Color Zoom Camera
User Manual
V1.0.0
Hikvision Digital Technology Co., Ltd.
http://www.hikvision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CZ2132PN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION DS-2CZ2132PN

  • Page 1 Color Zoom Camera User Manual V1.0.0 Hikvision Digital Technology Co., Ltd. http://www.hikvision.com...
  • Page 2 UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.” © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 3 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 4 Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by HIKVISION Employees with knowledge and training in working with these types of devices that contain live circuits.
  • Page 5 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 6 6. If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. 7. If the product does not work properly, please contact your dealer or the nearest service center. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 7 Color Zoom Camera User Manual Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 8 The average time varies because of differences between operating environment and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 9: Table Of Contents

    3.2.10 VIDEO Parameters Setting ................... 26 3.2.11 SPECIAL Functions Setting ................... 28 3.2.12 EXIT ..........................32 Appendix Specification ......................... 33 1 DS-2CZ2132P(N) ......................... 33 2 DS-2CZ2152P(N) ......................... 35 3 DS-2CZ2152P(N)-IRA ........................37 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 10: Chapter 1 Introduction

    AGC: AGC is a control circuit that automatically changes the gain of a receiver or other piece of equipment, so that the desired output signal remains essentially. When under low illumination, AGC © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 11 3D Digital Noise Reduction: Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise initiated by CCD besides processing the noise in the separated Y video signal and C video signal. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 12: Application

    Color Zoom Camera User Manual 1.3 Application The product is applicable to the large-sized monitoring scenes, such as large warehouse, surrounding area of residential district, dock, plaza, school, station, park, etc. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 13: Chapter 2 Hardware Overview

    The lens is integrated in the camera. The focal length of the 2132 camera is 3.9-85.8mm, the 2152 camera is 3.84-88.4mm, the 2182 camera is 3.4-102mm and the 2192 camera is 3.3-119mm. 2.2 Side Plate Figure 2.2.1 DS-2CZ2132P(N) side plate Figure 2.2.2 DS-2CZ2152P(N) side plate © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 14 Color Zoom Camera User Manual Figure 2.2.3 DS-2CZ2182P(N) side plate Figure 2.2.4 DS-2CZ2192P(N) side plate Figure 2.2.5 DS-2CZ2152P(N)-IRA side plate © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 15: Rear Plate

    Color Zoom Camera User Manual 2.3 Rear Plate Figure 2.3.1 Rear plate of DS-2CZ2132P(N),DS-2CZ2152P(N),DS-2CZ2182P(N)and DS-2CZ2192P(N) 2.4 Connections 2.4.1 Rear Plate Definition © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 16: I/O Interfaces Description

    The interfaces description of DS-2CZ21X2P(N) are as follows: Pin No. Name Description ZOOM (Wire Control Interface) Lens Zoom Adjustment (Wire Control Interface) Common Interface for the Pins No. 1 and No. 3 FOCUS (Wire Control Interface) Focus Adjustment © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 17  You can use the 4-IN interface to trigger the switching between the Day mode and Night mode.  Connect an alarm output device to the 6-OUT interface . The motion detection can trigger alarm output. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 18: Power Supply

    Please make sure that the power adapter can match with the camera. The standard power supply of the camera is usually 12V DC (Please refer to technical specifications for more details). © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 19: Chapter 3 Menu Functions

     The menu items are on the left. The options are on the right.  “…” means there is a submenu you can enter.  “---” means this menu is not available. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 20: Main Menu Overview

    Press Menu button to enter SPECIAL submenu. The submenu items are shown in Table SPECIAL 3.2.2. 11. EXIT QUIT/SAVE/DEFAULT Table 3.2.1 Main menu set The SPECIAL Submenu Menus Options 1.GAMMA 0.45/1 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 21: Cam Id Setting (Camera Id)

    LEVEL to darken the scene. The range is from 0 to 63. 3. Move the cursor to RET to return to the previous menu. 4. If you want to save the settings, move the cursor to EXIT, press the left/right buttons to © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 22: Blc/Wdr Setting (Back Light Compensation/ Wide Dynamic Range)

    3. Press the up/down buttons to position the cursor on RET to return to the previous menu. 4. If you want to save the settings, move the cursor to EXIT, press the left/right buttons to choose SAVE, press the menu button to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 23 SAVE, press the menu button to save the settings. LEVEL1 - - -| - - - - 00 LEVEL2 - - -| - - - - 07 Figure 3.2.4 Wide Dynamic Range © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 24: Shutter Setting

