Page 1 USER MANUAL KS-M220 / KS-M221 21.5” Multi-Functional Modular Kiosk System KS-M220 & KS-M221 M2...
Page 2 KS-M220 / KS-M221 21.5” Multi-Functional Modular Kiosk System COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Mar. 2021. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 4: Table Of Contents
Top View of BE-0996RA-**N ..........3-6 3.3.2 Jumper Setting of BE-0996RA-**N........3-7 3.3.3 Bottom View of BE-0996RA-**N ........3-8 3.3.4 I/O View of BE-0996RA-**N ..........3-9 How To Set Jumpers ............... 3-10 Setting KS-M220 High-End Level Connectors and Jumpers ... 3-12...
Page 5 3.5.1 COM2 Connector Pin9 Definition Selection Guide (JP_COM2) ............... 3-12 3.5.2 COM Connectors (COM1, COM2) ........3-13 3.5.3 Internal USB 2.0 Connector (JUSB1) ....... 3-14 3.5.4 ATX Power Input Connector (ATX1) ......... 3-15 3.5.5 HD Audio Connector (AUDIO1) ........3-15 3.5.6 Speaker Connectors (SPK_L_OUT1, SPK_R_OUT1) ..
Page 6 3.7.2 Jumper Setting of BE-0986RB ........3-35 3.7.3 Bottom View of BE-0986RB ..........3-36 3.7.4 I/O View of BE-0986RB ........... 3-36 Setting KS-M221 Entry Level Connectors and Jumpers ....................... 3-37 3.8.1 COM3 and COM4 PIN9 Definition Selection Guide (JP_COM3, JP_COM4) ........... 3-37 3.8.2 COM Port (COM1, COM2, COM3, COM4) .....
Page 7 ® 4.2.6 Installing Intel Serial I/O Driver Utility ......4-15 BIOS SETUP ..................5-1 Introduction ................5-2 Accessing Setup Utility for KS-M220 High-End Level System . 5-4 5.2.1 Main ................... 5-7 5.2.2 Advanced ................5-9 5.3.3.1 Advanced – CPU Configuration ......5-10 5.3.3.2...
Page 8 5.3.3.3 Advanced – PCH-FW Configuration ....5-12 5.3.3.4 Advanced – Trusted Computing ......5-13 5.3.3.5 Advanced – ACPI Settings ......... 5-15 5.3.3.6 Advanced – F81866 Super IO Configuration ..5-16 5.3.3.7 Advanced – Hardware Monitor ......5-19 5.3.3.8 Advanced – F81866 Watchdog ......5-21 5.3.3.9 Advanced –...
Page 9 KS-M220 / KS-M221 KDS Body Exploded Diagrams ......A-12 KS-M220 / KS-M221 KDS Control Box Exploded Diagrams ....A-31 KS-M220 / KS-M221 Cash Pay Lower Parts Exploded Diagrams ..A-38 KS-M220 / KS-M221 M-Type Lower Parts Exploded Diagrams .....A-55 Appendix B Technical Summary ..........B-1 Technical Summary for KS-M220 High-End Level System ..
Page 10 Revision History The revision history of KS-M220 / KS-M221 User Manual is described below: Version No. Revision History Date In Section 2.4 Safety Precautions, added the caution  message: “The equipment power supply cord shall be connected to a socket-outlet with 2021/03/31 earthing connection.”...
Page 11: Introduction
Introduction This chapter provides the introduction for KS-M220 / KS-M221 system as well as the framework of the user manual. The following topic is included: • About This Manual Page: 1-1 KS-M220 SERIES USER MANUAL...
Page 12: 1.1 About This Manual
It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for the KS-M220 / KS-M221 system as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines the system specifications.
Page 13: Getting Started
Getting Started This chapter provides the information for the KS-M220 / KS-M221 system. It describes the package contents and outlines the system specifications. The following topics are included: • Package List • System Overview • System Diagrams • System Specification •...
Page 14: 2.1 Packing List
2.1 Packing List If you discover any of the items listed above are damaged or lost, please contact your local distributor immediately. Item Q’ty KS-M220 / KS-M221 system Quick Reference Guide Manual / Driver DVD AC Power Adaptor Door Key...
Page 15: 2.2 System Overview
Chapter 2 Getting Started 2.2 System Overview 2.2.1 KDS Type Front View Rear View Face Camera 21.5” Touch Panel Left Side View Right Side View Top View Bottom View KS-M220/KS-M221 SERIES USER MANUAL Page: 2-3...
Page 16: M-Type
Chapter 2 Getting Started 2.2.2 M-Type Front View Face Camera 21.5” Touch Panel Credit Card Reader IC Card Reader (Customer Assigned) Barcode Scanner Thermal Printer Page: 2-4 KS-M220/KS-M221 SERIES USER MANUAL...
Page 17 Chapter 2 Getting Started Rear View Rear I/O Ports KS-M220/KS-M221 SERIES USER MANUAL Page: 2-5...
Page 18 Chapter 2 Getting Started Side View Page: 2-6 KS-M220/KS-M221 SERIES USER MANUAL...
Page 19 Chapter 2 Getting Started Top View KS-M220/KS-M221 SERIES USER MANUAL Page: 2-7...
Page 20: Cash Pay Type
Chapter 2 Getting Started 2.2.3 Cash Pay Type Front View Face Camera 21.5” Touch Panel Credit Card Reader IC Card Reader (Customer Assigned) Barcode Scanner Thermal Printer Page: 2-8 KS-M220/KS-M221 SERIES USER MANUAL...
Page 21 Chapter 2 Getting Started Rear View Rear I/O Ports KS-M220/KS-M221 SERIES USER MANUAL Page: 2-9...
Page 22 Chapter 2 Getting Started Side View Page: 2-10 KS-M220/KS-M221 SERIES USER MANUAL...
Page 23 Chapter 2 Getting Started Top View Bottom View KS-M220/KS-M221 SERIES USER MANUAL Page: 2-11...
Page 24: 2.3 Specifications
Thermal Printer (optional)  2" or 3" Standalone Thermal printer  2T2R PCIe Half-Mini Card Wi-Fi Module (optional) Environment  5°C ~ 35°C (41°F~ 95°F) Operating Temp.  0°C ~ 60°C (32°F~ 140°F) Storage Temp.  20%~ 85% (no condensation) Humidity Page: 2-12 KS-M220/KS-M221 SERIES USER MANUAL...
Page 25: 2.4 Safety Precautions
If heavy stains are present, moisten a cloth with diluted neutral washing • agent or alcohol and then wipe thoroughly with a dry cloth. • If dust is accumulated on the case surface, remove it by using a special vacuum cleaner for computers. KS-M220/KS-M221 SERIES USER MANUAL Page: 2-13...
Page 26: System Configuration
The following topics are included: • External I/O Ports Diagrams • Main Board Jumper Settings and Component Locations • How to Set Jumpers • Setting Main Board Connectors and Jumpers KS-M220/KS-M221 SERIES USER MANUAL Page: 3-1...
Page 27: 3.1 System Rear I/O Ports Diagrams
Chapter 3 System Configuration 3.1 System Rear I/O Ports Diagrams 3.1.1 KDS Type DC In RJ45 / Power (Power) RJ11 Button Page: 3-2 KS-M220/KS-M221 SERIES USER MANUAL...
Page 28: M-Type
Chapter 3 System Configuration 3.1.2 M-Type AC In RJ45 / RJ45 / (Power) RJ11 RJ11 3.1.3 Cash Pay Type AC In RJ45 / RJ45 / (Power) RJ11 RJ11 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-3...
Page 29: Reference Table
Chapter 3 System Configuration 3.2 KS-M220 High-End Level System Jumper & Connector Quick Reference Table JUMPER Description NAME Clear CMOS Data Selection JCMOS1 COM2 Pin9 RI/5V/12V Selection JP_COM2 SPI Override Protection Selection LVDS VCC Selection Backlight PWM Level Selection V3P3 MPCIE Selection...
Page 30 SATA 3.0 Connector SATA1 SATA Power Connector JHDD_PWR1 I2C Wafer JI2C1 LVDS Connector JLVDS1 Panel Inverter Connector JINV1 Mini PCI Express Slot M_PCIE1 mSATA Connector M_SATA1 SPI Connector DDR4 SO-DIMM Memory Socket 1 DIMM1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-5...
Page 31: 3.3 Ks-M220 High-End Level System Component Locations
Chapter 3 System Configuration 3.3 KS-M220 High-End Level System Component Locations 3.3.1 Top View of BE-0996RA-**N USB 2.0 Audio HDMI LAN2 LAN1 USB 3.0 Speaker Connector Battery (Left) Connector Speaker Connector (Right) COM2 Mini PCIe 8DI+8DO mSATA COM1 SATA 3.0...
Page 32: Jumper Setting Of Be-0996Ra-**N
Pins 3, 6: ON Pins 4, 5: ON 800x600 Channel S/6bit Pins 1, 8: ON Pins 2, 7: ON Pins 3, 6: ON Pins 4, 5: ON 3.3V (default) JLVDS1 ATX1 JFP1 JUSB1 Disable Enable (default) DIMM1 CPU_FAN1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-7...
Page 33: Bottom View Of Be-0996Ra-**N
Chapter 3 System Configuration 3.3.3 Bottom View of BE-0996RA-**N Page: 3-8 KS-M220/KS-M221 SERIES USER MANUAL...
Page 34: I/O View Of Be-0996Ra-**N
Chapter 3 System Configuration 3.3.4 I/O View of BE-0996RA-**N LAN1 LAN2 4 x USB 2.0 Ports 2 x USB 3.0 Ports HDMI KS-M220/KS-M221 SERIES USER MANUAL Page: 3-9...
Page 35: 3.4 How To Set Jumpers
PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. Page: 3-10 KS-M220/KS-M221 SERIES USER MANUAL...
Page 36 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this Page: 3-11 KS-M220/KS-M221 SERIES USER MANUAL...
Page 37: Setting Ks-M220 High-End Level Connectors And Jumpers
Chapter 3 System Configuration 3.5 Setting KS-M220 High-End Level Connectors and Jumpers 3.5.1 COM2 Connector Pin9 Definition Selection Guide (JP_COM2) Jumper Location: JP_COM2 Description: COM2 Port pin9 RI/+5V/+12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM2 JP_COM2 JP_COM2 KS-M220/KS-M221 SERIES USER MANUAL...
Page 38: Com Connectors (Com1, Com2)
RS-485+ DTR# DSR# RTS# CTS# Note: COM2: Pin 9 is selectable for RI, +5V or +12V by JP_COM2 jumper setting. Default setting is RI. Please see “COM2 PIN9 Definition Selection Guide” for selection details. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-13...
Page 39: Internal Usb 2.0 Connector (Jusb1)
Connector Location: JUSB1 Description: Internal USB 2.0 Connector USB 2.0 connector signals: ASSIGNMENT ASSIGNMENT (option) USBP7N USBP10N USBP7P USBP10P JUSB1 Note: The functions of JUSB1 option pins are only supported on Core-i5 / i3 SoC boards. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-14...
Page 40: Atx Power Input Connector (Atx1)
+12V / +24V +12V / +24V ATX1 3.5.5 HD Audio Connector (AUDIO1) Connector Location: AUDIO1 Description: HD Audio Connector for Line In/Line Out/Mic In. PIN ASSIGNMENT PIN ASSIGNMENT MIC1-L MIC1-R HD_LINE-IN-L_L HD_LINE-IN-R_L AUDIO1 LINE-OUT-L LINE-OUT-R KS-M220/KS-M221 SERIES USER MANUAL Page: 3-15...
