protech PA-1822 User Manual

Semi-self service payment kiosk
Hide thumbs

Advertisement

Quick Links

Download this manual
USER
MANUAL
PA-1822 M0
PA-1822
Semi-Self Service
Payment Kiosk

Advertisement

loading
Need help?

Need help?

Do you have a question about the PA-1822 and is the answer not in the manual?

Questions and answers

Related Manuals for protech PA-1822

Summary of Contents for protech PA-1822

  • Page 1 USER MANUAL PA-1822 Semi-Self Service Payment Kiosk PA-1822 M0...
  • Page 2 PA-1822 15” Semi-Self Service Payment Kiosk With 10.4” Customer Touch Display COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Oct. 2016. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Introduction This chapter provides the introduction for the PA-1822 Kiosk as well as the framework of the user manual. The following topics are included: • About This Manual...
  • Page 5 PA-1822 user manual. Chapter 2 Getting Started This chapter includes the physical illustrations, quick setup and specifications for the PA-1822 system. Read the safety reminders carefully on how to take care of your system properly. Chapter 3 System Configuration This chapter outlines the locations of the motherboard and sensor board components and their respective functions.
  • Page 6 Getting Started This chapter provides the information for the PA-1822 system. It describes how to set up the system quickly and outlines the system specifications. The following topics are included: • Package List • System Overview • System Specification • Safety Precautions Experienced users can go to Chapter 3 System Configuration on page 3-1 for a quick start.
  • Page 7 Chapter 2 Getting Started Package Contents Item Q’ty PA-1822 Semi-Self Service Kiosk PA-1822 Quick Reference Guide Manual/Driver DVD AC Power Cord If you discover any of the items listed above are damaged or list, please contact your local distributor immediately.
  • Page 8 Chapter 2 Getting Started System Overview Front View Rear View Side View Page: 2-3...
  • Page 9 Chapter 2 Getting Started Coin insert Power Button Maintenance Door Note insert 10.4" Reserved space 15" Touch Customer for "Credit Card Panel-PC Touch Reader" for Sales Display Clerk Change Area Scanner Printer Drawer Maintenance Cover Page: 2-4...
  • Page 10 Chapter 2 Getting Started PAYMENT function relevant Coin Acceptor Credit Card Reader Insert Coin Credit Card (customer consign) Bill Acceptor Barcode Reader Insert Cash Scan Thermal Change area printer Get receipt Get change back Page: 2-5...
  • Page 11 Chapter 2 Getting Started 2.3 System Specifications System Customer Side Page: 2-7...
  • Page 12 Avoid exposure to sunlight for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use the PA-1822 when it has been left outdoors in a cold winter day.
  • Page 13 System Configuration This chapter contains helpful information about the various component modules comprised in PA-1822 as well as the BIOS operation. PA-1822 consists of the component modules as below: • 01. 2D Scanner_RIOTEC FS5022J • 02. 10.4 Inch Touch Monitor_PHISTEK P104VR •...
  • Page 14 Chapter 3 System Configuration 3-1. 01. 2D Scanner_RIOTEC FS5022J Page: 3-2...
  • Page 15 Chapter 3 System Configuration 3-2. 02. 10.4 inch Touch Monitor_PHISTEK P104VR Cabinet Color Black Cover Lens PMMA Hardness> 5H(JIS D0202) ,T> 93% Display type 10.4” TFT active matrix with LED backlight Resolution 800 x 600 (support 1024 * 768 @60Hz) Brightness 300 nits (typical) Contrast ratio...
  • Page 16 Chapter 3 System Configuration 3-3. 03. 3-Inch Printer_EPSON M-T532IIAP-000 Control Board Power Supply Connector This connector is used to connect the printer to an external power source. 1) Pin assignments: See the following table. 2) User side connector model: Housing: 5195-04 (MOLEX) Terminal: 5194...
  • Page 17 Paper ※ Make sure the "Paper Holder" is closed before you feed paper. Holder CAUTION FOR YOUR TROUBLESHOOTING NEEDS, CONSULT THE ATTACHED DOCUMENT "3-Inch Printer_EPSON Kit" of "PA-1822 e-MANUAL” OR CONTACT OUR SERVICE WINDOW. Page: 3-5...
  • Page 18 If you received your Smart Coin System already mounted on the baseplate, remove it. slide off Remove the SCS from the mounting plate. CAUTION FOR MORE INFORMATION AND YOUR TROUBLESHOOTING NEEDS, PLEASE SEE THE ATTACHED DOCUMENT "09. SMART-coin-system-technical-manual" of "PA-1822 e- MANUAL" or CONTACT OUR SERVICE WINDOW. Page: 3-9...
  • Page 19 Chapter 3 System Configuration Indicator Flash Codes A summary of the Status Indicator Flash Codes for the payout module are shown here: Led Colour Status Description Action Green Flashing Enabled and ready to dispense 1 Flash Hopper disabled Host system to send enables command.
  • Page 20 Door Open Dispense 0.5sec) Error occurs LED Pattern Color Indications Error (Machine Lock) CAUTION FOR MORE INFORMATION AND YOUR TROUBLESHOOTING NEEDS, PLEASE SEE THE ATTACHED DOCUMENT "07. Note Acceptor_JCM Vega-RC Twin" of "PA-1822 e-MANUAL" or CONTACT OUR SERVICE WINDOW. Page: 3-12...
