protech PPC-7915F User Manual

Intel® atom n270 15” /17” /19” fanless panel pc
Hide thumbs

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
PPC-7915F/PPC-7917F/
PPC-7919F
PPC-7915F/
PPC-7917F/
PPC-7919F
Intel® ATOM N270
15" /17" /19" Fanless Panel PC
M1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PPC-7915F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech PPC-7915F

Summary of Contents for protech PPC-7915F

  • Page 1 USER’S MANUAL PPC-7915F/ PPC-7917F/ PPC-7919F Intel® ATOM N270 15” /17” /19” Fanless Panel PC PPC-7915F/PPC-7917F/ PPC-7919F...
  • Page 2 Copyright Notice PPC-7915F/PPC-7917F/ PPC-7919F Intel® ATOM N270 Panel PC System With LCD / Touch screen OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.
  • Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............Case Illustration ……………………………………… System Specification ............Safety & Notification ............1-10 CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ……..…………………………...
  • Page 5 4-14 Exit Without Saving ………………………………… 4-30 APPENDIX A SYSTEM ASSEMBLY Exploded Diagram of PPC-7915F Whole System ..... Exploded Diagram of PPC-7915F Packing …………….…..Exploded Diagram of PPC-7915F Wall Mounting …………… Exploded Diagram of PPC-7917F LCD Panel ………………. Exploded Diagram of PPC-7917F Packing ……………….….

  • Page 6: Table Of Contents

    Contents APPENDIX B TECHNICAL SUMMARY Block Diagram ................Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..........…....
  • Page 7 CHAPTER INTRODUCTION This chapter gives you the information for PPC-7915F/PPC-7917F/PPC- 7919F. It also outlines the System specifications. Section includes: About This Manual Case Illustration System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for a Quick Start.

