Dark Gray Modular Wall System (x4)
Instruction Manual
SKU: PP-MWS63D-T
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-mws63d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-MWS63D-T and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo PP-MWS63D-T

  • Page 1 Dark Gray Modular Wall System (x4) Instruction Manual SKU: PP-MWS63D-T Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-mws63d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 ASSEMBLY STEPS STEP 1 Remove the protective film on Pads (H) and apply them to the bottom of Feet (B). STEP 2 Install Foot Supports (A) to Feet (B) using M8x16mm Screws (S-B) and 5mm Allen Wrench (T-B). NOTE: Holes on Foot Supports (A) are perpendicular to the end of the feet.
  • Page 4 STEP 3 Assemble Bottom Support Columns (C) to Feet (B) using M5x10mm Screws (S-C) and 3mm Allen Wrench (T-A). Attach Top Support Columns (D) using Connecting Bars (F) with M5x10mm Screws (S-A) and T30 Screwdriver (T-C). STEP 4 If necessary, loosen quick connections on Crossbars (E) using T30 Screwdriver (T-C).
  • Page 5 STEP 5 Attach Crossbar (E) to the very bottom of one of the support assemblies. Lock the quick connection using T30 Screwdriver (T-C). Repeat with a second support assembly. Use a level to make sure Crossbar (E) is level with Feet (B). STEP 6 Slide Panel (G) into the slots on Support Columns (C) and the bottom Crossbar (E).
  • Page 6 STEP 7 Slide on second Panel (G) into the slots on Support Columns (C) and the middle Crossbar (E). Install the upper Crossbar (E) using a level, ensuring the the lower panel is set in the slots on both crossbars. Tighten the quick connections using T30 Screwdriver (T-C).
  • Page 7 STEP 9 Press Caps (I) into the tops of Support Columns (C). Remove adhesive backing from Screw Cover Stickers (J) and place them over the screws on Crossbars (E). Optional Orientations The panels are modular, so they can be paired with multiple panels in several orientations.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