  • Page 21 ISO I ,II, III; JIS I,II and support information key reader Fingerprint 8-bit grayscale reader CAUTION FOR MORE INFORMATION AND YOUR TROUBLESHOOTING NEEDS, PLEASE SEE THE ATTACHED DOCUMENT "09. 15-Inch Panel-PC_Prox PA-6322-PPC" OF "PA-1822 e-MANUAL" OR CONTACT OUR SERVICE WINDOW. Page: 3-15...
  • Page 22 Chapter 3 System Configuration Rear I/O Storage USB1 DRW1 COM2 COM1 DC In Printer 2/3/4 LAN 2nd- Power COM3 COM4 (reserved) SIDE I/O Power USB5 Button Page: 3-16...
  • Page 23 Chapter 3 System Configuration Power Button To turn on the system, press the power button on the side of the system briefly. ACTION ASSIGNMENT Click Release +3.3V Power Button DC-IN Port DC IN: DC Power-In Port (rear IO) ASSIGNMENT ASSIGNMENT +24V +24V DC IN...
  • Page 24 Chapter 3 System Configuration COM Port COM1, COM2, COM3: COM Ports (rear IO) ASSIGNMENT ASSIGNMENT DCD1/2/3 DSR1/2/3 RXD1/2/3 RTS1/2/3 TXD1/2/3 CTS1/2/3 COM 1 RI/+5V/+12V /COM 2 selectable DTR1/2/3 (Maximum /COM 3 current: 1A) /COM 4 (option) USB Port USB1, USB2, USB3, USB4, USB5: USB Type A Ports USB 1 USB 1~4: Rear I/O /USB 2...
  • Page 25 Chapter 3 System Configuration LAN Port LAN: LAN RJ45 Port (rear IO) ASSIGNMENT ASSIGNMENT MDIP0 MDIP2 MDIN0 MDIN2 MDIP1 MDIP3 MDIN1 MDIN3 RA Ver. LAN LED Indicator: Left Side LED Yellow Color Blinking LAN Message Active Yellow Green No LAN Message Active Right Side LED Green Color On 10/100Mbps LAN Speed Indicator...
  • Page 26 Chapter 3 System Configuration Printer Power Port (Optional) PRINT PWR: DC24V power supply for the stand-printer ASSIGNMENT +24V PRINT POWER Cash Drawer Port DRW1 is used by default. If you need a second port, adopt the method below. ASSIGNMENT ASSIGNMENT DRW2 Sense 12V/24V (Max.
  • Page 27 Modules Sections included:  1. 1D /2D Scanner RIOTEC FS5022J  2. 10.4” Touch Display PHiStek P104VR  3. 3” Printer Module EPSON M-T532IIAP kit  9. Coin System_Innovative SMART Coin System  7. Note Acceptor JCM Vega-RC Twin & iPRO-RC ...
  • Page 28 1. RIOTEC FS5022J 1D /2D Scanner Folder Files Description Root RIOTEC FS5022J (52-820-50220107).pdf Specification 2. PHiStek P104VR 10.4” Touch Display Folder Files Description \Driver POS Ready7(32 64-bit) Driver Root PHISTEK P104VR.pdf Specification 3. EPSON M-T532IIAP 3” Printer Module Folder Files Description BA-T500II driver \Driver...
  • Page 29 7. JCM Vega-RC Twin Note Acceptor Windows 32 64bit + .NET Framework 2.0 或以上版本 Folder Files Description \iPRO-RC iPRO RC Manual Manual \Vega-RC Twin Vega RC Twin Manual \SDK\Document ID03-001E(Rev05) Communication Communication Spec Specification \SDK\Demo Project JCM DemoProject Demo Code \SDK\Utility ID003 Basic Driver Function test utility...
  • Page 30 README The DRIVER DISC introduction Intel® Chipset Software Installation Utility Introduction The Intel® Chipset Software Installation Utility installs Windows *.INF files to the target system. These files outline to the operating system how to configure the Intel chipset components in order to ensure the following features function properly: SATA Storage Support (SATA &...
  • Page 31 LAN Driver Utility PA-6322 is enhanced with LAN function that can support various network adapters. Installation platform for the LAN driver is listed as follows: Installing LAN Driver To install the LAN Driver, follow the steps below: Connect the USB CD-ROM device to PA-6322 and insert the driver disk. Open the “LAN”...
  • Page 32 API Package Content You can find the enclosed API Package files in the Protech Manual /Driver CD. Depending on the machine types, the API Package may include the following files: Function DLL Directory Function File Name Description ProxAPI Cash Drawer...
  • Page 33 API Procedure Take VB2005 .NET for example. Follow the instructions below to perform the API procedure: Step 1. Declare a function. You may create a module in your project and fill in the function. Example: Cash drawer Declare Function GetCashDrawerStatus Lib CashDrawer.dll (ByVal num_drawer as short) As Boolean Declare Function CashDrawerOpen Lib CashDrawer.dll (ByVal num_drawer as short) As Boolean...
