5.

SPECIFICATIONS

Parameter
Dimensions
Weight
Operating
temperature
Storage temperature
Power consumption
Channel count
Sample rates
Analog performance
Audio latency
16
Value
115x94x27mm (BxHxD)
65 g
0..+70°C, non-condensing
-40..+85°C, non-condensing
7W max., depending on the channel count used
Flexible from 128x0 to 0x128 (in blocks of 16) when both sides run at x1
(44.1 / 48 kHz). Requires at least SRC firmware 2.0 and MVR firmware 5.0.
Up to 64x64 when either side is running at x2 speed (88.2 / 96 kHz)
Up to 32x32 when either side is running at x4 speed (176.4 / 192 kHz)
Arbitrary sample rates between 32kHz and 192kHz
THD+N: -133 dB typ. / -120dB max.
Dynamic range (A-weighted, 20 Hz to 20 kHz): 139 dB
For up-sampling conversions: t/s = 16/fs_in + 32/fs_in
fs_in / kHz
44.1
48
88.2
96
176.2
For down-sampling conversions: t/s = 16/fs_in + (32/fs_in)*(fs_in/fs_out)
fs_in / fs_out /
kHz kHz
48 44.1
88.2 44.1
48
96 44.1
48
88.2
t / ms
1.09
1.03
0.54
0.5
0.27
t / ms
1.06
0.91
0.84
0.89
0.83
0.53
fs_in / fs_out /
kHz kHz
176.4 44.1
48
88.2
96
192 44.1
48
88.2
96
176.4
t / ms
0.82
0.76
0.45
0.42
0.81
0.75
0.45
0.42
0.26
