7.1.1 Maintenance .......................... 20 Repairing the product .......................... 20 Disposing of the product ........................ 20 8 Accessories and spare parts ........................ 21 Accessories............................. 21 9 Electromagnetic compatibility........................ 22 General notes on the operating environment .................. 22 Accessories and cables .......................... 22 Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 4
Table 4 – Emission class and group ....................... 26 Table 5 – Recommended separation distances between portable and mobile HF communications equipment and the product ........................ 26 10 Faults and messages .......................... 27 10.1 Troubleshooting ............................ 27 11 Subsidiaries.............................. 29 Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Designates a possible imminent risk. If this is not avoided, it could lead to minor injuries. NOTICE ATTENTION Designates a possibly harmful situation. If this is not avoided, the products could be damaged. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
2 Normal use 2.1 Intended use The KARL STORZ OR table interface module is designed for installation in the KARL STORZ SCB Interface control and for use as a stand-alone device. It is used for remote control of designated OR tables from the KARL STORZ OR1 system with a compatible interface between the KARL STORZ control unit and third-party OR tables.
Only use approved accessories. Comply with national and local regulations. Only make changes to the product if these changes are approved by KARL STORZ. 3.4 Damaged products Damaged products can result in injury to patients, users, or third parties. In the event of a fault, the housing may heat up.
IEC standards. Input and output equipment connected to the product must comply with IEC 60601-1. Use either the power cord supplied by KARL STORZ or a power cord which has the same properties and which bears a national mark of conformity.
When using explosive narcotic gases: Operate the product outside of the hazard zone. Do not use the product in the presence of flammable anesthetics. The product must not be operated in oxygenated environments. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Product description 4 Product description 4.1 Technical description The OR1 table interface is an interface module and allows the remote control of operating ® tables via the KARL STORZ SCB system. The overall system comprises the following components, see also Possible combinations [p. 11]: –...
Please note that the products listed here may not yet be available in all countries due to differences in approval requirements. Only the system components and standards listed below may be used within the system. If necessary, detailed information can be requested from the responsible KARL STORZ contact partner. Control unit ®...
Product description 4.4.1 Basic configuration OR1 table interface with panel PC Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 14
Product description OR1 table interface with touch monitor Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Federal (USA) law restricts this device to sale by or on the order of a physician. CE marking With this mark, the manufacturer declares the compliance of the devices with the applicable standards and directives The device must not be modified in any way Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
CE mark indicates the responsible notified body. Prevention of pollution by electronic devices Separate collection of electrical and electronic devices. Do not dispose of in household refuse. Unique Device Identifier Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Install the product out of reach of patients. Secure the transmitter and communication unit (WU10001). 5.3 Testing the product Check that the product is functioning properly and is in good working order. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Execute the desired movement command. ð The operating table moves to the selected position. 6.3 Switching off the product Use the standby button to switch the product to standby mode. Switch the overall system off. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
If they are not described in more detail here, maintenance activities may only be performed by KARL STORZ or by a company authorized by KARL STORZ. 7.1.1 Maintenance Maintenance work may only be carried out by KARL STORZ or a company authorized by KARL STORZ. Interval...
Cable for release switch F 3C, length 1.5 m 1744491 Patch cable, CAT, 5E, length 2 m 4800118 OR1 data transfer cable RS232, 2 m WU10004 OR1 data transfer cable RS232, 2 m WU10005 Release switch WO10027 Patch panel WO10026 Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
The power supply qual- transients/bursts ity should be that of a ± 1 kV for input and ± 1 kV for input and acc. to IEC typical commercial or output lines output lines 61000-4-4 hospital environment. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 23
80 MHz 80 MHz bances, induced 1 kHz 80% AM modu- 1 kHz 80% AM modu- by radio-fre- lation lation quency fields acc. 6 V in ISM band 6 V in ISM band to IEC 61000-4-6 Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 24
– guidelines Conducted HF distur- 3 V 3 V Portable and mobile HF bances acc. to IEC communications equip- 150 kHz to 80 MHz 61000-4-6 ment should be used no closer to any part of the Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 25
If abnormal perfor- mance is observed, additional measures may be necessary, such as re-orienting or relocating the product. Over the frequency range from 150 kHz to 80 MHz, field strengths should be less than 3 V/ Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 26
Note: At 80 MHz and 800 MHz, the separation distance for the higher frequency range ap- plies. Note: These guidelines may not apply in all situations. The propagation of electromagnetic waves is affected by absorptions and reflections of buildings, objects, and people. Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 27
Product software not compat- Contact Service ible with manufacturer-de- pendent transmitter or com- munication unit Manufacturer-dependent Replace transmitter or transmitter or communication communication unit unit faulty Observe the manufacturer documents Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
Page 28
Observe the manufacturer documents Manufacturer-dependent Connect transmitter or transmitter or communication communication unit to unit without power supply the power supply Replace faulty supply cable if necessary Observe the manufacturer documents Instructions for use • OR1™ Table Interface • ZWV442_EN_V1.0_02-2021_IFU_CE-MDR...