  • Page 34 Sample Code VB Declaration Method Declare Function GetCashDrawerStatus Lib CashDrawer.dll (ByVal num_drawer as short) As Boolean Declare Function CashDrawerOpen Lib CashDrawer.dll (ByVal num_drawer as short) As Boolean Call Function Open cash drawer: CashDrawerOpen(1) Open cash drawer1 CashDrawerOpen(2) Open cash drawer2 Check cash drawer status: Dim receive_status as Boolean Check cash drawer1 status...
  • Page 35 Declare Function Digital_Initial Lib “Digital.dll” ( ) As Long Declare Function Digtial_Set Lib “Digital.dll”(ByVal hex_value As Short) As Long Declare Function Digtial_Get Lib ”Digital.dll” ( ) As Short Declare Function GPIO_Initial Lib “GPIO.dll” ( ) As Long Declare Function GPIO_SetPort Lib “GPIO.dll”(ByVal direct As long) Declare Function GPIO_Set Lib “GPIO.dll”(ByVal dout_value As long) As Boolean Declare Function GPIO_Get Lib “GPIO.dll”( ) As Short Declare Function GetCashDrawerStatus Lib CashDrawer.dll (ByVal num_drawer as...
  • Page 36 Cash Drawer Button/Item Description OPEN (button) Tap to open the cash drawer. Cash Drawer Status Cash drawer status will be displayed after OPEN is tapped. Cash Drawer is closed when the following picture is shown: Cash Drawer is opened when the following picture is shown:...
  • Page 37 Watchdog Button/Item Description Count Mode Select second or minute as the time unit of the (radio button) watchdog timer. Setting Time Set the timeout for the watchdog timer. (Maximum value: 255 seconds or minutes) Watch Dog Control Timeout Value: Simulation timer of the API program. The running watchdog timeout will be displayed (in seconds).
  • Page 38 API Function The API program-related sample programs, developed in VB.Net and C#, are provided for easy use of the API Package. Refer to the main API functions listed as below: API Function Cash Drawer CashDrawerOpen CashDrawer.dll GetCashDrawerStatus Watchdog Watchodog_Set (WD) Watchodog_Stop multilangXML WatchDog.dll...
  • Page 39 Watch Dog Function Watchdog_Set bool Watchdog_Set (int value); Purpose: Set the timeout for the watchdog timer. Value value = 0 ~ 255 Return: True (1) on success, False (0) on failure Watchdog_SetMinSec bool Watchdog_SetMinSec (int kind); Purpose: Set the unit of time as second/minute Value kind = 1 (Measured in unit of second) 2 (Measured in unit of minute)
  • Page 40 BIOS Operation BIOS Setup The board PA-6322 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 41 EFI BIOS provides an user interface allow users the ability to modify hardware configuration, e.g. change the system date and time, enable or disable a system component, decide bootable device priorities, setup personal password, etc., which is convenient for modifications and customization of the computer system and allows technicians another method for finding solutions if hardware has any problems.
  • Page 42 Figure 3-3. BIOS Setup Menu Initialization Screen You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen.
  • Page 43 Main Menu Path Main Figure 3-4. BIOS Main Menu BIOS Setting Options Description/Purpose BIOS Vendor No changeable Displays the BIOS vendor. options Core Version No changeable Displays the current BIOS core options version. Compliancy No changeable Displays the current UEFI version. options Project No changeable...
  • Page 44 Menu Path Advanced Figure 3-5. BIOS Advanced Menu BIOS Setting Options Description/Purpose ACPI Settings Sub-Menu System ACPI Parameters. F81866 Super IO Sub-Menu System Super IO Chip parameters. Configuration Hardware Monitor Sub-Menu Monitor hardware status F81866 Watchdog Sub-Menu F81866 Watchdog parameters CPU Configuration Sub-Menu CPU Configuration Parameters.
  • Page 45 ACPI Settings Menu Path Advanced > ACPI Settings Figure 3-6. ACPI Settings Screen BIOS Setting Options Description/Purpose Enable - Disabled Enables or disables the system’s Hibernation - Enabled ability to hibernate (OS/S4 Sleep State). This option may be not effective with some OSes.
  • Page 46 F81866 Super IO Configuration Menu Path Advanced > F81866 Super IO Configuration Figure 3-7. F81866 Super IO Configuration Screen BIOS Setting Options Description/Purpose Serial Port 1 Sub-menu Configure the parameters of Serial Configuration Port 1 (COMA). Serial Port 2 Sub-menu Configure the parameters of Serial Configuration Port 2 (COMB).
  • Page 47 Serial Port 1 Configuration Menu Path Advanced > F81866 Super IO Configuration > Serial Port 1 Configuration Figure 3-8. Serial Port 1 Configuration Screen BIOS Setting Options Description/Purpose Serial Port -Disabled Enable or disable Serial -Enabled Port 1. Device Settings No changeable options Display the current settings of Serial Port 1.
  • Page 48 Serial Port 2 Configuration Menu Path Advanced > F81866 Super IO Configuration > Serial Port 2 Configuration Figure 3-9. Serial Port 2 Configuration Screen BIOS Setting Options Description/Purpose Serial Port -Disabled Enable or disable Serial -Enabled Port 2. Device Settings No changeable options Display the current settings of Serial Port 2.