Page 41: Speaker Connectors (Spk_L_Out1, Spk_R_Out1)
Chapter 3 System Configuration 3.5.6 Speaker Connectors (SPK_L_OUT1, SPK_R_OUT1) Connector Location: SPK_L_OUT1 Description: Speaker Out Connector (Left side) PIN ASSIGNMENT AMP_OUTL+ AMP_OUTL- SPK_L_OUT1 Connector Location: SPK_R_OUT1 Description: Speaker Out Connector (Right side) PIN ASSIGNMENT AMP_OUTR+ AMP_OUTR- SPK_R_OUT1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-16...
Page 42: Digital Input / Output Connector (Jdio1)
Digital Input / Output Connector (JDIO1) Connector Location: JDIO1 Description: Digital Input / Output Connector ASSIGNMENT ASSIGNMENT DIN_0 DOUT_0 DIN_1 DOUT_1 DIN_2 DOUT_2 DIN_3 DOUT_3 DIN_4 DOUT_4 DIN_5 DOUT_5 DIN_6 DOUT_6 DIN_7 DOUT_7 JDIO1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-17...
Page 43: Front Panel Connector (Jfp1)
CPU Fan Connector signals: ASSIGNMENT VCC12 CPU_FAN1 3.5.9 Front Panel Connector (JFP1) Connector Location: JFP1 Description: Front Panel Connector ASSIGNMENT ASSIGNMENT HDD LED+ PWR LED+ HDD LED- PWR LED- JFP1 Power Button Reset Button KS-M220/KS-M221 SERIES USER MANUAL Page: 3-18...
Page 44: Battery Wafer (Jbat1)
Connector Location: JBAT1 Description: Battery Wafer ASSIGNMENT VBAT+ JBAT1 3.5.11 SPI Override Protection Selection (JP1) Jumper Location: JP1 Description: SPI Override Protection Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Disable (Default Setting) Enable Close Page: 3-19 KS-M220/KS-M221 SERIES USER MANUAL...
Page 45: Sata 3.0 Connector (Sata1)
Chapter 3 System Configuration 3.5.12 SATA 3.0 Connector (SATA1) Connector Location: SATA1 Description: Serial ATA (SATA) 6GB/s Connector SATA1 Serial ATA 6GB/s Connector (SATA1) signals: ASSIGNMENT TXPC TXNC RXNC RXPC KS-M220/KS-M221 SERIES USER MANUAL Page: 3-20...
Page 46: Sata Power Connector (Jhdd_Pwr1)
Chapter 3 System Configuration 3.5.13 SATA Power Connector (JHDD_PWR1) Connector Location: JHDD_PWR1 Description: Serial ATA Power Connector SATA Power Connector signals: ASSIGNMENT JHDD_PWR1 3.5.14 I2C Wafer (JI2C1) Connector Location: JI2C1 Description: I2C Wafer ASSIGNMENT I2C0_SCL I2C0_SDA JI2C1 Page: 3-21 KS-M220/KS-M221 SERIES USER MANUAL...
Page 47: Lvds Connector (Jlvds1)
LVDS Connector (JLVDS1) Connector Location: JLVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT +3.3V/+5V LVDS_CLKBM LVDS_CLKBP LVDS_YBM2 LVDS_YBP2 LVDS_YBM1 LVDS_YBP1 LVDS_YBP3 LVDS_YBM3 LVDS_YBP0 LVDS_YBM0 LVDS_CLKAP LVDS_CLKAM LVDS_YAP2 LVDS_YAM2 LVDS_YAP1 LVDS_YAM1 LVDS_YAP0 LVDS_YAM0 JLVDS1 LVDS_YAP3 LVDS_YAM3 +3.3V/+5V +3.3V/+5V KS-M220/KS-M221 SERIES USER MANUAL Page: 3-22...
Page 48: Panel Inverter Connector (Jinv1)
Chapter 3 System Configuration 3.5.16 Panel Inverter Connector (JINV1) Connector Location: JINV1 Description: Panel Inverter Connector ASSIGNMENT +12V Backlight PWM Backlight Enable JINV1 Page: 3-23 KS-M220/KS-M221 SERIES USER MANUAL...
Page 49: Mini Pci Express Slot (M_Pcie1)
Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-24...
Page 50: Msata Connector (M_Sata1)
Connector (M_SATA1) Connector Location: M_SATA1 Description: mSATA Slot ASSIGNMENT ASSIGNMENT 3.3V mSATA1_RX_DP 3.3V mSATA1_RX_DN M_SATA1 mSATA1_TX_DN mSATA1_TX_DP USB2_P9_DN USB2_P9_DP 3.3V 3.3V 3.3V Note: The USB function is only supported on Core-i5 / i3 SoC boards. Page: 3-25 KS-M220/KS-M221 SERIES USER MANUAL...
Page 51: Slide Switch For Lvds Resolution Selection (Sw1)
Description: LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 1024 x 768 Channel S/8bit (Default Setting) 800 x 600 Channel S/6bit 1024 x 768 Channel S/6bit 1280 x 768 Channel S/6bit 1280 x 800 Channel S/6bit KS-M220/KS-M221 SERIES USER MANUAL Page: 3-26...
Page 52 Chapter 3 System Configuration SELECTION SETTING 1280 x 960 Channel S/6bit 1280 x 1024 Channel D/8bit 1366 x 768 Channel S/6bit 1366 x 768 Channel S/8bit 1440 x 900 Channel D/8bit 1400 x 1050 Channel D/8bit Page: 3-27 KS-M220/KS-M221 SERIES USER MANUAL...
Page 53 Chapter 3 System Configuration SELECTION SETTING 1600 x 900 Channel D/8bit 1680 x 1050 Channel D/8bit 1600 x 1200 Channel D/8bit 1920 x 1080 Channel D/8bit 1920 x 1200 Channel D/8bit KS-M220/KS-M221 SERIES USER MANUAL Page: 3-28...
Page 54: Lvds Vcc Selection (Jp5)
Chapter 3 System Configuration 3.5.20 LVDS VCC Selection (JP5) Jumper Location: JP5 Description: LVDS VCC Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) Page: 3-29 KS-M220/KS-M221 SERIES USER MANUAL...
Page 55: Backlight Pwm Level Selection (Jp6)
Chapter 3 System Configuration 3.5.21 Backlight PWM Level Selection (JP6) Jumper Location: JP6 Description: Backlight PWM Level Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) KS-M220/KS-M221 SERIES USER MANUAL Page: 3-30...
Page 56: V3P3 Mpcie Selection (Jp9)
Chapter 3 System Configuration 3.5.22 V3P3 MPCIE Selection (JP9) Jumper Location: JP9 Description: V3P3 MPCIE Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION VCC3_3 (Default Setting) V3P3A Page: 3-31 KS-M220/KS-M221 SERIES USER MANUAL...
Page 57: Clear Cmos Data Selection (Jcmos1)
Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Open Normal (Default Setting) JCMOS1 Clear CMOS Close Data JCMOS1 Note: Please make sure the main power is off before you clear CMOS. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-32...
Page 58: Ks-M221 Entry Level System Jumper & Connector Quick
Mini PCI Express Slot M_PCIE1 mSATA Connector M_SATA1 LVDS Connector LVDS1 Front Panel Connector JFP1 HD Audio Connector AUDIO1 Panel Inverter Connector JINV1 SATA 3.0 Connector SATA1 SATA Power Connector SATA_PWR1 BIOS Reset Connector Page: 3-33 KS-M220/KS-M221 SERIES USER MANUAL...
Page 59: 3.7 Ks-M221 Entry Level System Component Locations
CAUTION: Always touch the motherboard components by the edges. Never touch components such as a processor by its pins. Take special cares while you are holding electronic circuit boards by the edges only. Do not touch the mainboard components. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-34...
Page 60: Jumper Setting Of Be-0986Rb
COM2 SATA_PWR1 LVDS Backlight M_SATA1 Control Selection COM1 SO_DIMM1 JFP1 3.3V M_PCIE1 (default) AUDIO1 Clear CMOS Data Normal Clear CMOS (default) LVDS1 JBAT1 PWR2 USB3 LVDS VCC Voltage FAN1 JINV1 JP_VDD1 SATA1 3.3V (default) Page: 3-35 KS-M220/KS-M221 SERIES USER MANUAL...
Page 61: Bottom View Of Be-0986Rb
Chapter 3 System Configuration 3.7.3 Bottom View of BE-0986RB 3.7.4 I/O View of BE-0986RB USB 3.0 HDMI KS-M220/KS-M221 SERIES USER MANUAL Page: 3-36...
Page 62: 3.8 Setting Ks-M221 Entry Level Connectors And Jumpers
COM3 and COM4 PIN9 Definition Selection Guide (JP_COM3, JP_COM4) Jumper Location: JP_COM3, JP_COM4 Description: COM3 and COM4 Port pin9 RI/5V/12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM3 JP_COM4 +12V JP_COM3 JP_COM4 JP_COM4 JP_COM3 Page: 3-37 KS-M220/KS-M221 SERIES USER MANUAL...
Page 63: Com Port (Com1, Com2, Com3, Com4)
COM2 (RS-485) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT Notes: COM2 is selectable as RS232, RS422, RS485 by BIOS setting. Default setting is RS232. Please see Chapter 5 “Advanced – Onboard Device Configuration” for selection details. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-38...
Page 64 COM4_CTS COM4_DTR COM4_RI_SEL Note: COM3, COM4: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI, please see “COM3 and COM4 PIN9 Definition Selection Guide” for selection details. Page: 3-39 KS-M220/KS-M221 SERIES USER MANUAL...
Page 65: Vga Port (Vga1)
VGA1 PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT CRT_RED CRT_GREEN CRT_DATA CRT_BLUE CRT_HSYNC CRT_VCC CRT_VSYNC CRT_CLK 3.8.4 HDMI Port (HDMI1) Port Location: HDMI1 Description: HDMI Port Connector ASSIGNMENT ASSIGNMENT HOT_PLUG_DET I2C_DATA I2C_CLK CLK- CLK+ HDMI1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-40...
Page 66: Lan Port (Lan1, Lan2)
Status Description Yellow Blink LAN Message Active Right Side LED No LAN Message Active Green 10/100Mbps LAN connection is enabled. Left Side LED Orange Giga LAN connection is enabled. No LAN switch/hub is connected Page: 3-41 KS-M220/KS-M221 SERIES USER MANUAL...
Page 67: Dual Usb 3.0 Port (Usb1)
USB 3.0 Port (USB2) Port Location: USB2 Description: USB 3.0 port x 2 USB 3.0 signals PIN ASSIGNMENT PIN ASSIGNMENT USB3_RXN2 USB3_RXP2 USB2_P2_DP USB3_TXN2 USB2_P2_DN USB3_TXP2 VCC5_USB1 USB2 USB3_RXN1 USB3_RXP1 USB2_P1_DP USB3_TXN1 USB2_P1_DN USB3_TXP1 VCC5_USB1 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-42...
Page 68: Usb 2.0 Port (Usb3)
GPI/GPO 3 GPI/GPO 7 Notes: Users can set the GPI/GPO configuration via Protech’s API/Utility. Default setting is GPI every time when system AC power is re-applied from power failure state Configuration can still be kept even in S5 state unless system AC power is lost.
Page 69: Mcu Fw Rewrite Connector (Jmcu1)
API document for more details. 3.8.13 DC Power Input Connector (PWR2) Connector Location: PWR2 Description: DC Power Input Connector PIN ASSIGNMENT PIN ASSIGNMENT VCC12 VCC12 PWR2 Note: The voltage of input power should be 12V or 16~24V. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-44...
Page 70: Mini Pci Express Slot (M_Pcie1)
Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. Page: 3-45 KS-M220/KS-M221 SERIES USER MANUAL...
Page 71: Msata Connector (M_Sata1)
Chapter 3 System Configuration 3.8.15 mSATA Connector (M_SATA1) Connector Location: M_SATA1 Description: mSATA Slot (USB type mPCIe card is supported.) ASSIGNMENT ASSIGNMENT V3P3S_MSATA SATA_RXP1 V3P3S_MSATA SATA_RXN1 M_SATA1 SATA_TXN1 SATA_TXP1 USB2_P0_DN USB2_P0_DP V3P3S_MSATA V3P3S_MSATA V3P3S_MSATA KS-M220/KS-M221 SERIES USER MANUAL Page: 3-46...
