UNIQUE UGP-13
Propane Refrigerator
Installation and Owner's Manual
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult a
qualified installer, service agency or the gas
supplier.
!SAVE THESE INSTRUCTIONS!
FOR YOUR SAFETY IF YOU SMELL GAS
Open windows.
Do not touch electrical switches.
Extinguish any open flame.
Immediately turn off gas supply and call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable and liquids in the
vicinity of this or any other appliance.
The installation of the appliance must conform with local codes or,
in the absence of local national Fuel Gas Code, ANSI Z233.1 and in Canada
B149.2 Propane Storage and Handling Code
V5-S5-2014
