American Standard Princeton T508.50X Series Installation Instructions

PRINCETON
PRESSURE BALANCING
BATH AND SHOWER
TRIM KITS
Thank you for selecting American-Standard...the benchmark of fine
quality for over 100 years.
To ensure that your installation proceeds smoothly-- please read these
instructions carefully before you begin.

Required Tools

Plumbers' Putty or Caulking

ROUGHING-IN DIMENSIONS (For reference only)

To assure proper positioning in relation to wall, note roughing-in dimensions.
FINISHED WALL
3-5/8" REF.
5-1/2" REF.
"SEE ILLUSTRATION "
74" FOR HEAD
CLEARANCE
18" OPTIONAL
3-5/8"
5-1/8" REF.
TOP OF TUB RIM
BOTTOM OF TUB

CARE INSTRUCTIONS:

DO: SIMPLY RINSE THE PRODUCT CLEAN WITH CLEAR WATER. DRY WITH A SOFT COTTON FLANNEL CLOTH.
DO NOT: CLEAN THE PRODUCT WITH SOAPS, ACID, POLISH, ABRASIVES, HARSH CLEANERS, OR A CLOTH
WITH A COARSE SURFACE.
Phillips Screwdriver
eflon ape
Flat Blade Screwdriver
1-5/8" TO 3-1/4"
SHR. 1/2" NOM.
1/2" NPT COPPER SWEAT
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 78'
6-3/4"
3-3/8"
3-3/8"
OUTLETS
1/2" NPT''
1/2" NPT
4"
Installation
Instructions
T508.50X
Adjustable Wrench
INLETS
1/2" NOM.
COPPER
INLETS
SWEAT
4-1/16"
SWEAT
INLETS
TUB 1/2" NOM.
COPPER SWEAT
SWEAT
INLETS (STOPS)
SHR. 1/2" NOM.
COPPER SWEAT
TUB 1/2" NOM.
COPPER SWEAT
INLETS 1/2" NPT
3-3/8"
THREADED INLETS
Certified to comply with ANSI A112.18.1
Channel Locks
2"
4-1/16"
5-7/8"
INLETS
1/2" NOM.
COPPER
SWEAT
OUTLETS
1/2" NPT
5-7/8"
THREADED INLETS (STOPS)
M968841
4-1/16"
INLETS
1/2" NPT
