAL Page: 4-19...

  • Page 80: Usb Configuration

    Device power-up - Auto The maximum time that the device will delay - Manual take before it properly reports itself to the Host Controller. Auto uses the default value: for a Root KF-7131 SERIES USER MANUAL Page: 4-20...
  • Page 81 0 to 40 one second increment. Mass Storage - Auto Display the device name and choose the Devices: - Floppy device emulation type. - Force FDD - Hard Disk - CD-ROM KF-7131 SERIES USER MANUAL Page: 4-21...

  • Page 82: Super Io Configuration

    Set the parameters for COM3. [*Active*] Serial Port 4 Sub-menu Set the parameters for COM4. [*Active*] Parallel Port Sub-menu Set the parameters for LPT port. [*Active*] PS2 Sub-menu Set the parameters for PS/2 controller. Controller (KB&MS) KF-7131 SERIES USER MANUAL Page: 4-22...

  • Page 83: Serial Port 1 Configuration

    Display the current settings of Serial Port 1. Possible: -Use Automatic Settings Select the IRQ and I/O -IO=3F8h; IRQ=4 DMA resource setting for Serial Port -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA KF-7131 SERIES USER MANUAL Page: 4-23...

  • Page 84: Serial Port 2 Configuration

    Display the current settings of Serial Port 2. Possible: -Use Automatic Settings Select the IRQ and I/O -IO=2F8h; IRQ=3 DMA resource setting for Serial -IO=3F8h; Port 2 IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,10,11,12 KF-7131 SERIES USER MANUAL Page: 4-24...

  • Page 85: Serial Port 3 Configuration

    Serial Port 3. Possible: -Use Automatic Settings Select the IRQ and I/O -IO=3E8h; IRQ=7 DMA resource setting for Serial -IO=3F8h; Port 3. IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F0h; KF-7131 SERIES USER MANUAL Page: 4-25...

  • Page 86: Serial Port 4 Configuration

    No changeable options Display the current settings of Serial Port 4. Possible: -Use Automatic Settings Select the IRQ and I/O -IO=2E8h; IRQ=7 DMA resource setting for Serial -IO=3F8h; Port 4 IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA KF-7131 SERIES USER MANUAL Page: 4-26...

  • Page 87: Parallel Port Configuration

    Enable or disable the printer port. -Enabled Logical device setting No changeable options Display the current settings of the printer port. Possible: - Use Automatic Select the IRQ and I/O resource setting Settings for the printer port. -IO=378h; IRQ=5 KF-7131 SERIES USER MANUAL Page: 4-27...
  • Page 88 EPP is the Enhanced Parallel Port mode, a -ECP Mode -ECP and EPP 1.9 Mode high-speed bi-directional mode for -ECP and EPP 1.7 Mode non-printer peripherals. ECP is the Enhanced Capability Port mode, a high-speed bi-directional mode for printers and scanners. KF-7131 SERIES USER MANUAL Page: 4-28...

  • Page 89: Ps2 Controller Configuration

    Logical device setting No changeable Display the current settings of the printer Current options port. Possible: - Use Automatic Select the IRQ and I/O resource setting Settings for the PS2 controller. -IO=60h; IO=60h; IRQ=1 KF-7131 SERIES USER MANUAL Page: 4-29...

  • Page 90: Chipset Menu

    Select the Chipset menu and press Enter to configure the North Bridge and South Bridge. Figure 4-23. Chipset Menu Screen BIOS Setting Options Description/Purpose North Bridge Sub-menu Set the parameter for North Bridge configuration. South Bridge Sub-menu Set the parameter for South Bridge configuration. KF-7131 SERIES USER MANUAL Page: 4-30...

  • Page 91: Configuring North Bridge

    Figure 4-24. North Bridge Configuration Screen BIOS Setting Options Description/Purpose Intel IGD Sub-menu Configure Graphic Settings. Configuration Memory Information No changeable options Display the DRAM information on platform. Total Memory No changeable options Display the DRAM size KF-7131 SERIES USER MANUAL Page: 4-31...