  • Page 49 Serial Port 3 Configuration Menu Path Advanced > F81866 Super IO Configuration > Serial Port 3 Configuration Figure 3-10. Serial Port 3 Configuration Screen BIOS Setting Options Description/Purpose Serial Port -Disabled Enable or disable Serial -Enabled Port 3. Device Settings No changeable options Display the current settings of Serial Port 3.
  • Page 50 Serial Port 4 Configuration Menu Path Advanced > F81866 Super IO Configuration > Serial Port 4 Configuration Figure 3-11. Serial Port 4 Configuration Screen BIOS Setting Options Description/Purpose Serial Port -Disabled Enable or disable Serial -Enabled Port 4. Device Settings No changeable options Display the current settings of Serial Port 4.
  • Page 51 Parallel Port Configuration Menu Path Advanced > F81866 Super IO Configuration > Parallel Port Configuration Figure 3-12. Parallel Port Configuration Screen BIOS Setting Options Description/Purpose Parallel Port -Disabled Enable or disable Parallel -Enabled Port. Device Settings No changeable options Displays current settings of Parallel Port.
  • Page 52 Hardware Monitor Menu Path Advanced > Hardware Monitor Figure 3-13. Hardware Monitor Screen BIOS Setting Options Description/Purpose No changeable Displays the processor's temperature. Temperature options System No changeable Displays the system's temperature. Temperature options No changeable Displays the voltage level of VCORE in VCORE options supply.
  • Page 53 F81866 Watchdog Menu Path Advanced > F81866 Watchdog Figure 3-14. F81866 Watchdog Screen BIOS Setting Options Description/Purpose Enable -Enabled Enable/ Disable Watch dog timer. WatchDog -Disable Watchdog Select seconds or minutes timer unit -60s Count for multiple options Sets the desired value (in seconds) Timer ranging from 1 to 255 for watchdog timer.
  • Page 54 CPU Configuration Menu Path Advanced > CPU Configuration Figure 3-15. CPU Configuration Screen BIOS Setting Options Description/Purpose Socket 0 Sub-Menu Report CPU Information Information CPU Speed No changeable Reports the current CPU Speed options 64-bit No changeable Reports if the processor supports Intel options x86-64 (amd64) implementation.
  • Page 55 Socket 0 CPU Configuration Menu Path Advanced > CPU Configuration > Socket 0 CPU Information Figure 3-16. Socket 0 CPU Information Screen BIOS Setting Options Description/Purpose No changeable Reports the CPU Signature. Signature options Microcode No changeable Reports the CPU Microcode Patch Patch options Version.
  • Page 56 IDE Configuration Menu Path Advanced > IDE Configuration Figure 3-17. IDE Configuration Screen BIOS Setting Options Description/Purpose Serial-ATA - Disabled Enable or disable SATA Device. Controller(s) - Enabled SATA Test - Disabled Enable or disable SATA Test Mode. Mode - Enabled SATA Speed - GEN1 Gen1 mode sets the device to 1.5 Gbit/s speed.
  • Page 57 BIOS Setting Options Description/Purpose SATA Port 1 - Disabled Enable or disable SATA port 1 Device HotPlug. HotPlug - Enabled SATA Port 0 [drive] Displays the drive installed on this SATA port 0. Shows [Empty] if no drive is installed. SATA Port 1 [drive] Displays the drive installed on this SATA port 1.
  • Page 58 CSM Configuration Menu Path Advanced > CSM Configuration Figure 3-19. CSM Configuration Screen BIOS Setting Options Description/Purpose CSM Support - Disabled Disable or enable CSM support. - Enabled CSM16 No changeable Displays the current CSM (Compatibility Module options Support Module) version. Version GateA20 - Upon Request...
  • Page 59 BIOS Setting Options Description/Purpose Video - Do not launch Controls the execution of UEFI and - UEFI Legacy Video. - Legacy Other PCI - Do not launch Select the launch method for other PCI devices - UEFI devices, such as NIC, mass storage or - Legacy video card.
  • Page 60 BIOS Setting Options Description/Purpose USB transfer 1 / 5 / 10 /20 sec The time-out value for Control, Bulk, and time-out Interrupt transfers. Device reset 10 / 20 / 30 / 40 sec USB mass storage device Start Unit time-out command time-out.
  • Page 61 North Bridge Menu Path Chipset > North Bridge Figure 3-22. North Bridge Menu Screen BIOS Setting Options Description/Purpose LCD Control Sub-menu Allows users to execute the LCD Control. Memory No changeable options Displays the DRAM information on the Information platform. Total Memory No changeable options Displays the DRAM size.
  • Page 62 LCD Control Menu Path Chipset > North Bridge > LCD Control Figure 3-23. LCD Control Screen BIOS Setting Options Description/Purpose Primary IGFX - CRT Selects the Primary Display Device. Boot Display - LVDS Secondary - Disabled Selects the Secondary Display Device. IGFX Boot - CRT Display...