Page 72: Lvds Connector (Lvds1)
LVDS Connector (LVDS1) Connector Location: LVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKB_DP LVDS_CLKB_DN LVDS_B2_DN LVDS1 LVDS_B2_DP LVDS_B1_DP LVDS_B1_DN LVDS_B3_DN LVDS_B3_DP LVDS_B0_DN LVDS_B0_DP LVDS_CLKA_DP LVDS_CLKA_DN LVDS_A2_DN LVDS_A2_DP LVDS_A1_DP LVDS_A1_DN LVDS_A0_DN LVDS_A0_DP LVDS_A3_DN LVDS_A3_DP LVDS_VCC LVDS_VCC Page: 3-47 KS-M220/KS-M221 SERIES USER MANUAL...
Page 73: Slide Switch For Lvds Resolution Selection (Sw1)
Jumper Location: SW1 Description: Slide Switch for LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 800 x 600 1CH/18bit (Default Setting) 1024 x 768 1CH/18bit 1024 x 768 1CH/24bit 1280 x 768 1CH/18bit 1280 x 800 1CH/18bit KS-M220/KS-M221 SERIES USER MANUAL Page: 3-48...
Page 74 Chapter 3 System Configuration SELECTION SETTING 1280 x 960 1CH/18bit 1280 x 1024 2CH/24bit 1366 x 768 1CH/18bit 1366 x 768 1CH/24bit 1440 x 900 2CH/24bit 1400 x 1050 2CH/24bit Page: 3-49 KS-M220/KS-M221 SERIES USER MANUAL...
Page 75 Chapter 3 System Configuration SELECTION SETTING 1600 x 900 2CH/24bit 1680 x 1050 2CH/24bit 1600 x 1200 2CH/24bit 1920 x 1080 2CH/24bit 1920 x 1200 2CH/24bit KS-M220/KS-M221 SERIES USER MANUAL Page: 3-50...
Page 76: Front Panel Connector (Jfp1)
RESET BTN POWER BTN 3.8.19 HD Audio Connector (AUDIO1) Connector Location: AUDIO1 Description: HD Audio Connector for Line In/Line Out/Mic In ASSIGNMENT ASSIGNMENT LINE-OUT-L LINE-OUT-L HD_GND HD_GND HD_LINE-IN-R HD_LINE-IN-L HD_GND HD_GND HD_MIC1-R HD_MIC1-L AUDIO1 Page: 3-51 KS-M220/KS-M221 SERIES USER MANUAL...
Page 77: Panel Inverter Connector (Jinv1)
SATA 3.0 Connector (SATA1) Connector Location: SATA1 Description: Serial ATA 3.0 Connector ASSIGNMENT SATA1 SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA_RXP0 3.8.22 SATA Power Connector (SATA_PWR1) Connector Location: SATA_PWR1 Description: Serial ATA Power Connector ASSIGNMENT SATA_PWR1 VCC5 KS-M220/KS-M221 SERIES USER MANUAL Page: 3-52...
Page 78: Bios Reset Connector (Jp9)
BIOS Reset Connector (JP9) Jumper Location: JP9 Description: BIOS Reset Usage Connector This connector is only for Protech's engineers. (Purpose: BIOS reset). Please do not use this connector; otherwise, the system might be crashed. 3.8.24 LVDS Backlight Control Selection (JP7) Jumper Location: JP7 Description: Jumper for selecting PIN4 (LVDS_BKLCTL) voltage of JINV1.
Page 79: Lvds Vcc Voltage Selection (Jp_Vdd1)
Description: Voltage selection jumper for selecting PIN1, PIN29, PIN30 (LVDS_VCC) voltage of LVDS1. JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V (Default Setting) JP_VDD1 JP_VDD1 Note: Please refer to PANEL INVERTER CONNECTOR for more information about pin definition of JINV1. KS-M220/KS-M221 SERIES USER MANUAL Page: 3-54...
Page 80: Clear Cmos Data Selection (Jp4)
Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Normal (Default Setting) Clear CMOS* Page: 3-55 KS-M220/KS-M221 SERIES USER MANUAL...
Page 81: Software Utilities
Chipset Software Installation Utility • Installing Graphics Driver Utility • Installing Sound Driver Utility • Installing LAN Driver Utility • Installing Microsoft Hotfix kb3211320 and kb3213986 Driver • ® Installing Intel Serial I/O Driver Utility KS-M220/KS-M221 SERIES USER MANUAL Page: 4-1...
Page 82: 4.1 Driver And Os Support For High-End Level System
Chapter 4 Software Utilities 4.1 Driver and OS Support For High-End Level System Enclosed with the KS-M220 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: For Windows 10 OS:...
Page 83: Installing Intel Chipset Software Installation Utility
The utility pack is to be installed only for Windows 10 (64-bit), and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).
Page 84: Installing Graphics Driver Utility
DP and HDMI interfaces and make the system work simultaneously. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Enter the Graphics folder where the driver is located (depending on your OS platform).
Page 85: Installing Lan Driver Utility
Enhanced with LAN function, KS-M220 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).
Page 86: Installing Sound Driver Utility
4.1.4 Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).
Page 87: Intel ® Management Engine Components Installer Installation
® Installation Instructions for Intel Management Engine Components Installer Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Enter the ME folder where the driver is located. Select Windows 10 (64-bit) for your OS platform. Click Setup.exe file for ME driver installation.
Page 88: Installing Intel Serial I/O Driver Utility
Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M220 and insert the driver disk. Open the Serial I/O folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.
Page 89: 4.2 Driver And Os Support For Entry Level System
® D:\BE-0986_V1.0\Driver\Platform Intel Serial I/O driver for  \Serial IO Windows 10 D:\Driver\Device Driver Installation for Barcode  Scanner and Thermal Printer Note: Install the driver utilities immediately after the OS installation is completed. KS-M220/KS-M221 SERIES USER MANUAL Page: 4-9...
Page 90: Installing Intel Chipset Software Installation Utility
Enter the Main Chip folder where the Chipset driver is located. Click Setup.exe file for driver installation. Follow the on-screen instructions to install the driver. Once the installation is completed, shut down the system and restart KS-M221 for the changes to take effect. Page: 4-10 KS-M220/KS-M221 SERIES USER MANUAL...
Page 91: Installing Graphics Driver Utility
Enter the Graphics folder where the driver is located. Click the Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart KS-M221 for the changes to take effect. KS-M220/KS-M221 SERIES USER MANUAL Page: 4-11...
Page 92: Installing Lan Driver Utility
Once the installation is completed, shut down the system and restart KS-M221 for the changes to take effect. For more details on the installation procedure, refer to the Readme.txt file that you can find on LAN Driver Utility. Page: 4-12 KS-M220/KS-M221 SERIES USER MANUAL...
Page 93: Installing Sound Driver Utility
Open the Sound folder where the driver is located. Click the Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart KS-M221 for the changes to take effect. KS-M220/KS-M221 SERIES USER MANUAL Page: 4-13...
Page 94: Microsoft Hotfix Kb3211320 And Kb3213986 Driver
Click the windows10.0-kb3211320-x64 and windows10.0-kb3213986-x64 files for critical security update. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart BE-0986 for the changes to take effect. Page: 4-14 KS-M220/KS-M221 SERIES USER MANUAL...
Page 95: Installing Intel Serial I/O Driver Utility
Select Windows 10 (64-bit) for your OS platform. Click the Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart KS-M221 for the changes to take effect. KS-M220/KS-M221 SERIES USER MANUAL Page: 4-15...
Page 96: Bios Setup
The BIOS Setup Utilities consist of the following menu items: • Main Menu • Advanced Menu • Chipset Menu • Boot Menu • Security Menu • Save & Exit Menu KS-M220/KS-M221 SERIES USER MANUAL Page: 5-1...
Page 97: 5.1 Introduction
Chapter 5 BIOS Setup 5.1 Introduction The KS-M220 / KS-M221 System uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the...
Page 98 After the system is powered on, users can access the BIOS setup menu by pressing <Del> or <Esc> immediately while the POST message is running before the operating system is loading. All the menu settings are described in details in this chapter. Page: 5-3 KS-M220/KS-M221 SERIES USER MANUAL...
Page 99: Accessing Setup Utility For Ks-M220 High-End Level System
Chapter 5 BIOS Setup 5.2 Accessing Setup Utility for KS-M220 High-End Level System After the system is powered on, BIOS will enter the Power-On Self-Test (POST) routines and the POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del>...
Page 100 US English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. Page: 5-5 KS-M220/KS-M221 SERIES USER MANUAL...
Page 101 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-6...
Page 102: Main
Displays the date that the current BIOS Time version is built. Built-in Display - Disabled Enables/Disables Built-in Display - Enabled (LVDS). It is recommended to disable Built-in Display function for the system without LVDS. Page: 5-7 KS-M220/KS-M221 SERIES USER MANUAL...
Page 103 The “Day” is automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-8...
Page 104: Advanced
System Super I/O Chip Parameters. Configuration Hardware Monitor Sub-Menu Monitor hardware status. F81866 Watchdog Sub-Menu F81866 Watchdog Parameters. USB Configuration Sub-Menu USB Configuration Parameters. Enables system to wake from S5 using S5 RTC Wake Settings Sub-Menu RTC alarm. Page: 5-9 KS-M220/KS-M221 SERIES USER MANUAL...
Page 105: Advanced - Cpu Configuration
Displays the CPU Speed. Displays the number of CPU Number of Processors No changeable options processors. CPU VMX hardware support for virtual No changeable options machines. SMX (Secure Mode No changeable options Secure Mode extensions support. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-10...
Page 106: Advanced - Sata Configuration
The SATA Configuration allows users to enable / disable the SATA controller as well as the operational mode after the SATA controller is enabled. The following screen indicates the functions available when the SATA controller is enabled and the AHCI mode is selected. SATA Configuration Screen Page: 5-11 KS-M220/KS-M221 SERIES USER MANUAL...
Page 107: Advanced - Pch-Fw Configuration
Advanced – PCH-FW Configuration Menu Path Advanced > PCH-FW Configuration The PCH-FW allows users to view the information about ME (Management Engine) firmware information, such ME firmware version, firmware mode and firmware SKU. PCH-FW Configuration Screen KS-M220/KS-M221 SERIES USER MANUAL Page: 5-12...
Page 108: Advanced - Trusted Computing
The operating system will not show Security Device. The TCG EFI protocol and INT1A interface will not be available. Trusted Computing Screen *Trusted Computing Screen function is supported for "CPU i5-7300U" SKU only. Page: 5-13 KS-M220/KS-M221 SERIES USER MANUAL...
Page 109 TPM 2.0: Restricts support to TPM 2.0 devices • Auto: Supports both TPM 1.2 and TPM 2.0 with the default setting set to TPM 2.0 devices if not found. TPM 1.2 devices will be enumerated. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-14...
Page 110: Advanced - Acpi Settings
SUSPEND button is pressed. - Disabled Enables or Disables Lock of Legacy Lock Legacy Resources - Enabled Resources. - Disabled S3 Video Repost Enables or Disables S3 Video Repost. - Enabled Page: 5-15 KS-M220/KS-M221 SERIES USER MANUAL...
Page 111: Advanced - F81866 Super Io Configuration
The F81866 Super IO Configuration allows users to configure the serial ports 1-2. F81866 Super IO Configuration Screen BIOS Setting Options Description/Purpose Configures Parameters of Serial Port Serial Port 1 Configuration Sub-Menu 1 (COMA). Configures Parameters of Serial Port Serial Port 2 Configuration Sub-Menu 2 (COMB). KS-M220/KS-M221 SERIES USER MANUAL Page: 5-16...
