  • Page 1 SAVE VSR 200/B User Manual Document in original language | 398650 · v1.1...
  • Page 2 © Copyright Systemair UAB All rights reserved E&OE Systemair UAB reserves the rights to change their products without notice. This also applies to products already ordered, as long as it does not affect the previously agreed specifications. 398650 | v1.1...

  • Page 3: Table Of Contents

    Contents Overview ............1 4.8.1 Cleaning extract louvres and supply air diffusers......14 General Description ........1 4.8.2 Checking the outdoor air Warranty ..........1 intake ........14 Type label..........1 4.8.3 Checking the roof cowl (if Warnings............1 fitted)........14 Operation ............2 4.8.4 Checking and cleaning the SAVE LIGHT control panel ......2 duct system ......

  • Page 5: Overview

    For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re- port. Systemair will require these in the case of a warranty claim. Type label Before calling your service representative, make a note of the specification and production number from the type label, which can be found next to the external connections and inside of the unit.

  • Page 6: Operation

    | Operation Warning • This product is not intended to be used by children or people with reduced physical or mental ability or lack of experience and knowledge, if no instruction concerning the use has been given by the person responsible for their safety or that this person is supervising the operation.

  • Page 7: To Cancel Sleep Mode

    Operation | Refresh Auto — flashing High Normal (Minimum) (Maximum) slowly Automatic The fan can be Fan speed – 25% Fan speed – 45% Fan speed – 70% Sets speed of airflow control. set to Off by both supply and activating extract air fans Available only...

  • Page 8: Save Touch Control Panel / Save Connect

    | Operation SAVE TOUCH control panel / SAVE CONNECT Settings are done by touching the icons or options. The touch screen is sensitive and it is not necessary to press too hard. SAVE CONNECT solution (mobile application and Internet access module) has a similar menu structure and functionality as SAVE TOUCH control panel, so this section can also be used as a guide for the mobile application.

  • Page 9: Quick Information Screen

    Operation | Touch the alarm bar on the home screen to see all active alarms. Touch HELP button to know more about the alarm. To clear the alarm, touch ACKNOWLEDGE button. Note: The underlying cause of the alarm must be resolved first otherwise the alarm will appear again. If the problem continues contact your installation company or place of purchase.
  • Page 10 | Operation Duration have to be set for temporary user modes. SAVE VSR 200/B will return to its previous working mode after the set time expires. Note: AUTO mode is available for selection only if the optional Demand Control, Week Schedule and/or external fan control functions are activated.

  • Page 11: To Change The Temperature

    Operation | Icon Text Description Sets speed of both supply and extract air fans to Maximum levels to replace Refresh indoor air with a fresh air in a short period of time. Set duration in minutes. Sets speed of supply air fan to High level and extract air fan to Low level to increase air pressure within the apartment for better smoke extraction through Fireplace the chimney.

  • Page 12: To Set A Week Schedule

    | Operation 3.2.8 To set a week schedule While in home screen, touch menu icon and select Week Schedule. The menu is locked by default. Enter a password (default password is 1111). Touch icon at the bottom left corner of the screen to add a new schedule or press EDIT button to modify already added schedule.

  • Page 13: Maintenance

    1. It is recommended to do this every 5 years and is normally carried out by authorized companies specialized in this area. • Use original spare parts from Systemair only. • Scan the code on the type label to find a spare part list.

  • Page 14: To Clean The Air Chambers

    | Maintenance Note: Do not forget to tighten screws back after the maintenance! To clean the air chambers Danger • Make sure that the Mains supply to the unit is disconnected before performing any maintenance or electrical work! Dust and dirt collect in the air chambers inside the product. The product must be cleaned periodically. 1.

  • Page 15: To Reset The Filter Change Time

    Maintenance | When it’s time to change the filters an alarm is shown on the control panel display. When this occurs do the following: 1. Stop the unit by disconnecting the mains. 2. Remove the filter cover plates. 3. Pull out the filters towards you. Some force may be needed.

  • Page 16: To Clean The Heat Exchanger

    If the alarm Rotor guard is raised the rotor drive belt may be damaged or broken, see chapter 3.2.3. SAVE VSR 200/B units are delivered with two welded drive belts (1) — one mounted and one as extra if replacement is required.

  • Page 17: Temporary Belt Repair Solution

    Maintenance | 4.6.1 Temporary belt repair solution In case both welded belts break it is possible to use joint nipple as a temporarily quick repair solution until the welded belt can be replaced with a new one. Depending of how the unit is installed, it may be not necessary to remove the heat exchanger package in order to temporary repair a broken drive belt if the belt pulley can be accessed.

  • Page 18: Duct System Maintenance

    | Troubleshooting The motor bearings are life time lubricated and mainte- nance free. Even if the required maintenance, such as changing of fil- ters is carried out, dust and grease may slowly build up in- side the fans. This will reduce the efficiency. 1.

  • Page 19: Electrical Data

    Electrical data | 2. The unit could be in defrost mode. This reduces the fan speed and in some cases shuts down the supply air fan com- pletely during the defrosting cycle. The fans go back to normal after defrosting. There should be a defrosting function icon visible on the home screen if defrosting is active.

  • Page 20: Disposal And Recycling

    | Disposal and recycling Disposal and recycling This product is compliant with the European WEEE Directive and related national waste legislation. When disposing the unit, follow your local rules and regulations. This product packing materials are recyclable and can be reused. Do not dispose in household waste.
  • Page 21 398650 | v1.1...
