Overview; Technical Data; Placing Furniture On The Roller Bases - Powerfix Profi PMTR 4 A1 Translation Of Original Operation Manual

Overview

Lever arm
Hand grip
Roller base
Rotatable loading surface
Swivelling head

Technical data

Loading per roller base: 150 kg
Loading Lever arm: 150 kg
Weight: approx. 1,1 kg
Placing furniture on the roller
bases
1.
Ensure that there is sufficient space available to
work safely.
2.
Remove obstacles, e.g. other furniture items,
within ca. 1,5 m from the roller bases
Hints:
To avoid uneven lifting, always take into account
the load centre of gravity and place the lever
arm on the side to be lifted.
1.
Hold the lever arm
this you will require the least effort.
2.
Push the swivelling head
under the furniture and in the middle of it (A).
3.
To lift the furniture, slowly press the lever arm
down (B).
.
at the hand grip . With
of the lever arm
4.
Hold the lever arm
B
5.
Place one roller base
corner of the furniture piece.
C
6.
To lower the furniture piece onto the roller base
, slowly lift the lever arm
D
7.
Remove the lever arm
8.
Repeat the above procedure for the opposite
side of the furniture piece.
- 3 -
pressed down.
A
(C) under each raised
C
(D).
.
