Metered Dispensing Valve
For metered dispense of petroleum and synthetic oils.
1000 psi (7 MPa, 69 bar) Maximum Working Pressure
4 gpm (15.1 lpm) Maximum Flow Rate
Model 234114, Series A (1-16 quarts)
Model 253601, Series A (1-10 liters)
