3.6 Instrument Versions
CLM152-
MYCOM CLM 152
Conductivity and resistance measurement transmitter
Configuration and certificate
A1A
1-circuit; base version
A1C
1-circuit; feedback/hold contact/remote MR switching
A2A
2-circuit; base version
F1A
1-circuit; FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 2; NI outputs
F1B
1-circuit; 3 optocouplers/Chemoclean,
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 2; NI outputs
F1D
1-circuit; 3 optocouplers/Chemoclean/feedback/hold contact,
MR switching
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 2; NI outputs
F1G
1-circuit; feedback/hold contact/remote MR switching, Profibus,
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 2; NI outputs
F2B
2-circuit; 3 optocouplers/Chemoclean
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 2; NI outputs
G1A
1-circuit; FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 1; IS outputs
G1B
1-circuit; 3 optocouplers/Chemoclean,
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 1; IS outputs
G1D
1-circuit; 3 optocouplers/Chemoclean/feedback/hold contact,
MR switching
FM CL 1, Div 2; CL II/III Div 1;
CL. I Zone 1; IS outputs
G1G
1-circuit; feedback/hold contact/remote MR switching, Profibus,
FM CL. I, Div 2; CL II/III Div 1;
CL. I Zone 1; IS outputs
G2B
2-circuit; 3 optocouplers/Chemoclean,
FM CL. I, Div 2; CL II/III Div 1;
CL.I Zone 1; IS outputs
Power supply
1
Power supply: 115 V AC
8
Power supply: 24 V DC
Language version
A
Language: D, E, F, I switchable
Measuring process/Feature
31
NPT 1/2” cable entry, contacting and toroidal
41
NPT 1/2” cable entry, contacting and toroidal with moisture protection
Mounting
A
Without additional mounting kit
B
With post mounting kit
