- Page 1 Medical Thermal Camera CK350-M User’s manual Trademark Acknowledgments • SATIR is a trademark of SATIR Ltd. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. Copyright © 2017 SATIR Ltd. All rights reserved.
-
Page 2: Table Of Contents
Content Read This First External Interface Nameplate Connection Installing the driver Troubleshooting Attachment Specification... -
Page 3: Read This First
Read This First Equipment features Non-contact body temperature measurement Intended use Early diagnosis of breast tumors, diagnosis of vascular disease and skin lesions disease. Warnings Read on to learn about using IR camera properly. Do not disassemble Do not attempt to disassemble or alter any part of the equipment that is not expressly described this guide Stop operating immediately if it emits smoke or noxious fumes Failure to do so may result in fire or electrical shock. - Page 4 dust and dirt that collects on the plug, the exterior of the power outlet and the surrounding area In dust, humid or greasy environments, the dust that collects around the plug over long periods of time may become saturated with humidity and short-circuit, leading to fire.
- Page 5 Prevent Malfunction Read on to learn about preventing malfunction of IR camera Avoid damaging the detector of the IR camera Warning: Do not aim the IR camera directly into the sun or at other intense heat source which could damage the detector of the IR camera. Avoid Condensation Related Problems Moving the IR camera rapidly between hot and cold temperatures may cause condensation (water droplets) to form on its external and internal surfaces.
-
Page 6: External Interface
External Interface When powered on, this light will be green. Power interface USB interface Screw... -
Page 7: Nameplate
Nameplate Symbol Description： ：Class II equipment ：Attention! Please refer to the file supplied. -
Page 8: Connection
Connection Connecting to a computer Connect the USB cable (supplied) to the computer’s USB port and the camera’s terminal. Attach USB cable to the USB out on the IR camera. Plug the other end of the USB cable to the USB in jack on the computer. -
Page 9: Installing The Driver
Connection Installing the driver Attach the supplied USB cable (supplied) to the computer’s USB port and the camera’s USB terminal. Set the SAT solution disk (supplied) to the CD-ROM driver. Users of Windows XP Professional / Windows 2000 must first log in as an Administrator (computer system administrator) to install programs. - Page 10 Select [Include this location in the search:] then click [browse]. Locate the directory of the driver, and click [Ok] to return to the previous window. Then click [Next > Click [Continue Anyway]. Click [Finish] to finish the driver installation.
-
Page 11: Troubleshooting
Troubleshooting Problem Cause Solution Camera can’t Power is not turned on • Turn on the camera. be operated Power is not connected • Connect the power to correct voltage socket Still can’t be operated • Connect the support department Camera can’t Computer is not connected •... -
Page 12: Attachment
Attachment Packing List Project Quantity Thermal camera 10V 2.5A power adapters 5m double-headed USB cable Calibration report Users’ manual CD-ROM for Software（With a dongle） Warranty card Certificate of approval CD-ROM SatIrReport software Interface driver for USB2.0 Dataload.bin Users’ manual... -
Page 13: Specification
Specification Product Name Medical infrared thermal camera Product Model CK350-M Image performance Detector type UFPA Resolution 384×288 Spectral range 8~14 μm ≤50mK@30℃ Thermal sensitivity FOV /Min. focus distance 24°×18°/0.3m Spatial resolution 1.09mrad Measurement range 0℃to 60℃ Accuracy ±0.5℃ Focus Software control... - Page 14 Screw type 1/4”_20 Safety Features Classified by type of protection Class II with internal power supply. against electric shock No Application Part 。 Classified by type of protection against electric shock classified by level of protection Ordinary equipment. from inner liquid classified by security level of using Not AP / APG type.
