DAKE STANDING METAL BELT SANDER
Model SG-75
INSTRUCTIONAL MANUAL
WARNING!
Read and understand all instructions and responsibilities before operating. Failure to follow
safety instructions and labels could result in serious injury.
Dake Corporation
Phone: 800.937.3253
www.dakecorp.com
1809 Industrial Park Dr
Fax: 800.846.3253
Grand Haven, MI 49417
Advertisement
Table of Contents
Related Manuals for Laguna Tools Dake SG-75
Summary of Contents for Laguna Tools Dake SG-75
- Page 1 DAKE STANDING METAL BELT SANDER Model SG-75 INSTRUCTIONAL MANUAL WARNING! Read and understand all instructions and responsibilities before operating. Failure to follow safety instructions and labels could result in serious injury. Dake Corporation Phone: 800.937.3253 www.dakecorp.com 1809 Industrial Park Dr Fax: 800.846.3253 Grand Haven, MI 49417...
-
Page 2: Table Of Contents
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com TABLE OF CONTENTS DAKE STANDARD LIMITED WARRANTY ............2 RETURN & REFUND POLICY ................4 DAKE STANDARD TERMS & CONDITIONS OF SALE ........5 SPECIFICATIONS ....................6 SAFETY ........................ 6 SET UP ......................... -
Page 3: Dake Standard Limited Warranty
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com DAKE STANDARD LIMITED WARRANTY Finished Machines − Dake warrants to the original purchaser the finished machine manufactured or distributed by it to be free from defects in material and workmanship under normal use and service within 1 year (12 months) from the delivery date to the end user. - Page 4 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Warranty Exceptions: The following conditions are not applicable to the standard limited warranty: (a) Part installation or machine service was not completed by a certified professional, and is not in accordance with applicable local codes, ordinances and good trade practices. (b) Defects or malfunctions resulting from improper installation or failure to operate or maintain the unit in accordance with the printed instructions provided.
-
Page 5: Return & Refund Policy
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com RETURN & REFUND POLICY − Thank you for purchasing from Dake! If you are not entirely satisfied with your purchase, we are here to help. Returns − All Dake manufactured / distributed machines, parts and couplings include a 30-day return option. -
Page 6: Dake Standard Terms & Conditions Of Sale
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com DAKE STANDARD TERMS & CONDITIONS OF SALE All proposals and quotations for the original sale of our products are subject to the following terms and conditions: ACCEPTANCE OF ORDER: All orders are subject to acceptance by Dake at its main office in Grand Haven, Michigan. -
Page 7: Specifications
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com SPECIFICATIONS Model Number 961005 Horsepower 1.5HP Voltage 220V Single Phase Amps 3.9A Belt Included 80 Grit 3” x 79” Belt Speed 5018 FPM Base 16” x 13” Height 42” Weight 117 lbs. - Page 8 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com This is the safety alert symbol. When you see this symbol on your press be alert to the potential for personal injury. Employer is responsible to perform a hazard/PPE assessment before work activity. Follow recommended precautions and safe operating practices.
-
Page 9: Set Up
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com SET UP When unpacking machine inspect all parts for shipping damage. Metal Belt Grinder Belt Access Door Key (not shown) Spark Tray (inside machine) PLACEMENT Below is the minimum area needed for machine. Plan enough space for workpieces and any material stands that may be used in the future. -
Page 10: Electrical
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com ELECTRICAL Electrical wiring must be done by an electrician or qualified service personnel in accordance with all applicable codes and standards. Machine is prewired to operate on the following power supply requirements Nominal Voltage 208V, 220V, 230V, 240V Cycle... -
Page 11: Installing/Changing Belt
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com INSTALLING/CHANGING BELT 1. Make sure machine is not connected to power source. 2. Use key to unlock and open belt access door. 3. Turn belt tension lock knob counterclockwise to loosen lock collar and release belt tension lever. -
Page 12: First Time Operation
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com FIRST TIME OPERATION In the first run, there are 3 things to look for: • Belt tracks properly and will not come off wheel. • Motor runs correctly. • E-Stop disables machine properly. 1. -
Page 13: Operation
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com OPERATION 1. Turn machine on. 2. Position work piece on center of work rest. Always use 2 hands and the work rest to support your work. 3. Using both hands slowly feed it into contact wheel with light consistent pressure. DO NOT force the work against the belt/wheel. -
Page 14: Troubleshooting
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com TROUBLESHOOTING Symptom Possible Cause Possible Solution Machine does not 1. E-Stop cover depressed/at fault 1. Remove E-Stop over to reset. Replace start, or 2. Incorrect power supply voltage or if at fault. - Page 15 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Symptom Possible Cause Possible Solution Grinding belt slips 1. Incorrect grinding belt tension 1. Make sure tension lever is locked in during use. 2. Excessive feed pressure tensioning position 2.
-
Page 16: Electrical Diagram
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com ELECTRICAL DIAGRAM Motor junction box Push button magnetic switch 961005 REV042023... -
Page 17: Exploded Parts View
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com EXPLODED PARTS VIEW 961005 REV042023... -
Page 18: Parts List
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com PARTS LIST Item Description Part No Item Description Part No Door Lock Hex Bolt (M10-1.5x55mm) Door Retaining Ring (20mm) Belt 3” x 79” 80 Grit (Included) Idler Wheel Belt 3” x 79” 60 Grit 77021 Ball Bearing 6004ZZ Tension Lock Collar...