  • Page 63 South Bridge Menu Path Chipset > South Bridge Figure 3-24. South Bridge Screen BIOS Setting Options Description/Purpose Restore AC - Power Off Select the AC power state when power is Power Loss - Power On re-applied following a power failure. - Last State Power Off keeps the power off till the power button is pressed.
  • Page 64 Security Menu Path Security Figure 3-25. Security Menu Screen BIOS Setting Options Description/Purpose Administrator Password can be Specifies the administrator password. Password 3-20 alphanumeric characters. User Password can be Specifies the user password. Password 3-20 alphanumeric characters.
  • Page 65 Boot Menu Path Boot Figure 3-26. Boot Menu Screen BIOS Setting Options Description/Purpose Setup Prompt Numeric Number of seconds to wait for Timeout setup activation key. Bootup - On Selects the NumLock sate after the NumLock - Off system is powered on. State On: Enable the NumLock function automatically after the system is...
  • Page 66 Save & Exit Menu Path Save & Exit Figure 3-27. Save & Exit Menu Screen BIOS Setting Options Description/Purpose Save No changeable Exits and saves the changes in NVRAM. Changes and options Exit Discard No changeable Exits without saving any changes made in Changes and options BIOS settings.
  • Page 67 Configuring WatchDog Timer The I/O port address of the watchdog timer is 2E (hex) and 2F (hex). 2E (hex) is the address port. 2F (hex) is the data port. User must first assign the address of register by writing address value into address port 2E (hex), then write/read data to/from the assigned register through data port 2F (hex).
  • Page 68 ;------------------------------- Enable Watch PME--------------------------- dec dx 0FAh out dx, and al, out dx, ;-------------------------- Set second as counting unit dec dx mov al, 0f5h out dx, and al, out dx, ; ----------- Set timeout interval as 30seconds and start counting --- mov al, 0f6h out dx,...
  • Page 69 Update Procedure Prerequisites Prepare a bootable media (e.g. USB storage device) which can boot the system to DOS prompt. Download and save the BIOS file (e.g. 67220PD1.bin) to the bootable device. Copy AMI flash utility – AFUDOS.exe (V5.07) into the bootable device Make sure the target system can first boot to the bootable device.
  • Page 70 AFUDOS Command for System BIOS Update AFUDOS.exe is aforementioned AMI firmware update utility; the command line is shown as below: AFUDOS <ROM File Name> [option1] [option2]… You can type AFUDOS /? to see the definitions of all the control options. The recommended options for BIOS ROM update include the following parameters: /P: Program main BIOS image /B: Program Boot Block...
  • Page 72 Follow the wizard instructions to complete the installation. Launching the Program The steps below guide you to load the Prox-PMP3000 program. Click the MSR folder from the path: Start/Programs/Protech OPOS. Click Prox-PMP3000 to launch the program. Configuration of Prox-PMP3000 program...
  • Page 73 Button/Item Description Select the COM port number from the drop-down list. (only for UART/USB interface). AutoDisable (check box) Check to disable the device automatically when data is received. FreezeEvents (check box) Enable to trigger FreezeEvents, and the application will not allow events to be delivered.
  • Page 74 Description tab: S.O and C.O information Track Control tab items Button/Item Description DecodeData Set decode data properties applicable. ParseDecodeData Set parse decode data properties TransmitSentinels Set transmit-sentinels properties ErrorReporting Type Card, track TracksToRead Track1, track2, track3, tracks12, tracks13, tracks14, tracks23, tracks24, tracks34, tracks123, tracks124, tracks134, tracks234, tracks1234 (Tracks4 is not applicable).
  • Page 75 Track Data tab items Button/Item Description TracksData (Row) Display the data of all tracks (Track4 is not applicable). Parsed Data tab items Button/Item Description Parsed Data Display special properties. MB301X type (RS232/PS2) Key Name Type Default Value Note default string PMP3000 OPOS S.O Link...
  • Page 76 OPOS APIs support List OPOS Category Name Mutability VFD .SO Type Version Properties common AutoDisable Supported bool Properties common BinaryConversio long Applicable Properties common CapPowerRepor Read Supported long ting only Properties common CheckHealthTex Read Supported string only Properties common Claimed Read Supported bool...
  • Page 77 OPOS Category Name Mutability VFD .SO Type Version bool only Properties specific CapJISOne Read Supported bool only Properties specific CapJISTwo Read Supported bool only Properties specific CapTransmitSe Read Supported bool ntinels only Properties specific TracksToRead Supported long Properties specific DecodeData bool Applicable Properties...
  • Page 78 OPOS Category Name Mutability VFD .SO Type Version bool Methods common Open Supported Methods common Close Supported Methods common Claim Supported Methods common ClaimDevice Supported Methods common Release Supported Methods common ReleaseDevice Supported Methods common CheckHealth Applicable Methods common ClearInput Supported Methods common...
  • Page 79 MSR: GIGA-TMS MJR243 (RS-232) Commands List MSR Registry Operation Registry Path: [HKEY_LOCAL_MACHINE\SOFTWARE\OLEforRetail\ServiceOPOS\ MSR\MJR243] Registry Name Default Data Notes CapISO Capability for reading ISO track data CapJISOne (reserved) CapJISTwo (reserved) CapTransmitSentinels Capability for reading Transmit Sentinels Debug Enable the tracing and create a log file Description GIGATMS...
