Page 1 Hardware Maintenance Manual Type 6029...
Page 3 Hardware Maintenance Manual Type 6029...
Page 4 IBM may make improvements or changes in the products or the programs described in this publication at any time. Requests for technical information about IBM products should be made to your IBM Authorized Dealer or your IBM Marketing Representative.
Page 5: Table Of Contents
Send us your comments! . 126 Replacing a microprocessor . . 35 Problem determination tips. . 127 Removals . . 35 Notices . 127 Front bezel . 35 Trademarks . . 128 Hard disk drive . . 36 © Copyright IBM Corp. 2001...
Page 6 Hardware Maintenance Manual...
Page 7: Chapter 1. About This Manual
Computer products. Use this manual along with advanced diagnostic tests to troubleshoot problems effectively. Before servicing an IBM product, be sure to review the “Safety information” on page 93. Important Safety Information Be sure to read all caution and danger statements in this book before performing any of the instructions.
Page 8 Leia todas as instruções de cuidado e perigo antes de executar qualquer operação. Lea atentamente todas las declaraciones de precaución y peligro ante de llevar a cabo cualquier operación. Hardware Maintenance Manual...
Page 9: Chapter 2. General Checkout
Notes: v Type 6029 computers default to come up quiet (no beep and no memory count and checkpoint code display) when no errors are detected by POST. v To enable beep and memory count and checkpoint code display when a successful POST occurs, do the following: 1.
Page 10 If NO, continue to 002 . If YES, proceed to 003 . If the Power Management feature is enabled, do the following: 1. Start the Configuration/Setup Utility program (see “Setup Utility program” on page 12) 2. Select Power Management from the Configuration/Setup Utility program menu.
Page 11: Chapter 3. General Information
Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP) v Wake on LAN v Wake on Ring (in the IBM Setup Utility program, this feature is called Serial Port Ring Detect for an external modem and Modem Ring Detect for an internal modem) ©...
Page 12 Diskette and hard disk I/O control v Serial and parallel port I/O control v Security profile by device IBM preinstalled software The computer might come with preinstalled software. If it does, an operating system, device drivers to support built-in features, and other support programs are included.
Page 13: Physical Specifications
1. The operating systems listed here are being tested for compatibility at the time this publication goes to press. Additional operating systems might be identified by IBM as compatible with your computer following the publication of this booklet. Corrections and additions to this list are subject to change. To determine if an operating system has been tested for compatibility, check the Web site of the operating system vendor.
Page 14 Dimensions Heat output (approximate) in British thermal units (BTU) per hour: Height: 393 mm (15.5 in.) Minimum configuration: 188 BTU/hr (55 watts) Width: 179 mm (7 in.) Maximum configuration: 256 BTU/hr (75 watts) Depth: 393 mm (15.5 in.) Airflow Weight Approximately 0.79 cubic meters every 3 minutes (28 Minimum configuration as shipped: 9.1 kg (20 lb) cubic feet every 3 minutes) maximum...
Page 15: Available Options
Within the United States, call 1-800-IBM-2YOU (1-800-426-2968), your IBM reseller, or IBM marketing representative. v Within Canada, call 1-800-565-3344 or 1-800-IBM-4YOU. v Outside the United States and Canada, contact your IBM reseller or IBM marketing representative. Chapter 3. General information...
Page 16 Hardware Maintenance Manual...
Page 17: Chapter 4. Diagnostics
The following tools are available to help identify and resolve hardware-related problems. v Setup Utility program v Power-On Self-Test (POST) – POST Beep Codes – Error Code Format v Diagnostics program v Recovery utility – Full recovery – Partial recovery v Repair utility © Copyright IBM Corp. 2001...
Page 18: Setup Utility Program
Setup Utility program Attention: A customized setup configuration (other than default settings) might exist on the computer you are servicing. Running the Setup Utility program might alter those settings. Note the current configuration settings and verify that the settings are in place when service is complete.
Page 19: Product Recovery Program Menu
Product Recovery Program menu Type 6029 machines have recovery and diagnostics programs on a separate hard drive partition. The Enhanced Diagnostics diskette is not shipped with the machine. To download the Diagnostics program, see “Diagnostics program download” on page 14.
Page 20: Diagnostics
39. Diagnostics program download To download the Diagnostics program, do the following: v Go to http://www.ibm.com/. v Select Support. v Select Personal computing from the ″Get product support for″ pull-down menu. v Search for the machine type in the ″Quick Path″ box on the left.