  • Page 92: Gop Configuration

    IGD Turbo Enable - Disabled Enable or disable IGD Turbo - Enabled GFX Boost - Disabled Enable or disable GFX Boost accelerated - Enabled graphics processing DVMT Pre-Allocated - 32M Select DVMT 5.0 Pre-Allocated (Fixed) KF-7131 SERIES USER MANUAL Page: 4-32...

  • Page 93: South Bridge

    - Power On supply is restored following a power - Last State failure. Power Off keeps the power off unless • the power button is pressed. Power On keeps the system power on • KF-7131 SERIES USER MANUAL Page: 4-33...

  • Page 94: Usb Configuration

    - Disabled Enable or disable USB Port 0. - Enabled USB Port 1 - Disabled Enable or disable USB Port 1. - Enabled USB Port 2 - Disabled Enable or disable USB Port 2. KF-7131 SERIES USER MANUAL Page: 4-34...

  • Page 95: Pci Express Configuration

    Enable or disable PCI Express Port 2. 2(For mini PCI-E) - Enabled speed - Auto Select the speed of PCI Express Port 2. - Gen1 - Gen2 PCI Express Port 3 - Disabled Enable or disable PCI Express Port 3. KF-7131 SERIES USER MANUAL Page: 4-35...

  • Page 96: Security Menu

    BIOS settings. You can configure an Administrator password and then configure a user password. Heed that a user password does not provide access to many of the features in the Setup utility. Figure 4-29. BIOS Password Configuration Screen KF-7131 SERIES USER MANUAL Page: 4-36...
  • Page 97 Your system will then reboot and you'll be prompted for the password. To remove the password protection, highlight the Administrator Password item and type in the current password. Press Enter to disable the password protection from the dialog box that opens. KF-7131 SERIES USER MANUAL Page: 4-37...

  • Page 98: Boot Menu

    Boot Option #1~#n - [Drive(s)] Allow users to set the boot option - Disabled listed in Hard Drive BBS Priorities. Hard Drive BBS Sub-Menu Allow users to select the boot order of Priorities the available drive(s). KF-7131 SERIES USER MANUAL Page: 4-38...

  • Page 99: Configuring Hard Drive Bbs Priorities

    Figure 4-31. Hard Drive BBS Priorities Screen BIOS Setting Option Description/Purpose Boot Option #1 - #n - [Drive(s)] Change the boot order of the available - Disabled drive(s). KF-7131 SERIES USER MANUAL Page: 4-39...

  • Page 100: Save & Exit Menu

    Reset the system without saving any No changeable options and Reset changes made in BIOS settings. Load the optimized defaults for BIOS Restore Defaults No changeable options settings. Boot Override - [Drive(s)] Force to boot from the selected [drive(s)]. KF-7131 SERIES USER MANUAL Page: 4-40...

  • Page 101: Appendix A System Diagrams

    Appendix A System Diagrams This appendix contains exploded diagrams and part numbers of the KF-7131 system. The following topics are included: • Front Base Bracket Assembly • Barcode Scanner Bracket Assembly • Front Decoration Bracket Assembly • Ticket Holder and Card Bracket Assembly •...

  • Page 102: Front Base Bracket Assembly

    Appendix A System Diagrams Front Base Bracket Assembly Component Name Part No. Q’ty SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 BARCODE_SCANNER_ASSM KF-7131 SERIES USER MANUAL Page: A-2...

  • Page 103: Barcode Scanner Bracket Assembly

    Appendix A System Diagrams Barcode Scanner Bracket Assembly Component Name Part No. Q’ty BARCODE_SCANNER_HOLDER 80-029-03061391 RIOTEC_FS5020J TRUSS HEAD SCREW 22-242-50008011 M5x0.8Px8mm Page: A-3 KF-7131 SERIES USER MANUAL...

  • Page 104: Front Decoration Bracket Assembly

    Appendix A System Diagrams Front Decoration Bracket Assembly Component Name Part No. Q’ty SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 FRONT_DECORATION_BRACKET 80-006-02064391 KF-7131 SERIES USER MANUAL Page: A-4...

