D0T Series Audio Turret Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Type II
Type III
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
User Manual
Model
DS-2CE78D0T-IT3FS
DS-2CE76D0T-ITPFS
DS-2CE76D0T-ITMFS
0100001090428
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE78D0T-IT3FS
Summary of Contents for HIKVISION DS-2CE78D0T-IT3FS
- Page 1 This manual applies to the models below: Type Model Type I DS-2CE78D0T-IT3FS Type II DS-2CE76D0T-ITPFS Type III DS-2CE76D0T-ITMFS This manual may contain several technical mistakes or printing errors, and the content is subject to change without notice.
-
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 4 Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage...
-
Page 5: Product Features
1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor Smart IR Audio over coaxial cable Built-in mic 4 in 1 video output 1.2 Overview 1.2.1 Overview of Type I Camera DC12V Figure 1-1 Overview of Type I Camera Note:... -
Page 6: Installation
2 Installation Before you start Make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. Check the specification of the products for the ... - Page 7 6. Install the camera back to the mounting base and secure it. Figure 2-4 Install the Camera Back 7. Connect the corresponding power cord, and video cable. 8. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
- Page 8 Figure 2-7 Secure the Junction Box on the Wall 5. Route the cables through the bottom cable hole, or the side cable hole of the junction box. 6. Combine the junction box cover with its body. Figure 2-8 Combine the Junction Box’s Cover back to its Body 7.
- Page 9 4. Route the cables through the cable hole, or the side opening. 5. Install the camera back to the mounting base and secure it. Figure 2-11 Install the Camera Back 6. Connect the corresponding power cord, and video cable. 7. Power on the camera to check whether the image on the monitor is gotten from the optimum angle.
- Page 10 5. Secure the junction box’s body on the ceiling with four PA4 × 25 screws and expansion bolts. Figure 2-15 Secure the Junction Box on the Ceiling 6. Route the cables through the bottom cable hole, or the side cable hole of the junction box. 7.
- Page 11 Figure 2-18 Secure the Mounting Base to the Ceiling 5. Route the cables through the cable hole, or the side opening. 6. Secure the camera on the mounting base. Pull out the clip plate, and then to combine the camera with the mounting base. Push the clip plate in, and secure the camera by tightening the screw.
-
Page 12: Menu Description
3 Menu Description Please follow the steps below to call the menu. Note: The actual display may vary with your camera model. The menu is not available when you switch the video output to CVBS. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. -
Page 13: Video Format
1). Click up/down direction button to select the item. 2). Click Iris + to confirm the selection. 3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDEO FORMAT You can set the video format to 2MP@30fps or 2MP@25fps. -
Page 14: Video Settings
You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. AUTO Automatically switch Color, or B&W (Black and White) according to actual scene brightness. -
Page 15: Image Mode
IMAGE MODE IMAGE MODE is used to adjust the image saturation, and you can set it to STD (Standard) or HIGH-SAT (High Saturation). WHITE BALANCE White balance, the white rendition function of the camera, is to adjust the color temperature according to the environment. -
Page 16: Factory Default
Figure 3-7 AUTO SETTINGS 3.6 FACTORY DEFAULT Reset all the settings to the factory default. 3.7 EXIT Move the cursor to EXIT and click Iris+ to exit the menu. 3.8 SAVE & EXIT Move the cursor to SAVE & EXIT and click Iris+ to save the settings, and exit the menu.