Page 112 No changeable options Serial Port 1. - Auto Selects IRQ and I/O resource - IO=3F8h; IRQ=4; settings for Serial Port 1. - IO=3F8h; IRQ=3,4,5,7,10,11,12; Change Settings - IO=2F8h; IRQ=3,4,5,7,10,11,12; - IO=3E8h; IRQ=3,4,5,7,10,11,12; - IO=2E8h; IRQ=3,4,5,7,10,11,12; Page: 5-17 KS-M220/KS-M221 SERIES USER MANUAL...
Page 113 Selects IRQ and I/O resource - IO=2F8h; IRQ=3; settings for Serial Port 2. - IO=3F8h; IRQ=3,4,5,7,10,11,12; - IO=2F8h; IRQ=3,4,5,7,10,11,12; - IO=3E8h; IRQ=3,4,5,7,10,11,12; - IO=2E8h; IRQ=3,4,5,7,10,11,12; Mode - RS-232 Selects COM2 mode. - RS-422 - RS-485 KS-M220/KS-M221 SERIES USER MANUAL Page: 5-18...
Page 114: Advanced - Hardware Monitor
System temperature No changeable options Displays the system temperature. CPU Fan Speed No changeable options Displays CPU Fan speed. Detects and displays the voltage VCORE No changeable options level of the VCORE in supply. Page: 5-19 KS-M220/KS-M221 SERIES USER MANUAL...
Page 115 VSB3V in supply. Detects and displays the battery VBAT No changeable options voltage. Smart Fan Mode Configuration Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration Smart Fan Mode Configuration Screen KS-M220/KS-M221 SERIES USER MANUAL Page: 5-20...
Page 116: Advanced - F81866 Watchdog
Enables/Disables F81866 Watchdog Enable Watchdog - Disabled timer settings. - 1s Watchdog timer unit Watchdog timer unit. - 60s Numeric (from 1 to 255) The number of count for Timer. Count for Timer (Seconds) Page: 5-21 KS-M220/KS-M221 SERIES USER MANUAL...
Page 117: Advanced - S5 Rtc Wake Settings
Allows enabling scheduled S5 to S0 - Fixed Time (option enabled). • - Dynamic Time Fixed Time: System will wake on the hr::min::sec specified. • Dynamic Time: System will wake on the current time + Increased minute(s). KS-M220/KS-M221 SERIES USER MANUAL Page: 5-22...
Page 118 Multiple options ranging from Specifies a minute for a schedule Wake up minute 0 to 59 power-on event. Multiple options ranging from Specifies a second for a schedule Wake up second 0 to 59 power-on event. Page: 5-23 KS-M220/KS-M221 SERIES USER MANUAL...
Page 119 + Dynamic Time (selected) Increased minute(s). Specifies a period of time (in Multiple options ranging Wake up minute increase minutes) after which the board wakes from 1 to 5 up from S5 state. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-24...
Page 120: Advanced - Usb Configuration
Advanced > USB Configuration The USB Configuration allows users to configure advanced USB settings such as legacy USB support. USB Configuration Screen BIOS Setting Options Description/Purpose - Disabled Legacy USB Support Enables/Disables Legacy USB Support. - Enabled Page: 5-25 KS-M220/KS-M221 SERIES USER MANUAL...
Page 121: Advanced - Network Stack Configuration
- Disabled Ipv4 PXE Support disabled, Ipv4 PXE boot option will - Enabled not be created. - Disabled Enables Ipv6 PXE Boot Support. If Ipv6 PXE Support - Enabled disabled, Ipv6 PXE boot option will KS-M220/KS-M221 SERIES USER MANUAL Page: 5-26...
Page 122 PXE boot wait time Numeric (from 0 to 5) boot to abort after the Esc key is pressed. Number of times that the media Media detect count Numeric (from 1 to 50) presence will be checked. Page: 5-27 KS-M220/KS-M221 SERIES USER MANUAL...
Page 123: Chipset
This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Sub-Menu System Agent (SA) Parameters. Configuration PCH-IO Configuration Sub-Menu PCH Parameters. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-28...
Page 124: Chipset - System Agent (Sa) Configuration
SA PCIe Code Version No changeable options Displays the SA PCIe Code Version. VT-d No changeable options Supports VT-d capability. Memory Configuration Sub-Menu Memory Configuration. - Disabled VT-d Enables or Disables VT-d function. - Enabled Page: 5-29 KS-M220/KS-M221 SERIES USER MANUAL...
Page 125 No changeable options Displays the Memory Timings. (tCL-tRCD-tRP-tRAS) Displays the populated and enabled Channel 0 Slot 0 No changeable options channel and slot. Size No changeable options Displays the size of Channel 0 Slot 0. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-30...
Page 126: Chipset - Pch Io Configuratioin
Sub-Menu PCI Express Configuration settings. - Disabled PCH LAN Controller Enables or Disables onboard NIC. - Enabled - Disabled Enables or Disables integrated LAN Wake on LAN Enable - Enabled to wake the system. Page: 5-31 KS-M220/KS-M221 SERIES USER MANUAL...
Page 127 BIOS Setting Options Description/Purpose Displays the LAN assigned PCIE PCIE Port assigned to LAN No changeable options Port. Mini PCIe/ mSATA combo - Mini PCIe Mini PCIe/ mSATA combo port port - mSATA selection. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-32...
Page 128: Security
Setup utility than a user. Heed that a user password does not provide access to most of the features in the Setup utility. Security Screen BIOS Setting Options Description/Purpose Password can be 3-20 Specifies the administrator Administrator Password alphanumeric characters. password. Page: 5-33 KS-M220/KS-M221 SERIES USER MANUAL...
Page 129 <Enter>, and the password dialog entry box appears. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-34...
Page 130: Boot
Enables or Disables Quiet Boot Quiet Boot - Enabled options. - Disabled Enables or Disables Fast Boot Fast Boot - Enabled options. - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled Page: 5-35 KS-M220/KS-M221 SERIES USER MANUAL...
Page 131: Save & Exit
Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen KS-M220/KS-M221 SERIES USER MANUAL Page: 5-36...
Page 132 Save as User Defaults No changeable options User Defaults. Restores the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. Page: 5-37 KS-M220/KS-M221 SERIES USER MANUAL...
Page 133: Accessing Setup Utility For Ks-M221 Entry Level System
POST message will be displayed: POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: KS-M220/KS-M221 SERIES USER MANUAL Page: 5-38...
Page 134 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. Page: 5-39 KS-M220/KS-M221 SERIES USER MANUAL...
Page 135 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. Close the sub-menu. <Esc> Trigger the confirmation to exit BIOS setup menu. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-40...
Page 136: Main
Project Version No changeable options currently installed on the platform. Displays the date of current BIOS Build Date and Time No changeable options version. Access Level No changeable options Displays the current access level. Page: 5-41 KS-M220/KS-M221 SERIES USER MANUAL...
Page 137 TXE FW No changeable options Displays the TXE FW version. No changeable options Displays the GOP version. System Date month, day, year Specifies the current date. System Time hour, minute, second Specifies the current time. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-42...
Page 138: Advanced
System ACPI parameters. Onboard Device Configuration Sub-Menu Project specific parameters. Hardware Monitor Sub-Menu Monitor hardware status. F81964 Watchdog Sub-Menu Watchdog timer parameters. S5 RTC Wake Settings Sub-Menu RTC wake parameters. CPU Configuration Sub-Menu CPU configuration parameters. Page: 5-43 KS-M220/KS-M221 SERIES USER MANUAL...
Page 139 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose F81964 Super IO Configuration Sub-Menu System Super IO chip parameters USB Configuration Sub-Menu USB configuration parameters. Platform Trust Technology Sub-Menu Platform Trust Technology. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-44...
Page 140: Advanced - Acpi Settings
Hibernate (OS/S4 Sleep State). This Enable Hibernation (S4) -Enabled (default) option may be not effective with some OS. -Disabled Enables or Disables System ability to Enable Sleep (S3) -Enabled (default) Sleep (OS/S3 Sleep State). Page: 5-45 KS-M220/KS-M221 SERIES USER MANUAL...
Page 141: Advanced - Onboard Device Configuration
5.3.2.2 Advanced - Onboard Device Configuration Menu Path Advanced > Onboard Device Configuration Onboard Device Configuration Screen BIOS Setting Options Description/Purpose - RS-422 COM2 Mode Selection - RS-232 (default) Selects COM2 mode. - RS-485 KS-M220/KS-M221 SERIES USER MANUAL Page: 5-46...
Page 142: Advanced - Hardware Monitor
No changeable options Displays fan speed of the system fan. Displays the voltage level of VCORE in VCORE No changeable options supply. Displays the voltage level of VCC12V in VCC12V No changeable options supply. Page: 5-47 KS-M220/KS-M221 SERIES USER MANUAL...
Page 143 Displays the voltage level of VCC5V in VCC5V No changeable options supply. Displays the voltage level of VSB5V in VSB5V No changeable options supply. Displays the voltage level of VBAT in VBAT No changeable options supply. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-48...
Page 144 (speed) (default) will be increased or decreased linearly according to system temperature. The rule is as follows: < 40°C: 40% 40~50°C: 40~50% 50~60°C: 50~70% 60~65°C: 70~100% > 65°C: 100% Page: 5-49 KS-M220/KS-M221 SERIES USER MANUAL...
Page 145 Configuration [Manual Duty Mode] Smart Fan Mode Configuration Screen BIOS Setting Options Description/Purpose Manual Duty Mode Users can select expected duty cycle -30% (PWM fan type). -40% -50% -60% -70% -80% -90% - Full Speed (default) KS-M220/KS-M221 SERIES USER MANUAL Page: 5-50...
Page 146: Advanced - F81964 Watchdog
- Disabled (default) Enables / Disables F81846 Watchdog Enable Watchdog - Enabled timer settings. Multiple options Selects count of watchdog timer. Watchdog Timer Count ranging from 10 to 255 Watchdog Timer = 1sec * Count Page: 5-51 KS-M220/KS-M221 SERIES USER MANUAL...
Page 147: Advanced - S5 Rtc Wake Settings
• FixedTime: System will wake on - Disabled (default) Wake system from S5 - Fixed Time the hr::min::sec specified. • Dynamic Time: System will - Dynamic Time wake on the current time + Increased minute(s) KS-M220/KS-M221 SERIES USER MANUAL Page: 5-52...
Page 148 Sets a minute for a scheduled Wake up minute ranging from 0 to 59 power-on event. Multiple options Sets a second for a scheduled Wake up second ranging from 0 to 59 power-on event. Page: 5-53 KS-M220/KS-M221 SERIES USER MANUAL...
Page 149 S5 RTC Wake Setting Screen BIOS Setting Options Description/Purpose Sets a period of time (in minutes) to Multiple options Wake up minute increase wake up the system after it enters S5 ranging from 1 to 5 state. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-54...
Page 150: Advanced - Cpu Configuration
CPU power management options. When enabled, a VMM can utilize the Intel Virtualization - Disabled additional hardware capabilities Technology - Enabled (default) provided by Vanderpool Technology - Disabled (default) VT-d Enables / Disables CPU VT-d. - Enabled Page: 5-55 KS-M220/KS-M221 SERIES USER MANUAL...
Page 151 L1 Data Cache No changeable options L1 Data Cache size. L1 Code Cache No changeable options L1 Code Cache size. L2 Cache No changeable options L2 Cache size. L3 Cache No changeable options L3 Cache size. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-56...
Page 152 Advanced > CPU Configuration > CPU Power Management CPU Power Management Configuration Screen BIOS Setting Options Description/Purpose Enables / Disables Intel Speed Step - Disabled EIST feature for dynamic scaling processor - Enabled (default) frequency. Page: 5-57 KS-M220/KS-M221 SERIES USER MANUAL...
