Satir UPC80 User Manual

Upc series thermal camera core

Advertisement

Quick Links

Thermal Camera Core
UPC
User's manual
Trademark Acknowledgments
• SATIR is a trademark of SATIR Ltd.
• Other names and products not mentioned above may be registered
trademarks or trademarks of their respective companies.
Copyright © 2017 SATIR Ltd. All rights reserved.
nglish

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPC80 and is the answer not in the manual?

Questions and answers

Summary of Contents for Satir UPC80

  • Page 1 Thermal Camera Core User’s manual Trademark Acknowledgments • SATIR is a trademark of SATIR Ltd. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. Copyright © 2017 SATIR Ltd. All rights reserved.
  • Page 2 Copyright statement: SATIR Ltd. owns the copyright of this user’s manual. Without approve of SATIR, any organization or individual have no right to copy and reprint any part of it. SATIR reserves the right to change the functions and configurations of our products without prior notice.
  • Page 3: Table Of Contents

    Contents 1 Reading this first ................... 1 1.1 Safety precautions ................1 1.1.1 Warning .................. 1 1.1.2 Caution ................... 2 1.2 Prevent malfunction ................3 1.3 Maintenance and Support .............. 3 2 Preface ......................4 3 Introduction ....................... 5 4 Module introduction ................... 6 4.1、Main camera ...................
  • Page 4: Reading This First

    1 Reading this first 1.1 Safety precautions 1.1.1 Warning 1、 Before using the camera, please ensure that you read and understand the safety precautions described below. Always ensure that the IR camera operate correctly. 2、 The safety precautions noted on the following pages are intended to instruct you in the safe and correct operation of the IR camera and its accessories to prevent injuries or damage to yourself, other persons and equipment.
  • Page 5: Caution

    Failure to do so may result in fire or electrical shock. Immediately turn the IR camera’s power off, remove the IR camera battery or unplug the power cord from the power outlet. 8、 Do not use substances containing alcohol, benzene, thinners or other flammable substances to clean or main the IR camera.
  • Page 6: Prevent Malfunction

    the problem that caused by the unauthorized alter or maintain. 5、 When installing in outside, please take effective actions to prevent camera from water, humidity and dust. Prevent malfunction Avoid damaging the detector of the IR camera, please read contents carefully as follows: Avoid Condensation Related Problems 1、...
  • Page 7: Preface

    2 Preface Thermal imaging detection technology has been imperative means to guarantee the safety of industrial production in developed countries. It is used mainly in many fields such as electrical system, metallurgy, petrochemical industry, machinery, coal, transportation, firefight, security, etc. During continuous production task in company, we can apply thermal imaging detection technology to detect device located in danger so that avoid stopping procedure of manufacturing and design.
  • Page 8: Introduction

    UPC can be easily integrated in the existing surveillance & security cameras or CCTV systems, robots, UAVs and vehicles. SATIR UPC is composed of three parts: the main camera, control box and optional lenses. It provides high-quality infrared thermal image signal, analog video output and selectable lens matched with different field of view.
  • Page 9: Module Introduction

    4 Module introduction 4.1、Main camera It turns the thermal radiation into visual infrared images, and realizes relevant function. Its internal structure is consisted of UFPA detector and processing main board. The system is designed with a housing which meets IP40 (optional to IP54) encapsulation standards. 4.2、Optional lenses It collects radiation coming from target and focuses that on the detector.
  • Page 10: Structure And Function

    5 Structure and Function 5.1 Main structure Inside: detector, Main board, other component, Outside: housing, Connection port, control box. 5.1.1 Detector type UFPA, uncooled microbolometer, Spectral range: 8~14um, resolution 160*120, 25um, NETD:80mk@30℃ resolution 384*288, 25um, NETD:50mk@30℃ resolution 640*480, 17um, NETD:60mk@30℃ 5.1.2 Housing Front view Vertical view...
  • Page 11: Power System

    Side view Button view Back-end view Connector: Multifunctional port 5.1.3 Power system DC 8-12V 5.1.4 Video out Analog video output...
  • Page 12: Control Box

    5.1.5 Control box Keypad definition: Enter: pop out the menu, and save modified settings. C/A: If no menu, click it to calibrate camera; if under menu, go back to previous menu level without saving. Down: moving menu items/value down. Right: moving menu items/value right. Enter + C/A: turn the Down/Right definition to Up/Left.
  • Page 13: Combination Control Port