Page 21: Test Results
ChkDigits: Contains a 2-digit check-digit value to ensure the following: – Diagnostics were run on the specified date. – Diagnostics were run on the specified IBM computer. – The diagnostic error code is recorded correctly. v Text: Description of the error.
Page 22 v Destroys the Master Boot Record (MBR) on the hard drive. v Destroys all copies of the FAT Table on all partitions (both the master and backup). v Destroys the partition table. v Provides messages that warn the user that this is a non-recoverable process. Hardware Maintenance Manual...
Page 23: Quick And Full Erase - Hard Drive
The Full Erase Hard Drive provides a DOS utility that performs the following steps. v Performs all the steps in Quick Erase. v Provides a DOS utility that writes random data to all sectors of the hard drive. v Provide an estimate of time to completion along with a visual representation of completion status.
Page 24 Hardware Maintenance Manual...
Page 25: Chapter 5. Installing Options
Important: Before you install or remove any option, read “Safety information” on page 93. These precautions and guidelines will help you work safely. © Copyright IBM Corp. 2001...
Page 26: Locating Connectors On The Front Of The Computer
Locating connectors on the front of the computer The following illustration shows the locations of the USB connectors on the front of the computer. 1 and 2 USB connectors Hardware Maintenance Manual...
Page 27: Locating Connectors On The Rear Of The Computer
Locating connectors on the rear of the computer The following illustration shows the locations of the connectors on the back of the computer. Power connector Ethernet connector Mouse connector Audio line out connector Keyboard connector Audio line in connector Serial connector Microphone connector Parallel connector Serial connector...
Page 28: Obtaining Device Drivers
Obtaining device drivers Device drivers can be obtained for operating systems that are not preinstalled at http://www.ibm.com/pc/support/ on the World Wide Web. Installation instructions are provided in README files with the device driver files. Installing internal options The capabilities of the computer can be expanded by adding memory, drives, or adapters.
Page 29: Removing The Cover
Removing the cover Important: See “Safety information” on page 93and “Handling electrostatic discharge-sensitive devices” on page 96 before you begin. To remove the cover: 1. Shut down the operating system, remove any media (diskettes, CDs, or tapes) from the drives, and turn off all attached devices and the computer. 2.
Page 30: Locating Components
Identifying parts on the system board The system board is the main circuit board in the computer. It provides basic computer functions and supports a variety of devices that are IBM-installed or that can be installed later. Hardware Maintenance Manual...
Page 31: Identifying Parts On The System Board
The following illustration shows the locations of parts on the system board. 1 Fan connector 9 Secondary IDE connector 2 Microprocessor 10 Primary IDE connector 3 DIMM connector 1 11 Front USB connector 4 DIMM connector 2 12 Battery 5 Power connector 13 Virtual clear CMOS/BIOS recovery jumper (JP14) 6 Hard disk LED connector...
Page 32 3. To locate the DIMM connectors. See “Identifying parts on the system board” on page 24. 4. Open the retaining clips. 5. Make sure the notches in the DIMM align with the tabs on the connector. Push or insert the DIMM straight down into the connector until the retaining clips close.
Page 33: Installing And Removing Adapters
Installing and removing adapters This section provides information and instructions for installing and removing adapters. The computer has three expansion slots for PCI adapters. You can install an adapter up to 228 mm (9 inches) long. To install an adapter: 1.
Page 34 4. Install the adapter into the appropriate slot on the system board. 5. Secure the adapter with the screw as shown. To remove an adapter: 1. Remove the cover. See “Removing the cover” on page 23. Hardware Maintenance Manual...
Page 35: Installing And Removing Internal Drives
Also, it is important to correctly connect the internal drive cables to the installed drive. Drive specifications Type 6029 computers come with the following IBM-installed drives: v A CD-ROM, DVD-ROM, or CD-RW drive in bay 1 (some models) v A 3.5-inch diskette disk drive in bay 3 v A 3.5-inch hard drive in bay 4...
Page 36 The following table describes some of the drives that can be installed in each bay and their height requirements. 1 Bay 1 - Maximum height: 43.0 mm (1.7 in.) CD-ROM drive (preinstalled in some models) 5.25-inch hard disk drive 2 Bay 2 - Maximum height: 43.0 mm (1.7 in.) 5.25-inch hard disk drive 3.5-inch hard disk drive (requires a mounting bracket)
Page 37: To Connect The First Ide Cd Drive Or Dvd Drive
v If it is an additional CD drive or DVD drive, set it as a slave device. v If it is a hard disk drive, set it as a slave device. Refer to the documentation that comes with the drive for master/slave jumper information.