  • Page 8: Appendix B Technical Summary

    This chapter indicates on how to set up the BIOS configurations. Appendix A System Assembly This section gives you the exploded diagram for the whole system unit. Appendix B Technical Summary This section gives you the information about the Technical maps. Page: 1-2 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 9 Chapter 1 Introduction 1-2. CASE ILLUSTRATION Note: When insert this computer into any machine or wall, user should left at lease 5cm space for thermal issue. PPC-7915F Front View Rear View Top View Side View Bottom View Page: 1-3 PPC-7915F/PPC-7917F/PPC-7919F ′...
  • Page 10 Chapter 1 Introduction PPC-7917F Front View Rear View Top View Side View Bottom View Page: 1-4 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 11 Chapter 1 Introduction PPC-7919F Front View Rear View Top View Side View Bottom View Page: 1-5 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 12 KEYBOARD CONNECTOR : Mini DIN connector. Supports for AT/PS2 keyboard. MOUSE CONNECTOR : Mini DIN connector. Supports PS/2 Mouse. BUS SUPPORT : 1 PCI-E (x1) Slot, 1 x Mini-PCI Slot, 1 x CF Slot Page: 1-6 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 13 Chapter 1 Introduction DISPLAY : PPC-7915F 15” LCD Panel XGA 1024 x 768 PPC-7917F 17” LCD Panel SXGA 1280 x 1024 PPC-7919F 19” LCD Panel SXGA 1280 x 1024 WATCHDOG : 1~255 seconds Watchdog timer selectable w/Reset/NMI. SERIAL PORT : Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte FIFOs.
  • Page 14 COLOR : According to the supplier’s LCD specification. LCD MTBF : According to the supplier’s LCD specification. BACKLIGHT MTBF : According to the supplier’s LCD specification. DIMENSION : According to the supplier’s LCD specification. Page: 1-8 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 15 Chapter 1 Introduction TOUCH SCREEN : Type Resistive PPC-7915F : 4096 x 4096 Resolution PPC-7917F : 4096 x 4096 PPC-7919F : 4096 x 4096 PPC-7915F : 3H Hardness PPC-7917F : 3H PPC-7919F : 3H Controller USB interface Knock Life 35,000,000 Times...
  • Page 16 100V~240V, otherwise the system may be damaged. 2. Environmental Conditions a. Place your PPC-7915F/PPC-7917F/PPC-7919F on a sturdy, level surface. Be sure to allow enough room on each side to have easy access. b. Avoid extremely hot or cold places to install your PPC.
  • Page 17 If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and then wipe thoroughly with a dry cloth. d. If dust has been accumulated on the outside, remove it by using a special made vacuum cleaner for computers. Page: 1-11 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 18 CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...
  • Page 19 AT/ATX Power Selection …………………..… JP6, JP12, JP13 Reset/NMI Selection ………………….……… TV Out Connector ……………………………. JTV1 CF Card Master/ Slave Selection ……………. Digital Input/ Output Connector ……………… DIO_C1 Memory Installation ………………………….. DIM1 Reserved Pin ………………………………….. Page: 2-2 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 20 2-2. COMPONENT LOCATIONS INV1 INV2 LVDS1 LVDS2 JP_LV1 JP_LV2 FAN1 CPU_FAN1 JP12 JP13 JATX_PWR1 JPANEL1 JUSB1 JUSB2 JTV1 BIOS PCIE1 JP_COM1 COM1 COM3 COM4 JP11 JP10 JP_COM2 DIO_C1 PPC-7915F/PPC-7917F/PPC-7919F Connector, Jumper Component locations Page: 2-3 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 21 PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. Page: 2-4 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 22 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this Page: 2-5 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 23 RTS1 CTS1 COM2 : COM2 Connector The COM2 is selectable as RS-232/422/485. The pin assignment is as follows : ASSIGNMENT RS-232 RS-422 RS-485 DCD2 COM2 DTR2 DSR2 RTS- RTS2 RTS+ CTS2 CTS+ CTS- Page: 2-6 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 24 The pin assignment is as follows : ASSIGNMENT DCD4 DTR4 COM4 DSR4 RTS4 CTS4 COM4’s pin 9 is selectable for RI, +5V or +12V. For more information, please refer to our “2-5 COM RI and Voltage Selection”. Page: 2-7 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 25 Chapter 2 Hardware Configuration 2-5. COM1/2/3/4 RI & VOLTAGE SELECTION JP_COM1 : COM1 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION JP_COM1 COM1 JP_COM1 JP_COM1 ***Manufacturing Default -- RI. Page: 2-8 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 26 Chapter 2 Hardware Configuration JP_COM2 : COM2 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION JP_COM2 COM2 JP_COM2 JP_COM2 ***Manufacturing Default -- RI. Page: 2-9 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 27 Chapter 2 Hardware Configuration JP8 : COM3 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION COM3 ***Manufacturing Default -- RI. Page: 2-10 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 28 Chapter 2 Hardware Configuration JP7 : COM4 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION COM4 ***Manufacturing Default -- RI. Page: 2-11 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 29 The jumper settings are as follows : COM 2 Jumper Settings Jumper Function (pin closed) Illustrations RS-232 All Open JP10 RS-422 1-2, 3-4, 9-10 JP10 RS-485 1-2, 5-6, 7-8 JP10 *** Manufacturing default -- RS-232. Page: 2-12 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 30 COM2 is selectable for RS-232, 422, 485 function. The jumper settings are as follows : COM 2 JUMPER SETTING JUMPER ILLUSTRATION FUNCTION (pin closed) Auto 485 (default) JP11 No Auto 485 JP11 *** Manufacturing default – Auto 485. Page: 2-13 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 31 The pin assignments are as follows : ASSIGNMENT KBDATA 5VSB KBCLK MSDATA KB_MS1 5VSB MSCLK Reset 2-9. RESET CONNECTOR JPANEL1 (9, 11) : Reset Connector. The pin assignment is as follows : ASSIGNMENT JPANEL1 RST_BTN Page: 2-14 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 32 The pin assignment is as follows : ASSIGNMENT PW_BN1 JPANEL1 PW_BN2 Speaker 2-12. EXTERNAL SPEAKER CONNECTOR JPANEL1 (1, 3) : External Speaker Connector The pin assignment is as follows : ASSIGNMENT P_SPK JPANEL1 Page: 2-15 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 33 Note: To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. Page: 2-16 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 34 FAN1 : System Fan connector The pin assignment is as follows: ASSIGNMENT FAN1 FANPWM1 +12V FAN1 2-16. CPU FAN CONNECTOR CPU_FAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT CPU_FAN1 VCC12 LPC1_FANIO1 LPC1_FANPWM1 Page: 2-17 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 35 Chapter 2 Hardware Configuration 2-17. VGA CONNECTOR VGA1: VGA Connector The pin assignments are as follows: VGA1 ASSIGNMENT GREEN BLUE VGA IIC DATA HSYNC VSYNC VGA IIC CLK Page: 2-18 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 36 Chapter 2 Hardware Configuration 2-18. SERIAL ATA CONNECTOR SATA1~SATA2: The PPC-7915F/PPC-7917F/PPC-7919F possesses two Serial ATA Connector, SATA1~SATA2. The pin assignments are as follows: SATA1：SATA Connector The pin assignments are as follows： ASSIGNMENT SATA_TXPC0 SATA_TXNC0 SATA1 SATA_RXNC0 SATA_RXPC0 SATA2：SATA Connector The pin assignments are as follows：...
  • Page 37 Chapter 2 Hardware Configuration 2-19. PRINTER CONNECTOR JPRNT1: Printer Connector The pin assignments are as follows : JPRNT1 ASSIGNMENT ASSIGNMENT RSTBJ AFDJ RPD0 ERRJ RPD1 PAR_INITJ RPD2 SLINJ RPD3 RPD4 RPD5 RPD6 RPD7 ACKJ BUSY SLCT Page: 2-20 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 38 2-20. DIGITAL I/O CONNECTOR Digital I/O: Digital I/O Connector The pin assignments are as follows : ASSIGNMENT ASSIGNMENT DIN0 DOUT5 DIN1 DOUT6 DIN2 DOUT7 DIN3 DIN4 DIN5 DIN6 DIN7 DOUT0 DOUT1 DOUT2 DOUT3 DOUT4 Page: 2-21 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 39 JUSB1：Universal Serial Bus Connector The pin assignments are as follows： ASSIGNMENT VCCUSB4 USBP4N USBP4P JUSB1 VCCUSB5 USBP5N USBP5P JUSB2：Universal Serial Bus Connector The pin assignments are as follows： ASSIGNMENT VCCUSB6 USBP6N USBP6P JUSB2 VCCUSB7 USBP7N USBP7P Page: 2-22 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 40 RED Color On Giga LAN Speed Indicator No LAN switch/ hub connected. Right Side LED Orange Color Blinking LAN Message Active No LAN Message Active USB Signal： ASSIGNMENT VCCUSB1 USBP1N USBP1P VCCUSB0 USBP0N USBP0P Page: 2-23 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 41 RED Color On Giga LAN Speed Indicator No LAN switch/ hub connected. Right Side LED Orange Color Blinking LAN Message Active No LAN Message Active USB Signal： ASSIGNMENT VCCUSB3 USBP3N USBP3P VCCUSB2 USBP2N USBP2P Page: 2-24 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 42 Chapter 2 Hardware Configuration 2-23. ATX POWER CONNECTOR JATX_PWR1: Power Connector The pin assignments are as follows : ASSIGNMENT JATX_PWR1 5VSB PS_ON -12V Page: 2-25 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 43 Chapter 2 Hardware Configuration 2-24. SOUND CONNECTOR JAUDIO1 : Sound Connector The pin assignments are as follows： Line-In ASSIGNMENT LINE_L LINE_R Line-Out JAUDIO1 ASSIGNMENT SPK_L SPK_R Mic-In ASSIGNMENT MIC_IN1 MIC_IN2 Page: 2-26 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 44 Chapter 2 Hardware Configuration 2-25. LVDS CONNECTOR LVDS1：LVDS1 CONNECTOR LVDS1 The pin assignments are as follows： ASSIGNMENT ASSIGNMENT LCD_VCC LCD_VCC LCD_VCC Page: 2-27 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 45 Chapter 2 Hardware Configuration LVDS2：LVDS2 CONNECTOR LVDS2 The pin assignments are as follows： ASSIGNMENT ASSIGNMENT LCD_VCC LCD_VCC LCD_VCC Page: 2-28 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 46 INV1：Inverter1 Connector The pin assignments are as follows： INV1 ASSIGNMENT +12V ENABKL (Inverter Backlight ON/OFF Control Signal) INV2：Inverter2 Connector The pin assignments are as follows： ASSIGNMENT INV2 +12V ENABKL (Inverter Backlight ON/OFF Control Signal) Page: 2-29 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 47 Chapter 2 Hardware Configuration 2-27. LVDS PANEL VOLTAGE SELECTION JP_LV1：LVDS1 Panel Voltage Selection. The pin assignments are as follows： SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION LVDS_VCC3 JP_LV1 LVDS_VCC5 JP_LV1 *** Manufacturing Default – LVDS_VCC3. Page: 2-30 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 48 Chapter 2 Hardware Configuration JP_LV2：LVDS2 Panel Voltage Selection. The pin assignments are as