Instructions for use
KARL STORZ OR1 FUSION, Rel. 1.4.3

Advertisement

Table of Contents
loading

Related Manuals for Storz OR1 FUSION

Summary of Contents for Storz OR1 FUSION

  • Page 1 Instructions for use KARL STORZ OR1 FUSION, Rel. 1.4.3...
  • Page 2 09-2022 Copyright © All product illustrations, product descriptions, and texts are the intellectual property of KARL STORZ SE & Co. KG. Their use and reproduction by third parties require the express approval of KARL STORZ SE & Co. KG. All rights reserved.

  • Page 3: Table Of Contents

    5.3 Connecting the product  ......................19 6 Operation  ............................20 6.1 Switching on the product ......................20 6.2 User interface ..........................20 6.2.1 Symbols on the user interface  ..................21 6.3 Onscreen keyboard ........................22 Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 4 9.7 Table 5 – Recommended separation distances between portable and mobile HF communications equipment and the product ................99 9.8 Regulatory information on telecommunications  ................ 99 9.8.1 USA ..........................99 9.8.2 Canada  ......................... 99 Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 5 Table of contents 9.8.3 European Union  ......................100 10 Subsidiaries ............................101 Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 6: General Information

    ð Result of a completed action Actions in safety notes or in the case of a single step: Step 1 Lists Numbered list – Unnumbered list, 1st level Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 7: Description Of Warning Messages

    Designates a possible imminent risk. If this is not avoided, it could lead to minor injuries.   NOTICE    NOTICE Designates a possibly harmful situation. If this is not avoided, the products could be damaged. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 8: Normal Use

    2 Normal use 2.1 Intended use The OR1 FUSION CONTROL is designed for use in operation rooms by qualified personnel. The OR1 FUSION CONTROL is an appliance (comprising hardware and software) for the documentation of audiovisual data and patient data during diagnostic or therapeutic procedures. It allows the operation to be recorded and described for documentation purposes.

  • Page 9: Safety And Warning

    ISO standards. Furthermore, all configurations must comply with the requirements for medical electrical systems (see IEC 60601-1-1 or clause 16 of the 3rd edition of IEC 60601-1). Any person who Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 10: Dangers From Electrical Current

    Have the device installed and put into service by authorized and trained electricians of KARL STORZ SE & Co. KG or by companies authorized by KARL STORZ. Use either the power cord supplied by KARL STORZ or a power cord which has the same properties and which bears a national mark of conformity.

  • Page 11: Damage Due To Ingress Of Liquid In Electrical Components

    In case of a failure or malfunction, cease work immediately and switch to a backup system. Prior to each operation, make sure that the personnel are familiar with the procedure for switching over to the backup system. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 12: Electromagnetic Interference

    Only switch off the product using the rocker switch. Connecting non-compatible signal types to the patch panel in the OR can cause image interference and malfunctioning. Only connect permitted signal types. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 13: Data Loss

    Perform a system test which verifies perfect functioning after adding new software or hardware. Shut down the software via the user interface or by briefly pressing the rocker switch. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 14: Product Description

    4 Product description 4.1 Description of function KARL STORZ OR1 FUSION is designed for use in the operating rooms of clinics and hospitals. The product is used to aid the implementation and documentation of medical procedures aimed at examining and treating patients.

  • Page 15: Possible Combinations

    The product consists of the items listed in the scope and is used exclusively in combination with these. 4.4 Technical data Description Value Power supply Operating voltage 100 – 240 V Operating frequency 50/60 Hz Maximum current consumption 5 – 2 A Electrical protection class Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 16: Symbols Employed

    GHz ® Operating system Windows 10 Embedded Operating mode Continuous operation The KARL STORZ OR1 FUSION contains a lithium battery that needs to be checked and replaced regularly. 4.5 Symbols employed 4.5.1 Symbols on the packaging Symbol Meaning Manufacturer...