Page 38: To Connect An Additional Ide Cd Drive Or Dvd Drive
To connect an additional IDE CD drive or DVD drive 1. Locate the secondary IDE connector on the system board and the three-connector signal cable. See “Identifying parts on the system board” on page 24. 2. Connect the extra connector in the signal cable to the new CD drive or DVD drive.
Page 39: Replacing The Cover And Connecting The Cables
7. Replace any adapters that were removed to gain access to the battery. See “Installing and removing adapters” on page 27 for instructions for replacing adapters. 8. Replace the cover, and plug in the power cord. See “Replacing the cover and connecting the cables”.
Page 40 3. Position the cover on the chassis so that the guides on the top and bottom of the cover engage the chassis and push the cover to the closed position. Insert the screws that secure the cover. 4. Reconnect the external cables and power cords to the computer. See “Installing external options”...
Page 41: Chapter 6. Fru Removals
To remove the front bezel, do the following: 1. Turn off the server and peripheral devices and disconnect all external cables and power cords. 2. Remove the cover. See “Removing the cover” on page 23 © Copyright IBM Corp. 2001...
Page 42: Hard Disk Drive
3. Push the bezel securing snaps out from inside the computer. 4. Pull the bezel off the computer. Hard disk drive To remove the hard disk drive, do the following: 1. Turn off the computer and peripheral devices and disconnect all external cables and power cords;...
Page 43: Power Supply
4. Remove the screws securing the hard disk drive. 5. Remove the disk drive. Note: When replacing the hard disk drive, make sure you obtain the proper Recovery CD to install after you install the new hard drive. Power supply To remove the power supply, do the following: Chapter 6.
Page 44: System Board
1. Turn off the server and peripheral devices and disconnect all external cables and power cords; then, remove the cover. See “Removing the cover” on page 23. 2. Disconnect all power supply wires. 3. Remove the four screws holding the power supply to the back of the chassis. 4.
Page 45: Chapter 7. Symptom-To-Fru Index
Check the following for proper installation. Reseat v Power Cord v On/Off Switch connector v On/Off Switch Power Supply connector v System Board Power Supply connectors v Microprocessor(s) connection Check the power-on switch for continuity. Power Cord © Copyright IBM Corp. 2001...
Page 46 Check/Verify FRU/Action Check the power-on switch for continuity. Power-on Switch Hardware Maintenance Manual...
Page 47: Diagnostic Error Codes
Diagnostic error codes Refer to the following diagnostic error codes when using the diagnostic tests. See ″Diagnostics″ on page 11 for the specific type for information about the Diagnostic programs. In the following index, X can represent any number. Diagnostic Error Code FRU/Action 000-000-XXX 1.
Page 48 Diagnostic Error Code FRU/Action 000-197-XXX 1. Make sure the component that is called BIOS test warning out is connected and/or enabled 2. Re-run test 3. Component that is called out in warning statement 4. Component under test 000-198-XXX 1. If a component is called out, make sure BIOS test aborted it is connected and/or enabled 2.
Page 49 Diagnostic Error Code FRU/Action 001-038-XXX 1. Adapter card System Extension failure 2. System board 001-039-XXX 1. Flash the system System DMI data structure error 2. System board 001-040-XXX 1. Power-off/on system and re-test System IRQ failure 2. System board 001-041-XXX 1.
Page 50 Diagnostic Error Code FRU/Action 001-271-XXX 1. Device on IRQ4 System IRQ4 failure 2. System board 001-272-XXX 1. Device on IRQ5 System IRQ5 failure 2. System board 001-273-XXX 1. Diskette Cable System IRQ6 2. Diskette drive (diskette drive) failure 3. System board 001-274-XXX 1.
Page 51 Diagnostic Error Code FRU/Action 001-301-XXX 1. Flash the system System RTC Century byte error 2. System board 005-000-XXX 1. No action Video Test Passed 005-00X-XXX 1. Video card, if installed Video error 2. System board 005-010-XXX 1. Video card, if installed 005-011-XXX 2.
Page 52 Diagnostic Error Code FRU/Action 005-197-XXX 1. Make sure the component that is called Video test warning out is connected and/or enabled 2. Re-run test 3. Component that is called out in warning statement 4. Component under test 005-198-XXX 1. If a component is called out, make sure Video test aborted it is connected and/or enabled 2.
Page 53 Diagnostic Error Code FRU/Action 011-000-XXX 1. No action Serial port Interface Test Passed 011-001-XXX 1. Remove external serial device, if Serial port Presence present 2. Run setup, enable port 3. System board 011-002-XXX 1. System board 011-003-XXX Serial port Timeout/Parity error 011-013-XXX 1.
