Speco HT-7815DNV Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Weatherproof Day/Night Camera
with External Controls
• Day/Night DC varifocal auto iris lens (5mm-50mm) • External lens control of zoom and focus
• Split Glass Technology eliminates IR reflections • Mechanical day/night IR cut filter
• Lux level dip switch controls when the camera switches into B/W mode
• Built-in 25 IR LED'S & CDS sensor • IR range 100 ft.*
• UTP function built-in for use with twisted pair wiring in addition to standard coax
• 1/3" SONY ExView** CCD • Video test connector for easy installation • Dual voltage operation
• Built-in heater extends operating range and eliminates condensation • Weatherproof sunshield
• Rear panel controls (BLC, ELC, F/L, L/L) • Turbo AGC • Heat sink body

Specifications

Image Sensor . . . . . . . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . . . . . .
CDS Sensor . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . . . . . . .
TV System . . . . . . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . . . . . .
Sync System. . . . . . . . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . . . . . . .
IR/Cut Filter . . . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . . . . . .
Weatherproof Rating . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . .
*Depending on scene reflection
**ExView is a trademark of the Sony Corporation
HT-7815DNV Camera
Mounting Hardware
For more information contact us at:
HT-7915DNV
gray housing
HT-7915DNV/W
white housing
Features
1/3"Sony ExView** CCD
480 lines
.0.03 lux (IR off) 0.00 lux (IR on)
Day/Night DC Auto Iris Varifocal Lens (5mm-50mm)
Photoconductive Cells Adjustable
1/60 - 1/100,000 seconds
1.0 Vp-p into75 ohms composite
NTSC
2:1 Interlace
Line Locked/ Adjustable V-Phase
Line Lock/Internal On-Off
More than 60 dB
Mechanical - Auto Adjusts when required
24 Volts AC, 12 Volts DC- Dual Voltage
700mA
-20˚F to 122˚F - RH 95%
IP-65
.3.125"W x 3.5"H x 12"L
3 lbs.
Package Includes:
Instructions
Warranty card
5-50mm Lens
Video Test Cable
