11.0 Ucam Plus Apps Instruction
Saturation:
Sharpness:
Auto White Balance: Auto white balance when checked.
Hue:
Gain:
Gamma:
Backlight Contrast:
Power Line:
Reset to factory
defaults:
Click "<"on the right side of the screen to pop up resolution selection menu. Click ">" or
the middle of the screen to hide resolution selection menu. You can adjust resolution from
the factory default 800x600. Click "set resolution" to display the below screen. Slide up
and down to change resolution. After selection, click
After selecting a resolution, wait 10 seconds for the change to become effective.
Adjusts the image saturation.
Adjust the image sharpness. When over adjusted, it will increase the noise ratio.
Adjusts the hue.
Adjusts the gain.
Adjust the gamma.
Adjusts image contrast.
Adjusts power supply frequency. Required if you see stripes or little ripples.
Restore to factory default settings.
to confirm your choice.
