- Page 1 Advance Thermal Camera Hotfind - S User’s Manual QUICK USER GUIDE Trademark Acknowledgements SATIR is trademark of SATIR Europe (Ireland) Ltd. Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies...
- Page 2 Front View Figure Explanation Laser pointer Visual Camera Illuminator IR lens Focus ring Definable trigger LCD Display Micro USB TF Card Slot 10 Battery...
- Page 3 Component Guide Back / Bottom View Figure Explanation Power Indicator Cancel Auto adjust Enter Power switch Freeze/Active Omni selector Video output...
-
Page 4: Turning The Power On/Off
2. Hold the Power Button for 3 seconds will also turn off the unit Power Button 3. After a while the Start-Up image will appear on the screen SATIR 4. After the boot up touch the Icon to start the Main Menu... -
Page 5: Analysis Settings
ANALYSIS SETTINGS 1. Touch the (Setting Icon) in the main menu to enter into the Settings menu 2. Choose (Global Param) in the Setting Menu 3. Choose “Left Arrow” to reduce the value and “right Arrow “ to increase... - Page 6 ADD SPOT ANALYSIS 1. After starting the main-menu touch the SPOT Icon 2. Drag the (Spot) to the desired position, if you want to delete spot analysis drag the (Spot) to the Highlighted / Bin area...
-
Page 7: Save Image
SAVE IMAGE 1. Rotating the focus ring until the camera focuses on the subject then press (S) key on the key board to freeze the image 2.Once in the Media Mode .Touch “snapshot. Characters like “save to xxx.jpg” will then show on the top of the screen”... -
Page 8: Review Images
Review Images 1. Touch (File) to enter the File mode 2. Select the file /image you want, then touch to open it. -
Page 9: Packing List
Packing List HotFind V/L / VR / LR /S Series Description Quantity HotFind Thermal Camera Hotfind V / L Battery Charger Power Cord Battery 2Gb MiniSD Card USB Card Reader Card Adapter USB Cable (VG & LG only) Bluetooth Headset (VG & LG only) Hotfind VR / LR / S Sunshield Video Cable with BNC... -
Page 10: For After-Sales Support