Page 153: Advanced - F81964 Super Io Configuration
No changeable options Displays the super I/O chip model. Serial Port 1 Configuration Sub-Menu COM1 parameters configuration. Serial Port 2 Configuration Sub-Menu COM2 parameters configuration. Serial Port 3 Configuration Sub-Menu COM3 parameters configuration. Serial Port 4 Configuration Sub-Menu COM4 parameters configuration. KS-M220/KS-M221 SERIES USER MANUAL Page: 5-58...
Page 154 Allows user to change Device's - IO=3F8h; IRQ=4 Resource settings. New settings - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; Page: 5-59 KS-M220/KS-M221 SERIES USER MANUAL...
Page 155 Allows users to change Device's - IO=2F8h; IRQ=3 Resource settings. New settings - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; KS-M220/KS-M221 SERIES USER MANUAL Page: 5-60...
Page 156 Allows users to change Device's - IO=3E8h; IRQ=7 Resource settings. New settings - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup Change Settings - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2F0h; IRQ=3,4,5,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,7,9,10,11,12; Page: 5-61 KS-M220/KS-M221 SERIES USER MANUAL...
Page 157 Allows user to change Device's - IO=2E8h; IRQ=10 Resource settings. New settings will - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; be reflected on this Setup Page after Change Settings - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; System restarts. - IO=2F0h; IRQ=3,4,5,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,7,9,10,11,12 KS-M220/KS-M221 SERIES USER MANUAL Page: 5-62...
Page 158: Advanced - Usb Configuration
- Floppy MASS STORAGE Optical drives are emulated as - Forced FDD DEVICES: [drive(s)] 'CD-ROM'. Drives with no media - Hard Disk will be emulated according to a drive - CD-ROM type. Page: 5-63 KS-M220/KS-M221 SERIES USER MANUAL...
Page 159: Advanced - Platform Trust Technology
Chapter 5 BIOS Setup 5.3.2.9 Advanced - Platform Trust Technology Menu Path Advanced > Platform Trust Technology Platform Trust Technology Screen BIOS Setting Options Description/Purpose - Enabled fTPM Enables / Disables fTPM. - Disabled (default) KS-M220/KS-M221 SERIES USER MANUAL Page: 5-64...
Page 160: Chipset
Chapter 5 BIOS Setup 5.3.3 Chipset Menu Path Chipset Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-Menu North Bridge Parameters. South Bridge Sub-Menu South Bridge Parameters. Page: 5-65 KS-M220/KS-M221 SERIES USER MANUAL...
Page 161: Chipset - North Bridge
"8192 MB (LPDDR3)". Memory Speed No changeable options Displays memory speed. Displays current amount and type of Memory Slot0 No changeable options memory on each memory slot, e.g. "8192 MB (LPDDR3)". KS-M220/KS-M221 SERIES USER MANUAL Page: 5-66...
Page 162: Chipset - South Bridge
Description/Purpose HD-Audio Configuration Sub-Menu HD-Audio configuration settings. LPSS Configuration Sub-Menu LPSS configuration settings. PCI Express Configuration Sub-Menu PCI Express configuration settings. SATA Drives Sub-Menu SATA Drives configuration settings. Miscellaneous Configuration Sub-Menu Miscellaneous configuration settings Page: 5-67 KS-M220/KS-M221 SERIES USER MANUAL...
Page 163 Chipset - South Bridge - HD-Audio Configuration Menu Path Chipset > South Bridge > HD-Audio Configuration HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disable HD-Audio Support Enables / Disables HD-Audio support. - Enable (default) KS-M220/KS-M221 SERIES USER MANUAL Page: 5-68...
Page 164 Enables / Disables LPSS I2C #1 (D22:F0) - Enable (default) support. - Standard Mode - Fast Mode (default) Set LPSS I2C #1 Speed Selects LPSS I2C #1 speed. - Fast Plus Mode - High Speed Mode Page: 5-69 KS-M220/KS-M221 SERIES USER MANUAL...
Page 165 PCI E Express Root Port 1 (I210 LAN) Sub-Menu PCIE RP1 parameters (I210 LAN). PCI E Express Root Port 2 (I210 LAN) Sub-Menu PCIE RP2 parameters (I210 LAN). PCI E Express Root Port 3 (Mini-PCIe) Sub-Menu PCIE RP3 parameters (Mini-PCIe). KS-M220/KS-M221 SERIES USER MANUAL Page: 5-70...
Page 166 PCI E Express Root Port 1 Enables / Disables PCIE root port 1 - Enable (I210 LAN) (I210 LAN). - Auto (default) - Auto (default) PCIe Speed - Gen1 Configures PCIe speed. - Gen2 Page: 5-71 KS-M220/KS-M221 SERIES USER MANUAL...
Page 167 - Disable PCI E Express Root Port 2 Enable/Disable PCIE root port 2 - Enable (I210 LAN) (I210 LAN). - Auto (default) - Auto (default) PCIe Speed - Gen1 Configure PCIe speed. - Gen2 KS-M220/KS-M221 SERIES USER MANUAL Page: 5-72...
Page 168 - Disable PCI E Express Root Port 3 Enables / Disables PCIE root port 3 - Enable (Mini-PCIe) (Mini-PCIe). - Auto (default) - Auto (default) PCIe Speed - Gen1 Configures PCIe speed. - Gen2 Page: 5-73 KS-M220/KS-M221 SERIES USER MANUAL...
Page 169 Enables / Disables SATA port 0. - Enabled (default) Displays SATA drive branding SATA Port 1 No changeable options information if device exists on port 1. - Disabled Port 1 Enables / Disables SATA port 1. - Enabled (default) KS-M220/KS-M221 SERIES USER MANUAL Page: 5-74...
Page 170 Enables or Disables the Wake-On - Enable (default) LAN (WOL) function. Win 8/8.1/10 don't support WOL from hybrid shutdown state (S4). If user needs WOL from classic shutdown state (S5), please turn off 'fast startup' feature in OS. Page: 5-75 KS-M220/KS-M221 SERIES USER MANUAL...
Page 171: Security
Administrator Password alphanumeric characters. password. Password can be 3-20 User Password Specifies the user password. alphanumeric characters. Enter the sub-menu with option to enable password-protected HDD Security Configuration Sub-Menu HDD/SSD (if supported by SATA device). KS-M220/KS-M221 SERIES USER MANUAL Page: 5-76...
Page 172: Boot
Enable or Disable Fast Boot options. - Enabled - Windows (default) OS Selection - Android Selects the targeted OS. - Intel Linux - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled Page: 5-77 KS-M220/KS-M221 SERIES USER MANUAL...
Page 173: Save & Exit
Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen KS-M220/KS-M221 SERIES USER MANUAL Page: 5-78...
Page 174 Save as User Defaults No changeable options Defaults. Restores the User Defaults to all the Restore User Defaults No changeable options BIOS settings. Forces to boot the system from Boot Override - [Drive(s)] selected [drive(s)]. Page: 5-79 KS-M220/KS-M221 SERIES USER MANUAL...
Page 175: Appendix A System Diagrams
Appendix A System Diagrams This appendix provides the easy maintenance diagrams, system exploded diagrams and part numbers of KS-M220 / KS-M221 system. The following topics are included: • Easy Maintenance • KS-M220 / KS-M221 KDS Body Exploded Diagrams • KS-M220 / KS-M221 KDS Control Box Exploded Diagrams •...
Page 176 Installing Box PC Step 1. Insert the Box PC into the KDS and insert the key to lock up. Step 2. Pull out the key and fasten back the 2 screws to complete. Box PC KS-M220/KS-M221 SERIES USER MANUAL Page: A-2...
Page 177 Step 2. Fasten the 2 screws numbered “2” as shown to complete. Disassembling Tripod Step 1. Fasten the 6 screws numbered “1” in the drawing below. Step 2. Fasten the 2 screws numbered “2” as shown to complete. Page: A-3 KS-M220/KS-M221 SERIES USER MANUAL...
Page 178 Step 1. Insert KDS from top to bottom. Step 2. Fasten the two screws (numbered 2) in the drawing below. Step 3. Fasten the six nuts (numbered 1) in the drawing below to complete. KS-M220/KS-M221 SERIES USER MANUAL Page: A-4...
Page 179 Step 1. Insert KDS onto the Cash Pay central cabinet. Step 2. Fasten the 2 screws (numbered 2) in the drawing below. Step 3. Fasten the 6 nuts (numbered 1) in the drawing below to complete. Page: A-5 KS-M220/KS-M221 SERIES USER MANUAL...
Page 180 20-206-02116482 KS-M220 KDS MOUNT BRACKET-RAIL Step 2. Install the sleeve anchors into the intended locations. Note that the sleeve should be installed inside the wall.
Page 181 Step 3. Fix the KDS mount bracket-rail onto the wall: Step 4. Fasten 2 mount bracket-hook (P/N: 202-206-02115482) onto the rear of KDS with 4 screws (M6x1.0Px12mm (P/N: 22-251-60012011). Fasten two KDS mount Tighten 4 screws bracket-hooks. (M6x1.0Px12mm). Page: A-7 KS-M220/KS-M221 SERIES USER MANUAL...
Page 182 Step 5. Attach the KDS installed with the mount bracket-hook onto the mount bracket-rail fixed on the wall. Step 6. Adjust KDS to secure the mount bracket-hook into mount bracket-rail firmly. Step 7. Fasten the two M6x25mm (P/N: 22-225-60025031) screws to complete the installation. KS-M220/KS-M221 SERIES USER MANUAL Page: A-8...
Page 183 20-206-02116482 KS-M220 KDS MOUNT BRACKET-RAIL Step 2. Install the sleeve anchors into the intended locations. Note that the sleeve should be installed inside the wall.
Page 184 Step 3. Fix the KDS mount bracket-rail onto the wall: Step 4. Fasten 2 mount bracket-hook (P/N: 202-206-02115482) onto the rear of KDS with 4 screws (M6x1.0Px12mm (P/N: 22-251-60012011). Tighten 4 screws Fasten two KDS mount (M6x1.0Px12mm) bracket-hooks. KS-M220/KS-M221 SERIES USER MANUAL Page: A-10...
Page 185 Step 5. Attach the KDS installed with the mount bracket-hook onto the mount bracket-rail fixed on the wall. Step 6. Adjust KDS to secure the mount bracket-hook into mount bracket-rail firmly. Step 7. Fasten the two M6x25mm (P/N: 22-225-60025031) screws to complete the installation. Page: A-11 KS-M220/KS-M221 SERIES USER MANUAL...
Page 186 Appendix A System Diagrams KS-M220 / KS-M221 KDS Body Exploded Diagrams Step 1-1 ITEM Description Part No. Q’ty KS-M220 KDS L-TYPE BRACKET 20-206-02024482 (w/Plate) FLAT HEAD SCREW (M3x0.5Px6mm) 22-215-30006111 (Black) ROUND HEAD WITH SPRING 22-232-30060211 WASHER SCREW M3x0.5Px6mm KS-M220 KDS FRAME-L (Black)
Page 187 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 KDS FRAME-TOP (Black) 20-007-01004482 KS-M220 KDS FRAME-BTM (Black) 20-007-01001482 FLAT HEAD SCREW ψ6.4 / 22-215-40008711 M4x0.7Px8mm (Black) KS-M220 SILICONE FOAM 30-013-06200482 STRIP(White) D3 L=26mm Page: A-13 KS-M220/KS-M221 SERIES USER MANUAL...
Page 188 Appendix A System Diagrams Step 1-2 ITEM Description Part No. Q’ty 21.5'' Capacitive Touch Panel (GFF) 52-380-13795701 KS-M220 TOUCH PANEL VHB ELO-S 34-026-05002482 KS-M220 TOUCH PANEL VHB ELO-L 34-026-05001482 KS-M220 TOUCH PANEL VHB ELO-B1 34-026-05006482 (344x23.5x0.8mm) KS-M220 TOUCH PANEL VHB 34-026-05005482 (180x12.6x0.8mm)
Page 189 Appendix A System Diagrams Step 1-3 Page: A-15 KS-M220/KS-M221 SERIES USER MANUAL...
