Endress+Hauser mycom CLM 152 Operating Manual page 96

Instrument data
PARAM
Short operation
Start-up
Parameter
System
configuration
Code
Output contacts
General settings
General settings
Current output
Current output 1
Current output 2
Temperature
Temperature
compensation
Temperature
measurement
Meas. range 1-4
Select substance
(only for FBU)
Hold on calibration
Calibration
no
yes
Limit contactor Limit configuration
Alarm configuration
Operating mode
No. of MRs
Internal MRS
no switch point 1
2 switch points 2
4 switch points 3
Chemoclean
Hold on
Hold
Hold off
Limit contactor 1
Limit operation
Limit contactor 2
mode
Meas. range 1-4
Setpoints
Chemoclean Automatic on
Automatic off
Start cleaning
Display contrast
Language
Deutsch, English,
Francais, Italiano
Air set
bypass
perform
Measuring cell
Meas. type Measuring cell
Conductivity CLS 50, CLS 52,
Concentration 2-ring: k = 0,01;
Resistance k = 0,1; k = 1; k = 10
Mainteance code Specialist code
Relay function
NAMUR contact type
(dep. on configuration)
NC contact
NO contact
Language Filter length
Deutsch, English,
Francais, Italiano
Current monitoring Error current
(cable break monitoring) off
active MIN current
inactive MAX current
Meas. current range Output damping
Current output 1
Current output 1
0 ... 20 mA
4 ... 20 mA
2nd current output Meas. current range
Current output 2
0 ... 20 mA
(only for difference)
4 ... 20 mA
Select meas. range Type of Tc
no comp.
linear
(only on FBU)
NaCl DIN 746
Tc curve
Ultrapure water NaCL
Ultrapure water User
Temperature (MTC)
manual (MTC) Temperature 1
automatic (ATC)
(ATC)
Set offset
Temperature 1
actual value
Select substance Substance name
(for non-preprog.
substance)
ATC cal. sol. Calibration temperature
(at MTC)
Limit contactor 1 Off
Limit contactor 2 On
Meas. range
Select alarm
dependent
Meas. range
independent
Limit contactor 1 Operating mode
Limit contactor 2 Auto
Manual
MR value threshold 1 MR value threshold 2
(not for 1) (not for 1)
Operating mode Limit contact
Auto off/on
Manual
Limit 1 Meas. range 1-4
Date Time
Instruction
Calibrating
Meas. principle Unit
1-circuit
Difference
(only difference)
Assign faults
Contact type failure
to maintenance
relay
contact
Fleeting contact
to no contact
Steady contact
Temperature unit Date
°C, °F , K
Hold type Hold current
fixed current value
(only for fixed
last measured value
current value)
Select characteristic
linear
linear, bilinear,
log. table
Output damping Select characteristic
linear
Current output 2
linear, bilinear,
log. table
for linear Ref. temperature
Select substance
with Tc curve
(MTC)
Temperature 2
(only for difference)
(ATC) (ATC)
Set offset
Display temperature
Temperature 2
offset
actual value
No. of support points Substance table
Substance
Meas. range
dependent
Meas. range
Meas. range 1-4
independent
Meas. range 1-4 Alarm threshold
Alarm delay
Limit contact
off/on
MR value threshold 3 MR value threshold 4
(not for 1+2) (not for 1+2)
Limit 2
Meas. type
Meas. principle
Conductivity
Concentration
(only for difference)
Resistance (MW)
Input contact
(only with FCXI card)
Note
Temperature sensor 1
PT 100
PT 1000
NTC 30 kW
Time
Temperature coeff.
Tc
Susbtance name
Support points
Tc curve
Meas. range 1-4
Min/Max
function
Setting
Automatic on
Automatic off
SI unit
mS/cm, mS/cm
mS/m, S/m
Relay function
(dep. on configuration)