  • Page 105: Ticket Holder And Card Bracket Assembly

    Appendix A System Diagrams Ticket Holder and Card Bracket Assembly Component Name Part No. Q’ty PK-7090 PULL 30-080-08110284 BARCODE_SCANNER_BOT_BRACKET 80-006-02061391 SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 TICKET_HOLDER 80-029-03063391 CARD_HOLDER 80-029-03062391 TICKET_BRACKET 80-006-02069391 CARD_BRACKET 80-006-02062391 Page: A-5 KF-7131 SERIES USER MANUAL...

  • Page 106: Front Panel Cover Parts Assembly-1

    Component Name Part No. Q’ty SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 ROUND WASHER HEAD SCREW 22-232-30007011 M3x0.5Px7mm SPEAKER CAMERA_ASSM ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm FLAT HEAD SCREW 22-215-40010011 M4x0.7Px10mm SSD_ASSM 180D CONCEALED HINGE 20-012-35001375 KF-7130_PCB_ASSM KF-7131 SERIES USER MANUAL Page: A-6...

  • Page 107: Front Panel Cover Parts Assembly-2

    Appendix A System Diagrams Front Panel Cover Parts Assembly-2 Component Name Part No. Q’ty ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm TOUCH_PANEL_BACK_BRACKET 80-006-03117391 LCD_ASSY FRONT_PANEL_COVER_BRACKET 80-006-03061391 SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 TOUCH_PANEL_BRACKET 80-006-02110391 Page: A-7 KF-7131 SERIES USER MANUAL...

  • Page 108: Front Panel With Main Body Assembly

    Appendix A System Diagrams Front Panel with Main Body Assembly Component Name Part No. Q’ty FRONT_BASE_ASSM PANEL_LINK_BRACKET 80-006-03008391 FILLISTR HEAD SCREW 22-272-40004311 M4x0.7Px4mm KF-7131 SERIES USER MANUAL Page: A-8...

  • Page 109: Main Body Assembly

    Appendix A System Diagrams Main Body Assembly Component Name Part No. Q’ty SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 NFC_COVER 30-002-10130391 FRONT_BASE_BRACKET 80-006-02063391 REAR_BASE_BRACKET 80-006-02065391 Page: A-9 KF-7131 SERIES USER MANUAL...

  • Page 110: Nfc Cover And Bracket Assembly

    Appendix A System Diagrams NFC Cover and Bracket Assembly Component Name Part No. Q’ty NFC_COVER 30-002-10130391 NFC_ASSM ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm KF-7131 SERIES USER MANUAL Page: A-10...

  • Page 111: Main Body Internal Parts Assembly

    Appendix A System Diagrams Main Body Internal Parts Assembly 12 10 Page: A-11 KF-7131 SERIES USER MANUAL...
  • Page 112 Component Name Part No. Q’ty SLIP NUTS (UNC1/2-12T, H=11.5mm) 23-140-12122601 ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm FLAT HEAD SCREW T4.7x11mm 22-112-47011011 FILLISTR HEAD SCREW M4x0.7Px4mm 22-275-40004911 (Black) ROUND HEAD SPRING WASHER 22-232-60012031 SCREW M6x12mm KF-7131 SERIES USER MANUAL Page: A-12...

  • Page 113: Drawer Parts Assembly

    Appendix A System Diagrams Drawer Parts Assembly Page: A-13 KF-7131 SERIES USER MANUAL...
  • Page 114 BRACKET THERMAL_PRINTER_MYLAR 90-056-25100391 RECYCLE_CARD_BOX_BRACKET 80-006-03111391 REAR SLIDER DOOR BRACKET 80-006-02067391 HANDLE 30-080-08110284 CARD_PRINTER THERMAL_PRINTER Screws Details List Component Name Part No. Q’ty ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm FLAT HEAD SCREW M3x0.5Px6mm 22-215-30060011 (Black) KF-7131 SERIES USER MANUAL Page: A-14...

