Trademark Acknowledgments
• SATIR is trademark of SATIR
• Microsoft, Windows and Windows logo is either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other
countries.
•Other names and products not mentioned above may be registered
trademarks or trademarks of their respective companies.
Version 2.2
Copyright © 2021 SATIR LTD. All rights reserved
Entry Level Thermal Camera
Europe (Ireland)
D160-Pro
User's manual
LTD.
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D160-Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Satir D160-Pro

  • Page 1 • Microsoft, Windows and Windows logo is either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. •Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. Version 2.2 Copyright © 2021 SATIR LTD. All rights reserved...
  • Page 2 About this IR Camera User Guide Symbols Used This mark denotes issues that may affect the IR camera’s operation. This mark denotes additional topics that complement the basic operation procedures.
  • Page 3 Thumb Index Introduction of camera components. Preparing the IR Camera Describes basic functions, learning how to turn on/off the IR camera and work with the control panel and Basic function LCD monitor. Describes working with the camera, from each Shooting analysis settings to using the camera’s various analysis tools.
  • Page 4: Table Of Contents

    Table of Contents Read This First ....................5 Component Guide ..................10 Front View....................10 Side / Top View ..................11 Preparing the IR Camera ................12 Charging the device ................... 12 Turning the Power On / Off ............... 13 Basic Functions ....................
  • Page 5 File Manager ....................24 Connection and Download ................25 Connect to a Computer ................25 Maintenance ....................26 Upgrade Device ..................26 Default Setting ................... 27 Troubles Shooting ..................27 Appendix ......................28 Camera Care and Maintenance ..............28 Emissivity table ..................29 Specification ....................
  • Page 6: Read This First

    IR camera is operating and being operated correctly. Please note that SATIR, its subsidiaries and affiliates, and its distributors are not liable for any consequential damages arising from any malfunction of an IR camera or accessory that results in the failure of an image to be recorded or to be recorded in a format that is machine readable.
  • Page 7 Warnings Read on to learn about using IR camera properly. Avoid damaging eyesight Warning: Do not trigger the laser pointer in human or animal eyes. Exposure to the laser produced by the laser pointer may damage eyesight. Do not disassemble Do not attempt to disassemble or alter any part of the equipment that is not expressly described this guide.
  • Page 8 Remove the power cord on a regular periodic basis and wipe away the dust and dirt that collects on the plug, the exterior of the power outlet and the surrounding area In dust, humid or greasy environments, the dust that collects around the plug over long periods of time may become saturated with humidity and short-circuit, leading to fire.
  • Page 9 If your camera is used for prolong periods, the IR camera body may become warm Please take care when operating the IR camera for an extended period as your hands may experience a burning sensation. Once the equipment reach end of live 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 10 IR camera. Remove the PC card, and a household power source, from the IR camera and wait until moisture evaporates completely before resuming use. Right Reserved SATIR reserves the right to change the functions and configurations of our products without prior notice.
  • Page 11: Component Guide

    Component Guide Front View Description Component Number Trigger IR Lens Laser Interface Cover USB Interface Micro SD Card Tripod connector...
  • Page 12: Side / Top View

    Side / Top View Number Description Component On / Off , Menu, OK Button Power indicator Screen Back Button Navigation Buttons...
  • Page 13: Preparing The Ir Camera

    Preparing the IR Camera Charging the device 1. Open the top cover of the camera as shown above. 2. Connect the USB interface cable supplied to the supplied power adaptor...
  • Page 14: Turning The Power On / Off

    Turning the Power On / Off Press and hold to turn ON or turn OFF the Power.
  • Page 15: Basic Functions

    Basic Functions Menu Operation Description Function Component Hold: Power On/OFF Press: Display Menu and confirm operation Press: Exit the menu or return to previous Menu Navigation Buttons ● Press Buttons to select parameter. ● Press to start digital zoom.
  • Page 16 Description Function Component Charging Indicator When the device is charging, the LED indicator will turn Red. When it is fully charger the LED indicator will turn Green USB Interface Charging the Battery and exporting the saved Images with the USB Cable Trigger Press the trigger to capture a snapshot / image.
  • Page 17: Menu Description

    Menu Description Letter Description Component Function Min Temperature location Cold spot tracker Max and Min Temperature reading Readings from location E , A Center spot Location Center spot temperature Max Temperature location Hot spot tracker Unit display C or F LED status Light ON or OFF SD Card...
  • Page 18: Shooting

    Shooting IR camera Adjustment Focus This camera is fitted with a fixed focus. If the image appears out of focus, then the user will have to change position in order to optimise the image.
  • Page 19: Palettes Setting

    Palettes Setting The palettes allow you to select the desired colours. Steps 1. Select 2. Tap on the icons to select a palette type. White Hot The hot part is light-coloured in view. Black Hot The hot part is black coloured in view. Rainbow The target displays multiple colours, it is suitable for scene without obvious temperature difference.
  • Page 20: Temperature Measurement

    Temperature Measurement The thermography (temperature measurement) function provides the real-time temperature of the scene and display it on the left of your screen. The thermography function is turned on by default. Set Thermography Parameters You can set thermography parameters to improve the accuracy of temperature measurement.
  • Page 21: Laser Setting

    Laser Setting The Laser will help to identify and match up the thermal and visual imager for the end user. 1. In the live view interface, press button show the menu bar. 2. Press buttons to select Laser. 3. Press buttons to turn on / turn off laser light function. 4.
  • Page 22: Analysis

