ASSEMBLY INSTRUCTIONS
7. Assemble the cabinets parts as per the illustration.
Using a phillips head screwdriver, rotate the minifix
cam clockwise to fasten into place. Ensure all cams
are locked into place before moving the cabinet.
8. Insert the back panel as shown in the drawing.
9. Assemble the cabinets parts as per the illustration.
Using a phillips head screwdriver, rotate the minifix
cam clockwise to fasten into place. Ensure all cams
are locked into place before moving the cabinet.
