Summary of Contents for American Standard Colony Pro 7075054

  • Page 1 American Standard is devoted to making life, in the heart of your home, better every day… …so, thank you for inviting us in! With the very best in kitchen and bathroom products, we are here to help make your life happier, healthier and simpler.
  • Page 2: Inside The Box

    OWNERS MANUAL Colony Pro Single Control ® Centerset Lavatory Faucet 7075054 / 7075055 / 7075056 / 7075050 / 7075004 / 7075005 / 7075006 / 7075002 / 7075000 INSIDE THE BOX Image shown may vary from product purchased. Lever handle Drain assembly Spout Mounting RECOMMENDED TOOLS...
  • Page 3: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALL FAUCET Turn off hot and cold water supplies before beginning. • Insert FAUCET (1) and POP-UP CABLE (2) through mounting holes of Sink or Mounting Surface. • Assemble LOCKNUTS (3) onto SHANKS (4) from under side of Sink. Hand tight. SINK OR MOUNTING SURFACE...
  • Page 4 INSTALL POP-UP DRAIN • Push TAIL PIECE (11) down into TRAP (C) (threaded end up). • Thread LOCKNUT (5), WASHER (4) and GASKET (3) (Bevel side up) onto DRAIN BODY (10). • Apply a bead of PUTTY (D) to underside of FLANGE (2). •...
  • Page 5 MAKE WATER SUPPLY AND WASTE CONNECTIONS • Connect FLEXIBLE SUPPLIES (1, 2) directly to wall supplies. Connection on fitting supplies are 3/8" compression. Connect left SUPPLY (1) to Hot (Marked with a Red Band) and right supply to COLD (2) wall supply. •...
  • Page 6 SERVICE Turn off hot and cold water supplies before beginning. • To remove or replace cartridge: – Turn valve to OFF position. – Pull out PLUG BUTTON (1) and remove HANDLE SCREW (2). 2.5mm HEX KEY – Pull off HANDLE (3) and CAP (4). –...
  • Page 7: Tell Us What You Think

    Register your sink at www.americanstandard.com. Please save your proof of purchase (sale receipt). If you need assistance or do not have access to our website, please contact American Standard Customer Care at: (800) 442-1902. An American Standard representative will assist in completing the warranty registration.
  • Page 8 American Standard se consacre à rendre la vie au cœur de votre maison meilleure chaque jour... Merci de nous avoir invités! Avec les meilleurs produits de cuisine et de salle de bains, nous sommes là pour vous aider à rendre votre vie plus heureuse, plus saine et plus simple.
  • Page 9: Manuel Du Propriétaire

    MANUEL DU PROPRIÉTAIRE Colony Pro Robinet de lavabo cobiné à monocommande 7075054 / 7075055 / 7075056 / 7075050 / 7075004 / 7075005 / 7075006 / 7075002 / 7075000 CONTENU DE LA BOÎTE L’illustration peut être différente du produit acheté. Poignée à levier Assemblage de vidange...
  • Page 10: Consignes D'installation

    CONSIGNES D’INSTALLATION ASSEMBLAGE DU BEC Fermer l’alimentation en eau chaude et froide avant de commencer. • Insérez le ROBINET (1) et le CÂBLE ESCAMOTABLE (2) dans les trous de montage du lavabo ou de la surface de montage. • Assemblez les CONTRE-ÉCROUS (3) sur les TIGES (4) à partir de la sous-face du lavabo. Serrez à la main.
  • Page 11 INSTALLATION DE LA BONDE MÉCANIQUE • Poussez l’ABOUT (11) dans le SIPHON (C) (extrémité filetée vers le haut). • Vissez les CONTRE-ÉCROUS (5), la RONDELLE (4) et le JOINT D’ÉTANCHÉITÉ (3) (cote chanfrein vers le haut) sur le CORPS DU RENVOI (10). •...
  • Page 12 RACCORDS DE L’ALIMENTATION EN EAU ET DE LA BONDE DE VIDAGE • Raccordez les TUYAUX D’ALIMENTATION FLEXIBLES (1, 2) directement à l’alimentation murale. La connexion des raccords d’alimentation est une compression de 3/8 po. Raccordez le TUYAU D’ALIMENTATION gauche (1) à...
  • Page 13 ENTRETIEN Fermer l’alimentation en eau chaude et froide avant de commencer. • Pour retirer ou remplacer la cartouche : – Fermez le robinet. – Retirez le REPÈRE DE LA TEMPÉRATURE DE L’EAU (1) et la VIS DE POIGNÉE (2). CLÉ HEXAGONALE 2,5 mm –...
  • Page 14 Enregistrez votre lavabo au www.americanstandard.com. Conservez votre preuve d’achat (ticket de caisse). Si vous avez besoin d’aide ou n’avez pas accès à notre site Web, veuillez appeler le service à la clientèle d’American Standard au numéro suivant : 800 442-1902. Un représentant d’American Standard vous aidera à remplir l’enregistrement de la garantie.
  • Page 15 American Standard se dedica a mejorar la vida, en el corazón de su hogar, cada día..así que, ¡gracias por invitarnos! Con lo mejor en productos de cocina y baño, estamos aquí para ayudarle a hacer su vida más feliz, más sana y más sencilla. Nuestro compromiso con la calidad, la innovación y el desempeño nos ha convertido en...
  • Page 16: Manual Del Propietario

    MANUAL DEL PROPIETARIO Colony Pro Llave central ® monocomando para lavabo 7075054 / 7075055 / 7075056 / 7075050 / 7075004 / 7075005 / 7075006 / 7075002 / 7075000 DENTRO DE LA CAJA La imagen puede variar del producto comprado. Palanca Conjunto de drenaje Pico...
  • Page 17: Instrucciones De Instalación

    INSTRUCCIONES DE INSTALACIÓN INSTALAR EL PICO Apague los suministros de agua caliente y fría antes de comenzar. • Inserte la LLAVE (1) y el CABLE AUTOMÁTICO (2) a través de los orificios de montaje del lavabo o de la superficie de montaje. •...
  • Page 18 INSTALAR EL DESAGÜE AUTOMÁTICO • Empuje la PIEZA POSTERIOR (11) hacia abajo en la TRAMPA (C) (extremo enroscado hacia arriba). • Enrosque la CONTRATUERCA (5), la ARANDELA (4) y la JUNTA (3) (lado biselado hacia arriba) en el CUERPO DEL DESAGÜE (10). •...
  • Page 19 REALIZAR LAS CONEXIONES DE LOS SUMINISTROS DE AGUA Y EL DRENAJE • Conecte las MANGUERAS FLEXIBLES (1, 2) directamente a los suministros de la pared. La conexión en los suministros tiene una compresión de 3/8". Conecte el suministro izquierdo (1) al suministro de la pared de agua CALIENTE (marcado con una raya roja) y el suministro derecho al de agua FRÍA (2).
  • Page 20 SERVICIO Apague los suministros de agua caliente y fría antes de comenzar. • Para retirar o reemplazar el cartucho: – Coloque la válvula en la posición APAGADO. – Retire el BOTÓN DEL TAPÓN (1) y retire el TORNILLO PARA MANIJAS (2). –...
  • Page 21 Registre la lavabo en www.americanstandard.com. Guarde el comprobante de compra (recibo de compra). Si necesita asistencia o no puede acceder a nuestro sitio web, comuníquese con Atención al Cliente de American Standard llamando al: (800) 442-1902. Un representante de American Standard lo ayudará a completar la inscripción de la garantía.