  • Page 17: Symbols On The Product

    Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 18: Symbols On The Type Plate

    Storage/transport conditions Temperature -10 °C ... +60°C (14°F ... 140°F) Relative humidity 5 – 95 % (non-condensing) Air pressure 500 – 1,080 hPa Operating conditions Temperature 5 °C ... 35°C (41°F ... 95°F) Relative humidity 20 – 80 % (non-condensing) Air pressure 700 – 1,080 hPa Max. operating altitude 3,000 m Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 19: Preparation

    Nothing may be mounted in the defined free areas. 5.3 Connecting the product The product may only be connected to other components by KARL STORZ service personnel or personnel authorized by KARL STORZ. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 20: Operation

    Switch on the connected equipment. Switch on the product via the rocker switch. ð The software will start up. 6.2 User interface The following user interface appears when the KARL STORZ OR1 FUSION application is started: Messages Navigation bar Patient data...

  • Page 21: Symbols On The User Interface

    Switch microphone to mute. The microphone is set to mute as standard and must be activated manually. Volume Adjust the output level of the active speakers or headphones. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 22: Onscreen Keyboard

    A high volume could startle the surgeon. This can result in injury to the patient, surgeon, or third parties. Check the volume before each operation. Volume level Speaker ON/OFF Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 23: Presets

    Settings from the Capture, Routing, and Light modules can be saved via presets. These settings can be called up for particular procedures and for individual users. 6.5.1 Creating a preset Configure the required settings Tap the Presets menu. ð The Preset screen appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 24 Give the preset a name in the Description field. Activate the required checkboxes to assign the preset to procedures and physicians. Confirm the entries by pressing OK. ð The preset appears in the preset list: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 25: Using The Preset

    Tap the Presets menu. ð The Preset screen appears: Touch the desired preset. ð The selection turns orange: Confirm the selection by pressing OK. ð The preset settings are saved. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 26: Searching For A Preset

    ð All presets that contain the entered search term appear. 6.5.3.1 Search via the patient screen The search is limited to the type of procedure. Select the type of procedure. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 27: Current Procedure" Application Area

    6.6 "Current procedure" application area Some of the individual modules may not be available, depending on the upgrade level and configuration of the system. The application area contains the following modules: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 28: Patient

    6.6.1 Patient The administrator can limit or expand the scope of the documentation for the Patient module and this scope needs to be configured in cooperation with the KARL STORZ technicians during installation and commissioning. The following can be documented in the Patient module: –...
  • Page 29 Already created recordings are assigned to new patients when new data is entered. Ensure that all relevant patient data has been entered correctly before capturing the first still: ID, last name, first name, date of birth. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 30 ð The following screen appears: Enter all the members of the surgical team. Touch the button on the right next to the relevant field to select a team member from a list. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 31 10. Enter the identification numbers of the instrument trays used and the serial number of the endoscope used. 11. The mandatory fields are blocked once you have captured audio recordings and video recordings. Touch the Modify data button to unlock the mandatory fields. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 32 ð The following screen appears: Touch the Import DICOM Worklist button. ð The DICOM worklist window appears. Select a Parameter and enter a term in the search field. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 33: Checklist

    ð The data stored in the DICOM is preserved. ð The system is ready for the manual compilation of a new procedure. 6.6.2 Checklist The Checklist module provides a safety checklist for surgical procedures. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 34 ð The selected checklist starts. The selection cannot be canceled. ð Any entered patient data and procedure data appears. ð The progress indicator for the editing of the checklist is shown. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 35: Capture

    Touch the Finish button in the navigation bar to finish the checklist. 6.6.3 Capture The Capture module can be used to take video recordings, stills, and audio recordings during the procedure. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 36 6.6.3.1 Creating an annotation For documentation purposes, the start time can be overwritten with your own term. Left-click to select the capture you want. ð The context menu appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 37 Press the Video button under the preview for channel 1 or 2 to start the capture. ð The start of the capture is confirmed in the list of video sequences. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 38 Touch the Delete entry to mark the capture for deletion. ð The capture is not saved and is discarded permanently during data storage. Touch the Delete entry again to remove the deletion mark. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 39 Confirm the selected routing by pressing OK. ð The image ID, video ID, or audio ID is displayed on the target screens. The captures appear in chronological order. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 40: Edit