    Analysis Set Thermography Rules You can set thermography parameters to improve the accuracy of temperature measurement. Other parameters are set the same way as the laser. Temperature, measurement range, Unit, Palettes etc...
  • Page 23: Save A Snapshot

    Save a snapshot Insert memory card into the device, then you can capture snapshots, and mark and save important data. 1. In the live view interface, pull the trigger to capture snapshot. The live view freezes and device displays the snapshot with temperature information.
  • Page 24: Reviewing Save Snapshot

    Reviewing save snapshot 1. Go to Menu > Picture to view the capture snapshots. 2. Press button to view the selected picture, press / button to switch pictures. 3. (Optional) Press button to delete picture in picture view interface.
  • Page 25: File Manager

    File Manager Connect the device to your PC with supplied cable, you can export the recorded videos and captured snapshot. Steps 1. Open the cover of cable interface. 2. Connect the device to your PC with cable and open the detected disk.
  • Page 26: Connection And Download

    Connection and Download Connect to a Computer Connection Connect the USB cable to the computer’s USB port and the multi- functional dock’s terminal. • You do not need to turn off the computer or camera when making this connection. • Please refer to your computer manual for information regarding the location of the USB port...
  • Page 27: Maintenance

    Maintenance Upgrade Device Steps 1. Connect the device to your PC with cable and open the detected disk. 2. Copy the upgrade file and paste it to the root directory of the device. 3. Disconnect the device from your PC. 4.
  • Page 28: Default Setting

    Troubles Shooting Default Setting Problem Cause Solution Camera will Power is not turned on • Turn on the camera. See not operate Turning the Power On / Off Insufficient battery voltage • Fully charge the battery. Camera will Internal memory is full •...
  • Page 29: Appendix

    Appendix Camera Care and Maintenance Use the following procedures to clean the camera body, lens, LCD monitor and other parts. Wipe the body clean with soft cloth or eyeglass Camera Body lens wiper. First use a lens blower to remove dust and dirt, then remove any remaining dirt by wiping the lens lightly with soft cloth.
  • Page 30: Emissivity Table

    Emissivity table Emissivity Material Temperature ° C ( ) approximation Metal Aluminum Polished aluminum 0.09 Commercial aluminum 0.09 foil Electrolytic 6 00 0.55 ~ chromeplate alumina Mild alumina 25 ~ 600 0.10 ~ 0.20 Strong alumina 25 ~ 600 0.30 ~ 0.40 Brass Brass mirror (highly 0.03...
  • Page 31 Emissivity table (cont.) Emissivity Material Temperature ° C ( ) approximation Polished cast iron 0.21 Processed cast iron 0.44 Polished tempered 40 ~ 250 0.28 Iron Polished steel ingot 770 ~ 1040 0.52 ~ 0.56 Raw welded steel 945 ~ 1100 0.52 ~ 0.61 Surface ferric oxide 0.69...
  • Page 32 Emissivity table (cont.) Emissivity Material Temperature ° C ( ) approximation Lead Pure lead (Non- 2 25 0.06 0 .08 ~ ~ oxidization) Mildly oxidized 25 ~300 0.20 ~ 0.45 Magnesium Magnesia 275 ~ 825 0.55 ~ 0.20 Magnesia 900 ~ 1670 0.20 0 ~ 100 0.90 ~ 0.12...
  • Page 33 Emissivity table (cont.) Emissivity Material Temperature ° C ( ) approximation Stainless steel 18-8 0.16 304(8Cr,18Ni) 215 ~ 490 0.44 ~ 0.36 310(25Cr,20Ni) 215 ~ 520 0.99 ~ 0.97 Commercial tin plate 0.07 Strong oxidization 0 ~ 200 0.60 Zinc Oxidizing at 400°C 0.01 galvanized shining...
  • Page 34 Emissivity table (cont.) Emissivity Material Temperature ° C ( ) approximation Carbon piece 0.85 Isolation piece 0.91 0 .94 ~ Sheet metal 0.88 ~ 0.90 Glass pipe 0.90 Loop type 0.87 Porcelain enamel 0.90 products Porcelain enamel 0.83 0 .95 ~...
  • Page 35 Emissivity table (cont.) Emissivity Material Temperature ° C ( ) approximation Electric materials Epoxy glass plate 0.86 Epoxy 0.80 hydroxybenzene plate Gilded sheet copper 0.30 Solder-coated copper 0.35 Tin-coated lead wire 0.28 Brass wires 0.87 ~ 0.88 Block talcum terminal 0.87...
  • Page 36: Specification

    Specification All data is based on SATIR’s testing standard. Subject to change without notice. Type Image performance FOV/Min.focus distance 50° x 38.3°/0.15m Spatial resolution 1.7 mrad Thermal sensitivity ≤0.05°C@25°C Resolution 160x120 (17µm) Spectral range 8-14µm Focus Fixed Image presentation Image mode LCD Display 2.4”...
  • Page 37 Emissivity, ambient temperature, distance, relative Correction humidity, Alarm Image storage Type 8GB Removable Micro SD card File format .JPG(thermal/Visual) Power system Battery type Built-in rechargeable lithium-ion battery Charge interface Micro USB Battery operating time >8 hours Charging time <3Hrs Environment specification Operating temperature -10°C to +50°C range...