     When the IRIS value is MANUAL… and the SHUTTER value is 1/50, 1/120, 1/250, 1/500, 1/1K, 1/2K, 1/4K, 1/10K, the AGC value can be set to LOW, HIGH, OFF.  When the IRIS value is ELC, the AGC value can be set to LOW, HIGH, OFF. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 25: Wb Setting (White Balance)

     6300K is an estimated value for outdoor application. And the RED and BLUE values are not adjustable.  When you select USER, you can adjust the RED and BLUE values to meet your demand. USER BLUE Figure 3.2.5 Manual White Balance © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 26: Focus Setting

    The DAY/NIGHT mode can be set to TRIG, AUTO…, DAY and NIGHT.  TRIG mode, the day and night mode is switched by triggering the 4-IN interface on the rear plate of the camera. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 27: Video Parameters Setting

    1. Move the cursor to the VIDEO SET… . 2. Press menu button to enter the submenu as shown in Figure 3.2.8. In the submenu, the adjustable features are DNR, MIRROR, EXPOSURE, DEFINITION, CONTRAST, CHROMA, POS/NEG, EIS and SUPPRESS. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 28 The default setting of the POS/NEG is +. It means the image is positive. If you select -, you can see the image turn to positive.  EIS Turning the EIS (Electronic Image Stabilization) function on may reduce the image vibration caused by external environment. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 29: Special Functions Setting

    When you select 1, the brightness will not be affected. When you select 0.45, the brightness will be adjusted.  MASK (Privacy Mask) Steps: 1. Move the cursor to MASK, press the left/right buttons to select ON… . © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 30 - - -| - - - - - 03 MOSAIC ON/OFF Figure 3.2.10 Motion Detection  MD (Motion Detection) Steps: 1. Move the cursor to MD, press the left/right buttons to select ON… . © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 31 Figure 3.2.11 Motion Detection  ZOOMRATE You can adjust this feature to change the speed of zoom. The value ranges from 1 to 5. The value is larger, the speed is higher.  EZOOM © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 32 RS485 PROTOCOL PELCO-D BAUDRATE 2400 ADDRESS Figure 3.2.12 RS-485 Settings  PRESET There are up to 254 presets that can be configured. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 33: Exit

     DEFAULT: When you select DEFAULT, all the settings will be initialized to factory settings before exit the menu.  QUIT: When you select QUIT, all the modifications will be canceled before exit the menu. 2. Press the menu button to confirm your selection. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 34: Appendix Specification

    Slow Shutter Max. X256 Privacy Mask On/Off, Maximum 8 Zones Motion Detection Off/Mode1/Mode2 Gamma Amendment 0.45/1 Digital Zoom, 3D Digital Noise Reduction, POS/NEG ,Mirror, Video Resolution, Electronic image stabilization, Back Light © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 35 -10°C - 60°C (14°F - 140°F), Humidity 90% or Operating Conditions less(non-condensing) Power Supply 12VDC / 300mA ±10% Power Consumption Max. 4W Dimension 64 x 69 x 120mm(2.53” x 2.42” x 4.46”) Weight 450g (0.99lbs) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 36: Ds-2Cz2152P(N)

    Max. X256 Privacy Mask On/Off, Maximum 8 Zones Motion Detection Off/Mode1/Mode2 Gamma Amendment 0.45/1 Digital Zoom, 3D Digital Noise Reduction, POS/NEG ,Mirror, Video Resolution, Electronic image stabilization, Back Light Compensation Zoom speed © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 37 -10°C - 60°C (14°F - 140°F), Humidity 90% or Operating Conditions less(non-condensing) Power Supply 12VDC / 300mA ±10% Power Consumption Max. 4.5 W Dimension 66 x 76 x 128mm (2.6” x 3.0” x 5.0”) Weight 550g (1.21lbs) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 38: Ds-2Cz2152P(N)-Ira

    Max. X256 Privacy Mask On/Off, Maximum 8 Zones Motion Detection Off/Mode1/Mode2 Gamma Amendment 0.45/1 Digital Zoom, 3D Digital Noise Reduction, POS/NEG ,Mirror, Video Resolution, Electronic image stabilization, Back Light Compensation Zoom speed © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 39 12VDC / 300mA ±10% Power Consumption Max. 15 W Weather Proof Rating IP66 IR Range Approx 100 meters Dimension 117 x 97 x 255mm (4.6” x 3.8” x 10.0”) Weight 2.5kg (5.51lbs) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 40 Color Zoom Camera User Manual First Choice for Security Professionals © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