    Touch the Edit menu. ð The following screen appears: The following 3 tabs are available for editing the captures: Viewer – – Stills from videos – Still editing Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 41 Start a capture and touch the Camera button. ð The still appears on the right next to the preview window. 6.6.4.3 Still editing Stills can be edited in the Still editing tab. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 42: Finish

    To ensure that the documentation can be saved, all mandatory fields must be completed. Editing of the safety checklist is optional. The user is responsible for using and managing removable storage devices. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 43 Activate the checkbox for the desired destination directory. Insert a USB stick, CD, or DVD. The user is responsible for the management of removable data carriers. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 44: Control" Application Area

    Medical Device Control – Operate integrated medical devices directly on the touchscreen. Entertainment Operate iPod. Light Operate room lighting. Room Control 1–3 Control room functions in operating rooms. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 45: Anesthesia Safety

    Routing to a target outside the operating room may impinge on the patient's data protection rights. Adhere to the currently valid legislation in the respective country. Touch the Routing menu. ð The module appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 46 The components and monitors of the KARL STORZ OR1 FUSION are not diagnostic or therapeutic devices. The preview of the KARL STORZ OR1 FUSION is not to be used for diagnostic or therapeutic purposes. The preview image can be displayed in three sizes: –...
  • Page 47 To switch from the large image to the fullscreen image, touch the Screen symbol in the top right. To return from the fullscreen image to the large image, touch anywhere on the image. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 48 The cor- ner for the secondary image can be freely selected. Quad The images from four sources are each shown in a quadrant of the target monitor. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 49 Operation Assigning an image source to a target Tap a source, e.g., Endoscopic Cam. ð The preview appears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 50 ð The signal is shown on the target monitor as a full-screen image. Assigning two image sources to a target Select the desired image composition, e.g., PAP, in the marked area. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 51 Operation Tap the first source, e.g., Endoscopic Cam. ð The preview appears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 52 ð The preview appears. Click in the marked area to assign the source to the same target. ð The signal is shown on the right half of the target monitor. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 53 Assigning four image sources to a target Select the desired image composition, e.g., QUAD, in the marked area. Tap the first source, e.g., Endoscopic Cam. ð The preview appears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 54 Click in the marked area to assign the source to a target, e.g., Monitor 1. ð The signal is shown on the target monitor as the main image. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 55 Operation Tap another source, e.g., Room Cam. ð The preview appears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 56 ð The screen changes to standby mode. To switch on a screen again, touch the monitor symbol again for approx. 3 seconds. ð The screen is switched back on again. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 57: Controlling The Room Camera

    With the Medical Device Control - SCB module, you can operate integrated medical devices directly on the touchscreen. To use the Medical Device Control, see the KARL STORZ SCB control NEO System and KARL STORZ OR1 SCB CONTROL instructions for use. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 58: Entertainment

    Operate the device on the touchscreen. ð The device is synchronized simultaneously. Touch the Home button to return to the KARL STORZ OR1 FUSION screen. Operation directly on the device is also possible at any time. The display on the touchscreen is synchronized simultaneously.

  • Page 59: Light

    Activate the Random checkbox to play the songs in the selected category in random order. Activate the Repeat checkbox to repeat the selection infinitely. 6.7.6 Light The Light module can be used to operate the room lighting. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 60: Room Control

    The following room functions can be controlled: – Room light – Dimming the lights – Selection and combination of the colors red, green, and blue – Air conditioning and ventilation systems – Blinds Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 61: Previous Procedures" Application Area

    Images and videos can be copied from the system to other data carriers and networks (PACS, HIS, AAR). The coloring of the module is different to prevent any confusion between the content of the filing cabinet and the current treatment. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 62 ð The following screen appears: Touch a button under Select source to import past data to select the desired data source. ð The available data is shown as a table: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 63 6.8.1.2 Copying a data set The Copy function is available for completed procedures. ü A data set is opened. Touch the Copy button. ð A window with possible destination media appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 64: Open Tasks