Page 190 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 KDS TOUCH HOLDER 20-229-02027482 (w/Paint) (Black) 21.5'' Capacitive Touch Panel 52-380-13632101 SLIP NUTS (M4x0.7P,H=4.5mm) 23-142-40450801 KS-M220 SILICONE FOAM STRIP 30-013-06100482 (White) L=1770mm KS-M220 EVA (D16xT2.5mm) 30-013-16100482 KS-M220/KS-M221 SERIES USER MANUAL...
Page 191 Appendix A System Diagrams Step 1-4 Locations to attach LCD Panel Poron Page: A-17 KS-M220/KS-M221 SERIES USER MANUAL...
Page 192 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 KDS LCD HOLDER (w/Plate) 20-229-02026482 21.5" TFT LCD Panel(LED Backlight), 52-351-13215302 250nits (1920x1080) FILLISTR HEAD SCREW 22-272-30003011 M3x0.5Px3mm FLAT HEAD SCREW#1/ψ5.0 / 22-212-30004311 M3x0.5Px4mm, FLAT=1.1mm KS-M220 LCD PANEL PORON-S 30-013-24200482 (280x5x2.5mm)
Page 193 Appendix A System Diagrams Step 1-5 ITEM Description Part No. Q’ty KS-M220 KDS LCD HOLDER (w/Plate) 20-229-02026482 LED Driver Board 52-152-29201530 ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm Touch Control Board for 21.5" ELO 52-370-07241301 2.1M FHD Fixed-Focus Face Camera 52-151-08000231 ROUND HEAD SCREW ψ3.3 /...
Page 194 Appendix A System Diagrams Step 1-6 ITEM Description Part No. Q’ty KS-M220 KDS Frame Module KS-M220 KDS LCD Module SLIP NUTS (M4x0.7P,H=4.5mm) 23-142-40450801 KS-M220/KS-M221 SERIES USER MANUAL Page: A-20...
Page 195 Appendix A System Diagrams Step 1-7 ITEM Description Part No. Q’ty KS-M220 KDS Frame Module KS-M220 KDS LCD Module Drawer Support Module ROUND HEAD WITH SPRING 22-235-30008011 WASHER SCREW #2/M3x0.5Px8mm Page: A-21 KS-M220/KS-M221 SERIES USER MANUAL...
Page 196 Appendix A System Diagrams Step 2-1 KS-M220/KS-M221 SERIES USER MANUAL Page: A-22...
Page 197 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 KDS WIFI ANT ACRYLIC 30-021-10130482 SLIP NUTS(M3x0.5P,H=4mm) 23-142-30400801 PA-6222/6225 SPEAKER CABLE 27-021-33505071 L=250mm KS-M220 KDS SPEAKER FILM 90-083-25100482 HEX CU NUTS (M2x0.4P,H=6mm) 23-160-20060041 KS-M220 KDS WIFI ACRYLIC PORON 30-013-24300482 WASHER (OD=φ10mm,ID=φ...
Page 198 Appendix A System Diagrams Step 2-2 KS-M220/KS-M221 SERIES USER MANUAL Page: A-24...
Page 199 FLAT HEAD SCREW ψ6.4 / 22-215-40008711 M4x0.7Px8mm(Black) HSF,KR-M220 Male pin Daughter Card KR-M220-G0B-A1N ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm KS-M220 KDS FH PLATE (w/Plate) 20-205-02001482 KS-M220 KDS REAR COVER WELD 20-204-02118482 SPCC (w/Paint) (Black) Page: A-25 KS-M220/KS-M221 SERIES USER MANUAL...
Page 200 Appendix A System Diagrams Step 2-3 ITEM Description Part No. Q’ty KS-M220 KDS REAR COVER WELD 20-004-01001482 D-Sub 9-Pin F Cable USB2.0 CABLE (Type A(F) to 10F/P2.0) 27-006-48211111 L=550mm 8P8C MODULAR COUPLER JACK 10-085-08012135 SHIELDED Power Switch M12(12F) to ATX 6F/P4.2x2+POWER...
Page 201 Appendix A System Diagrams ITEM Description Part No. Q’ty M12(12F) to ATX 6F/P4.2x2+POWER 27-012-48213111 DIN (4ML=200mm+350mm+650mm) Power Switch Nut CARD GUIDE 90-062-04200000 Page: A-27 KS-M220/KS-M221 SERIES USER MANUAL...
Page 202 Appendix A System Diagrams Step 2-4 ITEM Description Part No. Q’ty KS-M220 KDS REAR COVER DRAWER 30-013-15400482 EVA (268.8x13.2x0.5mm) KS-M220 KDS EVA (42x5x0.5mm) 30-013-15300482 KS-M220 KDS EVA (315.5x5x0.5mm) 30-013-15200482 KS-M220/KS-M221 SERIES USER MANUAL Page: A-28...
Page 203 ITEM Description Part No. Q’ty KS-M220 KDS Frame Module FLAT HEAD SCREW ψ6.4 / 22-215-40008711 M4x0.7Px8mm(Black) KS-M220 KDS Rear Cover Module ROUND HEAD WITH SPRING 22-235-30008011 WASHER SCREW #2/M3x0.5Px8mm PAN HEAD SCREW M3x0.5Px12mm 22-222-30012811 KS-M220 KDS IO COVER (w/Paint) 20-204-02068482...
Page 204 Step 3-2 ITEM Description Part No. Q’ty Remark Rubber Foot 12x1.5mm SLIP NUTS(M6x1.0P,H=6mm) 23-142-60601271 Used on KDS KS-M220 Side Cover Patch 30-013-36100482 Wall Mount type SNAP RIVET 90-016-04300000 KS-M220 KDS SIDE COVER Used on KDS 20-204-02069482 (w/Paint) (Black) Wall Mount type PLASTIC RIVET(Φ3.5mm)
Page 205: Ks-M220 / Ks-M221 Kds Control Box Exploded Diagrams
Appendix A System Diagrams KS-M220 / KS-M221 KDS Control Box Exploded Diagrams Step 4-1 location of the key lock opening ITEM Description Part No. Q’ty KS-1132 C510ZSS-1 Lock Plate 80-025-02001450 LOCK_C510ZSS-1_CORE 20-025-35001000 LOCK_C510ZSS-1_BIG NUT 20-025-35001000 LOCK_C510ZSS-1_WASHER 20-025-35001000 LOCK_C510ZSS-1_S NUT 20-025-35001000...
Page 206 ITEM Description Part No. Q’ty FLAT HEAD SCREW #1/ψ5.0 / 22-212-30004311 M3x0.5Px4mm, FLAT=1.1mm KS-M220 KDS DRAWER FRONT 20-204-02067482 COVER (w/Paint) (Black) KS-M220 KDS DRAWER TRAY 20-254-01001482 KS-M220/KS-M221 SERIES USER MANUAL Page: A-32...
Page 207 Appendix A System Diagrams Step 4-3 ITEM Description Part No. Q’ty KS-M220 HDD HOLDER 20-229-02001482 SHOCK ABSORB RUBBER(Black) 90-013-01200000 2.5” HDD (SSD) FILLISTR HEAD SCREW 82-272-30005013 M3x0.5Px4.8mm Page: A-33 KS-M220/KS-M221 SERIES USER MANUAL...
Page 208 Appendix A System Diagrams Step 4-4 KS-M220/KS-M221 SERIES USER MANUAL Page: A-34...
Page 209 Description Part No. Q’ty BE-0996 BE-0996RA-D1N BE-0986RB-J0N BE-0986RB-J0N ROUND WASHER HEAD SCREW 22-242-30005311 M3x0.5Px5mm KS-M220 KDS BLOWER FAN 21-004-06060401 (60x60x15mm) HSF,KR-M220 Male pin Daughter Card KR-M220-G0B-A1N BE-0996 CPU THERMAL COPPER 81-002-24225001 BLOCK (42x25x5mm) BE-0986 CPU THERMAL COPPER 81-002-23025001 BLOCK (30x25x5mm)
Page 210 Appendix A System Diagrams Step 4-5 ITEM Description Part No. Q’ty FLAT HEAD SCREW #1/ψ5.0 / 22-212-30004311 M3x0.5Px4mm,FLAT=1.1mm KS-M220 KDS DRAWER COVER 20-204-02021482 (w/Plate) KS-M220/KS-M221 SERIES USER MANUAL Page: A-36...
Page 211 Appendix A System Diagrams Step 4-6 ITEM Description Part No. Q’ty KR-M221 Female Daughter Card KR-M221-G0B-A1N KS-M220 KDS GUIDE RAIL SUPPORT 20-202-02022482 (w/Plate) CARD GUIDE 90-062-04200000 KS-M220 KDS DRAWER 20-202-02021482 SUPPORT(w/Plate) ROUND HEAD WITH SPRING 22-235-30008011 WASHER SCREW #2 / M3x0.5Px8mm...
Page 212: Ks-M220 / Ks-M221 Cash Pay Lower Parts Exploded Diagrams
Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Lower Parts Exploded Diagrams KS-M220 / KS-M221 Cash Pay Body Parts Assembly Exploded Diagram (Part 1) KS-M220/KS-M221 SERIES USER MANUAL Page: A-38...
Page 213 KS-M220-C DOOR SHEET (w/Plate) 20-247-02022482 KS-M220-C LOCK BAR 20-208-07002482 KF-7330 PANEL LOCK SPRING(ψ10) 23-002-00001002 KS-C220_COIN_BOX_ASM SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 KS-M220-C DOWN COIN BOX RAIL 20-240-02021482 (w/Plate) KS-M220-C BODY COVER (w/Paint) 20-204-02115482 (Black) ROUND WASHER HEAD SCREW 22-232-40006311 M4x0.7Px6mm KS-M220-C COM RAIL...
Page 214 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Body Parts Assembly Exploded Diagram (Part 2) KS-M220/KS-M221 SERIES USER MANUAL Page: A-40...
Page 215 Appendix A System Diagrams ITEM Description Part No. Q’ty PK-7090 CONCEALED HINGE 80-012-30001284 ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm KS-M220-C USB CABLE BRACKET 20-206-03003482 KS-M220-C BOTTOM COVER 20-204-03001482 KS-M220-C BOTTOM PLATE 20-205-02062482 (w/Paint)(Black) SLIP NUTS (M3x0.5P, H=4mm) 23-142-30400801 SLIP NUTS (M8x1.25P, H=7.5mm)
Page 216 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Body Parts Assembly Exploded Diagram (Part 3) KS-M220/KS-M221 SERIES USER MANUAL Page: A-42...
Page 217 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220-C BODY SPOT CASE 20-201-02064482 (w/Paint)(Black) KS-M220 OAD BRACKET(w/Plate) 20-206-02023482 KS-M220-C AC IN BOX COVER 20-204-02113482 (w/Paint)(Black) KS-M220 FLUSH PULL (Black) 30-080-08100482 KS-M220 POWER BUTTON 20-260-02064482 BRACKET(w/Plate) SLIP NUTS (M4x0.7P,H=4.5mm) 23-142-40450801 Circuit Breaker &...
Page 218 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Bill Acceptor Assembly Exploded Diagram KS-M220/KS-M221 SERIES USER MANUAL Page: A-44...
Page 219 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220-C PAYOUT BRACKET-IPRO 20-206-02029482 (w/Plate) KS-M220-C IPRO SIDE BRACKET L 20-206-02111482 (w/Plate) KS-M220-C IPRO SIDE BRACKET R 20-206-02028482 (w/Plate) KS-M220-C IPRO SIDE BRACKET 20-206-02112482 COVER (w/Plate) ROUND WASHER HEAD SCREW 22-232-40006311 M4x0.7Px6mm...
