Summary of Contents for Ssl DDC28B
-
Page 2: Table Of Contents
CONTENTS Precautions........................1 How to Handle Discs....................1 Precautions & Warnings....................1 Lithium Battery Cell Warnings..................1 Drivers and Connections.....................1 Other Warnings......................1 Installation........................2 Installation Opening....................2 To Install the Car Radio....................2 Electrical Connections....................3 Control Panel Button Locations..................3-4 General Operation......................5 Turn Unit On/Off......................5 Adjust Volume (VOL)....................5 Adjust Menu Options (SEL)..................5 Set the Clock (CLK)....................6 Change the Source (MODE)..................6... -
Page 3: Precautions
PRECAUTIONS How to Handle Discs • Handle a disc by its edges. Do not touch the playing side • Before inserting a disc, wipe the disc outward from the disc center with a clean, soft, dry and lint-free cloth. Do not use solvents or thinners such a petrol/benzene or cleaners. -
Page 4: Installation
INSTALLATION Installation Opening This unit can be installed in any dashboard Having an opening as shown the right figure. 103 mm 182 mm If installation angle exceeds30 horizontal, the unit may not perform properly. To Install the Car Radio 1. Make sure the ignition is turned off, and then disconnect the cable from the vehicle battery’s negative (-) terminal. -
Page 5: Electrical Connections
Electrical Connections WIRING DIAGRAM CAUTION +12V DC NEGATIVE GROUND 8. Front left PRE-AMP output (White) 9. Front right PRE-AMP output (Red) 10. Rear left PRE-AMP output (White) 11. Rear right PRE-AMP output (Red) 12. Radio antenna socket - Only use speakers with 4 ohms impedance. - Do not attach the control panel to the chassis before wiring is complete. - Page 6 Remove panel (power)/Volume knob and SEL (select/menu) button MODE (source) button 3. BAND(band) button (anser call) button 4. AMS (automatic store / preset station scan, automatic music search) button (pause/play), Preset station1 button 6. INT (intro) , Preset station 2 button 7.
-
Page 7: General Operation
GENERAL OPERATION Turn Unit On/Off • Press any button on the front panel or on the remote control to turn on the unit. • Press and hold the power ( ) button on the front panel or briefly press the power ( ) button on the remote control to turn the unit on or off. -
Page 8: Set The Clock (Clk)
GENERAL OPERATION (CONT.) • Rotate the knob on the front panel or press the VOL+ VOL- button on the remote control to adjust the selected item. Set the Clock (CLK) 1. To display clock time, press the button. 2. To set clock time, press and hold the button and the hour will flash. -
Page 9: Radio Operation
RADIO OPERATION Switch Between USA area and Europe area Frequency In radio mode, press the button to enter the switch state of the US(USA) and EU(Europe) frequency, then rotate it to switch between US(USA) and EU(Europe) frequency. The system will change the frequency setting in about 3 seconds. Change Bands (BAND) Press the BAND... -
Page 10: Disc/Usb/Sd Card Operation
DISC / USB / SD CARD OPERATION To insert DISC / USB / SD CARD • To play files on a disc, insert a disc with the label surface facing upward into the disc slot. Playback will begin automatically. Label surface up •... -
Page 11: Select The Track Or File For Playback In Mp3 Format
DISC / USB / SD CARD OPERATION (CONT.) Select the track or file for playback in MP3 format Press the button repeatedly to select one of the following 3 search modes: NUM SCH (Searching by track or file serial number) DIR SCH (Searching by folder serial number) FILE SCH (Searching by track or file name) Searching by track or file serial number:... -
Page 12: Bluetooth Operation
2. When the phone finds the car audio system, the “SSL DDC28B” name will be displayed. 3. Choose the “SSL DDC28B” from the device list to pair and connect with the car audio system. Upon confirming, the BT logo will stop flashing. -
Page 13: Remote Control
REMOTE CONTROL Remove Insulating Sheet The remote control comes with an insulating sheet attached to the underside of the remote control, as illustrated on the right. The remote control will not work until the insulating sheet is removed. Replace Lithium Battery Cell 1. -
Page 14: Specifications
SPECIFICATIONS General Chassis Dimensions.............178(W) x 160(D) x 100(H) mm Power Supply Requirement ..................DC 12V Current Consumption ..................15A (max.) Maximum Power Output ..................80W x 4CH Radio USA/ Europe Frequency Range..........87.5 - 107.9 MHz (200KHz/Step) 87.5 - 108.0 MHz(50KHz/Step) Usable Sensitivity ....................30 dBu I.F. -
Page 15: Tr O U B L E S H O O T I N
TROUBLESHOOTING The following chart will help in solving most problems that may occur. If you still have questions after going through the checklist, please consult your local customer service representative. Before going through this check list, refer the wiring and operating procedures.