Page 54 Diagnostic Error Code FRU/Action 014-001-XXX 1. Remove external parallel device, if Parallel port Presence present 2. Run setup, enable port 3. System board 014-002-XXX 1. System board 014-003-XXX Parallel port Timeout/Parity error 014-013-XXX 1. System board 014-014-XXX Parallel port Control Signal/Loopback test failure 014-015-XXX 1.
Page 55 Diagnostic Error Code FRU/Action 015-002-XXX 1. Remove USB device(s) and re-test USB port Timeout 2. System board 015-015-XXX 1. Remove USB device(s) and re-test USB port External Loopback failure 2. System board 015-027-XXX 1. Flash the system USB port Configuration/Setup error 2.
Page 56 Diagnostic Error Code FRU/Action 018-195-XXX 1. PCI card PCI Card Test aborted by user 2. Information 3. Re-start the test, if necessary 018-196-XXX 1. Press F3 to review the log file PCI Card test halt, error threshold exceeded 2. Re-start the test to reset the log file 018-197-XXX 1.
Page 57 Diagnostic Error Code FRU/Action 020-199-XXX 1. Go to the ″Undetermined problems″ PCI test failed, cause unknown section 2. Flash the system and re-test 3. Replace component under function test 020-262-XXX 1. PCI card PCI system error 2. Riser card, if installed 3.
Page 58 Diagnostic Error Code FRU/Action 030-00X-XXX 1. SCSI signal cable 030-01X-XXX 2. Check power supply SCSI interface failure 3. SCSI device 4. SCSI adapter card, if installed 5. System board 030-027-XXX 1. SCSI signal cable SCSI interface Configuration/Setup error 2. Flash the system 3.
Page 59 Diagnostic Error Code FRU/Action 035-196-XXX 1. Press F3 to review the log file RAID interface test halt, error threshold 2. Re-start the test to reset the log file exceeded 035-197-XXX 1. Make sure the component that is called RAID interface test warning out is connected and/or enabled 2.
Page 60 Diagnostic Error Code FRU/Action 071-199-XXX 1. Go to the ″Undetermined problems″ Audio port test failed, cause unknown section 2. Flash the system and re-test 3. Replace component under function test 071-25X-XXX 1. Speakers Audio port failure 2. Audio card, if installed 3.
Page 61 Diagnostic Error Code FRU/Action 086-196-XXX 1. Press F3 to review the log file Mouse Port interface test halt, error 2. Re-start the test to reset the log file threshold exceeded 086-197-XXX 1. Make sure the component that is called Mouse Port interface test warning out is connected and/or enabled 2.
Page 62 Diagnostic Error Code FRU/Action 170-195-XXX 1. Information Voltage Sensor(s) Test aborted by user 2. Re-start the test, if necessary 170-196-XXX 1. Press F3 to review the log file Voltage Sensor(s) test halt, error threshold 2. Re-start the test to reset the log file exceeded 170-197-XXX 1.
Page 63 Diagnostic Error Code FRU/Action 175-199-XXX 1. Go to the ″Undetermined problems″ Thermal Sensor(s) test failed, cause section unknown 2. Flash the system and re-test 3. Replace component under function test 175-250-XXX 1. Check fans 175-251-XXX 2. Check Power supply Thermal Sensor(s) limit error 3.
Page 64 Diagnostic Error Code FRU/Action 217-28X-XXX 1. Hard Disk Drive Cable 217-29X-XXX 2. Check power supply voltages Hard Disk Drive (SCSI) error 3. Hard Disk drive (SCSI) 4. SCSI adapter card 5. System board 220-000-XXX 1. No action Hi-Capacity Cartridge Drive Test Passed 220-XXX-XXX 1.
Page 65: Beep Symptoms
Beep symptoms Beep symptoms are short tones or a series of short tones separated by pauses (intervals without sound). See the following examples. Beeps Description 1-2-X v One beep v A pause (or break) v Two beeps v A pause (or break) v Any number of breaks Four continuous beeps Use the following table to diagnose beep symptoms.
Page 66 Beep Symptom FRU/Action 2-2-4 CMOS configuration info validation 1. Battery failed 2. System Board 2-3-1 Screen initialization failed 1. Jumper on J28 2. System Board 2-3-2 Screen memory failed 1. System Board 2-3-3 Screen retrace failed 1. System Board 1-2 Search for video ROM failed 1.
Page 67: No-Beep Symptoms
No-beep symptoms Symptom/Error FRU/Action No beep during POST but computer works 1. System Board correctly. No beep during POST. 1. See “Undetermined problems” on page 2. System Board 3. Memory Module 4. Any Adapter or Device 5. Riser Card 6. Power Cord 7.
