- Page 1 Link 150 M3 MCU Facility Preparation Link Wireless Telephone System Part Number: 72-0075-05 Issue F...
-
Page 2: Trademark Information
No representation or other affirmation of fact contained in this document including but not limited to statements regarding capacity, response-time performance, suitability for use, or performance of products described herein shall be deemed to be a warranty by SpectraLink for any purpose, or give rise to any liability of SpectraLink whatsoever. -
Page 3: Important Safety Information
SpectraLink Corporation WARNING: Changes or modifications to this equipment not approved by SpectraLink Corporation may cause this equipment to not comply with part 15 of the FCC rules and void the user’s authority to operate this equipment. WARNING: SpectraLink products contain no user-serviceable parts inside. Refer servicing to qualified service personnel. -
Page 4: Table Of Contents
SpectraLink Corporation 1. About This Document SpectraLink Corporation Model Numbers Related Documents Customer Support Hotline Icons and Conventions 2. Link Wireless Telephone System Overview System Operation The Front Panel of the MCU 3. Site Preparation Installation Steps Materials Required by Customer Determine Location of MCU 4. -
Page 5: About This Document
PBX) Available at http://www.spectralink.com/consumer/resources/interface_guides.jsp. Customer Support Hotline SpectraLink wants you to have a successful installation. If you have questions please contact the Customer Support Hotline at (800) 775-5330 Monday through Friday, 6 a.m. to 6 p.m. Mountain time. -
Page 6: Link Wireless Telephone System Overview
Master Control Unit (MCU) Serves as the connecting point, or gateway, between the Base Stations and the existing telephone system. One or more of these boxes (approximately 12” x 3” x 7”) are typically installed in the telephone equipment room and provide connectivity from the telephone system to the Link WTS. - Page 7 SpectraLink Corporation SpectraLink offers an analog MCU that works with telephone systems (CO, PBX or key systems) with analog (loop start) ports. SpectraLink also offers digital MCUs that work with the most common brands of telephone systems (PBX or key systems) digital ports.
-
Page 8: The Front Panel Of The Mcu
SpectraLink Corporation The Front Panel of the MCU The MCU’s front panel contains the connections to the telephone system, switches to control system administration, and status LEDs. PN: 72-0075-05-F.doc Link WTS – Link 150 M3 MCU Button: Selects a specific line or Base STEP Station during registration process. -
Page 9: Site Preparation
SpectraLink Corporation Site Preparation All site preparation steps should be completed prior to the arrival of the SpectraLink field service engineer. A SpectraLink customer support representative will contact the customer the week before the scheduled installation date to confirm that pre- installation tasks have been completed. -
Page 10: Installation Steps
SpectraLink Corporation Installation Steps This table lists the installation steps and the person usually responsible for each step. Task Description Site Preparation Determine location of MCU Run Cable for System Run cable to Base Station locations Terminate cable at Base Station locations... -
Page 11: Materials Required By Customer
• The MCU must be within 250 feet of the PBX for a digital interface and within 2,200 feet of the Base Stations. See your telephone system specifications for distance limitations for analog modules. If your system has more than one MCU, the units should be mounted vertically, side by side physically touching the adjacent unit. -
Page 12: Run Cable For System
Run Cables to Base Station Locations The Base Station locations should be designated on the building floor plans provided to the SpectraLink field service engineer. Base Stations can be mounted easily on raised or acoustical ceiling tiles. Avoid locating Base Stations in high or hard-to-reach places, as this will hinder maintenance, testing and/or repositioning. -
Page 13: Pull Cable
SpectraLink Corporation Pull Cable Pull the cable from the MCU location (usually in the telephone equipment room) to the Base Station locations designated on the floor plans. If the cabling exits the building, consult the telephone system manual, the National Electrical Code (NEC) and local codes for instructions on providing lightning and other over-current protection. -
Page 14: Prepare Demarc Blocks
Prepare Demarc Blocks The MCU is connected to the existing telephone system using RJ-21 connections. An MCU is designed to operate with a specific interface to the telephone system: two-wire digital or analog, or four-wire digital. The number of demarcation blocks required for the system depends on the number and type of interface modules to be installed. - Page 15 SpectraLink Corporation Based on the number and type of interfaces in the system, determine the number of 25-pair cables required to connect line ports and Base Stations to the demarcation blocks. The diagrams that follow provide an overview of the connections.
