Dark Gray 102" x 70" Cloth Room Divider
Instruction Manual
SKU: PP-RD-102B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-rd-102b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-RD-102B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo PP-RD-102B

  • Page 1 Dark Gray 102" x 70" Cloth Room Divider Instruction Manual SKU: PP-RD-102B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-rd-102b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
  • Page 3 ASSEMBLY STEPS STEP 1 Press Small Inserts (S-D) into both ends of Crossbars (D). Press Large Inserts (S-E) into the bottoms of x4 Lower Vertical Supports (B). Top of B STEP 2 Assemble Feet (C) to Lower Vertical Supports (B) with the installed Large Inserts (S-E) using ST4x40mm Screws (S-A) and a Phillips screwdriver.
  • Page 4 STEP 3 Slide Upper Vertical Supports (A) onto Lower Vertical Supports (B). STEP 4 Assemble Braces (H) to Feet (C) using M5x25mm Screws (S-B) and M5 Nuts (S-C). Secure x2 Crossbar (D) to x2 Lower Vertical Supports (B) using ST4x40mm Screw (S-A).
  • Page 5 STEP 5 Assemble x2 Crossbars (D) to x2 Vertical Supports (A) using ST4x40mm Screw (S-A) and a Phillips screwdriver. STEP 6 Slide x2 Dividers (F) onto the Crossbars (D).
  • Page 6 STEP 7 Secure the other upright assemblies to Crossbars (D) using ST4x40mm Screws (S-A) and a Phillips screwdriver. STEP 8 Assemble remaining Crossbars (D) and upright assemblies with Divider (F) using ST4x40mm Screws (S-A) and a Phillips screwdriver.
  • Page 7 STEP 9 Secure Connector Clips (E) to Upper Vertical Supports (A) and Lower Vertical Supports (B), then assemble the panels together. Assemble End Caps (G) to Upper Vertical Supports (A), x2 Lower Veritcal Supports (B)and Feet (C).