Page 68: Post Error Codes
Note: Type 6029 computers default to come up quiet (no beep and no memory count and checkpoint code display) when no errors are detected by POST. To enable beep and memory count and checkpoint code display when a successful POST occurs, do the following: 1.
Page 69 POST Error Code FRU/Action 1. Reseat adapters I/O channel parity error 2. Any adapter 3. Riser card 4. System Board 1. Adapter Memory Adapter ROM error 2. System Board 3. Riser card 1. Processor Internal cache test error 2. L2 Cache Memory 3.
Page 70 1. More than three password attempts were made to access the computer 1. System Board System Security: Invalid Remote Change Requested 191 System Security: IBM Embedded 1. System Board Security Hardware Reset 193 System Security: IBM Embedded 1. System Board...
Page 71 POST Error Code FRU/Action 1. Unsupported Memory 1. L2 Cache Memory External cache test error 2. System Board 1. Run Setup. Check System Summary POST detected a base memory or extended menu for memory. (See “Setup Utility memory type error program”...
Page 72 POST Error Code FRU/Action 1. Diskette Drive Not listed above 2. System Board 3. Riser card 4. External Drive Adapter 5. Diskette Drive Cable 6. Power Supply 1. Run Setup Math coprocessor configuration error 2. Processor 3. System Board 1. Processor Not listed above 2.
Page 73 POST Error Code FRU/Action 1117 1. Run Enhanced Diagnostics Failed baud rate test 1162 1. Run Configuration Serial port configuration error 2. Serial Adapter (if installed) 3. System Board 11XX 1. System Board Not listed above 1201 1. System Board 2.
Page 74 POST Error Code FRU/Action 1800 PCI/PnP Error! No Hardware Interrupt 1. Run Setup and verify PCI/ISA Available configuration settings. 2. If necessary, set ISA adapters to Not available to allow PCI adapters to properly configure. 3. Remove any suspect ISA adapters. 4.
Page 75 POST Error Code FRU/Action 180X, 188X 1. Run Setup and verify PCI/ISA PCI configuration or resource error configuration settings. 2. If necessary, set ISA adapters to Not available to allow PCI adapters to properly configure. 3. Remove any suspect ISA adapters. 4.
Page 76 POST Error Code FRU/Action 5962 1. Run Configuration An IDE device (other than hard drive) 2. CD-ROM Drive configuration error 3. CD-ROM Adapter 4. Zip or other ATAPI device 5. System Board 6. Riser card 62XX 1. 1st Store Loop Adapter 2.
Page 77 (if installed) 4. Modem 10118 1. Run Diagnostics and verify the correct operation of the modem slot 2. Modem 10119 1. Diagnostics detected a non-IBM modem 2. Modem 10120 1. Check PSTN Cable 2. External DAA (if installed) 3. Modem 10132, 10133, 10134, 1.
Page 78 POST Error Code FRU/Action 10461 1. Run Enhanced Diagnostics Drive format error 10462 1. Run Enhanced Diagnostics Controller seek error 10464 1. Run Enhanced Diagnostics Hard Drive read error 10467 1. Run Enhanced Diagnostics Drive non-fatal seek error 10468 1. Run Enhanced Diagnostics Drive fatal seek error 10469 1.
Page 79 POST Error Code FRU/Action 119XX 1. 3119 Adapter 121XX 1. Modem Adapter 2. Any Serial Device 3. System Board 4. Riser card 136XX 1. ISDN Primary Rate Adapter 2. System Board 3. Riser card 137XX 1. System Board 141XX 1. Realtime Interface Coprocessor Portmaster Adapter/A 143XX...
Page 80 POST Error Code FRU/Action 185XXXX 1. DBCS Japanese Display Adapter/A 2. System Board 3. Riser card 20001 to 20003 1. Image Adapter/A Image-I Adapter/A 2. Memory Module DRAM, VRAM 20004 1. Memory Module DRAM, VRAM 2. Image Adapter/A Image-I Adapter/A 20005 to 20010 1.
Page 81 POST Error Code FRU/Action Tape Drive green ″in use″ LED fails to come 1. Tape Drive 2. SCSI Adapter or System Board 3. SCSI Cable (internal) 4. SCSI Cable (external) Tape automatically ejected from drive 1. Tape Cassette Drive SCSI ID on rotary switch does not match 1.