Page 220 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Cash Flow Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220-C CF7900 HOLDER (w/Plate) 20-229-02023482 KS-M220-C CF7900 CLX COVER 20-204-02022482 (w/Plate) KF-7270 CAM LOCK 20-025-35002000 KS-M220-C_CF-7000_SHEET ROUND WASHER HEAD SCREW 22-232-40006311 M4x0.7Px6mm...
Page 221 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Change Box Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220-C CHANGE BOX 20-240-07001482 KS-M220-C CHANGE DOOR 30-056-10130488 KF-7330 COIN DOOR HINGE 20-012-02001375 MH-5100 COMPRESSION SPRING 23-002-01000252 (ψ6.1x25) FLAT HEAD SCREW #2/ψ6 / 22-212-40006011 M4x0.7Px6mm...
Page 222 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Coin Box Assembly Exploded Diagram 20-240-07002482 20-025-35001000 ITEM Description Part No. Q’ty KS-M220-C COIN BOX (w/Plate) 20-240-02023482 CAM LOCK 20-025-35004000 Lifting Handles 20-035-10001000 ROUND WASHER HEAD SCREW #2 / 22-232-40008011 M4x0.7Px8mm...
Page 223 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Front Door Assembly Exploded Diagram (Part 1) Page: A-49 KS-M220/KS-M221 SERIES USER MANUAL...
Page 224 KS-M220-C COIN INSERT CLX(w/Plate) 20-206-02027482 KS-C220_CHANGE_BOX_ASM ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm ROUND WASHER HEAD SCREW #2 / 22-232-40008011 M4x0.7Px8mm KS-M220-C TOP COIN BOX RAIL 20-240-02022482 (w/Plate) KS-M220-C IUC150 COVER (w/Paint) 20-204-02111482 (Black) SLIP NUTS (M4x0.7P,H=4.5mm) 23-142-40450801 SLIP NUTS (M3x0.5P,H=4mm)
Page 225 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Front Door Assembly KS-M220 / KS-M221 Cash Pay Front Door Assembly Exploded Diagram (Part 2) Exploded Diagram (Part 2) Page: A-51 KS-M220/KS-M221 SERIES USER MANUAL...
Page 226 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220-C MONEY BAR SHEET 20-208-02022482 (w/Plate) KS-M220-C MONEY BAR (w/Paint) 20-208-02061482 (Black) PK-7090 CAM LOCK 20-025-30001284 WASHERS(Φ9.5x4mm) 90-041-04108000 FLAT HEAD SCREW M3x0.5Px6mm 22-215-30006111 (Black) ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm KS-M220 HINGE BASE(w/Plate)
Page 227 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay Front Door Assembly Exploded Diagram (Part 3) ITEM Description Part No. Q’ty ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm KS-M220-C QP1000 PP(Black) 30-056-05100482 SLIP NUTS(M4x0.7P, H=4.5mm) 23-142-40450801 Page: A-53 KS-M220/KS-M221 SERIES USER MANUAL...
Page 228 Appendix A System Diagrams KS-M220 / KS-M221 Cash Pay L70 Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220-C L70 BRACKET (w/Paint) 20-206-02068482 (Black) SLIP NUTS (M4x0.7P, H=4.5mm) 23-142-40450801 KS-M220/KS-M221 SERIES USER MANUAL Page: A-54...
Page 229: Ks-M220 / Ks-M221 M-Type Lower Parts Exploded Diagrams
Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Exploded Diagrams KS-M220 / KS-M221 M-Type Lower Parts Body Assembly Exploded Diagram (Part 1) Page: A-55 KS-M220/KS-M221 SERIES USER MANUAL...
Page 230 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 BODY SPOT CASE 20-201-02062482 (w/Paint)(Black) PK-7090 CONCEALED HINGE 80-012-30001284 PK-7090 PLASTIC WHEEL 22-281-60007001 M6x1.0Px7.1mm (White) KS-M220 BODY PRINTER SUPPORT 20-206-02021482 (w/Plate) KS-M220 OAD BRACKET(w/Plate) 20-206-02023482 HEX HEAD WITH SPRING WASHER 22-251-60012011 SCREW #3 / M6x1.0Px12mm...
Page 231 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Body Assembly Exploded Diagram (Part 2) Page: A-57 KS-M220/KS-M221 SERIES USER MANUAL...
Page 232 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 AC IN BOX(w/Paint)(Black) 20-240-02061482 KS-M220 LOCK BAR 20-225-07001482 KF-7330 PANEL LOCK SPRING(ψ10) 23-002-00001002 KS-M220 RJ45 COVER (w/Plate) 20-204-02064482 FILLISTR HEAD SCREW #2 / 22-275-40004911 M4x0.7Px4mm ROUND WASHER HEAD SCREW #2 / 22-232-30007011 M3x0.5Px7mm...
Page 233 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Body Assembly Exploded Diagram (Part 3) Page: A-59 KS-M220/KS-M221 SERIES USER MANUAL...
Page 234 Appendix A System Diagrams ITEM Description Part No. Q’ty SLIP NUTS (M4x0.7P,H=4.5mm) 23-142-40450801 KS-M220 BODY BOTTOM BRACKET 20-206-02063482 (w/Paint)(Black) FLAT HEAD SCREW M4x0.7Px6mm 22-215-40006911 (Black) KS-M220 USB CABLE BRACKET 20-206-03004482 SLIP NUTS (M3x0.5P,H=4mm) 23-142-30400801 ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm...
Page 235 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Base Assembly Exploded Diagram Page: A-61 KS-M220/KS-M221 SERIES USER MANUAL...
Page 236 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M220 TUBE(w/Paint)(Silver) 20-223-02061482 KS-M220 BASE PLATE(w/Paint)(Silver) 20-205-02061482 KS-M220 BASE FRONT COVER 20-204-02066482 (w/Paint)(Silver) KS-M220 BASE BACK COVER 20-204-02065482 (w/Paint)(Silver) HOLE PLUG (Φ12.7~13mm)(Black) 30-054-04100008 ROUND WASHER HEAD SCREW #2 / 22-232-40008011 M4x0.7Px8mm SLIP NUTS(M8x1.25P, H=7.5mm)
Page 237 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Printer Door Assembly Exploded Diagram (Part 1) Page: A-63 KS-M220/KS-M221 SERIES USER MANUAL...
Page 238 Q’ty KS-M220 HINGE BASE(w/Plate) 20-232-02021482 FLAT HEAD SCREW M3x0.5Px6mm 22-215-30006111 (Black) PK-7090 CAM LOCK 20-025-30001284 SLIP NUTS (M3x0.5P,H=4mm) 23-142-30400801 FILLISTR HEAD SCREW 22-272-40004911 M4x0.7Px4mm KS-M220 PRINTER DOOR 20-247-02061482 (w/Paint)(Black) KS-M220 PRINTER DOOR SHEET 20-247-07001482 KS-M220/KS-M221 SERIES USER MANUAL Page: A-64...
Page 239 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Lower Parts Printer Door Assembly Exploded Diagram (Part 2) Page: A-65 KS-M220/KS-M221 SERIES USER MANUAL...
Page 240 Appendix A System Diagrams IUR150+IUP250/ ITEM Description Part No. Q’ty KS-M220 IUP250 BRACKET 20-260-02062482 (w/Paint)(Black) KS-M220 IUC150 IUR250 20-260-02061482 BRACKET(w/Paint)(Black) SLIP NUTS (M4x0.7P, 23-142-40450801 H=4.5mm) KS-M220 PRINTER DOOR 20-247-07001482 SHEET KS-M220/KS-M221 SERIES USER MANUAL Page: A-66...
Page 241 Appendix A System Diagrams KS-M220 / KS-M221 M-Type FM3080 Unit Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220 FM3080 HOLDER (w/Plate) 20-229-02021482 ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm Page: A-67 KS-M220/KS-M221 SERIES USER MANUAL...
Page 242 Appendix A System Diagrams KS-M220 / KS-M221 M-Type WP Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220 PRINTER HOLDER(w/Plate) 20-229-02022482 ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm KS-M220/KS-M221 SERIES USER MANUAL Page: A-68...
Page 243 Appendix A System Diagrams KS-M220 / KS-M221 M-Type Connecting Board Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M220 KR-1221 HOLDER 20-229-07001482 Connecting Board ROUND WASHER HEAD SCREW 22-232-30006311 M3x0.5Px6mm Page: A-69 KS-M220/KS-M221 SERIES USER MANUAL...
Page 244: Appendix B Technical Summary
Appendix B Technical Summary This appendix will give you a brief introduction of the allocation maps for KS-M220 / KS-M221 resources. The following topics are included: • BE-0996 M/B Block Diagram • BE-0986 M/B Block Diagram • Interrupt Map • I/O Map •...
Page 245: Technical Summary For Ks-M220 High-End Level System
Appendix B Technical Summary Technical Summary for KS-M220 High-End Level System BE-0996 M/B Block Diagram DP Port HDMI Port HDMI1.4a LVDS CH7511 Connector Digital Display Interface Dual Channel, 18/24-bit SO-DIMM DRAM Modules DDR4 1866/2133MHz SLOT *1 (non-ECC) USB 3.0 USB3.0...
Page 246: Interrupt Map
IRQ 77 Microsoft ACPI-Compliant System IRQ 78 Microsoft ACPI-Compliant System IRQ 79 Microsoft ACPI-Compliant System IRQ 80 Microsoft ACPI-Compliant System IRQ 81 Microsoft ACPI-Compliant System IRQ 82 Microsoft ACPI-Compliant System IRQ 83 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-3...
Page 247 IRQ 116 Microsoft ACPI-Compliant System IRQ 117 Microsoft ACPI-Compliant System IRQ 118 Microsoft ACPI-Compliant System IRQ 119 Microsoft ACPI-Compliant System IRQ 120 Microsoft ACPI-Compliant System IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-4...
Page 248 IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System IRQ 161 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-5...
Page 249 IRQ 194 Microsoft ACPI-Compliant System IRQ 195 Microsoft ACPI-Compliant System IRQ 196 Microsoft ACPI-Compliant System IRQ 197 Microsoft ACPI-Compliant System IRQ 198 Microsoft ACPI-Compliant System IRQ 199 Microsoft ACPI-Compliant System IRQ 200 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-6...
Page 250 IRQ 284 Microsoft ACPI-Compliant System IRQ 285 Microsoft ACPI-Compliant System IRQ 286 Microsoft ACPI-Compliant System IRQ 287 Microsoft ACPI-Compliant System IRQ 288 Microsoft ACPI-Compliant System IRQ 289 Microsoft ACPI-Compliant System IRQ 290 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-7...
Page 251 IRQ 323 Microsoft ACPI-Compliant System IRQ 324 Microsoft ACPI-Compliant System IRQ 325 Microsoft ACPI-Compliant System IRQ 326 Microsoft ACPI-Compliant System IRQ 327 Microsoft ACPI-Compliant System IRQ 328 Microsoft ACPI-Compliant System IRQ 329 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-8...
Page 252 IRQ 362 Microsoft ACPI-Compliant System IRQ 363 Microsoft ACPI-Compliant System IRQ 364 Microsoft ACPI-Compliant System IRQ 365 Microsoft ACPI-Compliant System IRQ 366 Microsoft ACPI-Compliant System IRQ 367 Microsoft ACPI-Compliant System IRQ 368 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-9...
Page 253 IRQ 401 Microsoft ACPI-Compliant System IRQ 402 Microsoft ACPI-Compliant System IRQ 403 Microsoft ACPI-Compliant System IRQ 404 Microsoft ACPI-Compliant System IRQ 405 Microsoft ACPI-Compliant System IRQ 406 Microsoft ACPI-Compliant System IRQ 407 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-10...
