Warnings/Alarm Messages - Danfoss VLT 2811 Quick Manual

1 Quick Guide

1.9.1 Warnings/alarm messages

1
No.
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
33
34
35
36
37-45 Internal fault (INTERNAL
W: Warning, A: Alarm, T: Trip locked
26
Description
Live zero error (LIVE ZERO
ERROR)
Mains phase loss (MAINS
PHASE LOSS)
Voltage warning high (DC
LINK VOLTAGE HIGH)
Voltage warning low (DC
LINK VOLTAGE LOW)
Overvoltage (DC LINK
OVERVOLT)
Undervoltage (DC LINK UN-
DERVOLT)
Inverter overload (INVER-
TER TIME)
Motor overloaded ( MOTOR,
TIME)
Motor thermistor (MOTOR
THERMISTOR)
Current limit (CURRENT
LIMIT)
Overcurrent (OVERCUR-
RENT)
Earth fault (EARTH FAULT)
Switch mode fault (SWITCH
MODE FAULT)
Short-circuit (CURR. SHORT
CIRCUIT)
Serial communication time-
out (STD BUS TIMEOUT)
HPFB bus timeout (HPFB
TIMEOUT)
Out of frequency range
(OUT FREQ RNG/ROT LIM)
HPFB communication fault
(PROFIBUS OPT. FAULT)
Inrush fault (INRUSH
FAULT)
Overtemperature (OVER-
TEMPERATURE)
FAULT)
MG.28.M1.02 - VLT
W A T Cause of Problem
X X X Voltage or current signal on terminals 53 or 60
is below 50% of preset value.
X X X No phase on mains supply side.
X The intermediate circuit voltage exceeds the lim-
it set.
X The intermediate circuit voltage is lower the limit
set.
X X X The intermediate voltage exceeds the limit set.
X X X The intermediate voltage is lower than the limit
set.
X X The frequency converter is close to tripping due
to overload.
X X The motor is too hot due to overload.
X X Either the motor is too hot or the thermistor has
been disconnected.
X X Output current is higher than set in par. 221.
X X X The peak current limit has been exceeded.
X X Discharge from output phases to earth.
X X Fault in switch mode power supply.
X X Short-circuit on the motor terminals or in the
motor.
X X No serial communication to the frequency con-
verter.
X X No serial communication to the communication
option card.
X Output frequency has reached the limit set in
either par. 201 or par. 202.
X X Fault only occurs in fieldbus versions. Please see
par. 953 in fieldbus literature.
X X Connected to mains too many times within 1 mi-
nute.
X X The upper temperature limit has been exceeded.
X X Please contact Danfoss.
® is a registered Danfoss trademark
VLT 2800 Quick Guide
