Operation
Interior Texture Sprayer
TX 65
Model 254970:
50 psi (3.5 bar) Maximum Fluid Working Pressure
100 psi (7 bar) Maximum Air Input Pressure
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Related Manuals:
311769
311763
For Water-Based Materials Only
311763B
ti8370a
Model 254970 Shown
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX 65 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco TX 65

Summary of Contents for Graco TX 65

  • Page 1 Operation Interior Texture Sprayer TX 65 311763B For Water-Based Materials Only Model 254970: 50 psi (3.5 bar) Maximum Fluid Working Pressure 100 psi (7 bar) Maximum Air Input Pressure Important Safety Instructions Read all warnings and instructions in this manual.
  • Page 2 Route hoses away from traffic areas, sharp edges, moving parts and hot surfaces. • Do not expose Graco hoses to temperatures above 130° F (55° C) or below -35° F (-37° C). Store hazardous fluid in an approved container. Dispose of hazardous fluid according to all local, state and national guidelines.

  • Page 3: Electric Shock Hazard

    Warnings Warnings Electric Shock Hazard To reduce the risk of electric shock: • Be sure sprayer is adequately grounded through electrical outlet. • Use only 3-wire, extension cords. • Make sure ground prongs are intact on sprayer and extension cords. Improper installation of ground- ing plug will result in a risk of electrical shock, fire or explosion that could cause serious injury or death.
  • Page 4 Warnings CAUTION Water or material remaining in unit when temperatures are below freezing can damage motor and/or delay pump startup. To insure water and material are completely drained out of unit: 1. Remove material line from sprayer. 2. Tip sprayer up as shown. Before adding material or starting unit in cold weather, run warm water through pump.

  • Page 5: Component Identification

    Texture Spray Gun (Manual 311777) ON/OFF Switch Nozzle (2 included, see Nozzle Selection, page 10) Power Cord (120V, 15 ft) Material Hose (20 ft) Material Hopper - 5 gallon Material Thickness Gauge Cord Wrap Accessories Bag Handle Air Compressor (Not Supplied by Graco)

  • Page 6: Pressure Relief Procedure

    Preparation Preparation Pressure Relief Procedure Check with a qualified electrician or serviceman if grounding instructions are not completely understood, To reduce risk of injury, follow this procedure or if in doubt as to whether the product is properly whenever you see this symbol throughout this grounded.

  • Page 7: Texture Spraying

    Setup Setup Important • To increase pump life, turn power off when not spraying. • Do not allow material to dry inside pump, hoses, gun or spray system. • To break in new pump run sprayer dry for no more than 2 minutes. 4.
  • Page 8 Setup 8. Point gun into waste bucket and pull trigger to pump 12. Turn on Air compressor and open gun valve to water through the system. Continue to trigger gun desired setting. until material hopper is empty. 9. Install burp guard (J). Caution, page 3. ti9775a ti8376a 13.

  • Page 9: Mixing Material

    Mixing Material Mixing Material 4. After texture material is thoroughly mixed, gently set Correct material mixture is essential. The pump ball end of Material Thickness Gauge on surface of will not operate if the mixture is too thick. mixture. Mix the material in a separate container before For an accurate test, be sure gauge is completely pouring it into hopper.

  • Page 10: Spray Techniques

    Spray Techniques Spray Techniques Recommended Nozzle Selection Chart • Set air compression at a minimum of 25 psi. Addi- tional air pressure may be needed for thicker materi- als or when product is applied to ceilings. Application Nozzle Size Air Volume 6 mm, white To Get Less Material Simulated...

  • Page 11: Shut Down And Clean-Up

    Shutdown and Cleanup Shutdown and Cleanup Keep pump and hose clean when switching between simulated acoustic, knockdown and orange peel applications. A dirty pump can release particles of texture into the finish. CAUTION • To increase pump life, turn power off when not spraying. •...

  • Page 12: Troubleshooting

    Refer to Grounding and Electrical Requirements, page 6. Gun needle plugged Clean needle and retry. Worn compressor Replace compressor. Contact a qualified Graco Service Center. Lines not connected Check all quick disconnect connections to gun and hoses. Damaged hose Replace hose.
  • Page 13 Troubleshooting Problem Cause Solution Speed of application slow or slower New pump hose not broken in Run pump dry for no longer than 2 properly minutes. Material too thick Thin material. Nozzle too small Change nozzles to a larger size. See Recommended Nozzle Selection Chart, page 10.

  • Page 14: Technical Data

    Maximum Delivery with Texture ....0.65 gpm TX 65 Dimensions and Weight Length ........19 in. (482 mm) with handle Width .
  • Page 15 Notes Notes...

  • Page 16: Graco Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