Page 82 POST Error Code FRU/Action 27512 1. WMSELF.DGS diagnostics file is missing 2. WMSELF.DGS diagnostics file is incorrect 27535 1. 3V Lithium Backup Battery 2. ServerGuard Adapter 27554 1. Internal Temperature out of range 2. ServerGuard Adapter 27555, 27556 1. ServerGuard Adapter 2.
Page 83: Miscellaneous Error Messages
Miscellaneous error messages Message/Symptom FRU/Action CMOS Backup Battery inaccurate 1. CMOS Backup Battery (see “Safety information” on page 93) 2. System Board Changing colors 1. Display Computer will not power-off. See “Power 1. Power Switch Supply Errors” on page 39. 2.
Page 84 Message/Symptom FRU/Action ″Insert a Diskette″ icon appears with a 1. System Board known-good diagnostics diskette in the first 2. Diskette Drive Cable 3.5-inch diskette drive. 3. Riser card 4. Network Adapter Intensity or color varies from left to right of 1.
Page 85: Undetermined Problems
1. Power-off the computer. 2. Remove or disconnect the following components (if installed) one at a time. a. Non-IBM devices b. External devices (modem, printer, or mouse) c. Any adapters d.
Page 86 Hardware Maintenance Manual...
Page 87 Chapter 8. Parts listing This section lists the replaceable FRUs for Machine Type 6029. Machine Type 6029 Chassis complete w/Cvrs (Black) (models 22A 22C 23C 26A 49P4537 26C 32A 32C 33C 36A 36C 12A 12C 13C 16A 16C) Chassis complete w/Cvrs (White) (models 10A 10C 30A...
Page 88 Machine Type 6029 CD-ROM Drive 48X (Black) (models 26A 26C 36A 36C 16A 33P3211 16C) CD-ROM Drive (Black) (models 26A 26C 36A 36C 16A 16C) 33P3215 CD-ROM Drive (White) (models 30A 30C 50A 50C) 33P3213 CD-ROM Drive (White) (models 30A 30C 50A 50C)
Page 89 Keyboards (Standard PS/2 Black) Arabic 32P5001 Belgian/French 32P5002 Belgian/UK 32P5003 Bulgarian 32P5004 Chinese/US (models 22C 23C 26C 32C 33C 36C 12C 13C 32P5005 16C) Czech 32P5006 Danish 32P5007 Dutch 32P5008 French 32P5009 French Canadian 32P5010 French Canadian 32P5011 German 32P5012 Greek 32P5013 Hebrew...
Page 90 Keyboards (Standard PS/2 White) US English (models 10A 30A 40A 50A) 32P5040 Arabic 32P5041 Belgian/French 32P5042 Belgian/UK 32P5043 Bulgarian 32P5044 Chinese/US (models 10C 30C 40C 50C) 32P5045 Czech 32P5046 Danish 32P5047 Dutch 32P5048 French 32P5049 French Canadian 32P5050 French Canadian 32P5051 German 32P5052...
Page 91: Chapter 8. Parts Listing
Power Cords Line Cord (models 12A 16A 10A 30A 40A 50A) 6952301 Line Cord (models 12A 16A 10A 30A 40A 50A) 13F9939 Line Cord (models 12A 16A 10A 30A 40A 50A) 13F9978 Line Cord (models 22A 26A 32A 36A 12A 16A 10A 30A 40A 14F0032 50A) Line Cord...
Page 92 Hardware Maintenance Manual...
Page 93: Chapter 9. Additional Service Information
The administrator password is used to restrict access to the Configuration/Setup Utility program. If the administrator password is activated, and you do not enter the administrator password, the configuration can be viewed but not changed. © Copyright IBM Corp. 2001...
Page 94: Vital Product Data
Note: Type 6029 computers have Enhanced Security Mode. If Enhanced Security mode is enabled and there is no password given, the computer will act as if Enhanced Security is disabled. If Enhanced Security is Enabled and an administrator password is given, the administrator password must be entered to use the computer.
Page 95: Alert On Lan
BIOS. v Current Level BIOS information – Run the Configuration Utility to determine the level of BIOS installed. v Sources for determining the latest level BIOS available 1. IBM Home Page http://www.ibm.com/pc/us/ 2. PC PartnerInfo-Technical Database (CTSTIPS.NSF) ®...
Page 96: Flash Recovery Boot Block Jumper
3. Insert the upgrade diskette into the diskette drive. 4. Power-on the computer. The IBM Logo will appear. 5. When the Flash Update Utility appears, select the country/keyboard, then press Enter.
