Surveillance Thermal Camera
JK362-PoE
User's manual
Trademark Acknowledgments
• SATIR is a trademark of SATIR Ltd.
• Other names and products not mentioned above may be registered
trademarks or trademarks of their respective companies.
Copyright © 2013 SATIR Ltd. All rights reserved.
Advertisement
Related Manuals for Satir JK362-PoE
Summary of Contents for Satir JK362-PoE
- Page 1 Surveillance Thermal Camera JK362-PoE User’s manual Trademark Acknowledgments • SATIR is a trademark of SATIR Ltd. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. Copyright © 2013 SATIR Ltd. All rights reserved.
- Page 2 Content Read this first Component guide Specification...
-
Page 3: Read This First
IR camera is operating and being operated correctly. Please note that SATIR, its subsidiaries and affiliates, and its distributors are not liable for any consequential damages arising from any malfunction of an IR camera or accessory, which results in the failure of an image to be recorded or to be recorded in a format that is machine readable. - Page 4 Warnings Read on to learn about using IR camera properly. Do not disassemble Do not attempt to disassemble or alter any part of the equipment that is not expressly described this guide Stop operating immediately if it emits smoke or noxious fumes Failure to do so may result in fire or electrical shock.
- Page 5 Do not handle the power cord if your hands are wet Handling it with wet hands may lead to electrical shock. When unplugging the cord, ensure that you hold the solid portion of the plug. Pulling on the flexible portion of the cord may damage or expose the wire and insulation, creating the potential for fires and electrical shocks.
- Page 6 Prevent Malfunction Read on to learn about preventing malfunction of IR camera Avoid damaging the detector of the IR camera Warning: Do not aim the IR camera directly into the sun or at other intense heat source which could damage the detector of the IR camera. Avoid Condensation Related Problems Moving the IR camera rapidly between hot and cold temperatures may cause condensation (water droplets) to form on its external and internal...
-
Page 7: Component Guide
Component guide Different views and interfaces Front view RJ45 Side view... - Page 8 *”+” only for JK362-POE...
- Page 9 Specification All data is based on SAT’s testing standard, subject to change without notice. Camera JK362 JK362-PoE Focal 6.8mm:46.6°X34.9° length/FOV 10.3mm:30°X22.5° 18.8mm:16.3°X12.2°(standard) 35mm:8.8°X6.6° Customized Thermal 0.05°@30°C sensitivity Detector type FPA,uncooled microbolometer Resolution 384X288 Spectral range 8-14um Focusing Focus free athermal lens...
- Page 10 USB Storage Optional Power Requirements 12VDC 12DC or PoE Consumption ≤32W,≤3.5W(with ≤35W,≤8W(with temperature controlling) temperature controlling) Start-up ≤5s ≤60s Environment specification Operating -35°C to +65°C temperature rang Storage -40°C to +70°C temperature range Humidity ≤95% non-condensing Encapsulation IP66 Shock resistance Vibration resistance Automatic...
- Page 11 Two-way voice Optional Video motion Optional detection(VMD) Sensitive area Optional shelter DHCP Optional Optional Boundary alarm Optional Solar power Optional supply Video recording Image recording Text annotation Detection distance(Human,car) detection 332m/1271m Recognition 82m/317m Notice: [1] The data is based on 18.8mm lens。...
