Operation, Parts
Cordless HandHeld
Airless Sprayers
Important Safety Instructions
Read all warnings and instructions in this manual, on the unit, and in the battery and
charger manual. Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
FIRE AND EXPLOSION HAZARD
Use only non-flammable or water-based materials, or
non-flammable paint thinners. Do not use materials
having flash points below 100°F (38°C). This includes,
but is not limited to, acetone, xylene, toluene, and
naphtha. For more information about your material,
request Safety Data Sheet (SDS) from the supplier.
Use oil-based materials outdoors or in a well-ventilated
indoor area with a flow of fresh air.
Spraying certain materials may cause static build-up in
the sprayer that can result in static shock to the user. If
this occurs, the material likely contains a flammable
solvent that can build up static and result in a fire or
explosion. Switch to an alternative material.
For portable spray applications of water-based and oil-based
Not approved for use in explosive atmospheres or hazardous locations.
non-flammable architectural paints and coatings only.
3A4476E
Operational video.
http://graco.com/hhsupport
844-241-9499
EN
Advertisement
Table of Contents
Related Manuals for Graco Ultra
Summary of Contents for Graco Ultra
- Page 1 Read all warnings and instructions in this manual, on the unit, and in the battery and charger manual. Be familiar with the controls and the proper usage of the equipment. Save these instructions. Operational video. http://graco.com/hhsupport 844-241-9499 FIRE AND EXPLOSION HAZARD Use only non-flammable or water-based materials, or non-flammable paint thinners.
-
Page 2: Table Of Contents
Graco Limited Warranty ........ -
Page 3: Models - Cordless Airless Handhelds
Models – Cordless Airless HandHelds Models – Cordless Airless HandHelds Model Sprayer Name Charger Voltage Tip Family Tip Size 17M363 Ultra 120V FFLPxxx 17P515 17N164 Ultimate 120V FFLPxxx 17P516 0.008 – 0.016 in. (0.20 – 0.41 mm) 17N165 17N166 TC Pro... -
Page 4: Important User Information
Before using your sprayer read this Owners Manual for complete instructions on proper use and safety warnings. Congratulations! You have purchased a high-quality paint sprayer made by Graco Inc. This sprayer is designed to provide superior spray performance with water-based and oil-based (mineral spirit-type) architectural paints and coatings. -
Page 5: Warnings
Warnings Warnings The following warnings are for the setup, use, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. - Page 6 Check parts for signs of damage. Replace any damaged parts. • This system is capable of producing 2000 psi (138 bar, 14 MPa). Use Graco replacement parts or accessories that are rated a minimum of 2000 psi (138 bar, 14 MPa).
- Page 7 Warnings TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed. • Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using. •...
-
Page 8: Know Your Sprayer
Know Your Sprayer Know Your Sprayer PRIME SPRAY PUMP Prime Pump/Spray Knob Cup Cover Battery FlexLiner Sprayer Trigger Cup Support Speed Control, ProControl II VacuValve Cap Spray Tip. Reverse-A-Clean (RAC) VacuValve Air Hole Spray Tip Guard VacuValve Reservoir Diagnostic Light Pump Filter 3A4476E... -
Page 9: Start Up
Start Up Start Up Remove battery from the sprayer. Turn Prime Pump/Spray Knob down to PRIME PUMP position to relieve pressure. Use only oil-based (non-flammable) or water-based materials, or non-flammable paint thinners. Do not use materials having flash points below 100°F (38°C). Do not use materials which state “FLAMMABLE”... - Page 10 Start Up Install FlexLiner in the cup support. The VacuValve is an important part of your new sprayer. It is used to evacuate the air out of the FlexLiner. Your sprayer will not spray if there is air in the FlexLiner.
- Page 11 Start Up Install battery onto sprayer. If sprayer does not spray, try one of the steps below: Turn Prime Pump/Spray knob down to Prime Pump position. Turn spray tip to • Make certain there is only one FlexLiner the UNCLOG position. To fill sprayer in cup support.
