Operation, Parts
Cordless HandHeld
Airless Sprayers
Important Safety Instructions
Read all warnings and instructions in this manual, on the unit, and in the battery and
charger manual. Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
FIRE AND EXPLOSION HAZARD
Use only non-flammable or water-based materials, or
non-flammable paint thinners. Do not use materials
having flash points below 100°F (38°C). This includes,
but is not limited to, acetone, xylene, toluene, and
naphtha. For more information about your material,
request Safety Data Sheet (SDS) from the supplier.
Use oil-based materials outdoors or in a well-ventilated
indoor area with a flow of fresh air.
Spraying certain materials may cause static build-up in
the sprayer that can result in static shock to the user. If
this occurs, the material likely contains a flammable
solvent that can build up static and result in a fire or
explosion. Switch to an alternative material.
For portable spray applications of water-based and oil-based
Not approved for use in explosive atmospheres or hazardous locations.
non-flammable architectural paints and coatings only.
3A4476B
Operational video.
http://graco.com/hhsupport
ti30035a
844-241-9499
EN
Advertisement
Table of Contents
Related Manuals for Graco Ultra
Summary of Contents for Graco Ultra
- Page 1 Read all warnings and instructions in this manual, on the unit, and in the battery and charger manual. Be familiar with the controls and the proper usage of the equipment. Save these instructions. Operational video. http://graco.com/hhsupport ti30035a 844-241-9499 FIRE AND EXPLOSION HAZARD Use only non-flammable or water-based materials, or non-flammable paint thinners.
-
Page 2: Models - Cordless Airless Handhelds
Models – Cordless Airless HandHelds Models – Cordless Airless HandHelds Model Sprayer Name Charger Voltage Tip Family Tip Size 17M363 Ultra 120V FFLPxxx 17P515 17N164 Ultimate 120V FFLPxxx 17P516 0.008 – 0.016 in. (0.20 – 0.41 mm) 17N165 17N166 TC Pro... -
Page 3: Important User Information
Before using your sprayer read this Owners Manual for complete instructions on proper use and safety warnings. Congratulations! You have purchased a high-quality paint sprayer made by Graco Inc. This sprayer is designed to provide superior spray performance with water-based and oil-based (mineral spirit-type) architectural paints and coatings. -
Page 4: Fire And Explosion Hazard
Warnings Warnings The following warnings are for the setup, use, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. - Page 5 Check parts for signs of damage. Replace any damaged parts. • This system is capable of producing 2000 psi (138 bar, 14 MPa). Use Graco replacement parts or accessories that are rated a minimum of 2000 psi (138 bar, 14 MPa).
-
Page 6: Personal Protective Equipment
Warnings TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swallowed. • Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using. •... - Page 7 Cleanup 10. Turn Prime Pump/Spray knob forward to 12. If second spray tip was used, remove SPRAY position. cleaned spray tip from spray tip guard and install second spray tip. See Spray 11. While holding the sprayer upside down Tip Installation, page 22. Repeat steps point the sprayer into a waste pail.
-
Page 8: Cleaning Vacuvalve
Cleanup 15. Remove spray tip, spray tip guard, and Cleaning VacuValve pump filter. Clean with appropriate cleaning fluid (water or mineral spirits). A The VacuValve is an important part of your soft brush can be used to loosen and sprayer and it should be cleaned after every remove dried material if needed. - Page 9 Storage Storage With proper storage, the sprayer will be ready to use the next time it is needed. NOTICE Failure to store sprayer with Pump Armor can result in operational problems the next time you spray. Always circulate Pump Armor through the sprayer after cleaning. Water or solvents other than mineral spirits left in the sprayer will corrode and damage the pump.
- Page 10 Notes Notes 3A4476B...
- Page 11 Notes Notes 3A4476B...
- Page 12 Original instructions. This manual contains English. MM 3A4476 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2016, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
