Electrical Connections; Control Panel Button Locations - Ssl DDC28B User Manual

Electrical Connections

WIRING DIAGRAM
- Only use speakers with 4 ohms impedance.
- Do not attach the control panel to the chassis before wiring is complete.
- The maximum current of the Amp Remote trigger is 200mA.

CONTROL PANEL BUTTON LOCATIONS

23
22 21
15A
8. Front left PRE-AMP output (White)
9. Front right PRE-AMP output (Red)
10. Rear left PRE-AMP output (White)
11. Rear right PRE-AMP output (Red)
12. Radio antenna socket
19
CAUTION
+12V DC
NEGATIVE
GROUND
20 24
3