    If the system is shut down while copying is in progress, the following message appears: 6.8.2 Open tasks Unsaved patient data can be saved in the Open tasks module. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 65: Communication" Application Area

    6.9 "Communication" application area Some of the individual modules may not be available, depending on the upgrade level and configuration of the system. The application area contains the following modules: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 66: Access Status

    Room To Room Transmit audio data and video data to one or more rooms. 6.9.1 Access status An access status can be set in the KARL STORZ OR1 FUSION. The status can be changed via a drop-down menu in the header: Private Upon setting the access status to Private, all remote access queries are rejected.
  • Page 67 For room OR 1, the access status Public must be selected. – For rooms OR 2, OR 3, OR 4, etc., the access status Public, Room to Room, or Private can be selected. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 68: Streaming

    Further information about using the relevant application can be found in the corresponding instructions for use. 6.9.3 Phone The system phone functions can be operated in the Phone module. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 69 Touch Home in the navigation bar and then select the application area you want in the main menu. Touch the required application directly in the navigation bar. Touch Phone in the navigation bar to call up the phone functions again. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 70: Unified Communication

    The Unified Communication module provides an interface for external communication for transmitting audio data and video data, e.g., from endoscopic cameras and room cameras. Touch the Unified Communication menu. ð The following screen appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 71 The components and monitors of the KARL STORZ OR1 FUSION are not diagnostic or therapeutic devices. The preview of the KARL STORZ OR1 FUSION is not to be used for diagnostic or therapeutic purposes. The preview image can be displayed in three sizes: –...
  • Page 72 ð The normal image appears in the preview: Touch the Enlarge button to display a large image. Touch the OK button to return from the large image to the normal image. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 73 To return from the fullscreen image to the large image, touch anywhere on the image. 6.9.4.2 Adjusting the preview Start the Unified Communication module. ð The module preview appears: ð The preview shows the incoming video signal from the counterpart station. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 74 ð The onscreen keyboard appears: Enter the contact or virtual room and confirm by pressing Return. ð Available contacts and virtual rooms are displayed. Touch the required contact or virtual room. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 75 ð If the Private access status has been selected, only the Unified Communication symbol flashes. Touch the Unified Communication symbol in the navigation bar. ð The following window appears: Confirm the call by pressing OK. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 76 Confirm the selection by pressing OK. ð The source is available to the recipient and appears in the Shared Source area. 6.9.4.7 Selecting the target ü The Unified Communication module has been started. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 77 Touch the deactivated source for at least 3 seconds to activate a video. ð The symbol and the name of the source are displayed as normal. ð The blue standby symbol disappears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 78: Video Conference

    The Video Conference module provides an interface for video conferences in which audio data and video data is transmitted, e.g., from endoscopic cameras and room cameras. Touch the Video conference menu. ð The following screen appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 79 6.9.5.1 Editing the contact list Video conference partners can be displayed and saved via the contact list. Only contacts that are saved in the system are displayed. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 80 Tap the desired contact. Alternative: Enter a search term and confirm by pressing the RETURN button. ð Possible contacts appear. Tap the desired contact. ð The selection turns orange. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 81 Confirm the selection by pressing OK. ð The source is available to the recipient and appears in the Shared Source area. 6.9.5.5 Selecting the target ü The Unified Communication module has been started. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 82 Touch the source for at least 3 seconds to deactivate a video. ð The symbol and the name of the source are grayed out. ð A blue standby symbol appears. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 83: Room Connection

    – Via the "Room To Room" access status: Connection between 2 rooms (communication in both directions). Touch the Room to Room menu. ð The following screen appears: Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 84 Source selection and target selection The source selection determines the outgoing signal of a room-to-room connection. The target selection determines the destination on which the incoming signal is displayed. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 85 ð A connection request is sent to the selected room. Confirm the Request for Access with OK. ð The message in OR 1 disappears. 6.9.6.2 Establishing a room-to-room connection ü The Room To Room module has been started. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 86 ð The following window appears: Confirm the Request for Access with OK or deny it with Cancel. ð The Room To Room button flashes in the receiver navigation bar after confirmation. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 87 Deny the Request for Access by pressing Cancel. ð The following window is displayed to the sender, which is closed automatically after 10 seconds: 6.9.6.3 Selecting the source ü The Unified Communication module has been started. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 88 Confirm the selection by pressing OK. ð The source is available to the recipient and appears in the Shared Source area. 6.9.6.4 Selecting the target ü The Unified Communication module has been started. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 89 Once a target has been selected and confirmed by pressing OK, the signal only appears at the selected targets depending on the upgrade level and configuration of the system. The preview on the touchscreen is no longer available. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 90 ð The connection is disconnected. ð The room you were connected to is informed of the change in status. ð The selected sources disappear from the Shared Local Sources area. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 91: Switching Off The Product

