- Page 1 Operating instructions (original) Wastewater filtration unit AS 300 CG Type 539 Language: EN Version: 2 Phone: 02874/9156-0 deconta GmbH Fax: 02874/9156-11 Issue Date: Im Geer 20 E-mail: info@deconta.com 24.07.2023 46419 Isselburg Web: www.deconta.com...
-
Page 2: Table Of Contents
Qualification of the staff ................18 6.2.4 Warning of residual risks ................. 18 6.2.5 Means of transportation ................18 Internal transport ....................19 6.3.1 Transport space ..................19 Wastewater filtration unit AS 300 CG 2 from 30 Original operating instructions Version 2... - Page 3 15 Disposal ......................... 29 15.1 Qualification of the staff ..................29 15.2 Legislation ......................29 15.3 Waste ........................29 16 EC Declaration of Conformity ..................30 Wastewater filtration unit AS 300 CG 3 from 30 Original operating instructions Version 2...
-
Page 4: Product And Manufacturer
Product and manufacturer Product and manufacturer Product This operating manual describes the following product: Wastewater filtration unit AS 300 CG Serial number: Manufacturer Name and address deconta GmbH Im Geer 20 46419 Isselburg Phone 02874/9156-0 02874/9156-11 E-mail info@deconta.com Internet www.deconta.com... -
Page 5: About These Operating Instructions
The operator keeps these operating instructions or extracts thereof within easy reach in the immediate vicinity of the machine. When handing over the machine to another person, the operator passes these operating instructions on to that person. Wastewater filtration unit AS 300 CG 5 from 30 Original operating instructions Version 2... -
Page 6: Warnings
Description of the possible consequences for humans, animals and the environment that may occur as a result of the hazard. Escape Recommendations for action on how to avoid hazards Wastewater filtration unit AS 300 CG 6 from 30 Original operating instructions Version 2... -
Page 7: Symbols
The instruction sign is a safety sign that prescribes a certain behaviour. The following table gives an overview of the instruction signs used and their meaning. Symbol Meaning Symbol Meaning Wear safety shoes Use protective clothing Wastewater filtration unit AS 300 CG 7 from 30 Original operating instructions Version 2... -
Page 8: Description Of The Machine
This section contains information for understanding the machine. General description General description of the product The wastewater filtration unit was designed and built by deconta GmbH, Im Geer 20, 46419 Isselburg. Contaminated wastewater is cleaned via a 4-stage filtration unit consisting of coarse pre- filter, pre-filter, 2x fine filter. -
Page 9: Scope Of Delivery
Description of the machine Scope of delivery The delivery scope of the machine includes the following items: ▪ Wastewater filtration unit AS 300 CG ▪ Filters ▪ Service Pack ▪ These operating instructions Return delivery after termination of a lease... -
Page 10: Operating Modes
Product - waste: Geka connection for filtered wastewater into the sewage system ▪ Product - material feed: Geka connection for contaminated water ▪ Product - floor: castor wheels Wastewater filtration unit AS 300 CG 10 from 30 Original operating instructions Version 2... -
Page 11: Type Plate
The following accessories are optionally available for the wastewater filtration unit: Designation Item no. Illustration Wastewater hose 5m with Geka BU1504 connection 3/4". Wastewater hose with proximity BU1629 switch Wastewater filtration unit AS 300 CG 11 from 30 Original operating instructions Version 2... -
Page 12: Technical Data
▪ Pre-filter: 220 (disposable) ▪ Fine filter: 50 (disposable) ▪ Fine filter: 1 (disposable) ▪ Max. medium temperature: 50°C at 4bar technical modifications subject to alterations Wastewater filtration unit AS 300 CG 12 from 30 Original operating instructions Version 2... -
Page 13: Security
For this reason, objects that leave the construction area via airlocks must be cleaned. The deconta wastewater filtration unit provides treatment (filtering) of the contaminated wastewater. The user must comply with the operating parameters specified in the operating instructions. -
Page 14: Misapplication
Operating the machine in a technically unsound condition, not being aware of safety and hazards and not observing all instructions in the documentation. Use in potentially explosive atmospheres Wastewater filtration unit AS 300 CG 14 from 30 Original operating instructions... -
Page 15: Tasks And Qualifications Of The Staff
