- Page 1 Operating instructions (original) Water management system C 25 L Type 563 Language: EN Version: 2 Phone: 02874/9156-0 deconta GmbH Fax: 02874/9156-11 Issue Date: Im Geer 20 E-mail: info@deconta.com 24.07.2023 46419 Isselburg Web: www.deconta.com...
-
Page 2: Table Of Contents
Table of contents Product and manufacturer ....................4 Product ........................4 Manufacturer ......................4 Change index ......................4 About these operating instructions ................5 Purpose ........................5 Availability ......................5 Warnings ........................ 6 2.3.1 Warning words and warning colours ............6 2.3.2 Structure .................... - Page 3 Table of contents Internal transport ....................19 6.4.1 Transport space ..................19 6.4.2 Legislation ....................19 6.4.3 Warning of residual risks ................. 19 6.4.4 Means of transportation ................19 Assembly........................20 Put into operation ......................20 Operation........................22 Qualification of the staff ..................22 Warning of residual risks ..................
-
Page 4: Product And Manufacturer
Product and manufacturer Product and manufacturer Product This operating manual describes the following product: Water management system C 25 L Serial number: Manufacturer Name and address deconta GmbH Im Geer 20 46419 Isselburg Phone 02874/9156-0 02874/9156-11 E-mail info@deconta.com Internet www.deconta.com... -
Page 5: About These Operating Instructions
The operator keeps these operating instructions or extracts thereof within easy reach in the immediate vicinity of the machine. When handing over the machine to another person, the operator passes these operating instructions on to that person. Water management system C 25 L 5 from 31 Original operating instructions Version 2... -
Page 6: Warnings
Description of the possible consequences for humans, animals and the environment that may occur as a result of the hazard. Escape Recommendations for action on how to avoid hazards Water management system C 25 L 6 from 31 Original operating instructions Version 2... -
Page 7: Symbols
The instruction sign is a safety sign that prescribes a certain behaviour. The following table gives an overview of the instruction signs used and their meaning. Symbol Meaning Symbol Meaning Wear safety shoes Use protective clothing Water management system C 25 L 7 from 31 Original operating instructions Version 2... -
Page 8: Description Of The Machine
Manual starting is possible. 3.1.2 Version with control compulsory locking In this version, the control for the forced locking and forced showering of the deconta personal lock is integrated in the Water management system. Procedure for carrying out the risk assessment for machinery •... -
Page 9: Scope Of Delivery
Description of the machine Scope of delivery The delivery scope of the machine includes the following items: ▪ Water management system C 25 L ▪ Filters ▪ Service Pack ▪ These operating instructions Return delivery after termination of a lease... -
Page 10: Operating Modes
Product waste: Geka connection for filtered waste water into the sewerage system ▪ Product material feed: Geka connection for contaminated shower water ▪ Product floor: castor wheels Water management system C 25 L 10 from 31 Original operating instructions Version 2... -
Page 11: Type Plate
The following accessories are optionally available for the water management system: Designation Item no. Illustration Wastewater hose 5m with Geka BU1504 connection 3/4". Freshwater hose 5m with Geka BU1504a connection 1/2". Water management system C 25 L 11 from 31 Original operating instructions Version 2... -
Page 12: Technical Data
Power connection: 230 V ▪ Current consumption: ▪ Heating power: 1000 W ▪ Volume of service water: 25 litres ▪ Tank filling: manually via filling opening Water management system C 25 L 12 from 31 Original operating instructions Version 2... -
Page 13: Security
For this reason, persons leaving the construction area via airlocks must shower when exiting. The deconta Water management system heats the shower water and treats (filters) the contaminated wastewater. The user must comply with the operating parameters specified in the operating instructions. -
Page 14: Misapplication
Operating the machine in a technically unsound condition, not being aware of safety and hazards and not observing all instructions in the documentation. Use in potentially explosive atmospheres Water management system C 25 L 14 from 31 Original operating instructions... -
Page 15: Tasks And Qualifications Of The Staff