Page 97: Power Management
Power management Power management reduces the power consumption of certain components of the computer such as the system power supply, processor, hard disk drives, and some ™ monitors. Advanced Power Management and Rapid Resume Manager are features of some personal computers. Automatic configuration and power interface (ACPI) BIOS Being an ACPI BIOS system, the operating system is allowed to control the power management features of the computer and the setting for Advanced Power...
Page 98: Automatic Power-On Features
Wake on LAN: If the computer has a properly configured token-ring or Ethernet LAN adapter card that is Wake on LAN-enabled and there is remote network management software, you can use the IBM-developed Wake on LAN feature. When you set Wake on LAN to Enabled, the computer will turn on when it receives a specific signal from another computer on the local area network (LAN).
Page 99: Chapter 10. Related Service Information
Safety information The following section contains the safety information that you need to be familiar with before servicing an IBM computer. General safety Follow these rules to ensure general safety: v Observe good housekeeping in the area of the machines during and after maintenance.
Page 100: Electrical Safety
Electrical safety CAUTION: Electrical current from power, telephone, and communication cables can be hazardous. To avoid personal injury or equipment damage, disconnect the attached power cords, telecommunication systems, networks, and modems before you open the server covers, unless instructed otherwise in the installation and configuration procedures.
Page 101: Safety Inspection Guide
This guide addresses only those items. However, good judgment should be used to identify potential safety hazards due to attachment of non-IBM features or options not covered by this inspection guide.
Page 102: Handling Electrostatic Discharge-Sensitive Devices
Insulation must not be frayed or worn. 4. Remove the cover. 5. Check for any obvious non-IBM alterations. Use good judgment as to the safety of any non-IBM alterations. 6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
Page 103: Grounding Requirements
Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Safety notices (multi-lingual translations) The caution and danger safety notices in this section are provided in the following languages: v English v Brazilian/Portuguese...
Page 104 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.
Page 105 CAUTION: Use safe practices when lifting. CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.
Page 106 5. LIGUE os dispositivos. CUIDADO: Ao substituir a bateria de lítio, utilize apenas uma bateria IBM, Número de Peça 33F8354 ou uma bateria de tipo equivalente, recomendada pelo fabricante. Se o seu sistema possui um móídulo com uma bateria de lítio, substitua-o apenas pelo mesmo tipo de mídulo, do mesmo fabricante.
Page 107 Conserte nem desmonte Para descartar a bateria, entre em contato com a área de atendimento a clientes IBM, pelo telefone (011) 889-8986, para obter informações sobre como enviar a bateria pelo correio para a IBM. PRECAUCIÓN: Quando produtos a laser (unidades de CD-ROM, unidades de DVD, dispositivos de fibra ítica, transmissores, etc.) estiverem instalados, observe o seguinte:...
Page 108 fonte de energia elétrica. CUIDADO: CUIDADO: Não coloque nenhum objeto com peso superior a 82 kg (180 lbs.) sobre dispositivos montados em rack. Hardware Maintenance Manual...
Page 109 Chapter 10. Related service information...
Page 110 Hardware Maintenance Manual...
Page 111 Chapter 10. Related service information...
Page 112 Hardware Maintenance Manual...
Page 113 Chapter 10. Related service information...
Page 114 Hardware Maintenance Manual...
Page 115 Chapter 10. Related service information...
Page 116 Hardware Maintenance Manual...
Page 117 ATTENTION: Remplacez la pile au lithium usagée par une pile de référence identique exclusivement - voir la référence IBM - ou par une pile équivalente recommandée par le fabricant. Si votre système est doté d’un module contenant une pile au lithium, vous devez le remplacer uniquement par un module identique, produit par le même fabricant.
Page 118 v Ne cherchez pas à la réparer ou à la démonter. Pour la mise au rebut, reportez-vous à la réglementation en vigueur. ATTENTION: Si des produits laser sont installés (tels que des unités de CD-ROM ou de DVD, des périphériques contenant des fibres optiques ou des émetteurs-récepteurs), prenez connaissance des informations suivantes: v N’ouvrez pas ces produits pour éviter une exposition directe au rayon laser.
Page 119 électrique à l’intérieur de la machine. Il se peut que votre unité dispose de plusieurs cordons d’alimentation. Pour isoler totalement l’unité du réseau électrique, débranchez tous les cordons d’alimentation des socles de prise de courant. ATTENTION: Ne posez pas d’objet dont le poids dépasse 82 kg sur les unités montées en armoire.
Page 120 4. Netzstecker an Steckdose anschließen. 5. Gerät einschalten. ACHTUNG: Eine verbrauchte Batterie nur durch eine Batterie mit der IBM Teilenummer 33F8354 oder durch eine vom Hersteller empfohlene Batterie ersetzen. Wenn Ihr System ein Modul mit einer Lithium-Batterie enthält, ersetzen Sie es immer mit dem selben Modultyp vom selben Hersteller.