-
Page 12: Refilling Flexliner
Start Up Refilling FlexLiner If sprayer runs out of paint simply separate the cup support from the cup cover/sprayer and refill the FlexLiner. Remove battery from the sprayer and open the VacuValve to allow air into the FlexLiner. Separate the cup support from the cup ti29742a cover/sprayer. -
Page 13: How To Spray
Sprayer Name Tip Family Tip Part No. The speed control allows for infinite pressure Ultra FFLP FFLPxxx adjustment. To reduce overspray, always start at lowest speed setting and increase Ultimate FFLP... -
Page 14: Triggering Sprayer
How to Spray Triggering Sprayer 12 in. Pull trigger after starting stroke. Release (30 cm) trigger before end of stroke. Sprayer must be moving when trigger is pulled and released. EVEN FINISH ti30015a Aiming Sprayer Aim sprayer at bottom edge of previous THICK stroke, overlapping each stroke by half. -
Page 15: Spray Pattern Quality
How to Spray Clear Tip Clog When spraying vertical corners turn spray tip guard to the horizontal orientation and move sprayer up and down. In the event that particles or debris clog the spray tip, this sprayer is designed with a reversible spray tip that quickly and easily clears the particles without disassembling the sprayer. - Page 16 How to Spray Aim sprayer at waste area, turn Prime Turn Prime Pump/Spray knob down to Pump/Spray knob forward to spray Prime position. Rotate spray tip back to position. Pull trigger to clear clog. SPRAY position. Turn Prime Pump/Spray knob forward to SPRAY position, and resume spraying.
-
Page 17: Cleanup
Cleanup Cleanup Use only oil-based (non-flammable) or water-based materials, or non-flammable paint thinners. Do not use materials having flash points below 100°F (38°C). Do not use materials which state “FLAMMABLE” on the packaging. For more information about your material, request SDS from distributor or retailer. Clean in a well-ventilated area. - Page 18 Cleanup You can either dispose of the used To clean the cup cover and pump filter FlexLiner and install a new FlexLiner or shake the entire sprayer for ten seconds. clean a used FlexLiner. To clean the sprayer, fill FlexLiner approximately half-full with appropriate cleaning fluid (warm water or mineral spirits).
- Page 19 Cleanup 11. Turn Prime Pump/Spray knob forward to 13. If second spray tip was used, remove SPRAY position. cleaned spray tip from spray tip guard and install second spray tip. See Spray 12. While holding the sprayer upside down Tip Installation, page 22. Repeat steps point the sprayer into a waste pail.
-
Page 20: Cleaning Vacuvalve
Cleanup Cleaning VacuValve 16. Remove spray tip, spray tip guard, and pump filter. Clean with appropriate cleaning fluid (water or mineral spirits). A The VacuValve is an important part of your soft brush can be used to loosen and sprayer and it should be cleaned after every remove dried material if needed. -
Page 21: Storage
Storage Storage With proper storage, the sprayer will be ready to use the next time it is needed. NOTICE Failure to store sprayer with Pump Armor can result in operational problems the next time you spray. Always circulate Pump Armor through the sprayer after cleaning. Water or solvents other than mineral spirits left in the sprayer will corrode and damage the pump. -
Page 22: Common Procedures
Common Procedures Common Procedures Spray Tip Installation Insert Spray Tip. Spray tip must be pushed all the way into the tip guard. To avoid serious injury from skin injection do not put your hand in front of the spray tip when installing or removing the spray tip and tip guard. -
Page 23: Flush A New Sprayer
Common Procedures Flush a New Sprayer Make certain FlexLiner is in the cup support. Always start with a fully charged battery. Refer to battery and charger information provided. This sprayer arrives from the factory with a small amount of test material in the system. It is important that you flush this material from the sprayer before using it for the first time. - Page 24 Common Procedures Securely tighten cup cover onto cup 10. Turn Prime Pump/Spray knob forward to support. SPRAY position. Rotate spray tip 180 degrees to UNCLOG position. ti29739a ti29719a Align VacuValve on cup cover with Prime Pump/Spray knob. Push cup assembly onto sprayer and twist to lock. SPRAY UNCLOG 11.