follows： SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION LVDS_VCC3 JP_LV2 LVDS_VCC5 JP_LV2 *** Manufacturing Default – LVDS_VCC3. Page: 2-31 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 49 2-28. AT/ ATX POWER SELECTION JP6, JP12, JP13：AT/ ATX Power Selections. The pin assignments are as follows： Selections Jumper Setting Jumper Illustrations JP12 JP13 Open JP13 JP12 Open JP13 JP12 *** Manufacturing Default – ATX. Page: 2-32 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 50 Chapter 2 Hardware Configuration 2-29. RESET/ NMI SELECTIONS JP9：Watchdog Timer Selections. The pin assignments are as follows： Selections Jumper Setting Jumper Illustration RESET *** Manufacturing Default – NMI Page: 2-33 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 51 Luminance(Y) CVBS Chrominance(UV) 2-31. CF CARD MASTER/SLAVE SELECTION JP5：CF Card Master/ Slave Selection. The pin assignments are as follows： Selections Jumper Setting Jumper Illustration Master Close Slave Open *** Manufacturing Default – Master. Page: 2-34 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 52 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7 2-33. MEMORY INSTALLATION This system is enhanced with 1 DDR DRAM banks, which support up to DRAM BANK CONFIGURATION DIM 1 TOTAL MEMORY 256M 256MB 512M 512MB Page: 2-35 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 53 CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and sound driver, Intel® Chipset Software Installation Utility, touch screen driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: Introduction VGA Driver Utility Flash BIOS Update...
  • Page 54 Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our PPC-7915F/PPC-7917F/PPC-7919F package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the...
  • Page 55 Chapter 3 Software Configuration 3-2. VGA DRIVER UTILITY The VGA interface embedded with our PPC-7915F/PPC-7917F/PPC- 7919F can support a wide range of display. You can display CRT, LVDS simultaneously with the same mode. 3-3-1. Installation of VGA Driver: To install the VGA Driver, simply follow the following steps: (1).
  • Page 56 Chapter 3 Software Configuration 3-3. FLASH BIOS UPDATE 3-3-1. Introduction Users of PPC-7915F/PPC-7917F/PPC-7919F can use the program “Awdflash.exe” contained in the Utility Disk for system BIOS update. 3-3-2. Installation of system BIOS 1. Copy “Awdflash.exe” from Driver Disk to Drive C.
  • Page 57 File Name to Program: 7915xxxx.bin Verifying Flash Memory – 7FFFF OK Write OK No Update Write Fail F1: Reset F10: Exit Please reset or power off the system, then the Flash BIOS is fully implemented. Page:3-5 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL L...
  • Page 58 Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction The PPC-7915F/PPC-7917F/PPC-7919F Panel PC is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: For more details on Installation procedure, please refer to Readme.txt file found on LAN DRIVER UTILITY.
  • Page 59 “D:\Sound\pathname” refers to the full path to the source files. 3. Click on the OK button or press the ENTER key. 4. Click on the “Next” and OK prompts as they appear. 5. Reboot the system to complete the driver installation. Page:3-7 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL L...
  • Page 60 3. Click Setup.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. Page:3-8 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 61 3. Click Setup.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart it in order to complete the changes. Page:3-9 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL L...
  • Page 62 ;-------------------------------------------------------------------------------------------------- ; Disable Watch-Dog Timer ;-------------------------------------------------------------------------------------------------- dx, (800h+66h) ; Disabled Watch Dog al, 00h dx, al dx, (800h+67h) al, 00h dx, al dx, (800h+68h) ; Clear Status Bit al, 00h dx, al Page:3-10 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 63 CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Load Fail-Safe Defaults Load Optimized Defaults Password Setting...
  • Page 64 4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The PPC-7915F/ PPC-7917F/ PPC-7919F are equipped with the BIOS for system chipset from Phoenix -Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system.
  • Page 65 You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. Page: 4-3 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 66 < Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. Page: 4-4 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 67 Mode: Auto, Normal, Large or LBA. Auto: The BIOS automatically determines the optimal mode. Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more Page: 4-5 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 68 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. Page: 4-6 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 69 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table Page: 4-7 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 70 BIOS Features Setup Screen The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s boot-up sequence and security. A brief introduction of each setting is given below. Page: 4-8 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 71 3.If you are using Windows operating system. Please disable this feature. 