- Page 16 SpectraLink Corporation Two-wire Analog or Digital Interface The wiring diagram below shows the connections required for a two-wire analog or digital interface. Base Stn. 1-4 Base Stations Two-wire Analog or Digital Connection PN: 72-0075-05-F.doc Telephone Ports Pair 1-16 Pair 17 Unused...
- Page 17 SpectraLink Corporation Four-wire Digital Interface The wiring diagram below shows the connections required for a four-wire digital interface (available in a future release). Each MCU of this type requires two demarcation blocks which will be wired as indicated. Base Stations PN: 72-0075-05-F.doc...
-
Page 18: Install Demarc Blocks
The demarcation blocks used to connect the telephone system and Base Stations to the MCU should be installed on a typical telephone facility backboard. A 1/2” or 3/4” thick board mounted on the wall near the MCU is typical. Although this manual uses 66 blocks as examples, any standard cross-connect blocks are acceptable. -
Page 19: Connect Cables From Base Stations And Phone Lines To Demarc Blocks
Use the forms to track the Base Stations and handset port assignments connected to each MCU. As the SpectraLink field service engineer makes each Base Station or handset connection, fill in the information on... - Page 20 SpectraLink Corporation Two-wire Analog or Digital Demarc Block The demarc block for the two-wire analog or digital interface should be wired as follows. LINE1 ring LINE 2 ring LINE 3 ring LINE 4 ring LINE 5 ring LINE 6 ring...
- Page 21 SpectraLink Corporation Four-wire Digital Demarc Block The four-wire digital interface (future release) requires two demarc blocks, one to Connector and one to Connector Line 1 TX ring Line 2 TX ring Line 3 TX ring Line 4 TX ring Line 5 TX...
- Page 22 SpectraLink Corporation Line 1 RX ring Line 2 RX ring Line 3 RX ring Line 4 RX ring Line 5 RX ring Line 6 RX ring Line 7 RX ring Line 8 RX Telephone ring Ports Line 9 RX ring...
-
Page 23: Install Base Stations
The LED will blink red and green as the system software downloads to the Base Station and the Base Station is tested. When the LED blinks amber, the system is ready for operation. When the LED blinks green, a telephone has established a radio link with that Base Station. PN: 72-0075-05-F.doc Facility Preparation Link WTS –... -
Page 24: Mount Base Stations On Finished Ceilings
SpectraLink Corporation If the LED turns solid red, there should be an error message on the MCU’s LEDs. Refer to Link 150 M3 MCU: Installation and Operation for error STATUS code message information. Mount Base Stations On Finished Ceilings If your site does not have a dropped tile ceiling, the Base Station can be mounted to a finished ceiling or wall with a 4 to 5”... -
Page 25: Install Outdoor Base Stations
SpectraLink Corporation Install Outdoor Base Stations Outdoor Base Stations are equipped with a protective enclosure, designed to be mounted to a wall or pole. After the enclosure is mounted, the Base Station is inserted in the enclosure and connected. Only RCO Base Stations can be used outdoors. -
Page 26: Sample Schedule For Installation
10. Walk the site with the system administrator to show coverage. 11. Train the system administrator(s). Note: SpectraLink standard mounting is on 7/8” T-bar grid or on 3/4” steel beams. All areas must be accessible with standard on-site equipment. All other non-standard or non-accessible mounting of the Base Stations should be completed prior to the installation by the customer. -
Page 27: Link Wireless Telephone Planning Worksheet
MCU ID: _________ Tel No. Extension Port ID *On MCU No. 1: Reserve Port 1 for access to SpectraLink Diagnostic Modem **On MCU No. 1: Port 2 is used for administrative programming (analog system only) PN: 72-0075-05-F.doc Link WTS –... -
Page 28: Base Station Location Worksheet
SpectraLink Corporation Base Station Location Worksheet MCU: ________ Base Station # (e.g.: building, floor #, detailed description) Base Station 1 Base Station 2 Base Station 3 Base Station 4 MCU: ________ Base Station # (e.g.: building, floor #, detailed description) - Page 29 SpectraLink Corporation Attenuation, 14 Base Station Description, 9 Install, 25 Location form, 30 Outdoor, 27 Base Stations Cabling, 14, 15 Cabling, 16 Base stations, 14 Demarcation blocks, 20 Four-wire digital, 19 Two-wire analog or digital, 18 Ceiling clip, 25 Connection to Telephone System, 16...
