Maintenance Tip - Quick MILL QM67 EVO Instruction Manual

Gasket And Screen Installation - Continued
• Step 2
Remove the insert basket from one of your
portafilters and then insert the screen and
gasket into the portafilter as shown to the
right.
• Step 3
With the gasket and screen in the portafilter,
press the portafilter into the group head as
shown. Apply equal upward pressure on the
portafilter so the gasket goes in evenly. Once
the gasket is up far enough then lock the
portafilter into the group head and turn as far
right as possible. Then remove the portafilter
and re-install the insert basket and then work
the gasket up further into the grouphead
using the portafilter with the basket installed.
If you are having trouble then remove the
portafilter and press the screen up further by
hand and then try using the portafilter again.

Maintenance Tip:

procedure much easier. There are also benefits to having a new gasket. It will provide a
better seal for a better espresso extraction and it also enables you to be able to remove
the shower screen without ruining the gasket to provide for better cleaning which will
result in better tasting shots.
QM67 Dual Boiler Espresso Machine
Replacing the gasket on a yearly basis will make the replacement
Page 19
