Top Case Replacement & Installation
Instructions
Required Tools and Components
Tools
Anti-static wrist strap (1 MOhm resistance)
•
Soft ESD (electrostatic discharge) safe mat
•
Microfiber / lint free cloth
•
Safety glasses
•
Plastic pry tool (spudger)
•
Dispenser bottle with Isopropyl alcohol (use 91% or greater)
•
Cotton swab
•
Components
Top Case (Xbox Elite Series 2) (Refer to Illustrated Service Parts List)
•
Prerequisite Steps
Discharge the battery
For devices with rechargeable lithium-ion batteries that power on, fully discharge the battery
before beginning repair. To expedite the battery discharge process:
Connect the controller to a device wirelessly.
•
Operate the device in wireless mode until the battery is fully discharged and the device
•
powers off.