-
Page 25: Reference
Reference Reference Fan Width Fan width is the size of the spray pattern, which determines the area covered with each Spray Tip Selection stroke. Selecting Tip Size Hints: Spray tips come in a variety of hole sizes for • Select a fan width best suited to the spraying a range of fluids. -
Page 26: Cleaning Fluid Compatibility
Reference Cleaning Fluid Static Grounding Compatibility Instructions (Oil-Based materials) The equipment must be grounded to reduce the risk of static sparking. A static Oil- or Water-Based Materials spark can cause fumes to ignite or explode. A good ground provides an escape wire for •... -
Page 27: Maintenance
Maintenance Maintenance Routine maintenance is important to ensure proper operation of your sprayer. Activity Interval Inspect pump filter. Daily or each time you spray Inspect enclosure vents for blockage. Daily or each time you spray Inspect pump inlet holes located under pump filter for blockage. Each time the sprayer is cleaned Cleaning Outlet Valves Dirt and debris in the outlet valve assemblies may affect sprayer performance and require... -
Page 28: Replacement Parts
Replacement Parts Replacement Parts Ref. Torque Ref. Torque 10 in-lb (1.1 N•m) 55-65 in-lb (6.2 - 7.3 N•m) 8-10 in-lb (0.9 - 1.1 N•m) 5-7 in-lb (0.6 - 0.8 N•m) 10-15 in-lb (1.1 - 1.7 N•m) 3A4476E... - Page 29 FlexLiner, 32 oz. (3-pack) 17P212 FlexLiner, 32 oz. (25-pack) 17F005 FlexLiner, 42 oz. (3-pack) 17P549 FlexLiner, 42 oz. (25-pack) Ultra, Ultimate 17N392 Support, cup, 32 oz. TC Pro 16W846 Support, cup, 32 oz. 17P550 Kit, cup support, lid and plug 32 oz. includes 13, 1 of 14, 15,...
-
Page 30: Troubleshooting
Troubleshooting Troubleshooting 844-241-9499 Check everything in this Troubleshooting Table before you bring the sprayer to an authorized service center. Sprayer Diagnostics Problem Cause Solution Sprayer makes no sound Diagnostic light blinks two times Replace battery with a charged when trigger is pulled when trigger is pulled. - Page 31 Troubleshooting Problem Cause Solution Sprayer makes sound but Sprayer is not primed. Prime the pump. See Starting a no material is sprayed New Job, page 9. when trigger is pulled Make certain there is only one FlexLiner in the cup support. Make certain the cup cover is properly threaded to the cup support.
- Page 32 Troubleshooting Problem Cause Solution Sprayer sprays with poor Spray tip is partially clogged. See Clear Tip Clog, page 15. results Spray tip is not in correct position Rotate spray tip to SPRAY position. Incorrect spray tip for application of Install different size spray tip. material.
- Page 33 Troubleshooting Spray Pattern Diagnostics Problem Cause Solution Spray pattern is uneven: Operator is moving too Slow speed of movement. fast while spraying. Spray tip is clogged. Unclog spray tip or clean spray tip see Clear Tip Clog, page 15. Material difficult to Increase speed until desired atomize.
- Page 34 Troubleshooting Problem Cause Solution Spray pattern is too wide: Sprayer is too far away Move sprayer closer to surface. from target surface. Incorrect spray tip for Install different size spray tip. application of material. See Spray Tip Installation, page 22. Spray pattern “spits”...
-
Page 35: Technical Specifications
Technical Specifications Technical Specifications Cordless HandHeld Sprayer U.S. Metric Max Working Pressure 2000 psi 14 MPa, 138bar Weight 5.25 lb 2.4 kg Dimensions: Length 14.0 in. 36.1 cm Width 5 in. 12.7 cm Height 10.5 in. 26.7 cm Storage Temperature Range 32°... - Page 36 Notes Notes 3A4476E...
- Page 37 Notes Notes 3A4476E...
-
Page 38: Graco Limited Warranty
Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. - Page 39 Graco Limited Warranty Graco Information For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-888-541-9788 to identify the nearest distributor. 3A4476E...
- Page 40 Original instructions. This manual contains English. MM 3A4476 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2016, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