  • Page 80 OPOS MSR Service Object and Method Relations Status of support by Method Notes the driver ○ Open ○ Close ○ Claim ○ ClaimDevice ○ Release ○ ReleaseDevice ○ ClearInput ○ ClearInputProperties ○ DataEvent ○ Claimed Read only ○ DataCount Read only ○...
  • Page 81 The OPOS MSR Register program sets up the registry information of MSRHK reader for OPOS program usage. Installation The steps below guides you how to install the OPOS MSR Register program. Insert the setup CD Run the setup file OPOSMSR_Setup.exe located in the Software folder of the CD. This setup also installs the OPOS MSR Tester program.
  • Page 82 Configuration of OPOS MSR Register program Main screen buttons/items: Button/Item Description Control Object (Check box) Register the OPOSMSR.ocx common control object driver. The item needs to be checked to run the OPOS MSR Tester program. Service Object (Left pane) The Service Object driver types. So far only four driver types are supported.
  • Page 83 Example 1. MAGTEK USB HID Example 2. PROMAG MSR/MJR PART‐NO, Keyboard mode.
  • Page 84 Example 3. PROGRAM MSR PART‐NO, HID mode. If your system doesn’t have any other common control driver, click the Control Object check box. Note: To run the OPOPS MSR Tester program, the Control Object must be checked. MJR243 type Key Name Type Default Value Note...
  • Page 85 OPOS Category Name Mutability MSR .SO Type Version Properties common bool AutoDisable Not Applicable Properties common long BinaryConversion Not Applicable Properties common bool CapCompare Read only Not Applicable FirmwareVersion Properties common long CapPowerReporting Read only Not Applicable Properties common bool CapStatisticsReporting Read only Not Applicable Properties...
  • Page 86 OPOS Category Name Mutability MSR .SO Type Version Properties specific binary Track4Data Read only Not Applicable Properties specific long TracksToRead Supported Properties specific long TracksToWrite Not Applicable Properties specific bool TransmitSentinels Supported Methods common Open Supported Methods common Close Supported Methods common Claim...
  • Page 87 Configuration for OPOS MSR Tester Program Main screen buttons/items: Button/Item Description Device Name (Combo box) Enter the device name that will be loaded to the program. Track Data (Text boxes) Show the raw and parsed track data. Clear (Button) Clear all the track data in the text boxes.
  • Page 88 Open (Button) Open the OPOS driver and ready to get track data. Close (Button) Close the OPOS driver. Message (Text box) Display the result message of running the OPOS driver. To get the track data using OPOS driver, follow the steps below: Step 1: Enter the Device Name.
  • Page 89 Optional Fingerprint Driver Utility The fingerprinter driver utility can only be installed on a Windows platform, and it should be installed right after the OS installation is completed. Installing Fingerprint Driver To install the fingerprinter driver, follow the steps below: Connect the USB DVD-ROM device to PA-6322 and insert the driver disk.
  • Page 90 Exploded drawing & Cable map Cable map • Exploded drawing •...
  • Page 91 Cable Map...
  • Page 94 PN: 27-013-38313111 Cable_1 For Rear I/O AC socket to 3x Power adaptor AC inlet Path Point Point.PS3 Loca Point.P -tion .PS2 Side B to 24V/90W Power adaptor AC inlet port Point.PS3 Side A Side C to 24V/90W Power adaptor AC Cable Descri fixing on...
  • Page 95 PN: 52-002-10530001 DC outlet Cable_2 For 60W /12V Power adaptor to Power sharing cable Path Point Point. Point. Loca Point.PS3 Point.PS1 -tion .PS2 Side A Descri Side B to link from -ption Cable_1 Cable_3 Side A Side D...
  • Page 96 PN: 27-012-38303111, Cable_3 For Sharing DC12V power to 3 devices Path Point.P Point. Point. Point.PS3 Loca Point.PS1 -tion Side D to \Cable_4 Side A Point.PS3 Side A link 07-->03- Side E to Descri from 12V/60W Adaptor ->02-->0 Cable_5 Side A -ption Power adaptor house...
  • Page 97 PN: 27-012-37320111 Cable_5 For providing DC12V & RS232 to Vega-RC Note acceptor Path Loca Point.PS2 Point.6 Point.4 Point.PS1  -tion Point.PS3 18-->1--> Side B Com2 air Side A Descri link to Note  -ption acceptor Point.PS3 Big 4 P Side C...
  • Page 98 PN: 52-002-04095302 DC outlet Cable_7 For 90W /24V Power adaptor to 15” Touch Panel-PC DC-in Path    Loca Point.PS1 -tion Point.PS2 Point.6 Point.4 Side A link Descri from Cable_1 adaptor 1209 -ption Side C...
  • Page 99 When Note Acceptor is Vega-RC Twin PN: 52-002-08150201 DC outlet Cable_8 For 72W /24V Power adaptor to Coin hopper DC-in Path    Loca Point.PS1 -tion Point.PS2 Point.6 Point.PS3 Side A Side B to Descri link from 27-012-38302111 adaptor 19104568 -ption Cable_1...