    ð The software will shut down and the product will switch to standby mode. Alternatively, briefly press the rocker switch. ð The software will shut down and the product will switch to standby mode. Switch off all connected devices. Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 92: Maintenance, Servicing, Repairs, And Disposal

    The product meets the requirements of the Directive on Waste Electrical and Electronic Equipment (WEEE). Within the scope of application of this directive, KARL STORZ SE & Co. KG is responsible for the proper disposal of this product. The product must be disposed of in accordance with the applicable national laws and regulations at a suitable collection point for the reprocessing of electrical and electronic equipment.

  • Page 93: Accessories And Spare Parts

    OR1 signal lamp, ON AIR, RGB W22146 OR1 DP to VGA Cable, length 12 cm W23245 21.5" KARL STORZ Touchscreen WM100 24" KARL STORZ Touchscreen WM101 OR1 SmartScreen WM200 Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 94: Electromagnetic Compatibility

    WARNING Reduced immunity! Risk of injury! The use of accessories or cables other than those specified in the KARL STORZ instructions for use may result in increased emissions or decreased immunity of the product. The cables listed have been shown to comply with the requirements of IEC 60601-1-2.
  • Page 95 315° phase angles and 315° phase angles ated with an uninterrupt- Voltage interruption: Voltage interruption: ible power supply or a 100% for 250/300 cy- 100% for 250/300 cy- battery. cles cles Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 96 Pulse modula- TETRA 800, tion iDEN 820, 18 Hz CDMA 850, LTE band 5 1720 1700 – 1990 GSM 1800, Pulse modula- CDMA 1900, tion 1845 GSM 1900, 217 Hz DECT, Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 97 Field strengths from fixed HF transmitters as determined by an electromagnetic site survey should be less than the compliance level in each frequency range d = 1.2 √P 80 MHz to 800 MHz Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 98 IEC 61000-3-2 low voltage power supply network that supplies buildings used for domestic Voltage fluctuations/flicker emissions Complies purposes. acc. to IEC 61000-3-3 Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...

  • Page 99: Regulatory Information On Telecommunications

    The device must not cause harmful interference. – The device must be able to withstand harmful interference, including interference which may lead to undesirable functions. Includes IC: 1000M-8265NG Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 100 Electromagnetic compatibility 9.8.3 European Union The device may only be used indoors. Radio Equipment Directive (RED) 2014/53/EU Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 101 Gedik Is Merkezi B Blok, Kat 5, D 38-39, Bagdat Cad. No: 162, Maltepe Istanbul, Turkey Phone: +90 216 442 9500, Fax: +90 216 442 9030 **Sales for Industrial Endoscopy Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 102 Room 803-805, 8F Jin Jiang International Building, No. 1 West Linjiang Road, Wuhou District, 6100414, Chengdu, People’s Republic of China Phone: +86 28 86587977, Fax: +86 28 86587975 E-mail: info@karlstorz.com.cn Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 103 Subsidiaries Instructions for use • KARL STORZ OR1 FUSION, Rel. 1.4.3 • JEB924_EN_V3.0_09-2022_IFU_CE-MDR...
  • Page 104 KARL STORZ SE & Co. KG Dr.-Karl-Storz-Straße 34 78532 Tuttlingen Postfach 230 78503 Tuttlingen Germany Phone: +49 7461 708-0 Fax: +49 7461 708-105 E-mail: info@karlstorz.com www.karlstorz.com...