Page 121 v reparieren oder zerlegen. Die örtlichen Bestimmungen für die Entsorgung von Sondermüll beachten. ACHTUNG: Wenn ein Laserprodukt (z. B. CD-ROM-Laufwerke, DVD-Laufwerke, Einheiten mit Glasfaserkabeln oder Transmitter) installiert ist, beachten Sie folgendes. v Das Entfernen der Abdeckungen des CD-ROM-Laufwerks kann zu gefährlicher Laserstrahlung führen.
Page 122 Mit dem Betriebsspannungsschalter an der Vorderseite des Servers und dem Betriebsspannungsschalter am Netzteil wird die Stromversorgung für den Server nicht unterbrochen. Der Server könnte auch mehr als ein Netzkabel aufweisen. Um die gesamte Stromversorgung des Servers auszuschalten, muß sichergestellt werden, daß alle Netzkabel aus den Netzsteckdosen herausgezogen wurden. ACHTUNG: Keine Gegenstände, die mehr als 82 kg wiegen, auf Rack-Einheiten ablegen.
Page 123 5. ACCENDERE le unità. ATTENZIONE: Quando si sostituisce la batteria al litio, utilizzare solo una batteria IBM con numero parte 33F8354 o batterie dello stesso tipo o di tipo equivalente consigliate dal produttore. Se il sistema di cui si dispone è provvisto di un modulo contenente una batteria al litio, sostituire tale batteria solo con un tipo di modulo uguale a quello fornito dal produttore.
Page 124 Smaltire secondo la normativa in vigore (D.Lgs 22 del 5/2/9) e successive disposizioni nazionali e locali. ATTENZIONE: Quando si installano prodotti laser come, ad esempio, le unità DVD, CD-ROM, a fibre ottiche o trasmettitori, prestare attenzione a quanto segue: v Non rimuovere i coperchi. L’apertura dei coperchi di prodotti laser può determinare l’esposizione a radiazioni laser pericolose.
Page 125 siano scollegati dalla sorgente di alimentazione. ATTENZIONE: Non poggiare oggetti che pesano più di 82 kg sulla parte superiore delle unità montate in rack. Chapter 10. Related service information...
Page 126 Hardware Maintenance Manual...
Page 127 Chapter 10. Related service information...
Page 128 Hardware Maintenance Manual...
Page 129 PRECAUCIÓN: Cuando desee sustituir la batería de litio, utilice únicamente el número de pieza 33F8354 de IBM o cualquier tipo de batería equivalente que recomiende el fabricante. Si el sistema tiene un mídulo que contiene una batería de litio, sustitúyalo únicamente por el mismo tipo de mídulo, que ha de estar creado por el mismo fabricante.
Page 130: Safety Notices (Multi-Lingual Translations)
v Calentarla a una temperatura que supere los 100 C (212 F) v Repararla o desmontarla Despréndase de la batería siguiendo los requisitos que exija el reglamento o la legislaciín local. PRECAUCIÓN: Cuando instale productos láser (como, por ejemplo, CD-ROM, unidades DVD, dispositivos de fibra íptica o transmisores), tenga en cuenta las advertencias siguientes: v No retire las cubiertas.
Page 131 El botín de control de alimentaciín del dispositivo y el interruptor de alimentaciín de la fuente de alimentaciín no apagan la corriente eléctrica suministrada al dispositivo. Es posible también que el dispositivo tenga más de un cable de alimentaciín. Para eliminar la corriente eléctrica del dispositivo, asegúrese de desconectar todos los cables de alimentaciín de la fuente de alimentaciín.
Page 132: Send Us Your Comments
We want to know your opinion about this manual (part number 24P2934). Your input will help us to improve our publications. Please photocopy this survey, complete it, and then fax it to IBM HMM Survey at 919-543-8167 (USA). Name: _________________________________________...
Page 133: Problem Determination Tips
IBM intends to make these available in all countries in which IBM operates. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Subject to IBM’s valid intellectual property or other legally protectable rights, any...
Page 134: Trademarks
Trademarks The following terms are trademarks of the IBM Corporation in the United States, other countries, or both: Alert on LAN OS/2 Warp EtherJet ServeRAID e-business logo ServerGuide HelpCenter ServerProven HelpWare TechConnect Tivoli OS/2 Update Connector NetView Wake on LAN...
Page 136 Part Number: 24P2971...

IBM 6029 Hardware Maintenance Manual