3. C1E FUNCTION: This is enabled to reduce power during idle operation. 4. EXECUTE DISABLE BIT: To select enable or disable the No-Execution Page Protection Technology. Page: 4-9 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 72 <-> to move it down the list. Press <ESC> to exit this menu. ↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Select Hard Disk Boot Device Priority Page: 4-10 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 73 When enabled, the BIOS will shorten or skip some check items during POST. FIRST/SECOND/ THIRD/ OTHER BOOT DEVICE: The BIOS attempt to load the operating system from the devices in the sequence selected in these items. Page: 4-11 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 74 Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. Page: 4-12 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 75 DVMT Mode [DVMT] DVMT/ FIXED Memory Size [128 MB] Boot Display [CRT+LFP1] ↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults Chipset Features Setup Screen Page: 4-13 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 76 This field applies only when synchronous DRAM is installed in the system. The choices are 2 & 3. PRECHARGE DEALY (tRAS): Precharge Delay This setting controls the precharge delay, which determines the timing delay for DRAM precharge Page: 4-14 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 77 The On-Chip Frame Buffer Size can be set as 8MB. This memory is shared with the system memory. DVMT MODE: Intel Dynamic Video Memory Technology Mode. DVMT/FIXED MEMORY SIZE: DVMT Memory Size Select. BOOT DISPLAY: To select the boot-up display type. Page: 4-15 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 78 If bios setup menu item supports USB device boot, it will cause Win9x detects the same storages twice when the system is rebooted, and USB HDD will fail. Note: this cause just happen under Win9x, the phenomenon is a limitation. Page: 4-16 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 79 (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support. 2. IDE DMA TRANSTER ACCESS: To Enable/Disable the IDE DMA transfer access. 3. ON-CHIP PRIMARY/SECONDARY PCI IDE: Page: 4-17 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 80 [Enhanced Mode]: Enable both SATA and PATA. Max.of 6 IDE drives are supported. [SATA Only]: SATA is operating in legacy mode. 8. PATA IDE MODE: To select PATA IDE Mode sequence. 9. SATA PORT: According PATA IDE Mode to determine SATA sequence. Page: 4-18 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 81 ↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Descriptions on each item above are as follows: 1. AUDIO FUNCTION: This item allows you to enable or disable onboard Audio function. Page: 4-19 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 82 4. ECP MODE USE DMA Select a DMA channel for the parallel port for use during ECP mode. ONBOARD SERIAL PORT 3/4: Select an address and corresponding interrupt for the third and forth serial ports Page: 4-20 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 83 This item allows the user to decide USB device operation mode. 4. USB KEYBOARD FUNCTION: Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard. Page: 4-21 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 84 ACPI FUNCTION: Users are allowed to enable or disable the Advanced Configuration and Power Management (ACPI). Page: 4-22 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 85 Soft-Off state. RESUME BY ALARM: When enabled, you can set the date and time at which the RTC alarm awakens the system from Suspend mode. Page: 4-23 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 86 This section covers technical items, which is strongly recommended for experienced users only. RESET CONFIGURATION DATA: Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have Page: 4-24 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 87 F6:Fail-Safe Defaults F7:Optimized Defaults Descriptions on each item above are as follows: 1. IRQ-n Assigned to: You may assign each system interrupt a type, depending on the type of device using the interrupt. Page: 4-25 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 88 This item shows you the current CPU temperature. VCORE: This item shows you the current system voltage. 5V /12V: Show you the voltage of 5V/12V. CPU FAN1 / FAN1 SPEED: This item shows you the CPU Fan1/FAN1 speed. Page: 4-26 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 89 When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. Page: 4-27 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 90 PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. Page: 4-28 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 91 You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. Page: 4-29 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 92 ►Integrated Peripherals word Quit Without Saving (Y/N)? N ►Power Management etup ►PnP/PCI Configura Saving ►PC Health Status Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Datas Page: 4-30 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