    5.1.6 Combination control port RS232, transfer and control commands Interface Port RS232 Baud rate 9600bps Start bit 1bit Date bit(hex) 8 bit Stop bit 1 bit Parity bit Manual control commands: FF 01 00 03 00 5F 63 FF 01 00 03 00 5E 62 FF 01 00 08 00 04 0D Down FF 01 00 10 00 04 15...
  • Page 14: Communication

    5.2.3 Communication Control signal transmission 5.2.4 Image quality The image should not involve abnormal phenomenon as follows: Image shadows, Horizontal stripe interruption, Oblique stripe interruption, Dispersive focusing, etc. 5.2.5 Consumption and Startup time Under normal condition:≤3W Startup time:≤5s...
  • Page 15: Menu Option

    6 Menu option As a new generation of infrared core product, SATIR UPC possesses kinds of pseudo-color modes on the base of temperature measuring function, and contains many characteristics of temperature measuring and surveillance & security products. It has two types of menu option: temperature measurement menu;...
  • Page 16 Max-temp tracking spot Max-temp value Center spot Isotherm width Temp-measurem ent bar Menu model as shown in below picture (other menu options are similar to this model, more details presented in following menu excels):  Non-temp measurement menu interface It just contains image ongly, not includes analysis functions of temp-measurement menu.
  • Page 17: Temp Measurement Menu

    to temp-measurement menu): 6.2 Temp measurement menu Analysis option: System Analysis Image Setup information Center Spot On/Off Tracking Spot Max/Min/Off Isotherm On/Off Emissivity 0.01~1 Distance 1~500m Ambient 25℃ - 60 ~ 5000℃ Temperature Humidity 0 ~ 100% Reflect 25℃ - 60 ~ 5000℃ Temperature Illustration: Default...
  • Page 18 Image option: System Analysis Image Setup information Palette Iron Iron/Rainbow/Feather/White hot/Black hot/Iron Inverted Level and Span Level and Span/ Level/ Span/Off Continuous AGC Off/Level and Span/ Level Shutter Period Normal Off/Short/Normal 0~15 Level 25.2 ℃ -40℃ ~ 270℃/180℃ ~ 620℃ Span ℃...
  • Page 19: Non-Temp Measurement Menu

    System information: System Analysis Image Setup information Serial Number UPC XXXXXX Produced On YYYY.MM.DD 2015.06.01 Version 1.0.0 1.0.0 6.3 Non-temp measurement menu Image option: Image Setup System information Palette Iron Iron/Rainbow/Feather/White hot/Black hot/Iron Inverted Brightness Brightness Contrast/ Contrast Brightness/ Contrast/Off Continuous AGC Off/Brightness and Contrast/ Brightness...
  • Page 20 System information option: Image Setup System information Serial Number UPC XXXXXX Produced On YYYY.MM.DD 2015.06.01 Version 1.0.0 1.0.0...
  • Page 21: Installation

    7 Installation 7.1 Requirements for installer 1. Read and understand the manual completely. 2. Possess basic knowledge and operate skills in the field of electronic layout and electronic connection. 3. Possess certification of CCTV installation and maintenance. And the installer must own relevant qualification (working aloft). 4.
  • Page 22: Lens Installation

    Main camera 7.3.2 Lens installation See the below picture, point the lens direct to the camera. Plug in, and turn in clockwise direction. Focus to target, and lock the lens with the screw.
  • Page 23: Operating Environment

    8 Operating environment 8.1 Storage temperature -40°C to +70°C (-40°F to +158°F) 8.2 Operating temperature -15°C to +50°C (5°F to 122°F) 8.3 Working humidity ≤95%,uncondensed 8.4 Encapsulation standard IP40...
  • Page 24: Manufacturer Details

    9 Manufacturer Details...
  • Page 25 SATIR UPC specifications: Type UPC80 UPC160 UPC384 UPC640 Imaging performance FOV/Minimum 51.6°x38.7° 38.2°x28.6° 16.3°x12.2°/0. 48° Focus distance /0.3m /0.3m x36°/0.3 Thermal 100mK@30°C, 60mK@30°C 50mK@30°C, 50mK@ Sensitivity(NET #F1.0 , #F1.0 #F1.0 30°C, #F1.0 Detector type Focal Plane Array (FPA), uncooled microbolometer...
  • Page 26 Note: [1] Data base on the 384*288 camera with 19mm standard lens. [2] Different lenses will cause different size and weight of whole camera. SATIR reserves the right to change the functions and configurations of our products without prior notice.

This manual is also suitable for:

Upc160Upc384Upc640