Qualified waste management Disposer Dispose of machine company for legally compliant, proper and professional disposal of the machine Water management system C 25 L 15 from 31 Original operating instructions Version 2... -
Page 16: Notes On Occupational Health And Safety
Instruction of persons with regard to protective devices and supplementary protective devices Instruction of persons with regard to residual risks This list is not exhaustive and does not claim to be complete. Water management system C 25 L 16 from 31 Original operating instructions Version 2... -
Page 17: Transport
Disconnect the unit from the mains. To empty, remove the Geka cap from the "Empty tank" connection and open the ball valve behind the connection. Empty tank cap Ball valve "OUT Water management system C 25 L 17 from 31 Original operating instructions Version 2... -
Page 18: Loss Of Warranty Claims
Falling of the machine may be possible due to unintentional change of position when loading and unloading onto / from a means of transportation. Water management system C 25 L 18 from 31 Original operating instructions Version 2... -
Page 19: Internal Transport
Falling of the machine may be possible due to unintentional change of position when loading and unloading onto / from a means of transportation. Water management system C 25 L 19 from 31 Original operating instructions Version 2... -
Page 20: Assembly
The Water management system is delivered ready for operation ex works and is intended for immediate commissioning. If there is visible damage, do not operate the unit. Contact deconta GmbH immediately. Put into operation This section contains information on commissioning the machine. - Page 21 Hot water start Sewage pump start The wastewater pump can be started manually by pressing the "Wastewater pump start" button. Water management system C 25 L 21 from 31 Original operating instructions Version 2...
-
Page 22: Operation
Preset temperature (approx. 37°C). Do not change the settings on the heating rod. Danger of scalding! Check the outlet temperature before every shower! Heating rod Water management system C 25 L 22 from 31 Original operating instructions Version 2... -
Page 23: Number Of Persons
One person is needed to use the machine. Tools needed No tools are needed to use the machine. Required equipment No equipment is needed to use the machine. Water management system C 25 L 23 from 31 Original operating instructions Version 2... -
Page 24: Maintenance
Change filters only when the unit is switched off. Only use approved filters. Pull out the mains plug before opening the housing Water management system C 25 L 24 from 31 Original operating instructions Version 2... -
Page 25: Personal Protective Equipment Required
Remove dirty filters when damp to prevent the release of filter dust. ▪ Only use approved filters ▪ Damaged filter cartridges must not be used Union nut Filter head spanner Water management system C 25 L 25 from 31 Original operating instructions Version 2... -
Page 26: Reduction Of Legionella Growth
To clean the hoses and shower device, the heated water should also be removed from the shower device for approx. 3 minutes. Caution: Danger of scalding! Alternatively, an approved disinfectant can be used. Water management system C 25 L 26 from 31 Original operating instructions Version 2... -
Page 27: Spare Parts
If this is not possible, the alternative spare parts should correspond to the characteristics of the original spare parts in order to ensure the safe, trouble-free and economical use of the machine. Water management system C 25 L 27 from 31 Original operating instructions... -
Page 28: Circuit Diagram
Circuit diagram Circuit diagram Water management system C 25 L 28 from 31 Original operating instructions Version 2... -
Page 29: Cleaning
The optional hoses may only be stored completely emptied and in a hygienic condition! During storage, make sure that contamination with other substances is excluded. Drinking water hoses (freshwater hoses) and wastewater hoses must be stored separately. Water management system C 25 L 29 from 31 Original operating instructions... -
Page 30: Disposal
15.3 Waste The waste generated by the machine must be disposed of in a legally compliant, proper and professional manner. Water management system C 25 L 30 from 31 Original operating instructions Version 2... -
Page 31: Ec Declaration Of Conformity
Safety of machinery - Safety distances to prevent hazard zones from being reached by the upper and lower limbs (ISO 13857:2019) Name and address of the person authorised to compile the technical file: Boland, Thomas - deconta GmbH, Im Geer 20 - 46419 Isselburg Place: IsselburgDate : 14.06.2023...
