Black Clamp-on Desk Back Panel & Accessory Holder
Instruction Manual
SKU: PP-DK12B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-dk12b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-DK12B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo PP-DK12B

Summary of Contents for Vivo PP-DK12B

  • Page 1 Black Clamp-on Desk Back Panel & Accessory Holder Instruction Manual SKU: PP-DK12B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-dk12b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.

  • Page 3: Assembly Options

    ASSEMBLY OPTIONS: Above Mounting Above & Under Mounting Single Panel Assembly (pg 3-4) Double Panel Assembly (pg 7) Double Panel Assembly (pg 3, 5-6) Under Desk Cable Management Accessory Placement Single Panel Assembly (pg 8-9 All Assembly Options (pg 8-9) Double Panel Assembly (pg 8-9)
  • Page 4 ASSEMBLY OPTION A: Above Mounting Only STEP 1 Connect Lower Pole (B) and Pad (I) to Clamp Brace (E) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Secure Clamp (F) to Clamp Brace (E) using M6x8mm Screws (S-B) and 4mm Allen Wrench (T-A).
  • Page 5 STEP 2b: Double Panel Assembly Choose horizontal or vertical installation orientation and connect Peg Board (A) and Connecting Bracket (D) to Lower Pole (B) using M6x25mm Screws (S-C), M6 Washers (S-D), and 4mm Allen Wrench (T-A). Note: Use bottom hole of Connecting Bracket (D). HORIZONTAL ORIENTATION VERTICAL ORIENTATION HORIZONTAL ORIENTATION...
  • Page 6 STEP 2b: Double Panel Assembly (Continued) Connect second Peg Board (A) to Upper Pole (C) using M6x25mm Screws (S-C), M6 Washers (S-D), and 4mm Allen Wrench (T-A). Attach Pole Cap (H) to top of Upper Pole (C). HORIZONTAL ORIENTATION VERTICAL ORIENTATION...
  • Page 7 ASSEMBLY OPTION B: Above & Below Mounting STEP 1 Connect Lower Pole (B) and Pad (I) to Clamp Brace (E) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Secure Clamp (F) to Clamp Brace (E) using M6x8mm Screws (S-B) and 4mm Allen Wrench (T-A).
  • Page 8 ASSEMBLY OPTION C: Under Desk Cable Management STEP 1 Secure Clamp (F) and Pad (I) to Clamp Brace (E) using M6x8mm Screws (S-B) and 4mm Allen Wrench (T-A). STEP 2a: Single Panel Connect Peg Board (A) to front of Clamp Brace (E) using M6x5mm Screws (S-E) and a Phillips screwdriver.
  • Page 9 STEP 2b: Double Panel Connect Peg Boards (A) to front of Clamp Brace (E) using M6x5mm Screws (S-E) and a Phillips screwdriver. Use provided Zip Ties (T-B) for managing under desk cables.

  • Page 10: Accessory Placement

    ACCESSORY PLACEMENT Note: Accessories can be placed and used as desired. The following steps shows one way to mount/install accessories and uses the double panel horizontal assembly as an example. Shelf Mounting Place Shelf Hooks (J) at desired height on Peg Board (A) and then place Shelf (G) on Hooks so that magnets on edge make contact with Peg Board (A).

  • Page 11: Clip & Magnets

    Straight & Square Hooks Place Straight Hook (K) and Square Hook (L) as desired on Peg Board (A). Clip & Magnets Place Magnets (M), and Clip (N) as desired on assembly.
