VLT 2800 Quick Guide
1.2 Introduction
Use this Quick Guide to carry out quick and
EMC-correct installation of the frequency con-
verter in five steps.
1.2.1 Abbreviations
ELCB
NO
NC
PD2
RCD
1.2.2 Available Litterature
Read the safety section before
installing the unit.
NB!
The Operating Instructions, MG.
27.AX.YY, give further examples
of installation and describe all
functions in detail.
The Design Guide, MG.
27.EX.YY, contains extensive in-
formation.
Earth Leakage Circuit Breakers
Normally open
Normally closed
Dual phase (for 2822, 2840 that only run 3-phase as standard D2), 220 - 240 V
Residual Current Device
NB!
This quick guide contains only the very basic information necessary for installing and
running the drive.
For more information please consult the VLT 2800 Design Guide, MG.27.EX.YY
