Dark Gray 69" x 70" Cloth Room Divider
Instruction Manual
SKU: PP-RD-069B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-rd-069b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo PP-RD-069B
Summary of Contents for Vivo PP-RD-069B
- Page 1 Dark Gray 69" x 70" Cloth Room Divider Instruction Manual SKU: PP-RD-069B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-rd-069b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Secure Small Inserts (S-D) into one end of Crossbars (E) and Crossbars With Extension (D). Assemble Large Inserts (S-E) into the bottoms of Lower Vertical Supports (B). - Page 4 STEP 2 Assemble Feet (C) to Lower Vertical Supports (B) using ST4x40mm Screws (S-A) and a Phillips screwdriver. STEP 3 Insert Lower Vertical Supports (B) into the bottom of Upper Vertical Supports (A).
- Page 5 STEP 4 Assemble Braces (H) to feet (C) using M5x25mm Screws (S-B) and M5 Nuts (S-C). Secure x1 Crossbar (E) to x1 Lower Vertical Support (B) using ST4x40mm Screw (S-A). STEP 5 Assemble x1 Crossbar (E) to x1 Vertical Support (A) using ST4x40mm Screw (S-A) and a Phillips screwdriver.
- Page 6 STEP 6 Insert Crossbars with Extensions (D) to assembled Crossbars (E). STEP 7 Slide Divider (F) onto the crossbar assembly.
- Page 7 STEP 8 Secure the other upright assembly to the crossbar assembly using ST4x40mm Screws (S-A) and a Phillips screwdriver. STEP 9 Assemble End Caps (G) to Upper Vertical Supports (A) and Feet (C).
