Remove panel
1. (power)/Volume knob and
2. MODE (source) button
3. BAND(band) button
4. AMS (automatic store / preset station scan, automatic music search) button
5. (pause/play), Preset station1 button
6. INT (intro) , Preset station
7. RPT (repeat)
8. RDM (random)
9. -10(previous 10 tracks)
10. +10(next 10 tracks)
11. CLOCK (clock setting) button,
12. (tune down, seek down, previous track, fast reverse) button
13. (tune up, seek up, next track, fast forward)button
14. MUTE button
15. (eject) button
16. Disc slot
17. IR remote sensor
18. LCD Display
19. Sliding door for USB port
20. USB Port
21. Sliding door for AUX IN jack
22. AUX IN (auxiliary input) jack
4
25
, (anser call) button
2 button
, Preset station 3 button
, Preset station
, DIR-(previous folder), Preset station
, DIR+(next folder), Preset station
26
SEL (select/menu) button
4 button
(end call) button
23. Hands-free Microphone
24. Front panel release button
25. SD Card Slot
26. Reset button
5 button
6 button