  • Page 100 When Note Acceptor is iPRO-RC PN: 52-002-08150201 DC outlet Cable_8 For 150W /24V Power adaptor to Coin hopper DC-in Path cable24 side A Side A link from Cable_1 Side B Side B to Cable_24 Coin System Power Adaptor-cable Path Side A Side B Side C to Bill Acceptor...
  • Page 101 PN: 27-012-38319111 Cable_9 For providing 12V Power to 10.4” display Path    Loca Point.PS1 -tion Point.PS2 Point.6 Point.PS3 Side A link to Side B from 15” Descri 10.4” touch PPC 2nd 131419 Touch panel-PC 4109 -ption display DC-in display DC-out 12V port port...
  • Page 102 PN: 27-012-38327111, Cable_10 For providing 24V Power to Thermal Printer Path Point   Loca Point.PS3 Point.PS1 -tion .PS2 Point.6 Point.4 Side A link Cable 16171 Side B to Descri to 3” Printer entrance of 521 Thermal printer -ption Control /B Print-module 129 power in...
  • Page 103 When Note Acceptor is Vega-RC Twin PN: 27-024-38312032 Cable_13 For 15” Touch panel-pc RS232 to Note Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side A link to Side B to Descri 15” Touch 0912 note Cable_5 -ption panel-PC 12 Side B COM2 port...
  • Page 104 When Note Acceptor is iPRO-RC PN: 27-024-38312032 Cable_13 For 15” Touch panel-pc RS232 to Note Path Side A link to 15” Touch Side B panel-PC COM2 port to cable 25 side C Cable_25 iPro-RC Signal cable Path Side A Side B Side D Side C to cable13 side B...
  • Page 105 Cable_14 PN:27-006-28412111 & An attachment of Hub Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side A link to 9121 Side B to Descri 15” Touch 23 USB 3.0 Hub -ption panel-PC USB port USB1 port...
  • Page 106 PN: 52-820-50220107 USB cable Cable_15 For USB 3.0 Hub to Scanner Path Point Loca Point.6 Point.4 Point.PS1 -tion .PS2 Descri Side A link to 8654 BAR CODE -ption USB hub port1 10912...
  • Page 107 PN: 27-006-30224111 Cable_16 For 15” Touch panel-pc USB to Coin System USB Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side A link to 1011 Descri 15” Touch Side B to USB2 1914 -ption panel-PC 2nd display USB2 port...
  • Page 108 PN: 27-006-38317112 Cable_17 For 15” Touch panel-pc USB to 10.4” display Path    Loca Point.PS3 Point.PS1 -tion Point.PS2 Point.6 Point.4 Side A link Side B link to 10.4” Descri USB3 to 13141 from 15” Touch Touch -ption touch 9...
  • Page 109 PN: 27-006-30224111 Cable_18 For 15” Touch panel-pc USB to 3” Printer USB Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side B to Side A link 9121 Descri Printer to Printer 215 panel-PC -ption USB4 Control /B 1716 USB4 port CN21 port...
  • Page 110 PN: 27-017-38324111 Cable_19 For 15” Touch panel-pc VGA to 10.4” display Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side A link Side B to 1011 Descri from 15” Touch 10.4” Touch VGA PCC 1914 -ption panel-PC VGA LCD VGA port port...
  • Page 111 PN: 27-026-41420111 Cable_20 For 15” Touch panel-pc LAN to LAN extending connector Path Point Loca Point.6 Point.4 Point.PS3 Point.PS1 -tion .PS2 Side B to Side A link 1011 Descri from 15” Touch LAN CONN 0405 extending -ption panel-PC LAN 0608 port connector...
  • Page 112 Exploded drawing COMPONENT NAME PART NO. QTY. REMARK ADAPTER HOLDER 90W 20-029-03003414 ADAPTER HOLDER 150W 20-029-03001414 ADAPTER CHASSIS BRACKET 20-006-03003414 SCREW 22-232-40006311 8.5-9.5kgf-cm ADAPTER CHASSIS 20-015-03002414 SCREW 22-242-30005311 4.5-5.5kgf-cm ADAPTER 150W ADAPTER 60W ADAPTER 90W ADAPTER HOLDER 60W 20-029-03002414 CASE BASE ASSY...
  • Page 113 COMPONENT NAME PART NO. VEGA_BASE/數量 REMARK BASE 20-032-03061414 PLASTIC FOOT 90-004-28100000 CLUMP WEIGHT 80-004-02061414 PULL HANDLE 30-080-08110284 SCREW 22-232-40015211 8.5-9.5kgf-cm SCREW 22-232-40010011 8.5-9.5kgf-cm STOP BOARD 20-006-03009383 SCREW 22-235-40005911 8.5-9.5kgf-cm...
  • Page 114 COMPONENT NAME PART NO. VEGA_BLACK/數量 REMARK BEZEL VEGA (BLACK) 80-103-02061414 COIN BOX 20-040-07001414 DECOR COVER BLACK 80-104-02062414 DOOR PULLEY BRKT 80-006-02061414 FLANGED NUT M3 23-142-30400801 8.5-9.5kgf-cm WIRING DUCT FLANGED NUT M4 23-142-40450801 8.5-9.5kgf-cm SCREW 22-215-40006011 8.5-9.5kgf-cm HOPPER COVER STOP BITS 20-004-02001383 BOLT 22-272-40006911...