Page 254 IRQ 440 Microsoft ACPI-Compliant System IRQ 441 Microsoft ACPI-Compliant System IRQ 442 Microsoft ACPI-Compliant System IRQ 443 Microsoft ACPI-Compliant System IRQ 444 Microsoft ACPI-Compliant System IRQ 445 Microsoft ACPI-Compliant System IRQ 446 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-11...
Page 255 IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System IRQ 481 Microsoft ACPI-Compliant System IRQ 482 Microsoft ACPI-Compliant System IRQ 483 Microsoft ACPI-Compliant System IRQ 484 Microsoft ACPI-Compliant System IRQ 485 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-12...
Page 256 Intel(R) I211 Gigabit Network Connection IRQ 4294967293 Intel(R) I211 Gigabit Network Connection IRQ 4294967294 Standard SATA AHCI Controller Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). KS-M220/KS-M221 SERIES USER MANUAL Page: B-13...
Page 257: I/O Map
0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller KS-M220/KS-M221 SERIES USER MANUAL Page: B-14...
Page 258 Mobile Intel(R) Processor Family I/O 0x0000F040-0x0000F05F SMBUS - 9D23 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000FF00-0x0000FFFE Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources KS-M220/KS-M221 SERIES USER MANUAL Page: B-15...
Page 259: Memory Map
Motherboard resources Intel(R) Serial IO UART Host Controller - 0xFE034000-0xFE034FFF 9D27 0xDFFC0000-0xDFFDFFFF Intel(R) Ethernet Connection I219-V 0xFED00000-0xFED003FF High precision event timer 0xFD000000-0xFDABFFFF Motherboard resources 0xFD000000-0xFDABFFFF PCI Express Root Complex 0xFDAD0000-0xFDADFFFF Motherboard resources 0xFDB00000-0xFDFFFFFF Motherboard resources KS-M220/KS-M221 SERIES USER MANUAL Page: B-16...
Page 260 Standard SATA AHCI Controller 0xDF14C000-0xDF14C7FF Standard SATA AHCI Controller 0xA0000-0xBFFFF PCI Express Root Complex 0xC0000-0xC3FFF PCI Express Root Complex 0xC4000-0xC7FFF PCI Express Root Complex 0xC8000-0xCBFFF PCI Express Root Complex 0xCC000-0xCFFFF PCI Express Root Complex KS-M220/KS-M221 SERIES USER MANUAL Page: B-17...
Page 261 PCI Express Root Complex 0xDC000-0xDFFFF PCI Express Root Complex 0xE0000-0xE3FFF PCI Express Root Complex 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex KS-M220/KS-M221 SERIES USER MANUAL Page: B-18...
Page 262: Configuring Watchdog Timer
To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. KS-M220/KS-M221 SERIES USER MANUAL Page: B-19...
Page 263 ; -------------------------- Set timeout interval as 30 seconds ---------------------------- 0F6h ;------------------------------- Enable Watch PME-------------------------------------------- 0FAh ;------------------- Set second as counting unit and start counting -------------------- 0F5h 0F7h ;---------------------------- Exit the extended function mode ------------------------------ 0AAh KS-M220/KS-M221 SERIES USER MANUAL Page: B-20...
Page 264: Flash Bios Update
(3) The system will go into the BIOS setup menu. (4) Select [Boot] menu and set the USB storage device as the 1st boot device. (5) Press <F4> key to save the configuration and restart the system to boot into EFI Shell environment. KS-M220/KS-M221 SERIES USER MANUAL Page: B-21...
Page 265 /?” to view the definition of each control option. The recommended options for BIOS ROM update include the following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /X: Don’t check ROM ID. KS-M220/KS-M221 SERIES USER MANUAL Page: B-22...
Page 266 After the BIOS update procedure is completed, the following messages will display: Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. KS-M220/KS-M221 SERIES USER MANUAL Page: B-23...
Page 267 Appendix B Technical Summary Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. KS-M220/KS-M221 SERIES USER MANUAL Page: B-24...
Page 268: Technical Summary For Ks-M221 Entry Level System
RS232 F81964 LOW PIN COUNT RS-232 COM3/4 support 5V/12V (Super IO) SATA x1 COM 2 SATA3.0 RS232/422/485 BOARD ID SATA3.0 mSATA x1 FOR BIOS VERSION DETECT Mini PCI-E Slot (BE-0986RB default : 0001) USB2.0 Page: B-25 KS-M220/KS-M221 SERIES USER MANUAL...
Page 269: Interrupt Map
IRQ 73 Microsoft ACPI-Compliant System IRQ 74 Microsoft ACPI-Compliant System IRQ 75 Microsoft ACPI-Compliant System IRQ 76 Microsoft ACPI-Compliant System IRQ 77 Microsoft ACPI-Compliant System IRQ 78 Microsoft ACPI-Compliant System IRQ 79 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-26...
Page 270 IRQ 108 Microsoft ACPI-Compliant System IRQ 109 Microsoft ACPI-Compliant System IRQ 110 Microsoft ACPI-Compliant System IRQ 111 Microsoft ACPI-Compliant System IRQ 112 Microsoft ACPI-Compliant System IRQ 113 Microsoft ACPI-Compliant System IRQ 114 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-27...
Page 271 IRQ 143 Microsoft ACPI-Compliant System IRQ 144 Microsoft ACPI-Compliant System IRQ 145 Microsoft ACPI-Compliant System IRQ 146 Microsoft ACPI-Compliant System IRQ 147 Microsoft ACPI-Compliant System IRQ 148 Microsoft ACPI-Compliant System IRQ 149 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-28...
Page 272 IRQ 178 Microsoft ACPI-Compliant System IRQ 179 Microsoft ACPI-Compliant System IRQ 180 Microsoft ACPI-Compliant System IRQ 181 Microsoft ACPI-Compliant System IRQ 182 Microsoft ACPI-Compliant System IRQ 183 Microsoft ACPI-Compliant System IRQ 184 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-29...
Page 273 IRQ 264 Microsoft ACPI-Compliant System IRQ 265 Microsoft ACPI-Compliant System IRQ 266 Microsoft ACPI-Compliant System IRQ 267 Microsoft ACPI-Compliant System IRQ 268 Microsoft ACPI-Compliant System IRQ 269 Microsoft ACPI-Compliant System IRQ 270 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-30...
Page 274 IRQ 299 Microsoft ACPI-Compliant System IRQ 300 Microsoft ACPI-Compliant System IRQ 301 Microsoft ACPI-Compliant System IRQ 302 Microsoft ACPI-Compliant System IRQ 303 Microsoft ACPI-Compliant System IRQ 304 Microsoft ACPI-Compliant System IRQ 305 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-31...
Page 275 IRQ 334 Microsoft ACPI-Compliant System IRQ 335 Microsoft ACPI-Compliant System IRQ 336 Microsoft ACPI-Compliant System IRQ 337 Microsoft ACPI-Compliant System IRQ 338 Microsoft ACPI-Compliant System IRQ 339 Microsoft ACPI-Compliant System IRQ 340 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-32...
Page 276 IRQ 369 Microsoft ACPI-Compliant System IRQ 370 Microsoft ACPI-Compliant System IRQ 371 Microsoft ACPI-Compliant System IRQ 372 Microsoft ACPI-Compliant System IRQ 373 Microsoft ACPI-Compliant System IRQ 374 Microsoft ACPI-Compliant System IRQ 375 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-33...
Page 277 IRQ 404 Microsoft ACPI-Compliant System IRQ 405 Microsoft ACPI-Compliant System IRQ 406 Microsoft ACPI-Compliant System IRQ 407 Microsoft ACPI-Compliant System IRQ 408 Microsoft ACPI-Compliant System IRQ 409 Microsoft ACPI-Compliant System IRQ 410 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-34...
Page 278 IRQ 439 Microsoft ACPI-Compliant System IRQ 440 Microsoft ACPI-Compliant System IRQ 441 Microsoft ACPI-Compliant System IRQ 442 Microsoft ACPI-Compliant System IRQ 443 Microsoft ACPI-Compliant System IRQ 444 Microsoft ACPI-Compliant System IRQ 445 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-35...
Page 279 IRQ 474 Microsoft ACPI-Compliant System IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System KS-M220/KS-M221 SERIES USER MANUAL Page: B-36...
Page 280 Microsoft ACPI-Compliant System IRQ 4294967277 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967278 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967279 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967280 Intel(R) I210 Gigabit Network Connection #2 KS-M220/KS-M221 SERIES USER MANUAL Page: B-37...
Page 281 Express Root Port - 5AD9 Intel(R) Celeron(R)/Pentium(R) Processor PCI IRQ 4294967294 Express Root Port - 5AD8 Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). KS-M220/KS-M221 SERIES USER MANUAL Page: B-38...
Page 282: I/O Map
Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000002E8-0x000002EF Communications Port (COM4) 0x000002F8-0x000002FF Communications Port (COM2) KS-M220/KS-M221 SERIES USER MANUAL Page: B-39...
Page 283 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD8 0x0000F000-0x0000F03F Intel(R) HD Graphics 0x0000F040-0x0000F05F Intel(R) Celeron(R)/Pentium(R) Processor SMBUS - 5AD4 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller KS-M220/KS-M221 SERIES USER MANUAL Page: B-40...
Page 284: Memory Map
Intel(R) Serial IO I2C Host Controller - 0x91318000-0x91318FFF 5AAC Intel(R) Serial IO I2C Host Controller - 0x91317000-0x91317FFF 5AAC Intel(R) USB 3.0 eXtensible Host 0x91300000-0x9130FFFF Controller - 1.0 (Microsoft) Intel(R) Celeron(R)/Pentium(R) Processor 0x91200000-0x912FFFFF PCI Express Root Port - 5AD8 KS-M220/KS-M221 SERIES USER MANUAL Page: B-41...
Page 285 Intel(R) Trusted Execution Engine 0x9131D000-0x9131DFFF Interface 0x80000000-0x8FFFFFFF Intel(R) HD Graphics 0x91314000-0x91315FFF Standard SATA AHCI Controller 0x9131A000-0x9131A0FF Standard SATA AHCI Controller 0x91319000-0x913197FF Standard SATA AHCI Controller 0x7B800001-0x7BFFFFFF PCI Express Root Complex 0x7C000001-0x7FFFFFFF PCI Express Root Complex KS-M220/KS-M221 SERIES USER MANUAL Page: B-42...
Page 286: Configuring Watchdog Timer
To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. KS-M220/KS-M221 SERIES USER MANUAL Page: B-43...
Page 287 ; ---------------- Set timeout interval as 30seconds and start counting -------------- ;------------------------------- Enable Watch PME-------------------------------------------- ;-------------------------- Set second as counting unit -------------------------------------- ;-------------------------- Start the watchdog timer -------------------------------------- ;---------------------------------Exit the extended function mode ------------------------- KS-M220/KS-M221 SERIES USER MANUAL Page: B-44...
Page 288: Flash Bios Update
(3) System will go into the BIOS setup menu. (4) Select [Boot] menu. (5) Set the USB bootable device to be the 1 boot device. (6) Press <F4> key to save configuration and exit the BIOS setup menu. KS-M220/KS-M221 SERIES USER MANUAL Page: B-45...
Page 289 /?” to view the definition of each control option. The recommended options for BIOS ROM update include the following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /X: Don’t check ROM ID. KS-M220/KS-M221 SERIES USER MANUAL Page: B-46...
Page 290 After the BIOS update procedure is completed, the following messages will display: Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. KS-M220/KS-M221 SERIES USER MANUAL Page: B-47...
Page 291 Appendix B Technical Summary Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. KS-M220/KS-M221 SERIES USER MANUAL Page: B-48...

This manual is also suitable for:

Ks-m221

protech KS-M220 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech KS-M220

Summary of Contents for protech KS-M220

This manual is also suitable for:

Table of Contents