  • Page 115: Ssd Bracket Assembly

    Appendix A System Diagrams SSD Bracket Assembly Component Name Part No. Q’ty FILLISTR HEAD SCREW 82-272-30005013 M3x0.5Px4.8mm RUBBER WASHER (BLUE) 23-680-39580963 SSD_BRACKET 80-006-03113391 Page: A-15 KF-7131 SERIES USER MANUAL...

  • Page 116: Packing Assembly

    EPE BOTTOM RIGHT (761x447x141mm) 94-016-00301391 (EPE-7121BR D1) EPE TOP LEFT (761x610x181mm) 94-016-00304391 (EPE-7121TL D1) EPE TOP RIGHT (761x610x181mm) 94-016-00303391 (EPE-7121TR D1) CARDBOARD (TOP) (788x788x150mm) 94-004-01401391 CARDBOARD (BOTTOM) 94-004-01402391 (788x788x150mm) CARTON (773x773x1580mm) 94-004-01403391 PALLET (800x800x90mm) 94-004-05401391 KF-7131 KF-7131 SERIES USER MANUAL Page: A-16...

  • Page 117: Appendix B Technical Summary

    The following topics are included: • System Block Diagram • Interrupt Map • DMA Channels Map • I/O Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update Page: B-1 KF-7131 SERIES USER MANUAL...
  • Page 118 USB 6 WebCAM PWR1 FANGTEC Audio AUDIO_IN1 AG5120C24-S1-3F0 Line-Out SPK1 R-SPEAKER Memory System FAN Kiosk Bottom-Back RJ-45 Jack #1 SPK2 L-SPEAKER System FAN CPU_FAN1 Power Power WES4.5-D105 PWRSW Extension APC BE550G-TW 72W Adapter DC-IN EA10723B-240 Page: B-2 KF-7131 SERIES USER MANUAL...

  • Page 119: Interrupt Map

    ® Celeron ® processor N- and J-series AHCI - 0F23 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-3...
  • Page 120 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-4...
  • Page 121 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-5...
  • Page 122 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-6...
  • Page 123 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-7...
  • Page 124 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-8...
  • Page 125 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-9...
  • Page 126 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-10...
  • Page 127 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-11...
  • Page 128 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-12...
  • Page 129 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-13...
  • Page 130 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-14...
  • Page 131 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-15...
  • Page 132 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System KF-7131 SERIES USER MANUAL Page: B-16...
  • Page 133 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System 4294967291 Intel ® HD Graphics 4294967292 Intel ® USB 3.0 eXtensible Host Controller - 0100 (Microsoft) 4294967293 Intel Trusted Execution Engine Interface ® 4294967294 Realtek ® PCIe GBE Family Controller KF-7131 SERIES USER MANUAL Page: B-17...

  • Page 134: I/O Map

    Motherboard resources 0x00000064-0x00000064 Standard PS/2 Keyboard 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000070-0x00000070 System CMOS/real time clock 0x00000078-0x00000CF7 PCI Express Root Complex 0x00000080-0x0000008F Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller KF-7131 SERIES USER MANUAL Page: B-18...
  • Page 135 0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A20-0x00000A2F Motherboard resources 0x00000D00-0x0000FFFF PCI Express Root Complex 0x0000164E-0x0000164F Motherboard resources 0x0000E000-0x0000E0FF Realtek ® PCIe GBE Family Controller 0x0000E000-0x0000E0FF Intel ® Pentium ® processor N- and J-series / KF-7131 SERIES USER MANUAL Page: B-19...
  • Page 136 ® processor N- and J-series AHCI - 0F23 0x0000F070-0x0000F077 Intel ® Pentium ® processor N- and J-series / Intel ® Celeron ® processor N- and J-series AHCI - 0F23 0x0000F080-0x0000F087 Intel ® HD Graphics KF-7131 SERIES USER MANUAL Page: B-20...

