> Data transfer rates of up to 12 Mbits/sec
> Easy installation and set up with no software required
Specifications
> Product Height 1.34 in [34 mm]
> LED Indicators 1 - Power
> LED Indicators 1 - Host
> LED Indicators 1 - Link
> Product Length 4.21 in [107 mm]
> Number of Ports 1
> Shipping (Package) Weight 2.36 lb [1.07 kg]
> Product Weight 10.59 oz [300 g]
> Product Width 3.31 in [8.4 cm]
> Extension Distance 330 ft (100 m)
> USB Compatibility Supports USB 1.0 and USB 1.1 devices (multi-speed)
> Dimensions 4.2 x 3.3 x 1.3 Inches (107 x 84 x 34 mm)
> Weight 1.2 lbs (0.6 kg)
> Local Unit Connectors Upstream: 1 x 4 pin USB (Type B)<br>Downstream: 1 x RJ-45
> Remote Unit Connectors Upstream: 1 x RJ-45<br>Downstream: 2 x 6 pin USB (Type A)
> Total Shipping Weight 2.4 lbs (0.8 kg)
> Color Black
> USB Hub Support Up to 4 hubs connected to the local unit
> Enclosure Type Steel
> Maximum Cable Length 328 ft [100 m]
> Operating Temperature 4 to 40 ?C
> Industry Standards USB 1.1
> Data Transfer Rate Up to 12 Mbits/sec
> Maximum power available to USB at the Remote Unit 500 mA
> Input Voltage 15V DC