Qualified waste management Disposer Dispose of machine company for legally compliant, proper and professional disposal of the machine Wastewater filtration unit AS 300 CG 15 from 30 Original operating instructions Version 2... -
Page 16: Notes On Occupational Health And Safety
Instruction of persons with regard to protective devices and supplementary protective devices Instruction of persons with regard to residual risks This list is not exhaustive and does not claim to be complete. Wastewater filtration unit AS 300 CG 16 from 30 Original operating instructions Version 2... -
Page 17: Transport
Transport is the change of location of the machine by manual or technical means. In winter, because of the danger of frost, urgent attention should be paid: Drain water pipes, tank, filter housing and pumps Vent connection Drain plug Wastewater filtration unit AS 300 CG 17 from 30 Original operating instructions Version 2... -
Page 18: Loss Of Warranty Claims
Falling of the machine may be possible due to unintentional change of position when loading and unloading onto / from a means of transportation. Wastewater filtration unit AS 300 CG 18 from 30 Original operating instructions Version 2... -
Page 19: Internal Transport
The wastewater filtration unit is delivered ready for operation ex works and is intended for immediate commissioning. If there is visible damage, do not operate the unit. Contact deconta GmbH immediately. Wastewater filtration unit AS 300 CG 19 from 30... -
Page 20: Put Into Operation
Connect the wastewater hose to the "IN" connection of the coarse pre-filter and connect it to the place of use. ▪ Connecting the "OUT" connection to the wastewater channel ▪ Establish 230V power supply (safety plug) Wastewater filtration unit AS 300 CG 20 from 30 Original operating instructions Version 2... -
Page 21: Commissioning For Wastewater Hose With Proximity Sensor
The proximity sensor on the wastewater hose detects whether there is water in the hose and then switches the wastewater filtration unit on or off. The sensitivity of the proximity sensor can be readjusted using the screwdriver supplied. Wastewater filtration unit AS 300 CG 21 from 30 Original operating instructions... -
Page 22: Operation
One person is needed to use the machine. Tools needed No tools are needed to use the machine. Required equipment No equipment is needed to use the machine. Wastewater filtration unit AS 300 CG 22 from 30 Original operating instructions Version 2... -
Page 23: Maintenance
Change filters only when the unit is switched off. Only use approved filters. Pull out the mains plug before opening the housing Wastewater filtration unit AS 300 CG 23 from 30 Original operating instructions Version 2... -
Page 24: Personal Protective Equipment Required
Damaged filter cartridges must not be used Coarse pre-filter with Connection "IN bag filter 220µ Pressure gauge Prefilter 220µ Union nut Fine filter 5µ Fine filter 1µ Filter head spanner Wastewater filtration unit AS 300 CG 24 from 30 Original operating instructions Version 2... -
Page 25: Filter Change Bag Filter
Repairs and maintenance work may only be carried out in compliance with all relevant safety measures. The filters must be disposed of in accordance with the legal requirements. Wastewater filtration unit AS 300 CG 25 from 30 Original operating instructions Version 2... -
Page 26: Spare Parts
If this is not possible, the alternative spare parts should correspond to the characteristics of the original spare parts in order to ensure the safe, trouble-free and economical use of the machine. Wastewater filtration unit AS 300 CG 26 from 30 Original operating instructions... -
Page 27: Circuit Diagram
Circuit diagram Circuit diagram Wastewater filtration unit AS 300 CG 27 from 30 Original operating instructions Version 2... -
Page 28: Cleaning
The optional hoses may only be stored completely emptied and cleaned! When storing, make sure that contamination with other substances is excluded. Wastewater hoses must be stored separately from freshwater hoses. Wastewater filtration unit AS 300 CG 28 from 30 Original operating instructions... -
Page 29: Disposal
15.3 Waste The waste generated by the machine must be disposed of in a legally compliant, proper and professional manner. Wastewater filtration unit AS 300 CG 29 from 30 Original operating instructions Version 2... -
Page 30: Ec Declaration Of Conformity
The protection goals of the following additional legal regulations were met: Low Voltage Directive 2014/35/EU Name and address of the person authorised to compile the technical file: Boland, Thomas - deconta GmbH, Im Geer 20 - 46419 Isselburg The following harmonised standards were applied: EN 60204-1:2018...