  • Page 137: Memory Map

    N- and J-series / Intel ® Celeron ® processor N- and J-series Platform Control Unit - SMBus Port - 0F12 0xD0500000-0xD05FFFFF Intel ® Trusted Execution Engine Interface 0xD0400000-0xD04FFFFF Intel ® Trusted Execution Engine Interface KF-7131 SERIES USER MANUAL Page: B-21...
  • Page 138 AHCI - 0F23 0xE00000D0-0xE00000DB Intel ® Sideband Fabric Device 0xFF000000-0xFFFFFFFF Intel ® 82802 Firmware Hub Device 0xA0000-0xBFFFF PCI Express Root Complex 0xA0000-0xBFFFF Intel ® HD Graphics 0xC0000-0xDFFFF PCI Express Root Complex 0xE0000-0xFFFFF PCI Express Root Complex KF-7131 SERIES USER MANUAL Page: B-22...

  • Page 139: Configuring Watchdog Timer

    EFDR. (3) Exit the extended function mode To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the KF-7131 SERIES USER MANUAL Page: B-23...
  • Page 140 01h dx, al ;------------------------------- Enable Watch PME-------------------------------------------- mov al, 0FAh dx, al al, dx and al, 51h out dx, al ;-------------------------- Set second as counting unit -------------------------------------- dec dx mov al, 0f5h KF-7131 SERIES USER MANUAL Page: B-24...
  • Page 141 30h dx, al ; ---------------- Set timeout interval as 30seconds and start counting -------------- al, 0f6h dx, al al, 1Eh dx, al ;---------------------------------Exit the extended function mode ------------------------- mov al, 0aah dx, al KF-7131 SERIES USER MANUAL Page: B-25...

  • Page 142: Flash Bios Update

    (4) Select [Boot] menu. (5) Select [Hard Drive BBS Priorities] and set the USB bootable device as the 1 boot device. (6) Press F4 to save the configuration and exit the BIOS setup menu. KF-7131 SERIES USER MANUAL Page: B-26...
  • Page 143 Appendix B Technical Summary II. AFUDOS Command for System BIOS Update KF-7131 SERIES USER MANUAL Page: B-27...
  • Page 144 BIOS ROM may be crashed and the system will be unable to boot up next time. After the BIOS update procedure is completed, the following messages will be shown: KF-7131 SERIES USER MANUAL Page: B-28...
  • Page 145 5. Restart the system and boot up with the new BIOS configurations. 6. The BIO Update is completed after the system is restarted. 7. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. KF-7131 SERIES USER MANUAL Page: B-29...

  • Page 146: Acpi Functions List

    USB_CH6_OFF USB_CH7_ON USB_CH7_OFF USB_CH8_ON USB_CH8_OFF 1. RS232_Initial() C Prototype RS232_Initial(); Description This function is used to initial COM1 with following protocol: 115200 Baud, no parity, 8 data bits, 1 stop bit. Return Value None KF-7131 SERIES USER MANUAL Page: B-30...
  • Page 147 4. USB_CH2_ON C Prototype USB_CH2_ON(); Description This function is used to enable USB2 port. Return Value None 5. USB_CH2_OFF C Prototype USB_CH2_OFF(); Description This function is used to disable USB2 port. Return Value None KF-7131 SERIES USER MANUAL Page: B-31...
  • Page 148 None 8. USB_CH4_ON C Prototype USB_CH4_ON(); Description This function is used to enable USB4 port. Return Value None 9. USB_CH4_OFF C Prototype USB_CH4_OFF(); Description This function is used to disable USB4port. Return Value None KF-7131 SERIES USER MANUAL Page: B-32...
  • Page 149 12. USB_CH6_ON C Prototype USB_CH6_ON(); Description This function is used to enable USB6 port. Return Value None 13. USB_CH6_OFF C Prototype USB_CH6_OFF(); Description This function is used to disable USB6 port. Return Value None KF-7131 SERIES USER MANUAL Page: B-33...
  • Page 150 16. USB_CH8_ON C Prototype USB_CH8_ON(); Description This function is used to enable USB8 port. Return Value None 17. USB_CH8_OFF C Prototype USB_CH8_OFF(); Description This function is used to disable USB8 port. Return Value None KF-7131 SERIES USER MANUAL Page: B-34...

Table of Contents
