Project Source DC2430R Assembly Instruction Manual page 7

ASSEMBLY INSTRUCTIONS
4. Insert the shelf support hardware in the desired
locations. Recommended locations shown in the
illustration.
Hardware Used
EE Shelf support clear
5. Using a phillips head screwdriver, attach the
mounting plate as shown in the illustration.
Hardware Used
Hinge mounting plate
CC
6. Insert the hinge in the bore hole. Using a phillips
head screwdriver, turn the pre-installed screws
clockwise to lock into place.
Place the bumper on the door as shown
Hardware Used
DD
45 o Hinge
FF
Bumper 2MM
4
x 12
5
x 2
6
x 2
x 2
7
EE
CC
DD
FF