  • Page 93 SYSTEM ASSEMBLY This appendix contain exploded diagram of the system. Section includes: Exploded Diagram for PPC-7915F Whole System Exploded Diagram for PPC-7915F Packing Exploded Diagram for PPC-7915F Wall Mounting Exploded Diagram for PPC-7917F LCD Panel Exploded Diagram for PPC-7917F Packing...
  • Page 94 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7915F WHOLE SYSTEM LVDS INVERTER DIO Cable RESET SWITCH Invertor Extended Cable Page: A-2 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 95 PPC-7615 FIX XY Direction Touch of Resist For ELO Left 20-029-03004168 PPC-7615 Inverter Holder 30-015-04200000 Cable Tie 21-006-04545001 PS-8590 Thermal Pads 22-232-40004011 Round Head Screw 27-012-17111071 Power + SATA cable 34-017-01604000 BIOS Label 30-050-31100171 Foam Magnet core Page: A-3 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 96 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7915F PACKING Page: A-4 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 97 30-056-02100008 Mylar 34-004-01301008 LCD Panel Cardboard 34-005-00010007 Drier 30-013-15200168 PPC-7615 EVA For Wall 22-222-40020011 PAN Head Screw 22-215-30006111 Screw 22-230-30005811 Screw 34-017-03102168 Model Label 20-005-16001000 PROX Label 27-012-17103111 Transfer Power Cord Page: A-5 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 98 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7915F WALL MOUNTING Page: A-6 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 99 Appendix A System Assembly Page: A-7 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 100 Appendix A System Assembly Front 375.4 (openning) 192.75 192.75 Page: A-8 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 101 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7917F LCD PANEL Page: A-9 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 102 Touchscreen Oring 30-013-01100169 Wall Oring 30-013-01200169 Poron Touchscreen 30-013-24600169 Panel Sponge-1 30-013-24400169 Panel Sponge-2 30-013-24500169 30-056-02100071 Screw M3*6 sara head screw 22-215-30006111 M6*50 screw 22-252-60050011 M6 Nut 23-142-60501101 Touch screen LCD Panel Page: A-10 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 103 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7917F PACKING Page: A-11 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 104 Transfer Power Cable 27-012-17103111 PE Bag 34-010-00210003 30-056-02100071 Drier 34-005-00010007 Model Label 34-017-03102168 PROX Label 20-005-16001000 Outer Carton EPE-4602R 34-016-00301169 EPE-4602L 34-016-00302169 Drive CD 52-601-00000101 Quick Manual LCD Panel Cardboard 34-004-01301058 PPC-7917 Page: A-12 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 105 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7917F WALL MOUNTING Page: A-13 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 106 Appendix A System Assembly Page: A-14 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 107 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7919F LCD PANEL Page: A-15 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 108 Touchscreen Oring 30-013-01100170 Wall Oring 30-013-01200170 Poron Touchscreen 30-013-24600170 Panel Sponge-1 30-013-24400170 Panel Sponge-2 30-013-24500170 30-056-25500000 Screw M3*6 sara head screw 22-215-30006111 M6*50 screw 22-252-60050011 M6 Nut 23-142-60501101 Touch screen LCD Panel Page: A-16 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 109 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7919F PACKING Page: A-17 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 110 Transfer Power Cable 27-012-17103111 PE Bag 34-010-00210003 30-056-25500000 Drier 34-005-00010007 Model Label 34-017-03102168 PROX Label 20-005-16001000 Outer Carton EPE-4602R 34-016-00301170 EPE-4602L 34-016-00302170 Drive CD 52-601-00000101 Quick Manual LCD Panel Cardboard PPC-7919 Page: A-18 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 111 Appendix A System Assembly EXPLODED DIAGRAM FOR PPC-7919F WALL MOUNTING Page: A-19 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...
  • Page 112 Appendix A System Assembly Page: A-20 PPC-7915F/ PPC-7917F/ PPC-7919F ′ USER S MANUAL...

  • Page 113: Block Diagram

    APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...
  • Page 114 Appendix B Technical Summary BLOCK DIAGRAM Page: B-2 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...

  • Page 115: Interrupt Map

    Appendix B Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 Page: B-3 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...

  • Page 116: Rtc & Cmos Ram Map

    Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data Page: B-4 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...

  • Page 117: Timer & Dma Channels Map

    TIMER & DMA CHANNELS MAP Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available Floppy Available Cascade Available Available Available Page: B-5 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...

  • Page 118: I/O & Memory Map

    Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 Page: B-6 PPC-7915F/PPC-7917F/PPC-7919F ′ USER S MANUAL...
