EEI–3048
ARM CHAIR

STEP 3:

Place 2 pieces of Front Legs (2) to the front position of Chair Body (1) as shown.
Insert 2 pieces of Short Bolt (A) with 2 pieces of Flat Washer (C) into the bottom pre-drilled holes on Front Legs (2)
through the bottom pre-drilled on the back of Chair Body (1).
Insert 2 pieces of Long Bolt (B) with 2 pieces of Flat Washer (C) into the top pre-drilled holes on Front Legs (2) through
the top pre-drilled on the front of Chair Body (1).
Use Allen Wrench (D) to tighten Short Bolts (A) and Long Bolts (B). Do not fully tighten the Bolts (A&B) at this step.
3
B
C
2
Ax2

STEP 4:

Carefully turn over the assembling chair .
Please put a heavy object or seat one adult on top of the assembled Chair to pressure the chair for leveling.
Turn upside down again, then use Allen Wrench (D) to tighten Short Bolts (A) and Long Bolts (B) clockwise until secure.
Dx1
Customer Service 908-368-1025︱www.modwayfurniture.com
3
D
B
A A
C
C
C
2
1
Bx2 Cx4
D
B
C
A
1
C
Dx1
D
2
Hardware & Tools required
Hardware & Tools required