  • Page 115 COMPONENT NAME PART NO. QTY. REMARK BOLT 22-272-40006911 8.5-9.5kgf-cm SCANNER SCANNER COVER 20-004-03002414 SCREW 22-232-40006311 8.5-9.5kgf-cm LOCK HOPPER PLATE 20-005-02001383 FLANGED NUT M6 23-142-60601271 FLANGED NUT M3 23-142-30400801 8.5-9.5kgf-cm CAM LOCK 20-025-30001284 CASE (BLACK) 80-101-03061414 NOTE MOUTH COVER 80-004-02062414 NOTE MOUTH 20-004-07061414 COIN BASE ASSY...
  • Page 116 SMART_COIN/ONLY_SMA COMPONENT NAME PART NO. REMARK RT_COIN/數量 NOTE BASE 20-032-03001414 SCREW 22-232-40006311 8.5-9.5kgf-cm SMART COIN SCREW 22-232-50006011 16.5-18.5kgf-cm CABLE CLAMP 90-023-04700000 VEGA BASE ASSY...
  • Page 117 COMPONENT NAME PART NO. OPENING/數量 REMARK COMPONENT NAME PART NO. CLOSING/數量 REMARK FRONT CABLE COVER 80-104-02061414 REPAIR COVER 20-004-03001414 SCREW 22-215-30005011 SCREW 22-215-40006011 8.5-9.5kgf-cm...
  • Page 118 COMPONENT NAME PART NO. QTY. REMARK PAY BASE 20-032-03002414 GROMMET 90-026-04600000 SCREW 22-215-30005011 CONCEALED HINGE 20-012-35001383 SCREW 22-215-40010011 BOLT 22-272-40006911 8.5-9.5kgf-cm...
  • Page 119 COMPONENT NAME PART NO. QTY. REMARK POWER BOX CHASSIS 20-015-03001414 VELCRO TAPE 30-082-04200000 POWER CORD CABLE 27-013-38313111 HUB PLATE 20-005-03001414 SCREW 22-242-30005311 4.5-5.5kgf-cm SCREW 22-275-30008018 4.5-5.5kgf-cm MODULAR COUPLER JACK 10-085-10012035 CABLE CLAMP 90-023-04100414 SCREW 22-232-40008011 8.5-9.5kgf-cm FLANGED NUT M6 23-142-60601271 USB HUB...
  • Page 120 COMPONENT NAME PART NO. QTY. REMARK PPC SUPPORT BRACKET 20-106-03001414 SCREW 22-232-40010011 8.5-9.5kgf-cm BOLT 22-272-40006911 8.5-9.5kgf-cm ROTATE BASE 20-032-03001314 HINGE L 20-012-29001314 HINGE FIXING 80-012-03001314 HINGE R 20-012-29002314 STAND ROTATE COVER 30-002-28410314 THUMB SCREW 82-289-30015004 ROTATE BASE SPONGE 30-013-24100314 SCREW 22-232-50015011 16.5-18.5kgf-cm HINGE COVER R...
  • Page 121 COMPONENT NAME PART NO. QTY. REMARK PRINTER SLIDE BOARD 20-032-03003414 SCREW 22-232-40006311 8.5-9.5kgf-cm FULL EXTENSION DRAWER SLIDE 20-058-31001284 1set SCREW 22-235-40005911 8.5-9.5kgf-cm BASE ASSY...
  • Page 122 Use the screws provided for the thermal printer. COMPONENT NAME PART NO. QTY. REMARK PRINTER COVER 20-004-03006414 CAM LOCK 20-025-30001284 PRINTER PAPER SLOT 80-004-02063414 SCREW 22-215-30004311 4.5-5.5kgf-cm THERMAL PRINTER 52-701-02025008 3 INCH PAPER SUPPORT ANY 20-002-03001383 HEX CU BOSS M2.5 22-298-25010001 3 INCH PRINTER BASE ASSY 20-032-03001383...
  • Page 123 COMPONENT NAME PART NO. QTY. REMARK SECOND HINGE BRACKET-1 20-006-03002414 SECOND HINGE BRACKET-2 20-006-03001414 HINGE 25kgf-cm NI SCREW 22-232-40008011 8.5-9.5kgf-cm SCREW 22-215-40015011 8.5-9.5kgf-cm SECOND HINGE COVER (BLACK) 80-104-02065414 SCREW 22-232-40015211 8.5-9.5kgf-cm...
  • Page 124 COMPONENT NAME PART NO. QTY. REMARK FULL EXTENSION DRAWER SLIDE 20-058-31001284 SCREW 22-235-40005911 8.5-9.5kgf-cm JCM VEGA MODULE NOTE CHASSIS VEGA 20-015-03005414 JCM BRACKET 20-006-03002383 BASE LINK 20-032-03004414 M4 NUT 23-102-40300071 SCREW 22-215-40006011 8.5-9.5kgf-cm SCREW 22-135-30006011 PRINTER BASE ASSY DATE SCALE UNIT VERSION Name: VEGA BASE ASSY...
