Summary of Contents for Graco REACTOR 246028
Page 1
Reactor Electric Proportioner Part No. Description Reactor Electric 309551 Proportioner, Operation Manual (English) Reactor Electric 309574 Proportioner, Repair-Parts Manual (English) TI3764a-1 Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2003, Graco Inc. is registered to I.S. EN ISO 9001...
Page 2
Simplified Schematic, Motor Controls Simplified Schematic, Motor Controls 230Vac, 1 Phase FA N SW ITC H & 4 N O T U SED SW ITC H O N = E-30 O FF = X P2 H O SE PU M P SW ITC H (SEE M A N U A L) - PRESSU RE IM BA LA N C E...
Page 5
Simplified Schematic, Power Connections Simplified Schematic, Power Connections 230Vac, 1 Phase TI4200a 309727E...
Page 6
Detailed Schematic, Power Connections and Motor Controls Detailed Schematic, Power Connections and Motor Controls Voltage Full Load Part No. Model (phase) Peak Amps 246026 E-30 230V (1) 246028 E-XP2 230V (1) 248657 E-30 with 230V (1) 15.3KW 246196 PUMP CONTROL CIRCUIT BOARD 1071 CONNECTION...
Page 7
Detailed Schematic, Heater Controls Detailed Schematic, Heater Controls Only E-XP2 and E-30, with 15.3KW of heat, Models E-30 Models use 25A heater circuit breakers; E-XP2 use 3 heaters per side. and E-30, with 15.3KW of heat, Models use 40A. 309727E...
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
